Simple Multioperator Contesting subtitle: More POINTS for CADXA

1
(No Transcript)
2
Increasing CADXA Contest Points

• Thru Simple Multi-Operator Participation
•
  by Bob Epstein K8IA
• CADXA Contest Cheerleader

3
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)Profile of a successful
contester!

4
Simple Multi-Operator ContestingWhat This
Presentation Isnt

• It isn't a program designed for the top tier
  contesters in the  club.
• It isn't a technical talk.
• It isn't a program focusing on BIG stations.

5
Simple Multi-Operator ContestingWhat This
Presentation Is

• The main focus of the program will be to attempt
  to  interest the occasional/average club contest
  participant and Dxers  in increasing his effort
  to gain the club more points in Club
  Competition.

6
Simple Multi-Operator ContestingWhat This
Presentation Is

• Simple Multi-Op station configurations will be
  covered, as well  as ways for the single-op
  participant to "step it up".
• More sophisticated  configurations (Multi-Two,
  for example) will be looked a as well.

7
Simple Multi-Operator ContestingWhat This
Presentation Is

• Station owners will be encouraged to invite
  others to  participate in the contest fun as
  multi-op entities. Two CADXA station owners  have
  already indicated they will do this for CQWW SSB.
  Hopefully others will  follow.

8
Simple Multi-Operator ContestingWhat This
Presentation Is

• Contest topics to be covered include rigs,
  antennas,  switching, interfaces, contest
  software, station ergonomics, operating
  techniques, "tricks", experiments etc

9
Simple Multi-operator ContestingCONTESTS!

10
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• But..its NOT just all about points
• Its about HAVING FUN!
• Its about SHARPENING OPERATOR SKILLS
• Its about TESTING STATION EFFICIENCY

11
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• AND, Its about contributing to the CADXA Club
  Score!

12
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• CQWW Single Op Entry Categories (HP, LP, QRP)
• Single Op All Band Unassisted SOAB
• Single Op All Band Assisted SOAB (A)
• Single Op, Single Band (Assisted or Unassisted)

13
Simple Multi-Operator Contesting CQWW Multi-Op
Entry Categories

• Multi-Op One Xmtr aka Multi-Single (M-S)
• Multi-Op Two Xmtr aka Multi-Two (M-2)
• Multi-Op Multi Xmtr aka Multi Multi (M-M)

14
Simple Multi-Operator Contesting

• For this presentation, we will concentrate on
  the Multi-Op entry categories.
• Why?
• Because it has the potential to get CADXA more
  POINTS and generate more member FUN!

15
History of CADXA Club ScoresCQWW DX Contest

• 2002 48th Place of 56 total clubs
• 2003 14th Place of 47 total clubs
• 2004 18th Place of 47 total clubs
• 2005 7th Place of 49 total clubs
• 2006 15th Place of 60 total clubs
• 2007 16th Place of 52 total clubs
• VOODUDES are Huge Contributors

16
For 2008 CQWW Contest we need more CADXA
participation, because

• The share from 3X5A will be less (2/7), as there
  may only be 2 CADXA ops going there, AA7A and
  K5VT.

17
So What Do We Do?

• We can select Entry Categories that promote more
  points per hour operated. For example, All-Band
  instead of Single Band.
• We can extend casual All-Band entries to Multi-Op
  and more hrs.

18
Multi-Op Scenario 1

• Suppose Paul, W8AEF really wants to contribute to
  the club score but cannot put in a full-time
  operation that weekend.
• What does Paul do?

19
Multi-Op Scenario 1

• He invites some other people over to operate a
  Multi-Op category.
• And he has!!

20
Multi-Op Scenario 1

• Pauls team will operate MOST (Multi-Op, Single
  Xmtr) in CQWW DX SSB Contest!
• And CADXA score will benefit!

21
Multi-Op Scenario 2

• What if K8IA and N7RQ (aka N7AP) plan to do a M-2
  (aka Multi Two) Multi-Op Two Xmtr entry, but
  cant efficiently cover both positions all
  weekend?
• What do they do?

22
Multi-Op Scenario 2

• They invite others to operate
• And they have!
• And CADXA score will benefit

23
Simple Multi-operator Contesting Multi-Single
Rules - CQWW

• 1) Only one transmitter and one band permitted
  during any 10-minute period.
• ExceptionOneand only oneother band maybe used
  during any 10-minute period ifand only ifthe
  station worked is a new multiplier.

