Active Queue Management

1
Active Queue Management
Rong Pan Cisco System EE384y Spring Quarter 2008
2
Outline

• Queue Management
• Drop as a way to feedback to TCP sources
• Part of a closed-loop
• Traditional Queue Management
• Drop Tail
• Problems
• Active Queue Management
• RED
• CHOKe
• AFD

3
Queue Management Drops/Marks- A Feedback
Mechanism To Regulate End TCP Hosts

• End hosts send TCP traffic -gt Queue size
• Network elements, switches/routers, generate
  drops/marks based on their queue sizes
• Drops/Marks regulation messages to end hosts
• TCP sources respond to drops/marks by cutting
  down their windows, i.e. sending rate

4
TCPQueue Management- A closed-loop control
system
C
W/R
_
q

?
N
?

_
0.5
-
p
Queue Management
Time Delay

1
5
Drop Tail- problems

• Lock out
• Full queue
• Bias against bursty traffic
• Global synchronization

6
Tail Drop Queue ManagementLock-Out
Max Queue Length
7
Tail Drop Queue Management Full-Queue

• Only drop packets when queue is full
• long steady-state delay

8
Bias Against Bursty Traffic
Max Queue Length
9
Tail Drop Queue ManagementGlobal Synchronization
Max Queue Length
10
Alternative Queue Management Schemes

• Drop from front on full queue
• Drop at random on full queue
• both solve the lock-out problem
• both have the full-queues problem

11
Active Queue ManagementGoals

• Solve tail-drop problems
• no lock-out behavior
• no full queue
• no bias against bursty flow
• no global synchronization
• Provide better QoS at network nodes
• low steady-state delay
• lower packet dropping

12
Random Early Detection (RED)
Arriving packet
AvgQsize gt Minth?
no
yes
Admit the new packet
AvgQsize gt Maxth?
no
yes
end
Drop the new packet
Admit packet with a probability p
end
end
13
RED Dropping Curve
1
Drop Probability
maxp
0
minth
maxth
Average Queue Size
14
Effectiveness of RED- Lock-Out Global
Synchronization

• Packets are randomly dropped
• Each flow has the same probability of being
  discarded

15
Effectiveness of RED- Full-Queue Bias against
bursty traffic

• Drop packets probabilistically in anticipation of
  congestion
• not when queue is full
• Use qavg to decide packet dropping probability
  allow instantaneous bursts

16
What QoS does RED Provide?

• Lower buffer delay good interactive service
• qavg is controlled to be small
• Given responsive flows packet dropping is
  reduced
• early congestion indication allows traffic to
  throttle back before congestion
• Given responsive flows fair bandwidth allocation

17
Bad News - unresponsive end hosts
18
Scheduling Queue Management

• What routers want to do?
• isolate unresponsive flows (e.g. UDP)
• provide Quality of Service to all users
• Two ways to do it
• scheduling algorithms
• e.g. FQ, CSFQ, SFQ
• queue management algorithms with fairness
  enhancement
• e.g. CHOKe, AFD, WRED

19
Active Queue Manament With Enhancement to Fairness
FIFO

• Approximate fair bandwidth allocation
• Provide isolation from unresponsive flows
• Be as simple as RED

20
RED
Arriving packet
AvgQsize gt Minth?
no
yes
Admit the new packet
AvgQsize gt Maxth?
no
yes
end
Drop the new packet
Admit packet with a probability p
end
end
21
Random Sampling from Queue
UDP flow

• A randomly chosen packet more likely from the
  unresponsive flow

• Adversary cant fool the system

22
Comparison of Flow ID

• Compare the flow id with the incoming packet
• more acurate
• Reduce the chance of dropping packets from a
  TCP-friendly flows.

