Debugging Techniques

1
Debugging Techniques

• Annatala Wolf
• 222 Supplemental Lecture

2
Most of the art of programming is debugging

• Bugs are always present in large applications.
• The majority of a softwares life cycle is in the
  support phase, so debugging saves big money!

3
Bugs can be expensive and difficult to find
4
The Most Important Rule

• If youre lost or confused, randomly changing
  things around in code will not help
• You cannot fix the error if you dont know
  roughly where it is!
• Errors can only be caught and fixed by debugging
  in a systematic fashion

5
Fortunate News

• There are a lot of bugs in C that are extremely
  hard, or even impossible to find.
• I worked in industry for a year with a DoD
  contractor we spent all year looking for a
  three-year-old memory leak we never found
• However, Resolve/C prevents the
  worst-of-the-worst errors by limiting pointers
  to Kernels. To move objects around, we use
  instead (which is always safe).

6
Typical Debugging

• Usually, you will do debugging in an IDE
  (Integrated Development Environment) that has
  debug features like breakpoints (places you
  pause the program, and can run it line by
  line), watches (variables you track as the
  program runs), and other neat tools.
• There are also tools you can run separately as
  your code runs, i.e. a tool to find memory leaks
• You dont get this stuff in emacs the way we have
  it set up. ? So you must use strategy.

7
Real Programmers Use
xkcd.com
8
emacs Is Hard To Learn

• Regrettably, emacs is the only editor we can set
  up to work with Resolve/C in the UNIX system
  where we (securely) keep the code.

9
The Unix System

• Many students have no problems with coding, but
  using Unix, Solaris, and emacs proves challenging
  (and extremely annoying)
• Part of your job as a computer scientist will
  always involve working with unfamiliar systems
  that dont perform as expected, so youll have to
  get used to it
• The challenge is to learn only what you need to
  perform the tasks at hand

10
Basic Unix Commands

• cd directory
• change directories (use .. for previous
  directory, or for home directory)
• ls l
• long list of all files, including permissions,
  etc.
• cp source destination
• copy file (to move files, use mv instead)
• mkdir name
• make a new directory
• rm filename
• delete a file

11
Other Unix Commands

• less textfilename
• print the contents of a text file to the screen
• chmod 777 filename
• set a files permissions so it can be read, be
  written, and be executed by anyone (in case you
  cant access or execute a needed file, try this)
• rcpp-make
• compile all Resolve/C files in the current
  directory
• dos2unix textfilename
• convert \r to \n in a text file, so it works
  in Unix
• (use unix2dos for the opposite effect)

12
Unix Redirects

• If you successfully compile Example.cpp, it will
  make an executable file (one you can run) called
  Example
• To run Example, just type the name
• Example
• To redirect standard in to in.txt, add lt in.txt
  at the end
• Example lt in.txt
• To redirect standard out to out.txt, add gt
  out.txt
• Example gt out.txt
• To automatically overwrite out.txt if it
  exists, use gt!
• Example gt! out.txt
• To do this with both input and output, include
  both options
• Example lt in.txt gt! out.txt

13
Handout Clues

• Usually the Lab handout will contain all the
  information you need to navigate the UNIX system.
• If youre having trouble compiling or testing
  your code, look to the handout first
• If youre not certain what the requirements are
  for a correct implementation, the handout should
  give you a detailed description of the
  requirements
• Sometimes it may help to look at an old handout,
  such as the one from Closed Lab 1 (i.e., you
  wont be able to compile if you havent run
  getsetup)

14
Kinds of Errors

• There are many kinds of errors you may find in
  your code. Here are some well discuss
• Makefile Mischief
• Compile-Time Errors
• Type Errors (can be compile-time or runtime)
• Violated Assertions
• Program Crash
• Infinite Loop
• Unexpected Behavior

15
Makefile Mischief

• Makefile.rcpp is a small file the compiler
  creates any time you compile code. It tells the
  compiler which files are up to date, so it wont
  recompile things that havent changed.
• If you copy files to and from your account, the
  Makefile might become outdated. The compiler
  might seem to work, but changes arent being
  reflected. Or, you get odd linking errors.
• When in doubt, delete the makefile and recompile.
  This compiles everything fresh.

16
Reading Error Messages

• For any kind of error that produces an error
  message (syntax, violated assertion, or crash),
  the first strategy to fixing the error is to
  carefully examine the message.
• Always check the top of the error message and
  read down until you find something useful.
• Because of the way we use templates, there may be
  paragraphs of template code telling you what was
  instantiated where. You have to keep looking
  until you find the first thing that looks like a
  description of an error, rather than a template
  instantiation.

