Unit IV DNA, RNA, and Protein Synthesis

1
Unit IV- DNA, RNA, and Protein Synthesis
2
Importance and Structure of DNA
Deoxyribo-Nucleic Acid

• Historical Review
• 1900s Morgans studies with fruit flies showed
  that genes were located on chromosomes and
  chromosomes consisted of protein and DNA
• 1952- Hershey-Chase demonstrated that DNA (not
  protein) was the genetic material of a viral phage

3
Figure 16.2a The Hershey-Chase experiment phages
4
Figure 16.2b The Hershey-Chase experiment
5
Phages Infecting a bacterium
6
Figure 16.1 Transformation of bacteria
Griffith (and later Avery, McCarty and MacLeod)
7
The Structure of DNA

• Nucleotide monomers
• Phosphate
• Pentose Sugar (C5) Deoxyribose Sugar
• Organic Nitrogen Base
• Cytosine (C)
• Adenine (A)
• Guanine (G)
• Thymine (T)

8
Structure of DNA cont

• Polynucleotide chain with linkage via phosphates
  to next sugar, with nitrogen base away from
  backbone of
• Phos-sugar-phos-sugar
• Dehydration synthesis

9
Beginning of the 1950s several labs were
studying the structure of DNA

• Maurice Wilkins Rosalind Franklin
• X-ray crystallography x-rays pass through pure
  DNA and defraction of x-rays were then examined
  on film
• James Watson and Francis Crick did not have the
  expertise of Franklin and were without proper
  photos until

10
Figure 16.4 Rosalind Franklin and her X-ray
diffraction photo of DNA
11
Watson and Crick
12
April 1953 Classical one page paper in Nature
by Watson and Crick

• A double helix 2 polynucleotide strands
• Sugar-phosphate chains of each strand are like
  the side ropes of a rope ladder
• Paris of nitrogen bases, one from each strand,
  form the rungs or steps
• The ladder forms a twist every 10 bases (all from
  x-ray studies!)

13
Figure 16.5 The double helix
14
Internal Structure of DNA Purine and
pyridimine? REMEMBER X-RAY DATA
15
Confirms Erwin Chargaffs Rules

• of Adenine to of thymine
• of guanine equal to of cytosine
• This dictates the combinations of N-bases that
  form steps/rungs
• Does not restrict the sequence of bases along
  each DNA strand

16
Replication/Duplication of DNA

• Due to complimentary base paring one strand of
  DNA determines the sequence of the other strand
• Therefore, each strand of double stranded DNA
  acts as a template
• The double helix first unwinds controlled by
  enzymes and uses new nucleotides that are free
  in the nucleus to copy a complimentary strand off
  the original DNA strand

17
Figure 16.7 A model for DNA replication the
basic concept (Layer 1)
18
Figure 16.7 A model for DNA replication the
basic concept (Layer 2)
19
Figure 16.7 A model for DNA replication the
basic concept (Layer 3)
20
Figure 16.7 A model for DNA replication the
basic concept (Layer 4)
21
Information storage in DNA

• The 4 nitrogenous bases are the alphabet or
  code for all the traits the organism possesses
• Different genes or traits vary the sequence and
  length of the bases
• ATTTCGGAC vs. GGGATTCTAG vs. GATC

22
There are a series of enzymes that control DNA
replication enzymes which

• Uncoil the original double helix strand via a
  helicase
• Single-strand binding protein keeps helix apart
  so replication can start
• Prime an area to start replication primase
  except it adds RNA nucleotides at first
• Polymerase to join individual nucleotides
  (dehydration synthesis)
• Ligases to join short segments

23
Figure 16.8 Three alternative models of DNA
replication
24
DNA REPLICATION
25
Figure 16.9 The Meselson-Stahl experiment tested
three models of DNA replication (Layer 1)
26
Figure 16.9 The Meselson-Stahl experiment tested
three models of DNA replication (Layer 2)
27
Figure 16.9 The Meselson-Stahl experiment tested
three models of DNA replication (Layer 3)
28
Figure 16.9 The Meselson-Stahl experiment tested
three models of DNA replication (Layer 4)
29
Figure 16.10 Origins of replication in eukaryotes
30
Figure 16.11 Incorporation of a nucleotide into
a DNA strand
31
Antiparallel Arrangement of Double Strands

• The carbons of the deoxyribose sugar are numbered
• 3 carbon attached to an -OH group
• 5 carbon holds the phosphate molecule of that
  nucleotide
• 3 ready to bond with another nucleotide to form
  a polynucleotide link (5 to3)
• Notice complimentary strand in opposite direction
  (5 to 3)
• DNA always grows 5 to 3 never 3 to 5

32
Definitions

• Origins of Replication where replication of the
  DNA molecule begins
• Bacteria circular DNA 1 origin of replication
  (RF)
• Eukaryotes multiple origins of replication
  (ORFS)
• ORF Replication Fork

33
More Definitions

• DNA Polymerases enzymes that catalyze DNA
  replication
• Leading Strand Synthesized continuously towards
  the replication fork by the DNA polymerase in one
  long fashion
• Lagging Strand Synthesized by short fragments
  away from the replication fork by the DNA
  polymerase