23
Dropping Mechanism

• Drop packets (both incoming and matching samples
  )
• More arrival -gt More Drop
• Give users a disincentive to send more

24
Simulation Setup
D(1)
S(1)
10Mbps
S(2)
D(2)
10Mbps
m TCP
m TCP
Sources
Sinks
1Mbps
S(m)
D(m)
S(m1)
D(m1)
n UDP Sources
n UDP Sinks
S(mn)
D(mn)
25
Network Setup Parameters

• 32 TCP flows, 1 UDP flow
• All TCPs maximum window size 300
• All links have a propagation delay of 1ms
• FIFO buffer size 300 packets
• All packets sizes 1 KByte
• RED (minth,maxth) (100,200) packets

26
32 TCP, 1 UDP (one sample)
27
32 TCP, 5 UDP (5 samples)
28
How Many Samples to Take?
Maxth
minth
avg

• Different samples for different Qlenavg
• samples ? when Qlenavg close to minth
• samples? when Qlenavg close to maxth

29
32 TCP, 5 UDP (self-adjusting)
30
Analytical Model
discards from the queue
permeable tube with leakage
31
Fluid Analysis

• N the total number of packets in the buffer
• Li(t) the survival rate for flow i packets

Li(t)?t - Li(t ?t)?t ?i ?t Li(t)?t /N -
dLi(t)/dt ?i Li(t) N Li(0) ?i (1-pi
) Li(D) ?i (1-2pi )
32
Model vs Simulation- multiple TCPs and one UDP
1/(1e)
33
Fluid Model - Multiple samples

• Multiple samples are chosen

Li(t)?t - Li(t ?t)?t M?i ?t Li(t)?t /N -
dLi(t)/dt M?i Li(t) N Li(0) ?i (1-pi
)M Li(D) ?i (1-pi )M - M?i pi
34
Two Samples- multiple TCPs and one UDP
35
Two Samples- multiple TCPs and two UDP
36
What If We Use a Small Amount of State?
37
AFD Goal

• Approximate weighted bandwidth allocation
• Not only AQM, approximate WDRR scheduling
• Provide soft queues in addition to physical
  queues
• Keep the state requirement small
• Be simple to implement

38
AFD Algorithm Details (Basic Case Equal Share)
Di Drop Probability for Class i
Arriving Packets
Qlen
1-Di
Qref
Class i
Di
39
AFD Algorithm Details (General Case)
Di Drop Probability for Class i
Arriving Packets
Qlen
1-Di
Qref
Class i
Di
40
Not Per-Flow State
Fraction of flows

• State requirement on the order of of
  unresponsive flows
• Elephant Traps (developed jointly Stanford and
  Cisco)

41
AFD Solution Details

• Based on 3 simple mechanisms
• estimate per class arrival rate
• counting per class bytes over fixed intervals
  ( Ts )
• potential averaging over multiple intervals
• estimate deserved departure rate (so as to
  achieve the proper bandwidth allocation for each
  class)
• observation of queue length as measure of
  congestion
• perform selective dropping (pre-enqueue) to drive
  arrival rate to the desired departure rate

42
Mixed Trafficwith Different Levels of
Unresponsiveness
43
Drop Probabilities(note differential dropping)
44
Different Number of TCP Flows in Each Class
10 TCP Flows
Class 2
Class 1
5 TCP Flows
0
50
150
200
100
time
0
50
150
200
100
time
20 TCP Flows
15 TCP Flows
Class 4
Class 3
0
50
150
200
100
time
0
50
150
200
100
time
45
Different Class Throughput Comparison
46
Queue Length
47
Mfair
48
AFD Implementation Issues

• Monitor Arrival Rate
• Determine Drop Probability
• Maximize Link Utilization

49
Arrival Monitoring

• Keep a counter for each class
• Count the data arrivals (in bytes) of each class
  in 10ms interval arvi
• Arrival rate of each class is updated every 10ms
• mi mi(1-1/2c)arvi
• c determines the average window

50
Implementing the Drop Function

• If Mi ? Mfair then Di 0
• Otherwise, rewrite the drop function as
• Suppose we have predetermined drop levels, find
  the one such that Di Mi (Mi Mfair)

51
Implementing the Drop Function

• Drop levels are 1/32, 1/16, 3/32

• Suppose mi 100, mfair 62.0 gt Di 0.380,

52
AFD - Summary
Fairness
RED
Simplicity

• Equal share is approximated in a wide variety of
  settings
• The state requirement is limited

53
Summary

• Traditional Queue Management
• Drop Tail, Drop Front, Drop Random
• Problems lock-out, full queue, global
  synchronization, bias against bursty traffic
• Active Queue Management
• RED cant handle unresponsive flows
• CHOKe penalize unresponsive flows
• AFD provides approximate fairness with limited
  states