17
Compile-Time Errors

• Most compile-time errors are easy to catch, and
  easy to fix. You need to know how to do this by
  now, so dont expect more than 1/5 on a lab
  unless it at least compiles.
• Some errors may be masked by the fact that they
  dont cause a problem until later in your code.
  Example a missing brace may not be caught by the
  compiler until it notices code appearing in
  illegal places as a result later on.
• Take heart a compile-time error will always be
  found either at the location it is caught, or
  earlier. (For mysterious errors, check for
  matching braces and parentheses.)

18
Commenting Out Code

• One fast way to find compile-time errors in a
  crappy IDE like emacs is to comment code out. To
  do this, use // to turn lines of code into
  comments. If the error disappears, it must be in
  the sections you commented out!
• Make sure you comment out either single lines, or
  entire blocks (if you choose to comment out an
  opening brace, you have to comment out the block
  and closing brace and vice versa).
• If you comment out the body of a function, you
  may need to at least add a dummy return statement
  with an object of the correct type so that the
  function will compile.

19
Quick Error Finding

• If you comment code out, you should be able to
  isolate compile-time errors very quickly, since
  each time you do it you can halve the space where
  the error must be. This works with all
  compile-time errors (syntax and type errors).
• This method is called a binary search, and its
  fast! (Well discuss binary searches later.)
• You can use a similar strategy to correct syntax
  try several bits of code to figure out which
  works.

20
Type Errors

• These are usually caught at compile-time, but due
  to template use in C, its possible to see them
  at runtime in rare cases.
• Usually type error messages contain template crap
  galore. Scan from the top down carefully.
• Type mismatch errors will look something like
• cannot convert foo to bar in SomeFunction()
• bar expected where foo found
• no foo exists for type bar
• type mismatch from foo to bar.

21
Locating Type Errors

• Type errors happen when you try to use a variable
  of one type as though it is another type (a type
  mismatch), or try to use an operation that
  doesnt exist (maybe you called it off the wrong
  type, or typed the name wrong).
• If its a type mismatch, the message tells what
  two types caused the errorthe found type, and
  the one it expected to find.
• A type error should also have the exact location,
  within one line. If it refers to an error in an
  argument passed to an operation, look for the
  line the operation was called from, not the
  location of the operation it was calling.

22
Runtime Errors

• The call stack is the stack of operations that
  have been called while the program is running,
  which have not yet completed. This is printed
  out in some form for most runtime errors
• 1 main()
• 2 Recurse()
• 3 Recurse()
• 4 Helper()
• The bottom of the call stack is the place the
  error was caught. Here, an error was caught in
  Helper(). (That doesnt mean thats where the
  error actually is, but its a good place to
  start.)

23
Debugging Runtime Errors

• First strategy carefully read the error
• Second strategy use debug statements
• use them to isolate flow of control
• use them to peek at variables
• Third strategy write test code
• Isolate errors to an operation by writing code
  that tests only a single operation. Confirm each
  operation works, one at a time.

24
Using Debug Statements

• Debug statements can reveal two things where you
  are in code, and the value of a variable at a
  given point. To use them, put something like
  this in code
• debug (Loop in foo(), x value ltlt x)
• When the debug line runs, it outputs to standard
  error (the monitor, by default), similar to the
  code below
• object Character_OStream error
• error.Open_External()
• error ltlt Loop in foo(), x value ltlt x
• error.Close_External()

25
How Debug Works

• Debug statements are useful because you can use
  them even if standard out is redirected. Also,
  you can compile code so it will remove them from
  the finished product.
• To use them properly, you need to put in
  information about what part of code is running.
  This lets you isolate the flow-of-control (the
  order in which statements run, and which
  statements run at all).

26
Quick Debugging

• You can also use debug to peek at variables that
  can be sent to output (the five basic Resolve
  data types).
• Just be sure you include where the debug
  statement is in your code, otherwise you wont be
  able to tell two debug statements apart.
• Like commenting out code, you can narrow down
  flow-of-control issues very rapidly (halving the
  possible location of a flow problem each time you
  test).

