Multimedia Databases

1
Multimedia Databases

• Text I

2
Outline

• Spatial Databases
• Temporal Databases
• Spatio-temporal Databases
• Data Mining
• Multimedia Databases
• Text databases
• Image and video databases
• Time Series databases

3
Multimedia Data Management

• The need to query and analyze vast amounts of
  multimedia data (i.e., images, sound tracks,
  video tracks) has increased in the recent years.
• Joint Research from Database Management,
  Computer Vision, Signal Processing and Pattern
  Recognition aims to solve problems related to
  multimedia data management.

4
Multimedia Data

• There are four major types of multimedia data
  images, video sequences, sound tracks, and text.
• From the above, the easiest type to manage is
  text, since we can order, index, and search text
  using string management techniques, etc.
• Management of simple sounds is also possible by
  representing audio as signal sequences over
  different channels.
• Image retrieval has received a lot of attention
  in the last decade (CV and DBs). The main
  techniques can be extended and applied also for
  video retrieval.

5
Content-based Image Retrieval

• Images were traditionally managed by first
  annotating their contents and then using
  text-retrieval techniques to index them.
• However, with the increase of information in
  digital image format some drawbacks of this
  technique were revealed
• Manual annotation requires vast amount of labor
• Different people may perceive differently the
  contents of an image thus no objective keywords
  for search are defined
• A new research field was born in the 90s
  Content-based Image Retrieval aims at indexing
  and retrieving images based on their visual
  contents.

6
Feature Extraction

• The basis of Content-based Image Retrieval is to
  extract and index some visual features of the
  images.
• There are general features (e.g., color,
  texture, shape, etc.) and domain-specific
  features (e.g., objects contained in the image).
• Domain-specific feature extraction can vary with
  the application domain and is based on pattern
  recognition
• On the other hand, general features can be used
  independently from the image domain.

7
Color Features

• To represent the color of an image compactly, a
  color histogram is used. Colors are partitioned
  to k groups according to their similarity and the
  percentage of each group in the image is
  measured.
• Images are transformed to k-dimensional points
  and a distance metric (e.g., Euclidean distance)
  is used to measure the similarity between them.

k-dimensional space
k-bins
8
Using Transformations to Reduce Dimensionality

• In many cases the embedded dimensionality of a
  search problem is much lower than the actual
  dimensionality
• Some methods apply transformations on the data
  and approximate them with low-dimensional vectors
• The aim is to reduce dimensionality and at the
  same time maintain the data characteristics
• If d(a,b) is the distance between two objects a,
  b in real (high-dimensional) and d(a,b) is
  their distance in the transformed low-dimensional
  space, we want d(a,b)?d(a,b).

d(a,b)
d(a,b)
9
Text - Detailed outline

• Text databases
• problem
• full text scanning
• inversion
• signature files
• clustering
• information filtering and LSI

10
Problem - Motivation

• Given a database of documents, find documents
  containing data, retrieval
• Applications
• Web
• law patent offices
• digital libraries
• information filtering

11
Problem - Motivation

• Types of queries
• boolean (data AND retrieval AND NOT ...)
• additional features (data ADJACENT retrieval)
• keyword queries (data, retrieval)
• How to search a large collection of documents?

12
Full-text scanning

• for single term
• (naive O(NM))

ABRACADABRA
text
CAB
pattern
13
Full-text scanning

• for single term
• (naive O(NM))
• Knuth, Morris and Pratt (77)
• build a small FSA visit every text letter once
  only, by carefully shifting more than one step

ABRACADABRA
text
CAB
pattern
14
Full-text scanning
ABRACADABRA
text
CAB
pattern
CAB
...
CAB
CAB
15
Full-text scanning

• for single term
• (naive O(NM))
• Knuth Morris and Pratt (77)
• Boyer and Moore (77)
• preprocess pattern start from right to left
  skip!

ABRACADABRA
text
CAB
pattern
16
Full-text scanning

• Approximate matching - string editing distance
• d(survey, surgery) 2
• min of insertions, deletions,
  substitutions to transform the first string
• into the second
• SURVEY
• SURGERY

17
Full-text scanning

• string editing distance - how to compute?
• A dynamic programming
• Let s and t are two strings
• Then, start from the end and try to find the
  minimum number of operations
• cost( i, j ) cost to match prefix
  of length i of first string s with prefix of
  length j of second string t

18
Full-text scanning

• if si tj then
• cost( i, j ) cost(i-1, j-1)
• else
• cost(i, j ) min (
• 1 cost(i, j-1) //
  deletion
• 1 cost(i-1, j-1) //
  substitution
• 1 cost(i-1, j) //
  insertion
• )

19
Full-text scanning

• Complexity O(MN)
• More on your algorithms book
• Conclusions
• Full text scanning needs no space overhead, but
  is slow for large datasets

20
Text - Detailed outline

• text
• problem
• full text scanning
• inversion
• signature files
• clustering
• information filtering and LSI

21
Text Inverted Files
22
Text Inverted Files
Q space overhead?
A mainly, the postings lists
23
Text Inverted Files

• how to organize dictionary?
• stemming Y/N?
• Keep only the root of each word ex. inverted,
  inversion ? invert
• insertions?

