The Ecological Effects of Endocrine Disruption Dr' David Walker University of Arizona

1
The Ecological Effects of Endocrine
DisruptionDr. David WalkerUniversity of Arizona
David Walker1, Nick Paretti2, Gail Cordy2,
Timothy S. Gross3, Edward T. Furlong4, Dana W.
Kolpin5, and Dennis McIntosh6 1 University of
Arizona, Environmental Research Laboratory, 2601
E. Airport Dr., Tucson, AZ 85706
dwalker_at_ag.arizona.edu 2 USGS., WRD, 520 N. Park
Ave, Suite 221, Tucson, AZ 85719
nvp_at_email.arizona.edu 3 USGS-Florida Caribbean
Science Center, 7920 NW 71st St., Gainesville
Florida, 32653 tim_s_gross_at_usgs.gov 4 USGS,
National Water Quality Laboratory, Denver Federal
Center, P.O. Box 25046, MS 407, Lakewood, CO
80225-0046 efurlong_at_usgs.gov 5 USGS, WRD, P.O.
Box 1230, Iowa City, IA 52240 dwkolpin_at_usgs.gov 6
Delaware State University, 1200 N. DuPont Highway
Dover, DE 19901 dmcintosh_at_desu.edu
2
For Our Purposes

• An endocrine disruptor is a synthetic
  (anthropogenic) chemical that when absorbed into
  the body mimics, blocks, or otherwise alters
  hormone level, function, or binding and
  subsequently disrupts normal bodily functions
  including behavioral and/or strictly physiologic
  responses.

3
(No Transcript)
4
Aquatic Ecology and Endocrine Disruption

• An individual organisms ability to better-exploit
  a resource (or group of resources) in the face of
  environmental stress and inter-specific
  competition, coupled with conservation of the
  genetic material enabling this exploitation, is
  what drives speciation.

5

• Genetic conservation of traits is initiated, and
  sustained by, subtle behavioral cues for mating,
  spawning, aggression, territoriality, avoidance,
  etc.
• Any impairment of these behavioral cues or
  manifestation into physiological or morphological
  changes has the capability to stunt speciation by
  lowering fertility and fecundity.

6
Endocrine Disrupting Compounds

• FAR more than what can be included in this
  presentation.
• By the time breakdown products and metabolites
  are added to the mix, iterations become
  astronomical.

7
Just a Few Examples by Use Category

• Detergent Metabolites
• Fire/Flame Retardants
• Fragrances/Flavors
• Fuels/PAHs
• Herbicides/Insecticides
• Household Wastewater Compounds
• Non-Prescription Drugs
• Plasticizers/Antioxidants
• Prescription Drugs
• Steroids

8

• At the landscape scale, those compounds known to
  be powerful EDCs, but are not
  environmentally-persistent, exert less of an
  effect than those persistent, but relatively
  weaker, compounds.

9
Quantification and Research Design Issues One
Size Does Not Fit All
Genetic
Mechanistic Understanding
Biochemical
Physiological
Histopathological
Behavioral
Immunological
Reproductive
Bioenergetic
Assemblages
Populations
Ecological Significance
10
Observational versus Controlled Studies

• True control and replication is not possible in
  the field.
• Laboratory studies with control and replication
  give up some ecological significance.

11
Exposure and Causation

• Several studies have examined the effect of one
  or a very few EDCs on the physiological response
  of an organism.
• The vast magnitude of compounds in a matrix makes
  assumptions about individual compounds difficult
  to ascertain.
• Non-monotonic dose-response curves

12

• With new and emerging contaminants found almost
  on a daily basis, making assumptions about
  exposure and physiologic response must always
  carry the caveat of the compounds we analyzed
  for

13
Grab, Composite, or Integrated Samples?

• Problems associated with not knowing long-term
  exposure to fish or other organisms.

14
Passive Organic Chemical Integrative Sampler
(POCIS) and/or Semi-Permeable Membrane Devices
(SPMDs aka fatbags)
15

• Of all the tools at our disposal to study
  complex environmental issues in aquatic
  ecosystems, a sound understanding of ecological
  principles as they pertain to these ecosystems is
  the most essential.