24
Simple Multi-operator Contesting Multi-Single
Rules - CQWW

• 2) Ten-minute periods aredefined as starting
  with the first logged QSO on a band.
• 3) Logs found in violationof the 10-minute rule
  will automaticallybe reclassified as M2.

25
Simple Multi-operator Contesting Multi-Single
Rules - CQWW

• 4) If electronic loggingis used (Cabrillo), for
  each QSOthe run transmitter or multiplier
  transmitter must be indicated in the log.
• (Logging software will indicate this)

26
Simple Multi-operator Contesting Multi-Two Rules
- CQWW

• 1) A maximum of two transmitted signals at
  anytime on different bands. Both transmitters may
  work any and all stations. A station may only be
  worked once per band regardless of which
  transmitter is used.

27
Simple Multi-operator Contesting Multi-Two Rules
- CQWW

• 2) Each transmitter may make amaximum of 8 band
  changes in any clock hour (00 through 59
  minutes).
• (Example 20m to 40m to 20m are two band changes)

28
Simple Multi-operator Contesting Multi-Two Rules
- CQWW

• 3) Each of the two transmittersused must keep a
  separate chronological log for the entire contest
  period,or if electronic logging is used, the
  electroniclog submittal (Cabrillo) must indicate
  which transmitter made each QSO.

29
Simple Multi-operator Contesting Multi-Multi
Rules - CQWW

• No limit to transmitters, but only one signal and
  running station allowed per band.

30
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• Reasons for entering Multi-Operator categories
• You are allowed to use packet spots, so your
  multipliers will potentially be much greater
• You can share the operating, greatly reducing
  individual operator fatigue

31
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• Reasons for entering Multi-Operator categories
• You can feel part of a team!
• This all has the potential for more POINTS for
  CADXA

32
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• The simplest form of multi-op single xmtr
  contesting
• Two or more operators sharing a normally
  single-op configured station.
• A step up, would be one person operating and
  another feeding the Band Map listening to another
  band.

33
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• The next step up of multi-op single xmtr
  contesting
• Two radios, one running stations and the other
  then designated the Multiplier station.

34
Simple Multi-operator Contesting(Subtitle More
POINTS for CADXA)

• The most typical Multi-Single is
• One radio as Run station, one radio as Mult
  station.

35
Simple Multi-operator Contesting(Typical
Multi-Single Stations)

36
Simple Multi-operator Contesting(Typical
Multi-Single Stations)

37
Simple Multi-operator Contesting(Typical
Multi-Single Stations)

38
Contest Radios
39
Contest RadiosCan Be Anything..

• Ability to Interface with computer/logging
  program/audio/keying
• Has sufficient receiver specs to handle madness
  of big contest signals

40
Contest AntennasCan Be Anything..
41
Contest Antenna Can Be Anything..almost -)
42
Lets quickly look at some contesters antennas
43
Some Contest Stations are LargeHC8N
44
Some Contest Stations are LargePJ2T
45
Some Contest Stations are LargeW3LPL
46
Some Contest Stations are LargeK3LR
47
Some Contest Stations are LargeKC1XX
48
Some Contest Stations are LargeW0SD
49
Some Contest Stations are LargeVY2ZM
50
Some Contest Stations are LargeKH7X
51
Some Contest Stations are LargeW0AIH
52
Some Contest Stations are LargeN5TW
53
Some Contest Stations are LargeWB9Z
54
Some Contest Stations are LargeW5KFT
55
Some Contest Stations are LargeVE6JY
56
Some Contest Stations are LargeJL8GFB
57
Some Contest Stations are almost LargeAB5K
58
Some Contest Stations are almost LargeW6NL
59
Some Contest Stations are almost LargeES5TV
60
Some Contest Stations are almost LargeFY5KE
61
Some Contest Stations are almost LargeN5CQ
62
Some Contest Stations are almost LargeZS4TX
63
Some Contest Stations are almost LargeK7IR
64
Some Contest Stations are AverageK8IA
65
Some Contest Stations are SmallKG8V
66
Some Contest Stations are Small
67
Bandpass Filters and Coax StubsUsually essential
for multi-op multi-rig

• Why use?
• To reduce harmonic responses, phase noise, hash
  etc, allowing two or more radios/bands to be used
  at one time.
• To protect the off-band receiver from overload.

