OSRAM at a glance

• OSRAM... is one of the two leading lighting
  manufacturers in the world
• HeadquartersMunich
• Trade mark registration... on 17.04.1906 at the
  then Imperial Patent Office
• Founded... on 01.07.1919 by the merger of the
  light bulb production facilities of three
  companies AEG, Siemens Halske AG and Deutsche
  Gasglühlicht-Anstalt (Auer-Gesellschaft)

Origin of the company's nameThe metals osmium
(Os-) and wolfram (-ram) EmployeesMore
than 38,000 Production sites49 factories in 19
countries TurnoverEUR 4.3 billion ProfitEUR 465
million RD outlay5 percent of turnover
Long-term business strategy Innovation, global
presence, cost leadership
3
OSRAM The Lighting Specialist
Display/Optic Light sources for display
applications, Halogen and discharge lamps for
film and TV, special effects and airport
lighting, medicine and microscopy

• Ballasts and Luminaires
• Electronic control systems for (compact)
  fluorescent lamps, low-voltage halogen lamps,
  high-intensity discharge lamps
• Consumer luminaires

• Automotive Lighting
• Headlamps
• Auxiliary automotive lamps
• Headlight systems (USA only)

• General Lighting
• Standard incandescent lamps
• Halogen lamps
• Compact fluorescent lamps
• Fluorescent lamps
• High-intensity discharge lamps

N E W

• PMC
• Electronic, chemical, metal urgical and glass
  components for lamp manufacturing and
  similar technologies
• Sintered metals, connectors

• Machines
• Design and construction of machines and
  complete production lines for lamps and
  their components
• Elaboration of concepts for new production
  sites

LED SystemsCustomized LED-based lighting
solutions, e.g. LED modules for general lighting,
automotive and display/optic applications

• Opto Semiconductors
• LED components
• OLED
• High-power laser diodes
• Infrared components

4
Some like it hot.And cold.
LUMILUX T5 HO CONSTANT. Lots of light even at
very low or very high ambient temperatures.

• T5 fluorescent lamps with innovative amalgam
  technology for high-performance lighting
  solutions.
• LUMILUX T5 HO CONSTANT
• High luminous flux more than 90 of maximum
  luminous flux between 5C and 70C (instead of
  between 25C and 50C for previous T5 lamps)
• Ideal for cold luminaire temperatures of less
  than 25C T5 lamps can therefor be used for
  the first time for outdoor lighting
• They can also be used at temperatures above
  50C, for example in damp-proof luminaires and
  small recessed luminaires
• Electrically and geometrically compatible with
  conventional T5 lamps

5
LUMILUX T5 HO CONSTANT.
e.g. LUMILUX T5 HO CONSTANT Wattage Max.
luminous flux Light colour Length 54W/830 54
W 5550 lm 3000 K 1149 mm 54W/840 54 W 5550
lm 4000 K 1149 mm 80W/830 80 W 7000 lm 3000
K 1449 mm 80W/840 80 W 7000 lm 4000 K 1449 mm
6
LUMILUX T5 HO CONSTANT.
7
LUMILUX T5 HO CONSTANT.
100

90
80
70
60
50
T8 58W
40
T5 54W
30
T5 54W CONSTANT
20
10
- 10
0
10
20
30
40
50
60
70
80
oC
8
Heavenly light at any time of day or night.
LUMILUX SKYWHITE T5 HO. A new dimension in
light with a light colour of 880.

• A real asset innovative T5 fluorescent lamps
  with a colour temperature of 8000 K.
• LUMILUX SKYWHITE T5 HO
• Large amount of blue light in the wavelength
  range from 410 to 460 nm
• High luminous flux of up to 6550 lm and good
  colour rendering of Ra 80
• Improves contrast and reduces visual fatigue
• Optimum effect in luminaires designed
  specifically for them with appropriate glare
  reduction and optimum directional light

9
LUMILUX SKYWHITE T5 HO.
LUMILUX SKYWHITE Wattage Luminous flux at
35C Light colour Length 24W/880 HO 24 W 1850
lm 8000 K 549 mm 39W/880 HO 39 W 3225 lm 8000
K 849 mm 54W/880 HO 54 W 4650 lm 8000 K 1149
mm 80W/880 HO 80 W 6550 lm 8000 K 1449 mm
10
Life of T5 HE/HO (16mm) lamps with ECGs
Longer lamp life thanks to Cut Off technology
100
Rel. system luminous flux
Cut Off technology
90
16.
18.
80
70
Conventional ECG circuit
60
20.
24.
50
40
5
20
24
16
22
18
14
Hours burned thsd
Hours burned for the IEC 3-hour switching cycle
(165 min. ON/15 Min. OFF)
11
With light, less is often more.
Powerful light, compact dimensions New
applications in industry, for indoor and outdoor
lighting.

