Title: WiFi Kiosk an instant hotspot solution


1
WiFi Kioskan instant hotspot solution
  • Sales Department
  • Advanced Internet Access, LLC
  • TEL 425-814-2216
  • FAX 425-605-3549
  • Email sales_at_aiallc.com
  • www.InstantHotSpot.com

Ver 2.0
2
Reasonably priced, the Instant HotSpot WiFi
KIOSK, is the best solution for the Hotspot
business. All it needs is an Internet line (ADSL/
Cable Modem) and the WiFi KIOSK makes your venue
an Internet HOTSPOT, instantly. Now everyone
can become a hotspot owner and benefit from this
growing market, offering Hotspot service. No
extra costly back-end system is needed and no
operator to hire. Just find a good location, plug
it in, and start your Hotspot business!
3
Changeable Antenna
LED Display
Wireless Gateway inside
Select Buttons
Coin Acceptor
Cancel button for coin refund
Bill Accepter
Barred Coin/Unaccepted Coin Refund Slot
Ticket Print out slot
Coin Refund Slot
Thermal Printer inside
4
How Subscriber Access to Internet
I want to access to Internet.
Subscriber
5
Subscriber
6
Basic Topology
xDSL/Cable Modem
7
Rich Networking Functions
IP Plug and Play Transparent HTTP Proxy DHCP
Server Outgoing Email Redirection Various WAN
Connections NTP Client Dynamic DNS
8
Zero Configuration Internet Access
Easy-to-Use, Plug-and-Play Internet
AccessInstant HotSpots unique IP PlugPlay
(iPnP) technology allows subscribers to connect
with ease for broadband access without having to
re-configure any of their device IP settings
including DHCP, DNS, Proxy and dynamic and static
IP address assignments.
xDSL/Cable Modem
Dynamic IP
Fixed Global IP
Fixed Private IP
DHCP Client
HTTP Proxy
9
Transparent HTTP Proxy
This feature helps subscribers get online without
changing proxy settings, eliminating support
calls related to client proxy settings. (only
supports HTTP proxy).
HTTP
If subscribers browser has proxy server setting,
the WiFi KIOSK acts like a proxy server to serve
this laptop. Subscriber does not need to change
the proxy setting of his laptop.
Proxy Server Enable
Proxy Server Disable
10
DHCP Server
WiFi KIOSK supports a DHCP Server providing IP
address, Subnet, Gateway and DNS parameter to the
subscriber which is DHCP Client. The maximum IP
Pool for DHCP Server is 253.
xDSL/Cable Modem
DHCP Server
DHCP Client
DHCP Client
DHCP Client
11
Outgoing Email Redirection
The WiFi KIOSK will redirect subscribers
original message of E-mail according to SMTP
rules and send it out via the specified SMTP
server. This function helps subscribers send
E-mail via the local SMTP server when their
default SMTP server doesnt work or wont allow
connecting from the Internet.
Pre-installed SMTP Server 210.66.77.88
All SMTP packets from Subscribers will be
re-directed to specified SMTP Server which
pre-installed by service provider.
Send Mail
Send Mail
  • Relay function of this SMTP Server must be
    enabled.
  • Subscribers no need to modify the SMTP setting
    for their laptop.

Original SMTP Server Setting mail.aiallc.com
Original SMTP Server Setting 192.168.100.3
12
Various WAN Connections
The WiFi KIOSK provides alternative connections
to ISP such as PPPoE, PPTP, DHCP Client or Static
IP for Hotspot owner to establish their service
quickly and easily.
Static IP
DHCP Client
PPPoE
PPTP
13
NTP (Network Time Protocol) Client
Network Time Protocol can be utilized to
synchronize the time on WiFi KIOSK across a
network. A NTP Time Server is utilized to obtain
the correct time from a time source and adjust
the local time.
xDSL Modem/ Cable Modem
NTP Server
Update Time
NTP Client
14
Dynamic DNS
The DDNS service (Dynamic Domain Name Service) is
provided for administrator to remote access to
their WiFi KIOSK even their WiFi KIOSK uses an IP
associated with dynamic IP addresses, ex PPPoE
connection for WAN
WAN port Dynamic IP
xDSL/Cable Modem
DDNS Service Provider
Xyy.dyndns.org
Remote Access Workstation
15
User Accounting Authentication
Web-based Authentication Local
Authentication Customizable Billing Plan
Definable Select Button Printout Customization
User Account List
16
Web-based Authentication
The Login page displays with any browser,
prompting the subscriber to enter a username and
password for the first time Internet access.
Subscribers without valid username and password
cannot access Internet.