34
Definitions Cont

• Ligase combines (joins) short fragments
• Primer starts replication of DNA (in this case
  its RNA)
• Primase an enzyme that joins the RNA
  nucleotides to make the primer
• Helicase an enzyme that untwists the double
  helix at the replication fork
• Nuclease a DNA cutting enzyme

35
DNA REPLICATION -VIDEO
36
Figure 16.13 Synthesis of leading and lagging
strands during DNA replication
37
Figure 16.14 Priming DNA synthesis with RNA
38
Figure 16.15 The main proteins of DNA
replication and their functions
39
Figure 16.16 A summary of DNA replication
40
Figure 16.17 Nucleotide excision repair of DNA
damage
41
A PROBLEM!

• The end of the leading strand was initiated with
  an RNA primer
• Normally removed by other DNA polymerase
• Removal of gaps by DNA Polymerase doesnt work on
  lagging strand end
• RNA primer removed with no replacement
• A GAP!
• SHORTER AND SHORTER FRAGMENTS?

42
Prokaryotes have circular DNA no problem at
ends (there arent ANY!

• Eukaryotes have special terminal sequences of 6
  nucleotides that repeat from 100-1000 times with
  no genes included
• Telomers
• Protect more internal gene materials from being
  eroded
• Germ cells / sex cells have a special enzyme
  (telomerase) that actually restore shortened
  telomers
• Somatic cells telomer continues to shorten and
  may play a role in aged cell death
• Cancer cells
• A telomerase prevents very short lengths

43
Figure 16.19a Telomeres and telomerase
Telomeres of mouse chromosomes
44
Ribonucleic Acid (RNA)

• Structure of RNA
• Nucleotide monomer
• Phosphate
• Pentose sugar ribose (extra oxygen)
• Nitrogenous base (A/G/C/U)
• Single stranded
• 3 types (mRNA, tRNA, rRNA)

45
Synthesis of RNA - transcription

• DNA acts as a template, but only one strand of
  DNA utilized at a given time
• This exposed strand is controlled by specific
  enzymes that pair the DNA nucleotides with free
  RNA nucleotides which are also present in the
  nucleus
• These RNA nucleotides form a single stranded RNA
  nucleic acid
• DNA ATTGGCT
• RNA UAACCGA
• Short segments of DNA are transcribed at a time
  with start and stop messages

46
Figure 17.2 Overview the roles of transcription
and translation in the flow of genetic
information (Layer 1)
47
Figure 17.2 Overview the roles of transcription
and translation in the flow of genetic
information (Layer 2)
48
Figure 17.2 Overview the roles of transcription
and translation in the flow of genetic
information (Layer 3)
49
Figure 17.2 Overview the roles of transcription
and translation in the flow of genetic
information (Layer 4)
50
Figure 17.2 Overview the roles of transcription
and translation in the flow of genetic
information (Layer 5)
51
Figure 17.6 The stages of transcription
initiation, elongation, and termination (Layer 1)
52
Figure 17.6 The stages of transcription
initiation, elongation, and termination (Layer 2)
53
Figure 17.6 The stages of transcription
initiation, elongation, and termination (Layer 3)
54
Figure 17.6 The stages of transcription
initiation, elongation, and termination (Layer 4)
55
Figure 17.6 The stages of transcription
elongation
56
Three types of RNA

• mRNA messenger RNA
• Transcribed from a specific segment of DNA which
  represents a specific gene or genetic unit
• tRNA transfer RNA
• Transcribed from different segments of DNA and
  their function is to find a specific amino acid
  in the cytoplasm and bring it to the mRNA
• rRNA ribosomal RNA
• Transcribed at the nucleolus - with proteins
  function as the site of protein synthesis

57
Three types of RNA
58
Protein Synthesis Translation

• Ribosomes sites of protein synthesis
• 30 - 40 protein
• 60 - 70 RNA (rRNA)
• Assembled in nucleus and exported via nuclear
  pores
• Antibiotics can paralyze bacterial ribosomes, but
  not eukaryotic ribosomes (not targeting them)
• 2 ribosomal subunits a large and a small
• Small subunit has been used as a means of
  classifying different bacteria and different
  invertebrates (16S)
• Eukaryotes 18S
• There are three sites on the ribosome that are
  involved in protein synthesis

59
Ribosomes bring mRNA together with amino acid
bearing tRNAs

• Three ribosomal sites
• P Site (peptidyl-tRNA) holds the tRNA carrying
  the growing peptide chain after several amino
  acids have been added
• A site (aminoaccyl-tRNA) holds the next single
  amino acid to be added to the chain
• E site (exit site) site where discharged tRNA
  minus amino acids leave ribosome

60
Figure 17.15 Translation the basic concept
61
Preparation of Eukaryotic mRNA

• RNA splicing- a cut and paste job to remove
  nucleotides from transcribed mRNA
• 8000 nucleotides transcribed but the average gene
  contains 1200 nucleotides
• Long non-coding segments (introns) interspersed
  between coding segments (exons) expressed via
  amino acids