24
Text Inverted Files

• how to organize dictionary?
• B-tree, hashing, TRIEs, PATRICIA trees, ...
• stemming Y/N?
• insertions?

25
Text Inverted Files

• postings list more Zipf distr. eg.,
  rank-frequency plot of Bible

log(freq)
freq 1/rank / ln(1.78V)
log(rank)
26
Text Inverted Files

• postings lists
• CuttingPedersen
• (keep first 4 in B-tree leaves)
• how to allocate space Faloutsos92
• geometric progression
• compression (Elias codes) Zobel down to 2
  overhead!
• Conclusions needs space overhead (2-300), but
  it is the fastest

27
Text - Detailed outline

• text
• problem
• full text scanning
• inversion
• signature files
• Information Retrieval
• Vector Model and clustering
• information filtering and LSI

28
Signature files

• idea quick dirty filter

29
Signature files

• idea quick dirty filter
• then, do seq. scan on sign. file and discard
  false alarms
• Adv. easy insertions faster than seq. scan
• Disadv. O(N) search (with small constant)
• Q how to extract signatures?

30
Signature files

• A superimposed coding!! Mooers49, ...

m (4 bits/word) F (12 bits sign. size)
31
Signature files

• A superimposed coding!! Mooers49, ...

data
actual match
32
Signature files

• A superimposed coding!! Mooers49, ...

retrieval
actual dismissal
33
Signature files

• A superimposed coding!! Mooers49, ...

nucleotic
false alarm (false drop)
34
Signature files

• A superimposed coding!! Mooers49, ...

YES is MAYBE NO is NO
35
Signature files

• Q1 How to choose F and m ?
• Q2 Why is it called false drop?
• Q3 other apps of signature files?

36
Signature files

• Q1 How to choose F and m ?
• A so that doc. signature is 50 full

m (4 bits/word) F (12 bits sign. size)
37
Signature files

• Q1 How to choose F and m ?
• Q2 Why is it called false drop?
• Q3 other apps of signature files?

38
Signature files

• Q2 Why is it called false drop?
• Old, but fascinating story
• how to find qualifying books (by title word,
  and/or author, and/or keyword)
• in O(1) time?

without computers...
39
Signature files

• Solution edge-notched cards

1
2
40

• each title word is mapped to m numbers(how?)
• and the corresponding holes are cut out

40
Signature files

• Solution edge-notched cards

1
2
40
data
data - 1, 39
41
Signature files

• Search, e.g., for data activate needle 1,
  39, and shake the stack of cards!

1
2
40
data
data - 1, 39
42
Signature files

• Q3 other apps of signature files?
• A anything that has to do with membership
  testing does data belong to the set of words
  of the document?

43
Signature files

• Another name Bloom Filters
• Bloom-joins in System R Mackert and active
  disks Riedel99
• differential files SeveranceLohman
• Many other applications in Networks and databases

• http//www.eecs.harvard.edu/michaelm/NEWWORK/pos
  tscripts/BloomFilterSurvey.pdf

44
Information Retrieval

• What is the goal of IR?
• Build a system that retrieves documents that
  users are likely to find relevant to their
  queries.
• This set of assumptions underlies the field of
  Information Retrieval.

45
Some IR History

• Roots in the scientific Information Explosion
  following WWII
• Interest in computer-based IR from mid 1950s
• Probabilistic models at Rand (Maron Kuhns)
  (1960)
• Boolean system development at Lockheed (60s)
• Vector Space Model (Salton at Cornell 1965)
• Statistical Weighting methods and theoretical
  advances (70s)
• User Interfaces, Large-scale testing and
  application (90s)

46
Query Languages

• A way to express the question (information need)
• Types
• Boolean
• Natural Language
• Stylized Natural Language
• Form-Based (GUI)

47
Simple query language Boolean

• Terms Connectors (or operators)
• terms
• words
• normalized (stemmed) words
• phrases
• thesaurus terms
• connectors
• AND
• OR
• NOT

48
Boolean Logic
B
A
49
User Query
Collections of documents, files, etc
text input
50
Information need
Collections
text input
Reformulated Query