ADSL Modem
Blocked
Login Page
Login Page
Login Page
WITH valid credential
WITH valid credential
WITHOUT valid credential
17
Local Authentication
Login Page
Subscriber
18
Customizable Billing Plan
The Hotspot owner can customize the billing plan
depend on their business mode
19
Definable Select Buttons
The Hotspot owner can define the billing plan to
each select buttons
Button C
Button B
Button A
20
Display for Billing Plan
When the subscriber press select button, the
billing plan will show on the LED display
21
Printout Customization
This function allows Hotspot owner to customize
the contain of the ticket print out.
22
User Account List
WiFi KIOSK provides a simple WEB interface for
Hotspot owner to manage and monitor the user
accounts.
23
Wireless
802.11b Wireless LAN 64/128-bit WEP Encryption
24
802.11b Wireless LAN
IEEE 802.11b 11, 5.5, 2.1Mbps
xDSL / Cable Modem
802.11b/g compatible Wireless
Notebook with 11b/g Wireless Card
Notebook with 11b/g Wireless Card
25
64/128-bit WEP Encryption
Wired Equivalent Privacy is based on the use of
security keys and the popular RC4 encryption
algorithm. Wireless devices without a valid WEP
key will be excluded from network traffic.
xDSL / Cable Modem
WEP Encryption
WEP Encryption
WEP Encryption
WEP Encryption
26
Security and Firewall
Layer 2 Isolation SSL Login Page VPN Pass through
Administration Access Control Pass through
IP/MAC/URL Address Filtering
27
Layer 2 Isolation
This feature prevents every wireless subscriber
from communicating with each other, even they are
within same subnet. This is the best solution for
Hotspot security. Nobody can allow his/her
computers data to be shared with anyone else.
ADSL Modem
IP 192.168.1.2 Subnet 255.255.255.0 Gateway
192.168.1.254
IP 192.168.1.3 Subnet 255.255.255.0 Gateway
192.168.1.254
IP 192.168.1.1 Subnet 255.255.255.0 Gateway
192.168.1.254
28
SSL Login Page
SSL Login protects username and password while
subscriber logs in via web page.
Subscriber Logins Username/Password are
encrypted, therefore even if the packets are
captured, hackers cannot know the
username/password.
ADSL Modem
SSL Secure Login Page
Username ???????? Password ?????????
29
VPN Pass through
VPN Passthrough provides the subscribers who want
to run his VPN or secure tunneling client
software to connect to his/her companys VPN
server.
Company A
Secure Tunnel
Mail
FTP
Company B
Mail
FTP
30
Administration Access Control
The WiFi KIOSK integrates a secure administration
access control list that checks the source (IP
address) of administrator logins. A login is
permitted only if a match is made with the list
contained on the WiFi KIOSK. If a match is not
made, the login is denied, even if a correct
login name and password are supplied.
Specified IP Address For Administration
IP 211.21.185.12
IP 10.12.22.1
Only allow 211.21.185.12 to access
31
Pass-Through IP/ MAC/ URL Address
  • Pass-Through feature allows Hotspot owner to
    define non-authenticated access (Free Access)
    base on following condition
  • Destination IP or URL Address- allow subscribers
    to access specified Internet websites without
    authentication.
  • Source IP or MAC address allow subscribers
    notebook to access to Internet without
    authentication.

xDSL/Cable Modem
Pass through Destination URL?www.aiallc.com Sourc
e MAC address?00900e111233
www.aiallc.com
MAC 00900e111233
32
Filtering
Filtering allows the system administrator to have
a list of restricted destinations, which is
useful to block specified Internet websites or
Intranet areas.
33
Billing Mechanism
Time to Finish Accumulation
Two kinds of billing mechanisms are offered for
Hotspot owner to deploy for their Hotspot business
34
Time to Finish
500
420
450
400
430
440
410
After 1 hour , subscriber will be disconnected
and the account become invalid
Subscriber Purchased 1 hour account (Time to
Finish) and login on 400
35
Accumulation
500
420
450
400
430
440
410
Subscriber Login
Subscriber Login
Subscriber
After 20 minutes, subscriber logout from the
network.
Again subscriber login to utilize the remind
usage time.
Subscriber purchased 1 hour account (Accumulation)
and login on 400
36
Marketing Features
Customized Login Page Login Page
Redirection Advertisement Link Walled Garden
37
Customized Login Page
The Instant HotSpot WiFi KIOSK provides the
standard login page for subscribers to input
username and password. However, some Hotspots
like hotels, coffee shops and airports may want
to show their customized page or redirect their
hosted page for promotion or corporate image,
therefore Instant HotSpot WiFi KIOSK allows
service providers or Hotspot owners to specify or
modify the login page.
