CPL, Policies, Features, FET

1
CPL, Policies, Features, FET

• Jacques Sincennes

2
Overview

• Feature service enhancement through
  subscription to added functionality.
• CPL allows users to customize the service via
  call setup instructions.
• FET target the specification of telephone
  systems, the definition of features, and user
  customization of the service on top.

3
CPL in a nutshell

• CPL permits to customize the SIP/Proxy server by
  instructing it how to react under specific
  circumstances, during call setup.
• It is designed to minimize the risks of
  misbehaviors caused by erroneous scripts (e.g. by
  forbidding recursion) and claims to be intended
  for general users (as opposed to designers).

4
CPL-Driven System
User
CPL SIP/Proxy Server
Network
5
CPL Mode of Operation

• intercept INVITE message
• incoming and outgoing
• follow decision tree, based on message and/or
  environment values
• address/time/priority/string switches
• execute action
• proxy/redirect/reject
• optionally handle action response
• proxy -gt busy no-answer

6
CPL Locations

• CPL provides means of managing the list of target
• addresses through
• Static Location
• statically specifying an address
• Registration Lookup
• fetch the current user's address
• Source Lookup
• (dynamically) obtain addresses

7
Address- and Time-Switched Features

• Speed Call (address proxying)
• e.g. invite(12) -gt invite(555-1212)
• Outgoing Call Screening (address rejection)
• e.g. invite(1-976-555-1212) -gt reject
• Incoming Call Screening (address rejection)
• e.g. invite(1-800-salesman) -gt reject
• Do Not Disturb (timely rejection)
• e.g. time(lunch) -gt reject("Gone to Lunch")
• Night Service (timely proxying)
• e.g. time(day) -gt invite(01) time(night) -gt
  invite(02)

8
CPL Location Manipulations

• Call Forward on Busy
• proxy -gt busy -gt location (ForwardToTel) -gt proxy

• Call Forward
• location (ForwardToTel) -gt proxy
• Hunt Groups
• location (SetOfNumbersToForwardTo) -gt proxy
  (orderingsequential, timeout)
• Call Forking
• location (SetOfNumbersToForwardTo) -gt proxy
  (orderingparallel)

9
CPL Caveats

• Location
• sensitive lookups, storage
• Presence
• location and availability switches
• In-Call Processing
• Administrative operations

10
FET In a nutshell

• FET are lower level than CPL they aim at dealing
  with all system operations. Therefore, all of the
  current CPL functionality should be implementable
  by FET.
• Not unlike CPL, FET permit to customize the
  SIP/Proxy server by instructing it how to react
  this holds for call setup in particular, and for
  any other events in general.

11
FET-Driven system

• FET are executed as (or by) agents, and would
  share a similar view of the system to that of
  CPL.

User
FET SIP/Proxy Server
Network
12
FET Mode of Operation

• FET describe how the system reacts to the
  presence of events on the tuple-space
• FET of Basic Service and Features are used to
  define users policies
• User Agents implement the user's policies
• lookup the tuple-space for events related to user
• execute the first FET that applies
• repeat until no more event concerns user

13
Feature Execution Tree
Pre-Cdn
Action
Pre-Cdn
Action
Post-Cdn
14
FET Format
feature(Parameters, fet(Pre-Condition,
Action, Post-Condition) ).
caller goes off-hook (to initiate a call) and
gets dial-tone basic( Self, fet( status(Self,
idle), action(Self, off_hook), status(Self,
dial_tone), not(status(Self, idle)),
not(action(Self, off_hook)) ) ).
15
FET of Features

• call_Forward(Self, From, To,
• fet(event(invite(From, Redirector, Self)),
• event(invite(From, Self, To)),
• not(event(invite(From, Redirector, Self)))
  )).
• call_Screening(Source, Destination,
• fet(event(invite(Source, Redirector,
  Destination)),
• event(busy(Destination, Source)),
• not(event(invite(Source, Redirector,
  Destination))))).

16
Policies using FET

• time_period(0) ENTERPRISE forbids "luigi" to
  call "jack"
• policy(enterprise, FET) -
• time_period(0),
• call_Screening(luigi, jack, FET).
• time_period(1) "jack" forwards all incoming
  calls to "ruoshan"
• policy(jack, FET) -
• time_period(1),
• call_Forward(jack, _From, ruoshan, FET).

17
Other Actors The enterprise, group and other
entities may exist in the system as user's agents
do, with varied priorities. System data FET has
access to system data and is not limited to
static data provided in the user's policy.
Furthermore, it can also store data for later use
(e.g. redial, recall). FET Caveats Recursion Due
to its mode of operation, FET is sensitive to
loops.
