MGP Instruments Remote Monitoring System

1
MGP Instruments Remote Monitoring System

2001
5000 Highlands Pkwy., Ste 150 Smyrna, GA.
30082 770-432-2744 www.mgpi.com
2
MGP Instruments Facilities

• MGP Instruments S.A. - Lamanon, France
• HQ Facility
• Over 200 employees
• MGP Instruments, GMBH Munich, Germany
• RMS Facility
• 29 Employees
• MGP Instruments, Inc. - Smyrna, Georgia
• North American Facility
• 24 Employees
• RSCS, Inc. - Stratham, New Hampshire
• Northeast US and Canada Support
• Calibration and Repair Facility

3
MGP Instruments Dosimetry History

• Over 27 years experience
• Over 210,000 dosimeters delivered
• Electronic dosimeters in 20 countries
• Number 1 in the North American NPP market
• 18,000 DMC 2000S delivered in North America
• 90,000 DMC 2000 (military version) ordered by NATO

4
Product Overview

• Electronic Dosimetry
• DMC 2000, DMC2000X, DMC2000XB
• Portable Survey Instruments
• AMP 100, AMP 200, Telepole
• Remote Monitoring
• Telemetry WRM Receiver and Transmitters
• Direct Connection DDC 16 (Data Collector)
• Monitoring Software
• Teleview
• Teleview 2000
• Customer Support

5
Product Overview - cont.

• Monitoring Software
• Teleview (Stand-Alone / Networked)
• WinWRM
• Customer Support
• Product Training
• On-Site Technical Support Repair

6
DMC 2000 Development

• Commissioned by NATO Army
• Design features
• Lightweight
• Rugged
• Hands-Free Operation
• Prototype completed 1996
• Full production started 1998

7
DMC 2000 Family

• 2000 S Single silicon diode
• DDE from 50 keV to 6 MeV
• Si response 300 cps per R/hr
• 2000 X Three silicon diodes
• DDE from 20 keV to 6 MeV
• 2000 XB Three silicon diodes
• DDE from 20 keV to 6 MeV
• SDE from Pm-147 (62 keV) to Sr/Y-90

8
DMC 2000S Features

• Small and lightweight - 56 grams
• Rugged
• surface-mount circuit board
• durable, high resistant ABS plastic
• Standard battery (Renata CR2450) 1-year life
• (approximate 2000 working-hours)
• RF Resistant
• Waterproof (tested at 1 meter for 2 hrs.)
• Hands-Free operation

9
Type-Testing the DMC 2000S

• Factory type test report available
• US Effort - Type Test Committee
• Independent third-party (Battelle)
• Customers testing at their facilities
• Test-to-failure concept where possible
• Battelle Report Complete

10
Dosimeter Readers (LDMs)

• LDM 101
• Infrared Diodes
• stand-alone for configuration/calibration
• system mode for access control
• LDM 2000
• Hands-free communication
• - Up to 2 meter range
• - Magnetic coupling (125 kHz)

11
ALARA Dose Tracking with Hands Free Operation
12
(No Transcript)
13
(No Transcript)
14
Compact Transmitter - CTM 2000

• Clamshell design to contain DMC 2000S
• 50 mW peak power
• 3 user-selectable frequencies (904-924.5 MHz)
• 4 user-selectable transmission times
• (4 sec, 10 sec, 30 sec, 60 sec)
• Standard AAA battery 30 hour operation
• AC Power Option

15
Compact Transmitter CTM 2000
The Inside Story
16
External Transmitter

• External case w/belt clip
• 50 mW peak power
• 2 preset frequencies (900 MHz)
• 2 user-selectable transmission times
• (4 sec, 40 sec)
• Standard 9-V battery
• 100 hour operation
• Enable wireless operation of
• other meters
• AMP 100/200, RAM ION, Telepole

17
Multiplexor - MUX

• 1-5 unit Multiplexor with
• built-in CTM
• 10/60 seconds total cycle
• Polarized Locked Connectors
• Single battery (MUX CTM)
• Hard Wire Option
• compact design
• Applications Diver or any
• multiple dosimeter application