Standard Login Page
38
Customized Login Page
The Instant HotSpot WiFi KIOSK provides the
standard login page for subscribers to input
username and password. However, some Hotspot
owner like hotels, coffee shops and airports may
want to show their customized page or redirect
their hosted page for promotion or corporate
image, therefore WiFi KIOSK allows service
provider or Hotspot owner to specify or modify
the login page.
Frame Login Page
39
Login Page Redirection
This feature allows the Instant HotSpot WiFi
Kiosk to redirect the subscribers browser to a
specified home page as a Login Page
www.test.com/login.html
Web Server
Login Page
Login Page
40
Advertisement Link
The Instant HotSpot WiFi KIOSK allows the
Hotspot owner to input 10 URL links for
advertisement link purpose. The 10 URL Links will
pop-up after subscribers login success at first
time or every specified time randomly or from
1 to 10.
www.yahoo.com
www.msn.com
www.microsoft.com
41
Walled Garden
WiFi KIOSK prepare ten URL links that allows
subscriber to access the specific Web pages even
they didnt have a username or password. Its
free trying and can use for advertisement.
Instant HotSpot
www.InstantHotSpot.com
MSN
www.msn.com
Microsoft
www.microsoft.com
Standard Login Page
42
Extend Service Coverage
Extend Wireless Coverage Deploy Wireless and Wire
Coverage
43
Extend Wireless Coverage
The wireless gateway inside WiFi KIOSK provide
four 10/100 Ethernet LAN ports, its can be use
for the solution to extend wireless coverage by
Ethernet cable and Network Range Extenders.
))))
Range Extender
3rd Floor
))))
Range Extender
2nd Floor
))))
1st Floor
44
Deploy Wireless and Wire Coverage
The wireless gateway inside WiFi KIOSK provides
four 10/100 Ethernet LAN ports, and can be
utilized for wired connections
))))
Range Extender
3rd Floor
Ethernet Switch
2nd Floor
))))
1st Floor
45
Management
GUI Interface Real-time Session List LAN Device
Management Syslog System Status Back Up and
Restore
46
GUI Interface
WiFi KIOSK provide user friendly GUI for all
configuration of WiFi KIOSK
47
Real-time Session List
This function allow Hotspot owner to monitor the
real time usage status from remote site
Administrator
Global IP 210.66.37.22
Network Management PC
48
LAN Device Management
This function is provided to help Hotspot owners
remotely manage and control devices connected
under the LAN port of Wireless Gateway inside the
Instant HotSpot WiFi KIOSK.
AP 60001 10.59.1.1
80 00090e1a1122 TCP
Wired Switch 60002 10.59.1.2
80 00900e1a2e3a TCP
Wired
Administrator
http//210.66.37.2260001 to remote access AP
connect under LAN port of WiFi KIOSK
10.59.1.1
Global IP 210.66.37.22
Ethernet Switch
Network Management PC
10.59.1.2
49
Syslog
WiFi KIOSK provide 5 categories of logs which
will send to specified Syslog server. Network
manager can know the network status according to
the following logs. 1. System Category
System information System Boot Notice
System Manager Activity information 3.
Proprietary Accounting Account Created
Account Activated Subscriber Trace 5. LAN
Devices Management LAN Devices Information
LAN Devices Alarm
Syslog Server
2. Subscriber Wireless Association
Information Logged-in Users
4. Billing Billing Log
ADSL / Cable Modem
50
System Status
System Status page is provided for Hotspot owner
to understand the system status of WiFi KIOSK
which installed in real site.
51
Firmware Upgrade
The WiFi KIOSK allow Hotspot owner to upgrade the
firmware via HTTP or TFTP.
TFTP Server
xDSL/Cable Modem
HTTP
52
Backup and Restore
This function allow the Hotspot owner to save,
restore or reset configuration parameters of
Instant HotSpot WiFi KIOSK.
53
Extra Function
Payment Gateway
54
Payment Gateway Integrations
The WiFi KIOSK provides also common Payment
Gateways, for example iValidate.net. Hotspot
owner can deploy hotspot business not only
selling the ticket but also offer subscriber to
purchase the service by credit card.
iValidate.net
55
Credit Card Service
I want to go to Internet.
Payment Gateway
Select service and enter payment information.
Subscriber
Choose Credit service.
Key in username, Password and enjoy the internet
access
56
Q A
Write a Comment
User Comments (0)
About PowerShow.com