27
Debugging Collections

• If youre the client of a collection object, you
  may want to see whats inside it.
• It can be extremely helpful to create a helper
  operation that outputs (using debug statements)
  an entire collection you want to look at, while
  preserving it. (Note that you cant simply send,
  e.g., a Set object to output.)
• You can also do this inside a Kernel to peek at
  the fields of self, but it can be tricky to not
  change the state of the Representation if those
  fields include collections or complex objects.

28
Violated Assertions

• Violated assertions are good! They are among the
  easiest errors to locate and fix.
• Violated assertions tell you exactly what
  requires clause you broke, and which operation
  you were in when you made the bad call.
• The only time violated assertions are not easy to
  fix is when the underlying error is a logical
  error from something you did to screw up the
  Representation of a Kernel. In this case, the
  error might be that you screwed things up a long
  time ago, and only see the problem now.

29
Violated Assertion Sample

• 0 main
• 1 Some_Stuff()
• 2 Do_Stuff(Partial_Map_Text_To_Text)
• 3 Textoperator(Integer)
• Violated assertion at
• File /class/sce/rcpp-2007/RESOLVE_Foundation/Text
  /Text.cpp
• Line 526
• Operation operator
• Violated assertion is
• pos lt self

general location the bad call was made
operation whose contract we violated like a
red-headed stepchild from Mayberry
where Texts assertion is located not useful
to us
the part of the contract for Texts we
violated (this description is what was supposed
to be true, but was false)
30
Wait, I didnt write that!

• In Lab 4, we write the Kernel operation Define()
  for you, and you write the rest.
• Then students say Why did Define() trip an
  assertion? Didnt you guys write that?
• The reason this can happen is the checker for
  Define() will call your Is_Defined() to do its
  work! So if it breaks, its probably breaking in
  your Is_Defined(), or in a local operation it
  calls.
• Or, maybe you messed up the Representation.

31
Other Code Confusion

• Some of the test code we give you for Kernels
  will feature operations like Put_To(), to output
  the collection. But if your labs not already
  perfect, Put_To() might break.
• Why? Think about how we had to write Put_To() as
  a client of Set. It would need to call
  constructor, Remove_Any(x), Size(), Add(x), and
  the checker for Add(x) will call
  Is_Member(x) and there may even be local
  operations called by some of these.

32
Changing Concrete State

• When white-box testing a Kernel (using what you
  know about how the Kernel is implemented to
  design smarter test cases), be extra careful.
  Even if Put_To() works and preserves the object,
  it may change how the object is represented
  inside, so you might see unexpected results.
• Just think about what Put_To() must do as a
  client of your object, to figure it out.

33
Program Crash

• A program can crash for other reasons
• division by zero error
• I/O error
• ice cream dumped onto motherboard error
• species-based hatred for ugly-bag-of-mostly-water
• Look at the error carefully. Use debug
  statements to figure out when and where the crash
  happens.
• When and where is more important than why!
• some errors can be fixed even if you dont
  understand why its an error welcome to the art
  of programming ?

34
Infinite Loop

• Does your computer seem to have frozen? You
  probably have an infinite while() loop.
• For recursion, you get a heap overflow or
  segmentation fault error instead (because you
  will use up the memory in the program stack).
• The cure check your while loops to make sure the
  change condition is occurring
• Use debug statements to find the while loop that
  isnt stopping
• Use debug statements to check loop conditions

35
Unexpected Behavior

• This is usually the hardest problem to fix, as
  you get no error message the only error is bad
  output or bad results. The best approach is to
  debug specific cases.
• Sometimes you end up seeing a violated assertion
  during testing, but it has to do with something
  unrelated you did wrong a long time ago. The
  only cure for this is to test each operation
  independently of the others.
• In Kernels this is tricky, but still possible

36
Instructor and Grader

• Dont hesitate to ask us if youre lost.
• If you can figure it out yourself, though, youll
  probably do it a lot quicker than we can, and
  youll improve your ability to find errors.
• If you have a general problem, include your code
  so I can look at it. (Id prefer it included as
  a plain, attached text file in email.)
• If you have a specific error, also send me the
  error exactly as it appears (and the test case,
  for runtime errors). I can teach you to read it
  so you will learn more from the experience.

37
Summary

• Debugging is essential to programming. Most
  systems have more debugging options than what you
  must use. I empathize with you.
• However, with debug statements and comments there
  is literally no Resolve/C error in this class
  that you cant isolate and fix.
• When in doubt, dont guess. Guessing makes
  finding errors an intractable problem. Use
  systematic methods to find the errors instead.
• Dont be afraid to ask us (or your fellow
  classmates!) for debugging help.
