Weeds Water and Wool

1
Weeds Water and Wool

• A Day to Dye For
• Kathy Wildman Grafton WV
• kattwild_at_msn.com

2
(No Transcript)
3
Fibers

• Animal protein - sheep, alpaca, camel, angora
  rabbit, cashmere goat, silk worms etc
• Vegetable cellulose - cotton, hemp, ramie,
  flax, abaca, paper, kapoc, papyrus etc
• Mineral polyester, nylon, asbestos, fiberglass,
  angelhair etc

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
Natural Dyes

• Animal - cochineal, lac, mollusc
• Vegetable dyes can be extracted from all plant
  parts in various plants in all taxonomic
  categories from mushrooms to flowering plants
• Mineral ochre cave paintings, clays, ores,
  picric acid, Saxon Blue
• Synthetic Dyes - coal tars WH Perkin 1856
  mauvine searching for synthetic quinnine

10
(No Transcript)
11
Plant Pigments

• Carotenoids fat soluble - yellow and orange
  colors and some red colors
• Flavonoids - red through blue colors
• Lycopene tomatoes, Xanthophyll red chilies
• Anthocyanines - Water soluble red, purple,
  blue may change color red in acid blue in base
  pH indicator - hydrangeas

12
Fall Color - Fruit Ripening

• Chlorophyll breaks down, leaving the carotenoids.
• Chloroplasts (green plastids) gradually
  transform into chromoplasts (colored plastids)?
• Fruit/Leaf changes from green to yellow or red.

13
(No Transcript)
14
Substantive or Direct Dyes

• Become chemically fixed to the fiber without the
  aid of any other chemicals or additives, such as
  indigo or certain lichens.

15
(No Transcript)
16
Adjective Dyes or Mordant Dyes

• Require some sort of substance, (usually a metal
  salt) to prevent the color from washing or
  light-bleaching out.
• Metal ions from the salt form strong bonds with
  the fiber and also with the dye, thereby holding
  the dye to the fiber.

17
(No Transcript)
18
No mordant no knot Alum mordant 1 knot
Copper mordant 2 knots Iron mordant 3 knots
Tin mordant 4 knots
19
Mineral Mordants protein fibers

• Alum with cream or tartar
• Iron salts
• Copper
• Tin
• Chrome
• Dye container can affect color.

20
Plant Mordants cellulose fibers

• Some plants have a natural ability to extract
  such minerals from the earth, such as club moss.
• Tannins oak galls
• washing soda creates an alkaline dyebath

21
Chemistry

• Indigo oxidation reduction reaction

22
(No Transcript)
23

• Mordant effects
• Litmus test reagents
• Astrobrite goldenrod paper
• Hydrangea is affected by soil ammendments and
  can turn from pink to blue depending on Aluminum
  uptake governed by the soi pH

24
Beet Juice Indicator
http//www.cchem.berkeley.edu/demolab/demo_txt/Cab
bIndic.htm
25
Geography

• Logwood, cochineal and indigo inspired geographic
  exploration and supported colonial empires.
• Dyes were worth their weight in gold silk
  road trading routes.
• Colonial empires created wealth with extractive
  commodities.

26
Anthropology

• Dyes have been used in ritual and decoration from
  prehistory
• Costumes, body painting, and tatoos

27
(No Transcript)
28

• Everyday fabrics, clothing, furniture, decorative
  elements for the home and even the house yurts
  and tee-pees

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
History

• Dyes have both "gone to" and inspired wars while
  tie-dye clothed a peace movement.
• Military uniforms identify friend from foe.
• War paints and tatoos inspire ferocity, fidelity
  and commitment.

33

• Dyes were commoditized and guilds restricted
  introductions Woad wars.
• Fibers too inspired wars with wool financing
  England's 100 year War with France
• Cotton economics drove the American Civil War.

34
Social Studies

• Local plants yellow greens and brown
• Reds, blues and purples - rarer, expensive or
  imported
• Sumptuary Laws restricted use of royal colors
• Color based class system
• Colonialism sources of dyes

35
(No Transcript)
36
Math

• In addition to the math used to lay out a garden,
  there is lots of measuring and weighing involved
  in dyes

37
English Language Arts

• Eliza Lucas Pinckney introduced indigo crop in
  SC 1740 strong and successful woman Pres
  George Washington asked and accedpted to be a
  pallbearer
• http//www1.umn.edu/ships/modules/scimath/roleplay
  .htm

38
Current Events

• Face Painting, hair dyes and tatoos
• Environmental issues dye discharges land use
  issues. Pesticides vs organic cotton
• Pumice mining for stone washed jeans
• Weed laws for non native invasive plants
• Natural food coloring hyperactivity concerns
  red dye 2 vegan, religious and ick issues
• The Travels of a T-Shirt in the Global Economy -
  Pietra Rivoli - history, economics and politics

39
Preparing a Dye Bath

• Use 4 parts fresh plant matter to 1 part wool by
  weight.
• Break down plant parts to expose maximum surface
  area (chop as finely as practical) and simmer for
  one hour (roots or other hard parts may need to
  sit overnight).
• Strain out plant debris thru cloth and add enough
  water to accomodate wool without crowding.

40

• The mordants create binding sites on the wool
  fibers to which molecules of dye chemicals lock
  on permanently.
• In a diluted dye bath these molecules can still
  be matched to the sites.
• If a second batch of wool is dyed there will be
  fewer dye molecules available for binding (since
  most were removed in the first wool skeins) and
  the color will be paler.
• Leftover dye water might be used with pulp to
  make colored paper


41
(No Transcript)
42
Safety Precautions

• Many woods can cause contact dermatitis if
  handled without gloves.
• Wear a dust mask and safety goggles with all
  concentrated dyes.
• Keep powdered dyewoods and concentrates away from
  children and pets.
• Dye Utensils marked and separate from food
  containers and cooking areas
• Dispose fluids in black lines or away from water

43
(No Transcript)
44
Kitchen Dyes

• RED beet root, cherries, or red cabbage
• YELLOW onion skins
• GREEN spinach
• BROWN iodine, coffee, or tea
• BLUE dissolve a teaspoon of flour in about half
  a cup of water and add a drop or two of iodine
• PURPLE blackberries

45
Fiber Projects

• Yarn can used for friendship bracelets with
  weaving techniques common in Japan and South
  America.
• Make God's eyes for a Southwest study.
• A simple cardboard loom can make a small bag,
  coin purse or pillow.

46
(No Transcript)
47
Felting Projects

• Buy a fleece on the hoof and have it delivered
  and sheared on site. Scour fleece to remove
  lanolin and foreign matter.
• Invite a spinner to demonstrate and bring
  equipment.
• Try carding and drop spindles.
• Use fleece to make a felted potholder or ball
• Purchase carded wool to dye for felting.

48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
Dye Sources

• http//www.prairiefibers.com/
• http//www.dharmatrading.com/html/eng/1893-AA.shtm
  l?lnavdyes.html
• http//www.earthguild.com/products/dyes/dyenat.htm

• http//www.griffindyeworks.com/store/index.php?mai
  n_pageindexcPath1_4
• http//www.hillcreekfiberstudio.com/HFS-Shop/en-us
  /dept_13.html
• http//www.the-mannings.com/mannings_catalog.cgi?d
  ctonfirst_record_on_page0total_matching_rows1
  1tabcatalogtt106cmadctsession_id11de854850
  records_per_page10
• http//www.woolery.com/Pages/dyes.htmldyeseeds
• http//www.sinopia.com/index.asp?PageActionVIEWCA
  TSCategory2
• http//www.stevespanglerscience.com/product/1552
