Finding Potentially Hazardous Asteroids

1
Finding Potentially Hazardous Asteroids

• Nick Kaiser
• (with lots of help from Jim Heasley, Dave Tholen
  and Rob Jedicke)
• IfA Open House
• 04/26/03

2
Outline

• The asteroid hazard
• How do asteroids become hazardous?
• What can be done about it?
• What is the IfA doing about it?
• Pan-STARRS

3
The asteroid hazard

• The historical record
• From air-bursts to mass extinctions

4
Celestial Bombardment!

• Craters on
• Moon, Mercury,
• Venus, Mars
• And
• EARTH !!!

5
Celestial Bombardment!
Celestial Bombardment on the Moon!
6
Earth Has Been Hit Before!

• Asteroid crater in Canada
• seen from space

7
(No Transcript)
8
Earth Has Been Hit Before!

• Meteor crater in Arizona was formed about
  50,000 years ago. The impacting iron meteorite
  had a mass of 1 million tons and diameter of 50
  meters. The impact blast was equivalent to a 20
  megaton nuclear weapon and produced a crater over
  1 km in diameter.

9
Earth Has Been Hit Before!

• In 1908 a blast equivalent to a 15 megaton
  bomb occurred near the Tunguska river in Siberia.
  It occurred about 8 km over the Earths surface,
  flattening trees over a thousand square
  kilometers. The object was a stony body with a
  mass of 100,000 tons.

10
When the last Big-One Hit

• The impact that is thought to have killed off
  the dinosaurs -- the Chicxulub crater, which is
  off the Yuchatan peninsula in the Gulf of
  Mexico--was produced by an object 10-15 km in
  diameter, resulting in a crater 200 km in
  diameter.

11
Honolulu Advertiser October 10, 2002
12
It Can Happen Again!

• Public awareness of the danger from celestial
  impacts was heightened by the break up of comet
  Shoemaker-Levy 9 after a close pass by Jupiter.
• On its next orbit, the fragments collided with
  Jupiter producing atmospheric explosions.

13
It Can Happen Again!

• Impact of comet segments
• on Jupiter observed with
• IfA UH 88 telescope and
• infrared camera

14
(No Transcript)
15
It Can Happen Again!

• Even more recently, CNN and other news agencies
  reported that on March 8, 2002 asteroid 2002 EM7
  passed within 288,000 miles of Earth.
• This object is slightly larger than the Tunguska
  impactor and could have caused considerable
  damage had it hit the planet.
• 2002 EM7 came out of our blind spot, coming from
  the direction of the Sun. We didnt see it until
  after it had passed!

16
known asteroids in solar system
17
The asteroid collision rate
18
risk from asteroids
19
Summary of risk

• Mass extinctions
• every few tens of millions of years
• Global catastrophes
• million year events
• Regional damage/tsunamis
• 1000MT impacts every 70,000 years
• Tunguska events
• one per 1000 years
• Bottom line
• You are as likely to die from an asteroid strike
  as to die in an air crash

20
Collision risk from sub-km size asteroids

• Most of risk comes from km size objects and
  larger
• Very infrequent but very damaging
• Smaller objects can be damaging too
• Asteroid strikes in the ocean will generate big
  waves
• But will they cause much damage?
• Or will they break with little damage on the
  continental shelf?

21
(No Transcript)
22
Los Angeles Basin
23
How do asteroids become harmful

• Most asteroids reside in the main belt between
  mars and jupiter and are harmless
• But gravitational jostling can push asteroids
  onto unstable orbits
• These orbits then evolve, becoming elliptical and
  entering the inner solar system.
• Once on such an orbit, they last about 100M
  years, after which time they either get ejected
  or collide with a planet or with the sun

24
(No Transcript)
25
What can be done to reduce the risk?

• Asteroid collisions are one of many natural
  hazards
• But we can do something about it
• Go out and find all the potentially hazardous
  objects and see if they are actually hazardous
• If they all turn out to be safe then the risk
  will have been eliminated
• If not..

26
Mandate by U.S. Congress

• 1991 U.S. Congress directed NASA to conduct
  workshops on how potentially threatening
  asteroids could be detected, and how they could
  be deflected or destroyed.
• 1994 House Comm. on Science/Technology directed
  NASA and DoD to identify and catalogue within 10
  years orbits of all comets and asteroids 1km
  crossing orbit of Earth

27
Modern Existing Searches

• Among the active search programs in the U.S.
  are
• Spacewatch (Kitt Peak in Arizona)
• NEAT (JPL using USAF Maui telescopes)
• LINEAR (Lincoln Labs at White Sands, NM)
• LONEOS (Lowell Observatory)
• IfA UH88

28
Killer Asteroids and new
solar system objects
Detection with UH 88
29
(No Transcript)
30
What is the IfA doing?

• Pan-STARRS - a new telescope facility
• 4 smallish (1.8m) telescopes, but with extremely
  wide field of view
• Can scan the sky rapidly and repeatedly, and can
  detect very faint objects
• Project led by IfA with help from Air Force, Maui
  High Performance Computer Center, MITs Lincoln
  Lab and Science Applications International Corp.

31
(No Transcript)
32
Optical design
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
Pan-STARRS numbers

• 4 telescopes
• 4 billion pixels
• 10 terabytes per night
• 30 petabytes in 10 years
• 30,000,000,000,000,000 bytes!

40
Pan-STARRS Asteroid Search Strategy

• Pan-STARRS will target potentially hazardous
  objects
• Objects that may become actually hazardous in
  100 years

41
Potentially Hazardous Asteroids
42
Pan-STARRS capability

• Pan-STARRS will become operational in 2006
• By that time, the existing search programs will
  have found 70-80 of the 1km size objects, but
  will be running out of steam
• Pan-STARRS will push the completeness for km size
  objects to near unity
• And will find most of the objects with diameter
  300m
• Pan-STARRS will also do lots of other science,
  ranging from the formation of the solar system to
  the fate of the Universe as a whole.
