Citizens Bank Park Philadelphia Pennsylvania

1
Citizens Bank ParkPhiladelphia Pennsylvania

• Presented by
• Kevan Brown Andrew Matias

2
Presentation Outline

• Project development
• Project Engineering
• Project Funding
• Social and Political Issues
• Sources
• Questions?

3
The Plan

• Background
• -Professional baseball has been
• Sharing a stadium with the local
• Professional football team since
• 1971 (Veterans Stadium)
• -1996 Bill passed to develop 4 new
• Stadiums for professional sports
• teams in P.A.
• -Search for the site lasted for 2
• Years!
• -Project given to EwingCole
• engineering firm
• -Project began Nov. 2001, park opened
• April 2004 in time for the 2004 season
• Design Goals
• -clear view of downtown area
• -open web structural steel system
• That supports the artistic elements
• of the stadium

4
Project Engineering

• Field level is 23ft below street level which is
  also beneath the water table
• A system of sewer lines and draining pipes were
  of crucial importance to the design and current
  functionality of the stadium.
• Geotechnical Engineers were used to determine how
  much ground water needed to be removed to keep
  the construction site dry.
• A series of deep wells and drains keeps the water
  at bay.
• Also, a deep foundation system (comprised of
  steel H pipes) was required due to the upper
  layers of sediment being comprised of mainly sand
  and clay.

5
(No Transcript)
6
More Project Engineering

• Concrete shear walls and piers were used beneath
  the lower levels of the buildings and the seating
  bowl to provide lateral resistance to wind,
  seismic forces, and earth pressure.
• The seating bowl itself is one of the most
  distinctive features. The concept features a
  series of straight seating sections, each angled
  toward home plate all around the field.
• The resulting geometry maximizes views of the
  infield
• from each of the 43,500 seats.

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
How much did this project cost?
458 MILLION
50 of funding came from private institutions 50
of funding came from public financing Naming
rights bought by Citizens Bank
11
Social Political Issues

• Parking/ access to transportation
• Taxes

12
Sources

• http//www.ballparks.com/baseball/national/phibpk.
  htm
• HOME RUN. By Loos, Jared Patel, Pradeep. Civil
  Engineering (08857024), Jun2004, Vol. 74 Issue 6,
  p56-63 (ASCE)
