Availability Centric Routing ACR

1
Availability Centric Routing (ACR)

• Robust Interdomain Routing Without BGP Security
• July 25th, 2006

2
Current Routing Security Focus

• Current proposals like S-BGP, etc. use
  cryptography to provide control plane
• origin authentication
• path validity

3
Too Much and Too Little?

• These proposals are
• Heavy-weight requiring modifications to routers,
  continually updated address registries, increased
  BGP complexity.
• Insufficient providing no protection from
  malicious routers in the data-plane or links made
  unusable by congestion or bad route convergence.

4
A Different Approach

• Today end-hosts/edge routers often already
  provide end-to-end security using mechanisms such
  as SSL or IPSec.
• With end-to-end security, we claim that
• The routing infrastructure only has to worry
  about providing availability, i.e. the ability to
  find and use a valid path if it exists.

5
High-level Approach

• Clients learn multiple potential paths to a
  destination, instead of a single best path.
• Clients use end-to-end security mechanisms and
  monitor path performance to detect good paths.
• Clients can use adequate paths and change routes
  if necessary.

6
Taxonomy of Attacks

• Snooping Traffic Modification
• Traffic Analysis
• Destination Impersonation
• Spam Sources (unused space hijack)
• Black-holing Traffic
• Traffic Degradation

Lets think about whether the routing system
should handle them.
7
Attack Data Confidentiality Integrity

• Where Data Control Plane
• A secure control plane could make it harder for
  an attacker to get on path, but data-plane
  adversaries can access traffic.
• Verdict Use end-to-end encryption MACs, rather
  than rely on routing protocol.

8
Attack Traffic Analysis

• Where Data Control Plane
• Again, secure control plane makes attack more
  difficult, but providing real guarantees at the
  network layer is extremely difficult or even
  impossible (data worm-hole attack).
• Verdict Use mix-nets or other end-to-end
  mechanisms if needed, as Internet routing cannot
  provide an guarantees.

9
Attack Destination Impersonation

• Where Data Control Plane
• Problems with data-plane attacker (local or
  router) or DNS compromise means that even with
  secure control plane identity is not certain.
• Difficulty in having ISPs create and update
  address registry.
• Verdict End-to-End certificates or other
  authentication are still needed, and obviate
  requirement for identity in control plane (still
  useful as an optimization though).

10
Attack Spam Sources (unused hijack)

• Where Control Plane
• Spam is really caused by incentives and identity
  problems within higher-level systems (e.g.
  email), which would exist even with secure
  routing. The real cost of this vulnerability
  is minimal.
• Verdict While authenticated address ownership
  may be desirable, it is not a requirement for
  reliable communication.

11
Attack Black-holing Traffic

• Where Data Control Plane
• The ability to completely prevent communication,
  particularly when another valid path exists, is
  the key threat to a routing protocol.
• Verdict Yes, this is central to routing.

12
Attack Traffic Degradation / DoS

• Where Data Plane, remote hosts
• Paths can be rendered unusable for an
  application even if they are not completely
  unavailable according to the control plane.

• Verdict Yes, a routing protocol should allow
  destinations to avoid such links.

13
Defense Taxonomy Control Plane
Note Whisper only detects attacks, and only at a
limited number of ASes.
14
Defense Taxonomy Data Plane
15
What should routing security achieve?

• Its very hard to get guarantees about the
  identity of the path of data-flow.
• Furthermore, why would we care?
• If applications already use e2e security to
  handle these risks. As a result, they care about
  path quality, not path identity.

16
Availability Centric Routing

• Goals
• 1)Communication in the face of control plane,
  data plane, and link-DoS attacks.
• 2)Incentivized deployment and low barriers to
  adoption.
• 3)No requirements for globally coordinated
  adoption.

17
What is done end-to-end?

• Assume
• 1)Confidentiality, integrity and destination
  identity are handled end-to-end, e.g. SSL/IPSec.
• 2) Path quality monitoring, to decide when to
  change paths.

18
Packet Deflections

• ISPs offer users alternate paths (deflections)
  in addition to the normal path advertised via BGP.

D
A,B,C,D,F is normal BGP path for A -gt F. To
avoid D, A could request that C deflects packets
to E, yielding path A,B,C,E,F
A
B
C
F
E
19
Availability Providers

• Most path diversity comes from the densely
  connected tier-1 ISPs.
• To simplify, what if just these ASes acted as
  availability providers (APs) to offer
  deflections?

20
ACR Overview

• Source attempts to set-up a secure channel using
  default path.
• If set-up fails, it can request alternate paths
  from its AP, probing until it finds a working
  path.
• Sources monitor path performance, requesting
  alternate paths if the current path is
  inadequate.

21
Threats Against ACR with APs

• Deployment gaps between AP and source or
  destination create attack opportunities.
• Large number of invalid paths from AP makes
  probing time unrealistic.
• Path performance attacks

22
Attacks Exploiting Deployment Gaps

• If a provider ISP is duped, it is possible that
  a stub AS will not be reachable by any path seen
  by the AP.

A
If U does not offer deflections, a malicious AS M
could fool U by announce Ds prefix, making it
completely unreachable by the availability
provider A.
U
D
M
23
Handling Deployment Gaps

• Dests Business preferences help destinations
  (only fellow customers can attack).
• Sources Paths to a limited number of core APs
  are easy to manage.
• Local filtering can provide significant benefit.
  As can identifying expected links based on
  well-known core topology.

24
Attacking Probing Efficiency

• With BGP, each malicious AS can introduce one bad
  path to its neighbors.
• Total of paths limited by an ASs of
  neighbors, (more likely peers providers).
• Claim
• It is non-trivial to introduce many attractive
  paths quickly, especially without getting noticed.

25
More Efficient Probing

• Base Shortest AS-Path
• Anomaly Detection
• Most paths are stable, keep with what has worked
  (e.g. PGBGP).
• Destination Hints
• Let destination sign distribute hints about
  its upstream connectivity. Forces attacker paths
  to be longer.

26
Monitoring for Path Performance Attacks

• Data serves as probes to avoid preferential
  treatments of probe packets.
• Tricky Attack
• Malicious AS makes path appear valid, then
  black-holes or degrades performance.

27
Path Performance Monitoring

• Solutions
• Have traffic that is robust to hiccups (e.g.
  non-realtime)
• Duplicate traffic over paths that are likely to
  be trust disjoint
• Use smart probing techniques to help avoid bad
  control plane paths.

28
Deployability

• No requirement for address registries,
  cryptographic hardware, ICANN-based PKI, or new
  routing software.
• Deflections can be implemented using IP-in-IP
  encapsulation and MPLS over IP, which already
  exists in routers today.
• Deflections also improve performance.

29
Dirty Laundry

• CIDR and sub-prefix hijacks
• (Answer Use /24s, which approximates flat
  routing)
• Datagram communication
• (Answer either run over long-term secure
  channel, or have data be the identifier, ala
  DNSSEC)

30
ACR Summary

• Secure interdomain routing proposals are
  heavy-weight, but still insufficient.
• If end-points set up secure channels, the
  routing infrastructure must only provide multiple
  paths to guarantee availability.
• This approach has highly attractive properties
  for incentivized deployment