18
WRM-Plus Receiver

• Up to 5000 Range
• Range tested at Palo Verde, Hanford and MGPI
  Sites
• Indoor/Outdoor proven reliability
• Applications
• Wireless personnel monitoring
• Wireless area monitoring
• Underwater diver or multi-dosimeter
• monitoring
• Up to 100 dosimeters monitored together
• Based on 4-sec transmission
• More EDs for gt4 sec

19
WRM-Plus Receiver - cont.

• Output monitored at work site or remote
• Standard PC interface (local or modem)
• WIT 2400 Transceiver and Hopnet data repeater for
  extended range
• One-Port Terminal Server - Direct connection to
  LAN without a computer
• Teleview - Networkable software

20
Other Wireless Options

• AMP 50/100/200
• Hi-range GM tube attached to meter with
  waterproof cable
• AMP-50 50uR/hr-1 R/hr
• AMP-100 10 mR/hr-1000 R/hr
• AMP-200 1 R/hr - gt10,000 R/hr
• Up to 250 cable lengths
• Telemetry Interface (External Transmitter)
• Telepole
• Wide range GM attached to meter with extendable
  pole
• 50 uR/hr - 1000 R/hr

21
Other Wireless Options cont.

• RAM ION Ion chamber instrument
• 0.2 mR/hr-50 R/hr
• Open or Closed window
• Data logging, Optional Laser SMART meter
• ABPM-302 Continuous Air Monitor
• 6-channel (4 Alpha, 1 Beta, 1 Gamma)
• Superior radon discrimination
• Step-move filter - three months continuous
  operation

22
DMC 2000 Options - PEA 2000

• High-Noise environments
• Audible alarm
• Vibration
• Optional LED Earphone

23
Area Monitoring Options - DDC 16
24
Area Monitoring Options - DDC 16

• Up to 16 channels into a single readout/data
  storage device
• Dosimeters, AMP 100/200s, RAM IONS
• Data trending and downloading
• Uses standard RJ-11 handset telephone cable
• Direct connect to PC or Network addressable

25
Teleview Software
26
Teleview Software cont.

• 32-bit Windows based software
• (Win 95, 98, 2000, NT)
• WRM Plus, DDC-16, and CAM
• Real-time Personnel Area Monitoring
• Connects to Access Control auto login
• Network Ready - can view real-time radiological
  conditions from any LAN connected PC.
• New Version Teleview 2000 in development

27
Teleview Software cont

• Teleview 2000

28
Teleview Software cont
29
TeleMap

• Real-time, networked radiological data display
  for survey maps floor plans
• ALARA briefs, work order planning, 24hr area
  monitoring trending, etc.

30
WRM Application Stand Alone Station
31
WRM Application Short Haul Modem
32
WRM Application Telephone Modem
33
Data Broadcast WRM Signal
34
WRM Application Network - Multiple Remote
35
WRM Application Network W.I.T.
36
WRM Application Network 2.4 GHz System
Teleview Client Station
Teleview Client Station
Repeater
(( ))
LAN
WRM Base Receiver TCP/IP
Teleview Client Station
Teleview Server Station
Containment, Turbine, Auxilliary Bldg, Hot Cell,
etc.
37
WRM Application Network Multiple Client
38
(No Transcript)
39
Central Monitoring Station located at RRA Access
40
Refuel Floor Control Point Console
41
Drywell Control Point Console
42
Drywell Control Matrix Camera Pole
43
CMS Overview
Consoles (4) Central Monitoring Area, Drywell,
Refuel, Steam Tunnel, Outage Control
(non- console) Carts (2) Turbine, General
Use Cameras 70 Audio 96 Headsets
(wired/wireless) RMS up to 14 AM-16s, 7
WRMPlus receivers (all networked),
Teleview Future expansion to include TeleMap,
additional cameras and Access Control System
44
Summary

• DMC-2000 Advantages
• Lower Cost
• Single diode for monitoring applications
• Low Battery cost (purchase and disposal)
• Rugged Design
• Smaller and lighter
• Shock-resistant case
• Surface-mounted components
• Waterproof

• Industry Proven Reliability
• Telemetry Options
• Wireless and wired monitoring
• Real-Time Personnel/Area monitoring
• Market Share
• Currently 70 of US NPP market (DOE, Medical,
  Civil)
• 17,000 DMC 2000s delivered
• MGP Instruments here for the long haul!

