Probing Non-Perturbative QCD with
Antiprotons The PANDA Experiment at FAIR

• Introduction Why is QCD so much fun?
• The Physics Glue and Charm
• The Facility FAIR
• Accelerator and Antiproton Cooler Ring
• Detector PANDA
• Summary and Outlook

3
Physics with Panda
Charmed hadrons in the nuclear medium
CP-violation (D/? - sector)
inverted deeply virtual Compton scattering
4
QCD In Principle Simple ?

• Contains Self coupling of Gluons

• Coupling of Quarks to the Gluon fields

• Small coupling perturbative QCD
• Large coupling
• Lattice QCD
• Field theories with effective degrees of freedom

5
Running Coupling Constant
perturbative
strong
QCD
Of particular interest Transition from the
quark-gluon to the hadronic degrees of freedom
6
Physics with Panda
Charmed hadrons in the nuclear medium
CP-violation (D/? - sector)
inverted deeply virtual Compton scattering
7
Bound States of QCD


8
Flux Tubes and Hybrids
Simplified Lattice Approach

• Excitation of Flux Tube
• Additional angular momentum
• New (exotic) quantum numbers

Bali, 1991
Hybrid
9
Charmonium Hybrids
Excited gluon flux

• Predicted by bag models, flux tube models,
  constituent gluon models and LQCD.
• Three of the lowest lying c?c hybrids have exotic
  JPC (0-,1-,2-)
• ? no mixing with nearby c?c states
• Mass 4.2 4.5 GeV/c2.
• Charmonium hybrids expected to be much narrower
  than light hybrids (open charm decays
  suppressed).
• Cross sections for formation and production of
  charmonium hybrids similar to normal c?c states
• ( 100 150 pb).

CLEO
One-gluon exchange
10
Charmonium Hybrids

• Annihilation is a gluon rich process
• creates gluonic excitation in a direct way
• 2 complementary techniques
• Production(Fixed-Momentum)
• Formation(Broad- and Fine-Scans)
• Momentum range for a survey
• p 15 GeV

11
Bound States of QCD


12
Heavy Glueballs
2- 0-

• For light gg/ggg-systems
• unique identification difficult (mixing!)
• Exotic heavy glueballs
• m(0-) 4140(50)(200) MeV
• m(2-) 4740(70)(230) MeV
• Flavor-blindness
• decay into charmed final
• states possible

Morningstar,Peardon, PRD60(1999)34509 Morningstar,
Peardon, PRD56(1997)4043
13
Physics with Panda
Charmed hadrons in the nuclear medium
CP-violation (D/? - sector)
inverted deeply virtual Compton scattering
14
Charmonium Positronium of QCD

• Positronium

• Charmonium

Mass MeV
Binding energy meV
4100
y

(4040)

Ionization energy
P
( 3940)
3
2
0
3900
D
3
P
( 3880)
( 3800)
3
3
S

3
3
D
3
S
3
1
3
3
D
1
1
2
0
1
2
D
P
( 3800)
3
D
3
1
3
-1000
1
y

(3770)
D
2
0
2
P
3
3

D
3
2
P
3
D
1
2
3
2
2
S
3
2
S

2
1
1
1
2
P
1
3

Threshold
y

(3686)
600 meV
0
3700
1

2
P
3
0
h

(3590)
10-4 eV

c
-3000
c
(3556)

2
h
(3525)

c
c
(3510)

1
3500
c
(3415)

0
-5000
3300
1
S
3
810-4 eV
1
1
S

1

0
-7000
y
(3097)

3100

0.1 nm

-
e
e
C
1 fm
h
(2980)
C

c
2900
15
Charmonium Physics
Open questions
?(33S1)
DD
?c2(23P2)
?(13D3)
pp GeV/c
Mcc GeV/c2
?c(31S0)
?c1(23P1)
Peculiar ?(4040)
?(13D2)
DD
h1c(21P1)
?c0(23P0)
?(11D2)
?(13D1)
DD
Terra incognita for 2P and 1D-States
?(23S1)
?c(21S0)
?c2(13P2)
h1c(11P1)
?c1(13P1)
?c - ?(2S) splitting
?c0(13P0)
h1c unconfirmed
J/?(13S1)
?c inconsistencies
?c(11S0)
16
Advantage of Antiprotons

