Installation of SNORT, APACHE, PHP, MYSQL and SnortReport.

1
Installation of SNORT, APACHE, PHP, MYSQL and
SnortReport.

• Presented By
• Ositadimma Maxwell Ejelike
• Bahman Radjabalipour

2
HARDWARE AND SOFTWARE

• Operating System Windows 2003 Server Enterprise
  Edition and Microsoft Windows XP
• Hardware Compaq 1600 Pentium III dual Processor
  Server and Pentium IV workstation
• Software Installed
• Apache_1.3.24-win32-x86-src.msi
  www.apache.org
• Php-4.3.0-Win32.zip
  www.php.com
• Snort_243_Installer.exe
  www.snort.org
• WinPcap_3_1.exe
  http//www.winpcap.org
• Snortrules_snapshot_CURRENT 1.tar.gz
  www.snort.org
• Snortreport-1.3.1.tar.gz

• Jpgraph-1.20.3.tar.gz
• Gd-2.0.33.zip
• Mysql-4.0.17-win.zip
• Winrar

3
SOFTWARE INSTALLTION DIRECTORIES

• Operating System E\ drive.
• Snort F\Snortapps
• Apache E\Program Files\Apache Group\Apache
• SnortReport E\Program Files\Apache
  Group\Apache\htdocs\snortreport
• JPGraphE\Program Files\Apache
  Group\Apache\jpgraph-1.20.3
• GDE\Program Files\Apache Group\Apache\gd-2.0.33
• MYSQLE\bin mysql
• PHPF\Snortapps\php
• EtherealE\Program Files\Ethereal

4
WINPCAP

• It captures packets from the network cables and
  throws them to snort
• Its a Windows version of libpcap used in Linux
  for running snort
• The WinPcap gets information about the network
  adapters in the network.

5
SNORT

• Open sourced, lightweight, network intrusion
  detection system
• Uses easy to learn rules to detect and log the
  signatures of possible attacks
• It can also be use as a Sniffer
• Its a free utility with active community support

6
MYSQL

• SQL based database software
• Most supported platform for storing snort alerts
• Stores all IDS alerts triggered from our snort
  sensors.
• Snort can log directly to MYSQL natively, as the
  alerts come in.

7
MYSQL CONTD
8
MYSQL CONTD.

• Winmysqladmin
• Edit my.ini file
• Ran winmysqladmin from a command prompt
• Bind MySQL to the system localhost IP address, we
  use 127.0.0.1
• Set the communication port it's 3306 for a
  typical MySQL installation.
• Set the key_buffer setting for snort data, we
  choose 64M

9
MYSQL CONTD.

• Cleaning MYSQL and creating DB for Snort
• mysql -u root p
• delete from user where host ""
• delete from user where user "
• select from user
• drop database test
• show databases
• create database snort
• create database archive
• Grant INSERT, SELECT, UPDATE on snort. to
  snort_at_localhost identified by "snortdba"

10
APACHE WEB SERVER

• Web Server of choice for most websites
• The sole purpose is for hosting the SnortReport
  web-based console

11
APACHE WEB SERVER FOR SNORT

• LoadModule php4_module F/Snortapps/php/sapi/php4a
  pache.dll
• AddModule mod_php4.c
• Addtype application/x-httpd-php .php .phtml
• Order deny, allow Deny from all Allow from
  127.0.0.1

12
PHP

• General-purpose scripting language for web
  development
• Support for a database-enabled web page
• Provides support for SnortReport

13
PHP FOR SNORT

• Copy "F\snortapps\php\php4ts.dll" to "
  E\WINDOWS\system32" .
• Copy "C\snortapps\PHP\sapi\php4apache4.dll" to
  "E\Program Files\Apache Group\Apache\Modules"
• Copy the file "E\snortapps\php\php.ini-dist" to
  our ROOT Folder (E\WINDOWS) and renamed it to
  "php.ini".
• Edit the php.ini
• max_execution_time 60 session.save_path
  E/windows/temp removed the in front of "
  extensionphp_gd.dll" doc_root E\program
  files\apache group\apache\htdocs\snortreportexten
  sion_dir F\Snortapps\php\extensions

14
JDGRAPH AND GD 2.0.11

• A general graphics library that supports PNG
  images
• It is used to display the nice pie graph in
  SnortReport
• Uncompress it to the directory where Apache is
  installed

15
SNORTREPORT

• Snort Report is an add-on module for the Snort
  Intrusion Detection System.
• It provides real-time reporting from the MySQL
  database generated by Snort.
• Its a Web-based application for viewing all IDS
  alerts
• All sensor information is consolidated here for
  viewing

16
SNORTREPORT INSTALLATION

• Uncompress SnortReport
• Navigate to the snortreport folder and choose
  srconf.php. Edit the variables below server
  "localhost"
• user "snort"
• pass "snortdb"
• dbname "snort"
• define(Path of JDGRAPH", Path of GD")
• Reboot the machine
• Start your browser and type http//localhost/snor
  treport

17
Configuring snort.conf

• var HOME_NET 192.168.15.24/32
• output database alert, mysql, usersnort
  dbnamesnort passwordPASSWORD host127.0.0.1
  port3306 sensor_namemaxserver
• include RULE_PATH/bahman_Maxwell.rules
• Include F\Snortapps\etc\classification.config
• Include F\Snortapps\etc\reference.config

18
Configuring Snort as a Service

• snort /SERVICE /INSTALL -de -c F\snortapps\etc\sn
  ort.conf -l F\snortapps\log -i 2
• /SERVICE Windows command to access the Services
  commands
• /INSTALL The command that installs the program
  as a Window service

19
Running Snort as a service
20
Snort Report
21
Ethereal sniffing the packets