68
Bandpass Filters

• Commercial Offerings
• W3NQN Bandpass Filters

69
Bandpass Filters

• W3NQN BP Filters (continued)

70
Bandpass Filters

• Dunestar (N7EA) BP Filters

71
Bandpass Filters

• Dunestar (N7EA) BP Filters (contd)

72
Bandpass Filters

• ICE Products BP Filters (contd)

73
Bandpass Filters Where do they go?

• Bandpass filters, being mostly 200w rated units,
  are installed at the output of the HF radio
  before your amp and antenna.
• They can be manually selected or automatically
  switched via a band decoder attached to your
  radio.

74
Bandpass Filters What rejection can you
get?2nd Harmonic Attenuation (dB)(K0TO
measurements)
75
Bandpass Filters What rejection can you
get?Sub-Harmonic Attenuation (dB)(K0TO
measurements)
76
Coaxial Stub Filters What Are They and What You
Get?

• Coaxial cable can be carefully trimmed to make
  stubs that provide filtering affect at one or
  more frequency ranges.
• Typically, they are cut for ¼ wave (shorted) or ½
  wave (open) lengths and will attain approx 25-30
  db attenuation depending on configuration.

77
Coaxial Stub Filters Where can you find more
info?

• A real good reference on Coaxial Stubs is a book
  by W2VJN Managing Interstation Interference
  Coaxial Stubs and Filters, available thru INRAD.

78
Coaxial Stub Filters Where can you find more
info?
79
Antenna Switching

• Some simple, and some not so simple, multi-op
  stations use manual switching for the antennas.

80
Antenna SwitchingW9RE

81
Antenna Switching 2 radios

• One way A WX0B Six-Pak or Equivalent. This
  device routes any antenna to any of two radios.

82
W4RM 3 station Multi-Two
83
W4RM Run Station 1
84
W4RM Multiplier Station
85
W4RM Run Station 2
86
W4RM Antennas
87
K8LX Multi-Two
88
K8LX
89
K8IA/N7RQ 2 station Multi-1
90
K8IA/N7RQ 2 station Multi-1Position 1
91
K8IA/N7RQ 2 station Multi-1Position 2
92
Antenna Experiments (2008)The Beginning
93
Antenna Experiments (2008)Step One
94
Antennas in Different DirectionsRotator
Indicator Solution
95
Antenna Experiments (2008)Step Two
96
Minimal Functions of Contest Software

• Interface with your Radio (band, mode, freq, send
  cw, transfer audio)
• Log your Qsos correctly (time, date, callsign,
  exchange etc)
• Track your Multipliers, Dupes, Score
• Have a Band Map
• Create a Cabrillo file

97
Free real Contest Software

• N1MM Logger -Free, Well supported, highly
  featured, top notch contest program.
  http//n1mm.com
• CT for Windows Free. Simplified windows
  version of old dos CT. Limited in features and
  support. www.k1ea.com/

98
For Purchase real Contest Software

• Win-Test (64) Very well done software with all
  necessary features and great support.
  www.win-test.com
• WriteLog (30) Very stable and near full
  featured. Support has deteriorated.
  http//www.writelog.com/

99
Score Reporting

• Scores are reported to the sponsor via submission
  of your log in a formatted text file called a
  Cabrillo file.
• You can change the Cabrillo file via a text
  editor such as Notepad. Do NOT use a word
  processor.

100
Score Reporting

• The MOST important items in the Cabrillo header
  are your callsign and the CLUB NAME.
• Do NOT use CADXA in the header. It will pass CQ
  log checking robots OK but not ARRL. We lost
  points in 2008.
• Use Central Arizona DX Assn

101
Score Reporting

• START-OF-LOG 2.0
• ARRL-SECTION AZ
• CALLSIGN N7RQ
• CLUB Central Arizona DX Assn
• CONTEST CQ-WW-SSB
• CATEGORY MULTI-ONE ALL HIGH SSB
• CLAIMED-SCORE 1100294
• OPERATORS N7RQ K8IA