• ee- annihilation via
• virtual photon only
• states with JPC 1--

• Mass resolution is only limited by the beam
  momentum resolution

17
Recent discoveries hc (21S0) , X(3872)

• Discovery of the ?c(21S0) by
• Belle (BaBar, CLEO).
• Discovery of a new narrow
• state above DD threshold
• X(3872) at Belle ( CDF,
• D0, BaBar).

M(??c) 3637.7 ? 4.4 MeV/c2
_

M 3872.0 ? 0.6 ? 0.5 MeV/c2 ?? 2.3 MeV (90
C.L.)
18
Physics with Panda
Charmed hadrons in the nuclear medium
CP-violation (D/? - sector)
inverted deeply virtual Compton scattering
19
Hadrons in Nuclear Matter

• Currently at GSI
• many experiments devoted to the study of hadrons
  in nuclei and hadronic matter
• in-medium modifications of hadron properties
• KAOS, deeply bound pionic atoms, HADES
• hadrons with light quarks (u,d,s)

20
How about Charm ?

• Mass splitting for D mesons expected !
• Probes
• Measure excitation functions for D production on
  Nuclei with antiproton beam
• Modification of the width of Charmonium states
  near the D threshold

21
D Mesons in Nuclear Matter

• Excitation functions Width of
  Charmonium States

22
Charmonium in Nuclear Matter Observables
Predicted rates at L 1032 cm-2s-1 few 10
few 100 events/day S.H. Lee,
nucl-th/0310080
23
J/y Absorption in Nuclei
24
Physics SummaryQCD Systems to be Studied with
PANDA
25
The FAIR Facility (was GSI)
26
HESR High Energy Storage Ring
27
The PANDA Detector Top View
Length 2 m upstream, 10 m downstream
28
Proposed Detector (Overview)

• High Rates
• Total s 55 mb
• Vertexing
• (sp,KS,?,)
• Charged particle ID
• (e,µ,p,p,)
• Magnetic tracking
• Elm. Calorimetry
• (?,p0,?)
• Forward capabilities
• (leading particles)
• Sophisticated Trigger(s)

29
Participating Institutes(with Representative in
the Coordination Board)
45 Institutes from 12 Countries

• U Basel
• IHEP Beijing
• U Bochum
• U Bonn
• U INFN Brescia
• U INFN Catania
• U Cracow
• GSI Darmstadt
• TU Dresden
• JINR Dubna (LIT,LPP,VBLHE)
• U Edinburgh
• U Erlangen
• NWU Evanston
• U INFN Ferrara

• U Pavia
• IHEP Protvino
• PNPI Gatchina
• U of Silesia
• U Stockholm
• KTH Stockholm
• U INFN Torino
• Politechnico di Torino
• U Oriente, Torino
• U INFN Trieste
• U Tübingen
• U TSL Uppsala
• IMEP Vienna
• SINS Warsaw
• U Warsaw

• U Frankfurt
• LNF-INFN Frascati
• U INFN Genova
• U Glasgow
• U Gießen
• KVI Groningen
• IKP Jülich I II
• U Katowice
• IMP Lanzhou
• U Mainz
• U Politecnico INFN Milano
• U Minsk
• TU München
• U Münster
• BINP Novosibirsk

30
Summary and Outlook

• The FAIR Project will include a dedicated
  antiproton facility
• World-class research covering the many facets of
  non-perturbative QCD
• Additional benefits
• Continuation of the ongoing GSI program
  investigating hadrons in dense matter
• Measurement of hadronic interaction cross section
  CRUCIAL for the interpretation of QGP signals
• (J/y suppression)
• The future beyond the future
• Direct CP violation in the Charm sector
• Gravitation experiments with ultra-cold anti
  hydrogen
• CERN AD program with 100 times increased
  intensity and unprecedented beam quality!