• OSRAM DULUX 120 W HO CONSTANT, OSRAM DULUX L
  CONSTANT
• New amalgam technology produces a luminous flux
  of more than 90 in a temperature range from 5C
  to 70C
• High luminous flux of up to 9000 lm (OSRAM
  DULUX 120 W HO CONSTANT) and 4500 lm (OSRAM
  DULUX L CONSTANT 55 W)
• Very long average life of up to 20,000 hours.
  Reduced maintenance costs thanks to fewer
  relampings
• Lower procurement and installation costs for new
  systems because fewer luminaires and lamps are
  needed

12
OSRAM DULUX 120 W HO CONSTANT, OSRAM DULUX L
CONSTANT.

• OSRAM DULUX Wattage Base Max. length
  Luminous flux
• 120 W HO CONSTANT 120 W 2G8-1 230 mm 9000 lm
• L CONSTANT 55 W 2G11 4500 lm (40 W und 80 W
  in preparation)

13
High-pressure discharge lampsMilestones in
discharge vessels
Quartz
14
Technical benefits of round ceramic vesselsA
good all-rounder
Cylindrical HCI
POWERBALL HCI
Significant corrosion after 8,900 hours
Hardly any corrosion after 16,000 hours
15
Technical benefits of round ceramic vesselsA
good all-rounder
Benefits of POWERBALL HCI

• Longer life of 12,000 h
• Up to 10 higher luminous flux
• Smaller drop in luminous flux over its life
• Improved colour rendering
• More stable light colour over its life
• Same quality of light in all burning positions
• As standard in all OSRAM ceramic lamps (also
  HCI-TT E40)

16
Full power and a full choice.
POWERBALL HCI 250 W. Only from OSRAM four
different types and two light colours with
compact dimensions.

• The complete range POWERBALL HCI 250 W
• Available in tubular and ellipsoidal designs and
  as double- ended TS versions or super-compact TM
  versions
• The highlight POWERBALL HCI-TM 250 W (400 W in
  preparation)
• Much smaller dimensions than other discharge
  lamps of the same output
• For all applications in which light is focused
• Only one luminaire design for two lamps thanks
  to the G22 base 250 W with light colours
  WDL/NDL and 400 W with light colour NDL

Source Siteco Beleuchtungstechnik GmbH
17
POWERBALL HCI.

• POWERBALL HCI Luminous flux Length Diameter
  Base
• T 250W/830 WDL 25800 lm 226 mm 46 mm E40
• E 250W/830 WDL 24500 lm 226 mm 90 mm E40
• TS 250W/830 WDL 25000 lm 163 mm 25 mm Fc2
• TM 250W/830 WDL 26000 lm 175 mm 34 mm G22
• TM 400W/942 NDL 40000 lm 175 mm 34 mm G22

in preparation
18
Electronic control gear incredibly versatile.
QUICKTRONIC INTELLIGENT,QUICKTRONIC
PROFESSIONAL QTP5.ECG for T5/Ø16mm fluorescent
lamps.

• Whether dimmable (DALI or 1-10V interface) or
  non-dimmable, the geometry and the wiring are
  identical.
• QUICKTRONIC INTELLIGENT
• Automatic lamp detection and operation with
  rated data
• Unique whether dimmable or non-dimmable, QTi or
  QTP5, there is no difference in the geometry or
  the wiring
• High energy efficiency A2, high reliability
  with a life of 50,000 hours plus system
  guarantee
• QUICKTRONIC PROFESSIONAL QTP5
• Same as QUICKTRONIC INTELLIGENT but without
  automatic lamp detection

19
QUICKTRONIC INTELLIGENT, QUICKTRONIC
PROFESSIONAL QTP5.

• QUICKTRONIC INTELLIGENT QUICKTRONIC
  PROFESSIONAL
• QTi 1x/2x 14/24/21/39 HE/HO QTP5 1x/2x 14-35 HE
• QTi 1x/2x 28/54 HE/HO QTP5 1x/2x 24-39 HO
• QTi 1x/2x 35/49 (80) HE/HO QTP5 1x/2x 49 HO
• QTP5 1x/2x 54 HO
• QTP5 1x 80 HO

20
Electronic control gear is setting new standards.
POWERTRONIC PTi. The new generation of HID
ECGssmall, intelligent and heat-resistant.