45
Electronic Dosimetry at Nuclear Power Plants
Bechtel Hanford
Monticello
WNP-2
Kewaunee
Maine Yankee
Prarie Island
Big Rock Point
Vermont Yankee
Point Beach
Fitzpatrick
Palisades
Ginna
Bechtel INEEL
Seabrook
Duane Arnold
DC Cook
9 Mile Point
Pilgrim
Fermi
Zion
Perry
Indian Pt
Fort Calhoun
Susquehanna
Quad Cities
Byron
Millstone
TMI
Cooper
Davis Besse
Haddam Neck
Braidwood
Oyster Creek
Limerick
Dresden
Beaver Valley
Peach Bottom
LaSalle
Salem/Hope Creek
Clinton
Wolf Creek
Callaway
Calvert Cliffs
North Anna
Surry
Diablo Canyon
Watts Bar
Shearon Harris
McGuire
Catawba
Sequoyah
ANO
ORNL
Robinson
Oconee
San Onofre
Brunswick
Browns Ferry
Palo Verde
VC Summer
Vogtle
Comanche Peak
Grand Gulf
Farley
River Bend
Hatch
Waterford
South Texas Project
Crystal River
St Lucie
Turkey Point
MGP Instruments (DMC90, DMC100)
DMC2000
Competitors (Rados, Siemens, SAIC, Dositec)
46
TeleDosimetry at Nuclear Power Plants
Bechtel Hanford
Monticello
WNP-2
Maine Yankee
Kewaunee
Big Rock Point
Prarie Island
Vermont Yankee
Fitzpatrick
Point Beach
Palisades
Seabrook
Duane Arnold
DC Cook
9 Mile Point
Fermi
Ginna
Pilgrim
Zion
Indian Pt
Perry
Fort Calhoun
Susquehanna
Byron
Quad Cities
Millstone
TMI
Cooper
Davis Besse
Haddam Neck
Braidwood
Oyster Creek
Limerick
Dresden
Beaver Valley
Peach Bottom
LaSalle
Salem/Hope Creek
Clinton
Wolf Creek
North Anna
Calvert Cliffs
Callaway
Surry
Diablo Canyon
Shearon Harris
McGuire
Watts Bar
Catawba
Sequoyah
ANO
Robinson
Oconee
San Onofre
Brunswick
Browns Ferry
Palo Verde
VC Summer
Vogtle
Comanche Peak
Grand Gulf
River Bend
Farley
Hatch
Waterford
South Texas Project
Crystal River
St Lucie
Turkey Point
MGP Instruments
Competitors (Rados, Siemens, SAIC, Dositec)
47
Partner Systems (Audio/Visual)

• Industrial Video
• Bartlett Nuclear
• IIS
• Framatome
• ROV Technologies
• Brooks
• Home Grown

48
Share Equipment and Experience

• BWR-North America
• 26 out of 37 Reactors

• PWR-North America
• 47 out of 69 Reactors

49
MGP Instruments Presence in Canada
Canada
MGP Instruments Equipment in
Army
Nuclear Power Plants
50
MGP Instruments Presence in Europe
Norway
Sweden
U.K
Belgium
Holland
Czec. Rep.
Germany
Evaluation
Ukrania
in
France
Progress
Slovakia
Slovenia
Switzerland
MGP Instruments Equipment in
Bulgaria
Spain
Army
Navy
Italy
Air Force
Nuclear Power Plants
51
MGP Instruments Web Site

• Home Page www.mgpi.com
• Product Application Information
• Manual Downloads
• Software Downloads
• User Lists/Contacts
• Problem/Resolution Posting
• Product/Software Development

52
The End

• MGP Users Group (11th annual)
• June 25-29, 2001
• Atlanta, GA
• Last Year 69 Attendees
