Graphical model software for machine learning

1
Graphical modelsoftware for machine learning

• Kevin Murphy
• University of British Columbia

December, 2005
2
Outline

• Discriminative models for iid data
• Beyond iid data conditional random fields
• Beyond supervised learning generative models
• Beyond optimization Bayesian models

3
Supervised learning as Bayesian inference
Training
Testing
?
?
Y1
Yn
YN
Y
Y
X1
Xn
XN
X
X
N
4
Supervised learning as optimization
Training
Testing
?
?
Y1
Yn
YN
Y
Y
X1
Xn
XN
X
X
N
5
Example logistic regression

• Let yn 2 1,,C be given by a softmax
• Maximize conditional log likelihood
• Max margin solution

6
Outline

• Discriminative models for iid data
• Beyond iid data conditional random fields
• Beyond supervised learning generative models
• Beyond optimization Bayesian models

7
1D chain CRFs for sequence labeling
A 1D conditional random field (CRF) is an
extension of logistic regressionto the case
where the output labels are sequences, yn 2
1,,Cm
Edge potential
Local evidence
?
?ij
Yn1
Yn2
Ynm
?i
Xn
8
2D Lattice CRFs for pixel labeling
A conditional randomfield (CRF) is a
discriminative modelof P(yx). The edge
potentials?ij are image dependent.
9
2D Lattice MRFs for pixel labeling
Local evidence
Potential function
Partition function
A Markov Random Field (MRF) is an
undirectedgraphical model. Here we model
correlation between pixel labels using
?ij(yi,yj). We also have a per-pixelgenerative
model of observations P(xiyi)
10
Tree-structured CRFs

• Used in parts-based object detection
• Yi is location of part i in image

nose
eyeR
eyeL
mouth
Fischler Elschlager, "The representation and
matching of pictorial structures,
PAMI73 Felzenszwalb Huttenlocher, "Pictorial
Structures for Object Recognition," IJCV05
11
General CRFs

• In general, the graph may have arbitrary
  structure
• eg for collective web page classification,nodesu
  rls, edgeshyperlinks
• The potentials are in general defined on cliques,
  not just edges

12
Factor graphs
Square nodes factors (potentials) Round nodes
random variables Graph structure bipartite
13
Potential functions

• For the local evidence, we can use a
  discriminative classifier (trained iid)
• For the edge compatibilities, we can use a
  maxent/ loglinear form, using pre-defined features

14
Restricted potential functions

• For some applications (esp in vision), we often
  use a Potts model of the form
• We can generalize this for ordered labels (eg
  discretization of continuous states)

15
(No Transcript)
16
Learning CRFs

• If the log likelihood is
• then the gradient is

Tied params
cliques
Gradient features expected features
17
Learning CRFs

• Given the gradient rd, one can find the global
  optimum using first or second order optimization
  methods, such as
• Conjugate gradient
• Limited memory BFGS
• Stochastic meta descent (SMD)?
• The bottleneck is computing the expected features
  needed for the gradient

18
Exact inference

• For 1D chains, one can compute P(yi,i1x)
  exactly in O(N K2) time using belief propagation
  (BP forwards backwards algorithm)
• For restricted potentials (eg ?ij?(? l)), one
  can do this in O(NK) time using FFT-like tricks
• This can be generalized to trees.

19
Sum-product vs max-product

• We use sum-product to compute marginal
  probabilities needed for learning
• We use max-product to find the most probable
  assignment (Viterbi decoding)
• We can also compute max-marginals

20
Complexity of exact inference
In general, the running time is ?(N Kw), where w
is the treewidthof the graph this is the size
of the maximal clique of the triangulatedgraph
(assuming an optimal elimination ordering). For
chains and trees, w 2. For n n lattices, w
O(n).
21
Approximate sum-product
Algorithm Potential (pairwise) Time Nnum nodes,K num states,I num iterations
BP(exact iff tree) General O(N K2 I)
BPFFT(exact iff tree) Restricted O(N K I)
Generalized BP General O(N K2c I)c cluster size
Gibbs General O(N K I)
Swendsen-Wang General O(N K I)
Mean field General O(N K I)
22
Approximate max-product
Algorithm Potential (pairwise) Time Nnum nodes,K num states,I num iterations
BP (exact iff tree) General O(N K2 I)
BPDT (exact iff tree) Restricted O(N K I)
Generalized BP General O(N K2c I)c cluster size
Graph-cuts(exact iff K2) Restricted O(N2 K I) ?
ICM (iterated conditional modes) General O(N K I)
SLS (stochastic local search) General O(N K I)
23
Learning intractable CRFs

• We can use approximate inference and hope the
  gradient is good enough.
• If we use max-product, we are doing Viterbi
  training (cf perceptron rule)
• Or we can use other techniques, such as pseudo
  likelihood, which does not need inference.