16
Quantifying Endocrine Disruption in a Threatened
and Endangered Fish Species
17
(No Transcript)
18

• Unlike semi-arid or north-temperate regions,
  effluent-dependent waters (EDWs) in arid
  regions usually contain 100 effluent year-round.

19
The Santa Cruz River Near Tucson, Arizona

• Flows from Mexico near Nogales, Sonora northward
  to Tucson, Arizona.
• The only sections with flowing water are those
  due to discharge from WWTPs.

20
(No Transcript)
21
Roger Road WWTP

• Built in 1951.
• Treated effluent is discharged into the Santa
  Cruz River or diverted into the citys reclaimed
  water system.
• Treats the wastewater generated by a population
  of about 419,000.
• A capacity of 41 mgd and treated an average of 38
  mgd from 2004 to 2005.
• Produces secondarily-treated wastewater

22
Tucson
Santa Cruz River
Roger Road WWTP
23
(No Transcript)
24
This Study

• Laboratory study with controls, replicates, and
  randomization.
• Use fish native to the region (largely
  pollution-tolerant).
• Framework or foundation for refinement of future
  studies.
• Varying doses of effluent (treatments).
• Concentrate on long-term, persistent compounds.

25
Bonytail Chub (Gila elegans)
26
Control
Control
Treatment
Treatment
27
Water temperature maintained between 25-29o
C. Photoperiod was maintained at 12 hours of
light and dark
28
(No Transcript)
29
(No Transcript)
30
Treatment/Dosages

• Fish in raceways exposed for 3 months per
  treatment
• 1st treatment 1/3 by volume treated ww and 2/3
  water treated by RO
• 2nd treatment 2/3 by volume treated ww and 1/3
  water treated by RO
• 3rd treatment full strength treated ww

31
Results
32
(No Transcript)
33
(No Transcript)
34
Males - Overall
17ß-Estradiol Control (n 6) 217.3 Treatment (n
13) 547.4
11-ketotestosterone Control (n 6)
820.8 Treatment (n 13) 473.5
Vitellogenin Control (n 6) 0.09 Treatment (n
13) 0.32
35
Females - Overall
11-ketotestosterone Control (n 54)
591.3 Treatment (n 47) 530.4
17ß-Estradiol Control (n 54) 568.2 Treatment
(n 47) 403.7
Vitellogenin Control (n 54) 0.18 Treatment (n
47) 0.18
36
(No Transcript)
37
(No Transcript)
38
Synergistic Effects

• Ratios of primary male and female sex hormones,
  in undisturbed populations would be expected to
  have an inverse relationship i.e. as one
  increased, the other would decrease.
• We could therefore assume that major deviations
  from this inverse relationship between male and
  female primary sex hormones, could be attributed
  to impairment.

39
Control Males
Treatment Males
40
Control Females
Treatment Females
41

• Synergism, feedback mechanisms, and non-linearity
  of bio-markers makes data reduction necessary to
  determine trends.
• Ordination is a good statistical tool but still
  assumes some degree of linear correlation as
  would occur with a typical dose-response curve.

42
Males
43
Females
44
Summary

• Significant hormonal impairment of both sexes, as
  compared to controls, at very low concentration
  of compounds.
• This impairment could never have been determined
  in a field study.
• Commonly-used parametric analyses are often
  inadequate in determining impairment.

45
Summary (cont)

• Determination of either hormonal impairment or
  endocrine disruption requires using phased
  biomarkers.
• Phase 1 Aromatase/GnRH
• Phase 2 GtH I, GtH II
• Phase 3 Sex hormones
• Phase 4 Protein development (vtg, oocyte,
  spermiation)
• Phase 5 Intersex

46
Current and Future Research

• Fertility/fecundity and sex ratio/development of
  F2 generation.
• Behavior.
• Treatments using streambed sediment from affected
  EDWs.

47

• This study is highly representative of the
  biological effect of endocrine-disrupting
  compounds at the landscape scale.

48
Questions?