• Innovative ECGs with state-of-the-art
  microprocessor techno-logy for reliable system
  operation, economy and safety.
• POWERTRONIC PTi
• High flexibility one and two-lamp ECGs in 35 W
  and 70 W versions, suitable for ceramic and
  quartz lamps
• Extremely compact dimensions and low weight
• Excellent thermal behaviour, high permitted
  ambient temperature ta and case temperature tc
• Genuine life of 40,000 h at maximum case
  temperature tc (Corresponds to a life of at
  least 50,000 h at a 5C lower tc)

21
POWERTRONIC PTi.

• POWERTRONIC PTi Lamp System Max. ambient
  Max.case Dimensions wattage temperature
  ta temperature tc L x W x H (mm)
• PTi 35/220-240 S/I 35 W 43 W 65C 80C / 110
  mm x 75 mm x 30 mm (S)/ 75C 155 mm x 83 mm
  x 32 mm (I)
• PTi 2x35/220-240 S/I 2 x 35 W 86 W 55C 80C
  / 135 mm x 75 mm x 30 mm (S)/ 75C 180 mm x
  83 mm x 32 mm (I)
• PTi 70/220-240 S/I 70 W 80 W 55C 80C / 110
  mm x 75 mm x 30 mm (S)/ 75C 155 mm x 83 mm
  x 32 mm (I)
• PTi 2x70/220-240 S/I 2 x 70 W 160 W 55C
  80C / 163 mm x 90 mm x 32 mm (S)/ 75C 210
  mm x 98 mm x 32 mm (I)

in preparation
22
New dimensions in light.
Powerful LED light in very small packages ...

• Thanks to innovative ThinGaN and ThinFilm
  technologies, our new generation of long-life
  Golden DRAGON LED is now even more efficient
  and brighter. We can offer impressive system
  solutions featuring OPTOTRONIC control gear and
  LED modules.

23
DRAGON LED und OPTOTRONIC.
LED components and systems Fluorescent lamps
Compact fluorescent lamps Halogen lamps
High-intensity discharge lamps Electronic
control gear
LED modules No.of LED OPTOTRONIC
Optics DRAGONeye 1 350 mA DC 16-20 DRAGONpuck
3 350 mA DC 16-20 DRAGONtape 6 x 1 350 mA DC
optional 10, 30, 14 x 22 DRAGONx 1 350 mA
DC 12, 30, 60 DRAGONstick 6 24 V DC
24
Modern light for general lighting room
illumination with LED.
LED components and systems Fluorescent lamps
Compact fluorescent lamps Halogen lamps
High-intensity discharge lamps Electronic
control gear
OSTAR-Lighting. Small light source, great impact.

• Architectural illumination, room lighting,
  replacement of small incandescent light sources,
  pocket projectors.
• OSTAR-Lighting
• Compact light sources with high luminance and
  high luminous intensity, as bright as a 20 W
  halogen bulb (OSTAR 6-chip) with high
  reliability and long product life
• 100 dimmable without no change of colour,
  available in white and RGB (OSTAR-Projection)
• Design optimised for optical systems and
  secondary lenses
• Optimised OPTOTRONIC drivers OT 18 DIM (1x
  OSTAR 6- or 4-Chip) and OT 35 (3x OSTAR 4-Chip
  or 2x OSTAR 6-Chip)

25
OSTAR-Lighting.
LED components and systems Fluorescent lamps
Compact fluorescent lamps Halogen lamps
High-intensity discharge lamps Electronic
control gear

• OSTAR-Lighting 6-chip with 120 6-chip 4-chip
  with 120 4-chip without degree lens without
  lens degree lens lens
• Light colour Daylight White Daylight
  White Daylight White Daylight White at 5600 K at
  5600 K at 5600 K at 5600 K
• Brightness 420 lm at 700 mA 300 lm at 700 mA 280
  lm at 700 mA 200 lm at 700 mA
• Typical 22,5 V at 700 mA 22,5 V at 700 mA 15,2 V
  at 700 mA 15,2 V at 700 mAforward voltage
• Power consumption 15 W 15 W 10 W 10 W
