What is ALFTD?

• Application Level Fault Tolerance and Detection
• ALFTD complements existing system or algorithm
  level fault tolerance by leveraging information
  available only at the application level
• Using such application level semantic information
  significantly reduces the overall cost providing
  fault tolerance
• ALFTD may be used alone or to supplement other
  fault detection schemes
• ALFTD is scalable
• Error overhead can be traded off with invested
  time overhead for fault tolerance

3
ALFTD Overview

• Application Level Fault Tolerance and Detection
  allows for system survival of both data and
  system (instruction/hardware) faults.
• System faults cause a process to eventually cease
  functioning
• Data faults cause a process to continue running
  with incorrect results
• ALFTD has been implemented into OTIS to determine
  its feasibility as a fault detection and
  tolerance method for REE applications
• OTIS has two sets of related output data, the
  temperature and emissivity
• Experiments have focused mostly on the
  temperature output

4
OTIS Structure
4. Slave Calculations
5
OTIS Work Distribution

• OTIS dynamic workload distribution allows it to
  compensate for system faults
• Work originally partitioned for a failed
  processor is instead taken by the remaining
  processes
• OTIS does not compensate for data faults
• As long as the work is completed, there is no
  measure of correctness
• OTIS does not consider deadline repercussions

6
OTIS Fault Cases
7
ALFTD OTIS Structure
8
Secondaries in OTIS

• The secondary required for ALFTD is implemented
  to be functionally similar to the primary
• Secondary scaling occurs through resolution
  reduction
• OTIS natural data input exhibits spatial
  locality
• Points not directly calculated can be
  approximately estimated using interpolation
  between calculated points
• Secondary processes have been tested at 20-50
  of the primary calculation overhead
• While 50 affords better quality, 20 has less
  overhead

9
Example of Secondary Resolution
100 Secondary Resolution
50 Secondary Resolution
33 Secondary Resolution
25 Secondary Resolution

• (ALFTD Compensation for 10 rows in a sample
  dataset)

10
ALFTD Benefit
11
ALFTD Benefit (contd)
12
Fault Detection

• When to run the secondary, and when to use the
  secondary output, is determined by output filters
• Output filters are created to check for
  application-specific trends in data
• Aberrations from normal data characteristics can
  be considered to be the product of potentially
  faulty processes
• OTIS relies on natural temperature
  characteristics to detect potentially faulty data
• Spatial Locality temperature changes gradually
  over small areas
• Absolute Bounds temperature should not exceed
  certain values

13
Data Sets

• Three data sets were chosen for their interesting
  characteristics

14
Data Frequency (Values)
15
Data Frequency (Spatial Locality)
16
Validation Through Secondaries

• When the primary deadline is hit, rows are
  re-delegated to the secondaries if (and only if)
• The primary has returned results for that row
  suspected to be faulty
• The secondary results can be used to decide
  whether the results are indeed faulty
• A particular row was never successfully
  calculated
• The secondary results can be immediately used in
  place of the missing primary results

17
Validation Through Secondaries (contd)

• After the secondary has been run to verify a
  primarys results, the better data is chosen
  according to the following logic grid

Secondary
18
Fault Tolerance Results Spots

• Fault Tolerance with injected faults in Spots

19
Fault Tolerance Results Spots (contd)
Faulty Output
Fault-Free Output
33 ALFTD Computation Overhead
50 ALFTD Computation Overhead
25 ALFTD Computation Overhead
ALFTD-corrected faulty output
20
Fault Tolerance Results Spots (contd)
Difference Plots faulty output versus faultless
output
No ALFTD
25 ALFTD Computation Overhead
33 ALFTD Computation Overhead
50 ALFTD Computation Overhead
No Error
Max Error
21
Fault Tolerance Results Blob

• Fault Tolerance with injected faults in Blob

22
Fault Tolerance Results Blob (contd)
Faulty Output
Fault-Free Output
33 ALFTD Computation Overhead
50 ALFTD Computation Overhead
25 ALFTD Computation Overhead
ALFTD-corrected faulty output
23
Fault Tolerance Results Blob (contd)
Difference Plots faulty output versus faultless
output
No ALFTD
25 ALFTD Computation Overhead
33 ALFTD Computation Overhead
50 ALFTD Computation Overhead
No Error
Max Error
24
Fault Tolerance Results Stripe

• Fault Tolerance with injected faults in Stripe

25
Fault Tolerance Results Stripe(contd)
Faulty Output
Fault-Free Output
33 ALFTD Computation Overhead
50 ALFTD Computation Overhead
25 ALFTD Computation Overhead
ALFTD-corrected faulty output
26
Fault Tolerance Results Stripe(contd)
Difference Plots faulty output versus faultless
output
No ALFTD
25 ALFTD Computation Overhead
33 ALFTD Computation Overhead
50 ALFTD Computation Overhead
No Error
Max Error
27
Emissivity Data

• Emissivity is loosely proportional to temperature
  data
• Emissivity exhibits spatial locality
• Emissivity has natural bounds of expected data

lt0.5 - Faulty
gt1.0 - Faulty
Natural Metal 0.5
Vegetatation, Water 1.0
Rock 0.8 - 0.95
28
Emissivity Data (contd)

• Emissivity does not exhibit the same data
  closeness as temperature output
• This makes it very difficult to distinguish
  faulty from non-faulty data
• Luckily, faults present in temperature output are
  easily detected, and reflect faults in emissivity
  output.
• Emissivity does not have per-pixel independence
  of calculation
• Dependence on the correctness of neighboring
  pixels makes resolution reduction a viable, but
  not the best, method for secondary reduction

29
Data Frequency (Emissivity Values)
30
Conclusion

• ALFTD has already shown to be a worthwhile
  alternative to full redundancy
• Improvements on the scheme will increase fault
  coverage and decrease secondary calculation
  overhead in both the emissivity and temperature
  outputs
• OTIS, as a general matrix-based, master/slave
  program is a springboard to other, similar
  programs (e.g., NGST)
• ALFTD as a fault-detection scheme will continue
  to be effective in programs which exhibit
  natural output

31
Thank You!
32
Relative Error Calculation

• Error in OTIS output is calculated relative to a
  faultless template
• The average relative error is the average of all
  relative errors of the entire output
• Faulty value f(x,y)
• Faultless value F(x,y)
• Error