24
Pseudo-likelihood
25
Software for inference and learning in 1D CRFs

• Various packages
• Mallet (McCallum et al) Java
• Crf.sourceforge.net (Sarawagi, Cohen) Java
• My code matlab (just a toy, not integrated with
  BNT)
• Ben Taskar says he will soon release his Max
  Margin Markov net code (which uses LP for
  inference and QP for learning).
• Nothing standard, emphasis on NLP apps

26
Software for inference in general CRFs/ MRFs

• Max-product C code for GC, BP, TRP and ICM
  (for Lattice2) by Rick Szeliski et al
• A comparative study of energy minimization
  methods for MRFs, Rick Szeliksi, Ramin Zabih,
  Daniel Scharstein, Olga Veksler, Vladimir
  Kolmogorov, Aseem Agarwala, Marsall Tappen,
  Carsten Rother
• Sum-product for Gaussian MRFs GMRFlib, C code by
  Havard Rue (exact inference)
• Sum-product various other ad hoc pieces
• My matlab BP code (MRF2)
• Rivasseaus C code for BP, Gibbs, tree-sampling
  (factor graphs)
• Metlzers C code for BP, GBP, Gibbs, MF
  (Lattice2)

27
Software for learning general MRFs/CRFs

• Hardly any!
• Parises matlab code (approx gradient, pseudo
  likelihood, CD, etc)
• My matlab code (IPF, approx gradient just a toy
  not integrated with BNT)

28
Structure of ideal toolbox
Generator/GUI/file
train
testData
infer
decisionEngine
performance
decision
visualize
summarize
utilities
29
Structure of BNT
LeRay
Shan
Generator/GUI/file
GraphsCPDs
Cell array
BPJtree MCMC
EM StructuralEM
train
testData
NodeIds
VarElim
GraphsCPDs
Cell array
infer
JtreeVarElim
decisionEngine
policy
Array, Gaussian, samples
N1 (MAP)
visualize
summarize
LIMID
30
Outline

• Discriminative models for iid data
• Beyond iid data conditional random fields
• Beyond supervised learning generative models
• Beyond optimization Bayesian models

31
Unsupervised learning why?

• Labeling data is time-consuming.
• Often not clear what label to use.
• Complex objects often not describable with a
  single discrete label.
• Humans learn without labels.
• Want to discover novel patterns/ structure.

32
Unsupervised learning what?

• Clusters (eg GMM)
• Low dim manifolds (eg PCA)
• Graph structure (eg biology, social networks)
• Features (eg maxent models of language and
  texture)
• Objects (eg sprite models in vision)

33
Unsupervised learning of objects from video
Frey and Jojic Williams and Titsias et al
34
Unsupervised learning issues

• Objective function not as obvious as in
  supervised learning. Usually try to maximize
  likelihood (measure of data compression).
• Local minima (non convex objective).
• Uses inference as subroutine (can be slow no
  worse than discriminative learning)

35
Unsupervised learning how?

• Construct a generative model (eg a Bayes net).
• Perform inference.
• May have to use approximations such as maximum
  likelihood and BP.
• Cannot use max likelihood for model selection

36
A comparison of BN software
www.ai.mit.edu/murphyk/Software/Bayes/bnsoft.html
37
Popular BN software

• BNT (matlab)
• Intels PNL (C)
• Hugin (commercial)
• Netica (commercial)
• GMTk (free .exe from Jeff Bilmes)

38
Outline

• Discriminative models for iid data
• Beyond iid data conditional random fields
• Beyond supervised learning generative models
• Beyond optimization Bayesian models

39
Bayesian inference why?

• It is optimal.
• It can easily incorporate prior knowledge (esp.
  useful for small n, large p problems).
• It properly reports confidence in output (useful
  for combining estimates, and for risk-averse
  applications).
• It separates models from algorithms.

40
Bayesian inference how?

• Since we want to integrate, we cannot use
  max-product.
• Since the unknown parameters are continuous, we
  cannot use sum-product.
• But we can use EP (expectation propagation),
  which is similar to BP.
• We can also use variational inference.
• Or MCMC (eg Gibbs sampling).

41
General purposeBayesian software

• BUGS (Gibbs sampling)
• VIBES (variational message passing)
• Minka and Winns toolbox (infer.net)

42
Structure of ideal Bayesian toolbox
Generator/ GUI/ file
train
testData
infer
decisionEngine
performance
decision
visualize
summarize
utilities
