Title: TT300 Centrifugal Compressor


1
  • TT300 Centrifugal Compressor
  • APPLICATIONS
  • www.turbocor.com

2
ARI 550/590 - 1998
IPLV (COP) 0.01A 0.42B 0.45C
0.12D A EER or COP at 100 capacity B EER or
COP at 75 capacity C EER or COP at 50
capacity D EER or COP at 25 capacity IPLV
(kW/Ton) (0.01/A 0.42/B 0.45/C
0.12/D) A kW/Ton at 100 capacity B kW/Ton at
75 capacity C kW/Ton at 50 capacity D kW/Ton
at 25 capacity
1
3
Integrated Part Load Value
Weighted average values
load 100 75 50 25
1992 standard 17 39 33 11
1998 standard 1 42 45 12
ARI Standard 550/590-98
4
Flooded Type Evaporator and Water Cooled
Condenser (L. App) R134a
Conclusion On IPLV basis, the TT300 is 45 more
efficient than the leading screw compressor.
5
Turbocor vs. Screw Flooded Evaporator and W/C
Condenser
6
DX Type Evaporator and Water Cooled
Condenser R-134a
Conclusion On IPLV basis, the TT300 is 32 more
efficient than the leading screw compressor.
7
Turbocor vs. Screw D-X Evaporator and W/C
Condenser
8
DX Evaporator and Air Cooled Condenser R134a
Conclusion On IPLV basis, the TT300 is 29 more
efficient than the leading screw compressor.
9
Turbocor vs. ScrewD-X Evaporator and A/C
Condenser
10
Notes
  • Further 3 to 5 efficiency increase when dual
    compressors used on common circuit HXs.

11
(No Transcript)
12
The energy revolution in air-conditioning and
refrigeration compressors
13
The energy revolution in air-conditioning and
refrigeration compressors