62
(No Transcript)
63
Figure 17.17 The initiation of translation
64
Figure 17.18 The elongation cycle of translation
65
Protein Synthesis (cont)Initiation elongation
- termination

• Starting at one end of the mRNA, the small
  ribosomal subunit associates with the mRNA and
  accepts the first tRNA with its activated amino
  acid attached Initiation
• tRNA associate with a triplet codon exposed on
  the mRNA these are 3 nitrogenous bases that
  bond with 3 complementary bases exposed
  (anticodon) on the tRNA opposite the attached
  amino acid
• Wobble
• Arent 61 tRNAs, are 54tRNAs

66
Figure 17.4 The dictionary of the genetic code
67
Figure 17.3 The triplet code
68
tRNA complexes with its amino acid in the
cytoplasm using ATP activated tRNA

• The activated tRNA-amino acid complex moves
  towards the ribosomal area and find a triplet
  codon exposed that is complementary to the
  anticodon of the tRNA
• The first activated tRNA-amino acid, after its
  anticodon is bound to the mRNA codon, associates
  with the large ribosomal subunit which now joins
  the smaller subunit and the mRNA and the tRNA
  (TAKE A BREATH!)

69
The first tRNA and its amino acid now occupy the
P site of the large ribosomal subunit

• Review at this point the 2 part ribosome is
  assembled, the mRNA has started to be read, and
  one tRNA plus amino acid is occupying the P site
• That means the adjacent A site is free to accept
  a second activated tRNA and its amino acid, but
  only if the anticodon of this tRNA matches the
  next three base pairs exposed (codon)

70
Protein Synthesis continued

• At this point, there are 2 tRNA-amino acid
  complexes adjacent to each other Elongation
  involved one amino acid being added in a three
  step process
• Codon recognition the mRNA codon in the A site
  matches with the anticodon of the tRNA amino
  acid complex
• Peptide bond formation between the new amino acid
  in the A site and the amino acid (later peptide)
  in the P site
• Translocation

71
Translocation the ribosome moves the tRNA into
the A site, and its attached peptide to the P
site, as the previous tRNA from the P site moves
to the E (Exit) site and leaves the ribosome

• Review once this process is under way, an
  activated tRNA with its amino acid finds an
  exposed codon in the A site, attaches via
  H-bonds, then forms a peptide bond with the
  polypeptide associated with the tRNA sitting in
  the adjacent P site. For a moment, the longer
  polypeptide chain is only attached to the tRNA in
  the A site. Now the entire ribosome shifts so
  that the

72
Yet More Protein Synthesis

• The empty tRNA from the P site moves in to the E
  site and leaves the ribosome
• As the tRNA with the polypeptide chain moves from
  the A site to the now empty P site .exposing a
  new codon.
• GUESS WHAT HAPPENS NEXT?!

73
A question?

• Every time a new codon is exposed in the A site,
  a specific tRNA-AA complex moves into the site.
  What originally terermined this mRNA Codon

74
The Answer!

• The original DNA that was transcribed
• This elongation of 1 AA takes about 0.1 s
• Termination the above continues (dozens to
  hundreds or more AA added) until the STOP CODON
  is reached (codon at the end of the mRNA)
• This codon does not have a matching tRNA
  anticodon so the tRNA-AA attaches in the A site
  and the tRNA moves to the E site and releases the
  polypeptide chain

75
FIANALLY - SUMMARY

• The take home message
• At the ribosome, the genetic language of DNA is
  translated into a different language Via RNA
  into the functioning language of PROTEINS!!!!

76
Figure 17.17 The initiation of translation
77
Figure 17.18 The elongation cycle of translation
78
Figure 17.19 The termination of translation
79
Figure 17.20 Polyribosomes
80
Table 17.1 Types of RNA in a Eukaryotic Cell
81
Figure 17.23 The molecular basis of sickle-cell
disease a point mutation
82
Figure 17.24 Categories and consequences of
point mutations Base-pair insertion or deletion
83
Figure 17.24 Categories and consequences of
point mutations Base-pair substitution
84
Figure 17.25 A summary of transcription and
translation in a eukaryotic cell
85
Figure 18.19 Regulation of a metabolic pathway
86
Control of Protein SynthesisRegulation of Gene
Expression

• Every cell has the same numbers and types of
  chromosomes
• Development and normal gene function requires
  precise gene expression in an on and off manner
• Operon cluster of gene segments on DNA and its
  controlling segments
• Repressible
• Inducible

87
Regions of the Operon (DNA)

• Promoter region promotes transcription by
  binding with RNA polymerase
• Operator region binds a regulatory protein or
  chemical
• Overlaps with the RNA polymerase binding site
• Structural genes code for a particular peptide
  or several peptides
• Start or stop codes

88
Figure 18.20a The trp operon REPRESSIBLE
89
Figure 18.21a The lac operon INDUCIBLE
90
Figure 19.7 Opportunities for the control of
gene expression in eukaryotic cells