102
Before the Contest

• Update your Logging Program with latest Country
  file and Super Check Partial file.
• Get the computers networked properly
• Make some practice qsos Make sure logging pgm
  is working ok and controls radio
• Sync time on both computers
• Study propagation reports

103
Kurt Mudgeon Contest Operating Tips(credits to
K3ZO, K2YWE, K8LX and several others)The Kurt
Mudgeon Contest Team
104
Kurt Mudgeon Contest Operating TipsPhone Contests

• Use conventional or unmistakable phonetics
• Aristocratic Punctuality is poor phonetics for
  AP
• Maintain a friendly sense of urgency in your
  QSOs
• Chattiness will slow your rate and lose you
  contacts.

105
Kurt Mudgeon Contest Operating TipsPhone Contests

• Do not be intimidated by stations talking fast or
  unintelligibly.
• Firmly ask until you get all the exchange info.
  Use again?
• It is usually better to ask for one piece of
  missing info at a time.

106
Kurt Mudgeon Contest Operating TipsCW Contests

• Dont let your code speed keep you from enjoying
  CW contests
• Do not be intimidated by stations too fast for
  you to copy.
• Start with the slower stations higher in the
  band.
• Don't worry if you have to hear a call several
  times to get it.
• As the contest goes on you will improve!

107
Kurt Mudgeon Contest Operating TipsCW Contests

• Dont be shy about sending QRS.
• Call CQ high in the band at a speed comfortable
  for you.
• Most stations will slow down to your speed.
• Try moving frequency a bit if you cant seem to
  be heard.
• Often receiver bandwidths in a crowded band are
  set very narrow.

108
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• SP rates can be high early in the contest
• Everyone is new for you.
• You can quickly hop from station to station with
  little fear of Dupes.
• You are usually safe to call first and fill-in
  the call at the QSO end

109
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• Work bands that may close first. Move with
  propagation.
• This often means 10-15-20 in a.m. then 40-80-160
  later on.
• Try running rather than chasing spots when high
  bands are open.
• Go after the Mults when 20 has slowed, but 40
  hasn't opened yet

110
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• Verify the callsign of the station you're working
  and log it correctly
• Exploit any antenna/propagation advantages you
  may have.
• Call no more than 3 tries and then move on. Come
  back later.
• Change bands frequently

111
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• Dont get ego driven in pileups. The idea is to
  make contest points, not call endlessly in a
  no-win mess. ( My 3 call rule).

112
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• When using packet be aware of call accuracy.
  Verify before QSY!
• When using packet watch WHO is spotting WHOM.
  (Propagation driven).
• When using packet do not bother calling a
  semi-rare station that has just been spotted.
  WAIT.
• Mults mean a lot, esp at end of contest.

113
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• Dont waste your time calling a known big gun DX
  station that is weak unless you, too, are a big
  gun.
• Use the widest IF bandwidth you can stand
• Less chance to miss off-freq callers, especially
  on CW

114
Kurt Mudgeon Contest Operating TipsGeneral
Contesting

• Dont break a run pulling one station through
• Your rate will suffer if you take too long
• You will drive away impatient waiting stations
• Try twice and move on

115
Upcoming DX Contests

• CQ Worldwide DX Contest, SSB 0000Z, Oct 25 to
  2400Z, Oct 26
•
• CQ Worldwide DX Contest, CW 0000Z, Nov 29 to
  2400Z, Nov 30
•

116
Upcoming DX Contests

• ARRL Inter. DX Contest, CW
• 0000Z, Feb 21 to 2400Z, Feb 22
•
• ARRL Inter. DX Contest, SSB
• 0000Z, Mar 7 to 2400Z, Mar 8
•

117
Other Contests rest of 2008

• Nov 1-3 ARRL Sweepstakes CW
• Nov 15-17 ARRL Sweepstakes SSB
• Dec 5-6 ARRL 160 Contest
• Dec 13-14 ARRL 10M Contest

118
Team Meeting Topics

• Operating Schedules
• Equipment Familiarization
• Station Strengths and Weaknesses/Operating
  Strategy/Goals
• Contest logging software decision
• Household Rules and Idiosyncrasies

119
Keep the Troops Happy!

•

120
Help With The Clean Up
121
Stay In the Chair!
122
Keep Yo Butt Planted!
123
(No Transcript)
