Title: Operations Management (MD021)


1
Operations Management(MD021)
  • Capacity Management

2
What is capacity?
  • Capacity is the upper limit or ceiling on the
    load that an operating unit can handle
  • an upper limit on the rate of output

3
In the real world, we need to manage complex
systems like
but these are too complex to start out our
discussion of capacity management
4
Agenda
  • A Simple Example of a Processing System
  • Basic Definitions
  • Planning for Capacity
  • Evaluating Alternative Capacity Scenarios

5
A Simple Example of a Processing System
6
A simple processing system
RAW MATERIAL INPUTS
FACTORY CAPACITY ( MACHINE FOR PROCESSING)
CAPACITY 200 grains of sand/minute
FACTORY OUTPUT
7
For any fixed system, what happens as we increase
the number of jobs in the system?
Speed of Sand through Funnel
Response Time Time in System
Amount of Sand Poured Into Funnel
Jobs In System
8
Basic capacity management questions
  • How much sand should we allow into the system of
    funnels?
  • How many funnels should we have?
  • How big should our funnels be?
  • What kind of funnels should they be?
  • When should we add funnels?

9
What are the problems with these two systems?
DEMAND 200 grains/minute
DEMAND 100 grains/minute
200 grains/minute
100 grains/minute
100 grains/minute
200 grains/minute
10
There are several ways to increase capacity
100 grains/minute
scale up
modify your funnel or get a bigger funnel 400
grains/minute
scale out
get more funnels
change technology to big-mouth funnel 400
grains/minute
4 funnels X 100 grains/minute 400 grains/minute
11
Creating a balanced production system can be
fairly easy in simple systems
200 grains/minute
each 100 grains/minute
200 grains/minute
200 grains/minute
12
Easy to identify the bottleneck stage(s) by
observing where inventory builds up
200
400
100
200
100
200
400
400
100
13
In complex real-world systems
Here, you dont know individual capacities
which processing stage doesnt have sufficient
capacity?
14
Basic Definitions
15
Capacity
  • Capacity is the upper limit or ceiling on the
    load that an operating unit can handle
  • an upper limit on the rate of output
  • The basic questions in capacity planning are
  • What kind of capacity is needed?
  • How much is needed?
  • When is it needed?

16
Several definitions of capacity none is
universally applicable
  • Design capacity
  • Maximum output rate or service capacity an
    operation, process, or facility is designed for
  • Effective capacity
  • Design capacity minus allowances such as personal
    time, maintenance, and scrap
  • Actual output
  • Rate of output actually achieved--cannot exceed
    effective capacity.

17
Efficiency and Utilization
Both measures are expressed as percentages
18
Efficiency/Utilization Example
Design capacity 50 trucks/day Effective
capacity 40 trucks/day Actual output 36
units/day
  • Actual output 36
    units/day
  • Efficiency
    90
  • Effective capacity 40
    units/ day
  • Utilization Actual output 36
    units/day
  • 72
    Design capacity 50 units/day

19
Capacity cushion
  • Capacity Cushion
  • The amount of reserved capacity that a firm
    maintains to handle sudden increases in demand or
    temporary losses of production capacity.
  • Capacity Cushion 1 - Utilization

20
Commonly Observed Levels of Capacity Utilization
  • High Volume Manufacturing (Automated Flow Shop,
    Continuous Flow) level demand, perfect
    technology, perfect quality, no machine
    breakdowns, no worker breaks, no inventory
    shortages
  • Utilization in an ideal world close to 100, but
    often far less (85)
  • Job Shop, Batch Manufacturing variable demand,
    complex products, machine breakdowns, worker
    breaks, quality issues
  • Nationwide, average utilization about 70-85
  • Service high demand variability
    daily/weekly/lunch hour variation, interface with
    customers
  • Ranges from very low (20) to average (70-80)
  • E-Service/Websites huge demand spikes high
    demand can be 20X average demand
  • Many computer-based processes have utilization
    around 20
  • Often 35 utilization is the point at which you
    add more capacity

21
Using capacity utilization to diagnose problems
  • High capacity efficiency is usually GOOD
  • assumes you have some notion of historical
    effective capacity, which you often dont have
  • High capacity utilization may be GOOD
  • correct type of process
  • assuming all of your other performance measure
    objectives are being achieved (e.g., high
    quality, low cost, fast delivery)
  • High capacity utilization may be BAD if it is
    observed with
  • high costs
  • low revenues
  • low quality
  • slow deliveries

22
Planning for Capacity
23
Key Decisions of Capacity Planning
  • Amount of capacity needed
  • Timing of changes
  • Need to maintain balance throughout the system
  • Extent of flexibility of facilities and the
    workforce

24
Capacity Strategy Formulation
  • Capacity strategy for long-term demand will
    depend on
  • Expected demand patterns
  • Expected growth rate and variability of demands
  • Facilities
  • Cost of building and operating
  • Technological changes
  • Rate and direction of technology changes
  • Behavior of competitors
  • Availability of capital and other inputs

25
Operational tradeoffs concerning capacity
decisions
26
Steps in the Capacity Planning Process
  • Estimate future capacity requirements
  • Evaluate existing capacity
  • Identify alternatives
  • Conduct financial analysis
  • Assess key qualitative issues
  • Select one alternative
  • Implement alternative chosen
  • Monitor results

27
How much? Estimating capacity requirements for
a single product
  • Number of machines required (processing hours
    required for periods demand)/(hours available
    from one machine in the period, after removing
    desired capacity cushion)
  • M Dp/N(1-C)
  • D number of units (customers) forecast
  • p processing time (in hours per unit or
    customer)
  • N total number of hours per year during which
    the process operates
  • C desired capacity cushion rate

28
How much? Estimating capacity requirements for
several products
Q number of units in each lot s setup time
(in hours) per lot
29
Many factors determine whether to make yourself
or buy (outsource)
  • Available capacity/Cost of capacity
  • Expertise/Lack of expertise
  • Quality considerations can we achieve high
    quality requirements?
  • Nature of demand steady or variable?
  • Cost savings of outsourcing
  • Risks of losing control over operations
    disclosing proprietary information/intellectual
    capital

30
Capacity expansion alternatives When can we add
capacity?
  • Before demand is observed demand leading
  • After demand is observed demand trailing
  • When demand is observed demand matching
  • Add at regular time intervals steady expansion

31
System balance and flexibility? Many factors
determine effective capacity
  • Facilities design
  • Product and service factors
  • Process factors
  • Human factors
  • Operational factors
  • Supply chain factors
  • External factors

32
Common issues in planning and managing capacity
  • Try to design flexibility into production systems
  • Take account of stage of the product life cycle a
    product is in
  • Take a big picture systems-oriented approach to
    capacity changes how will it affect interrelated
    systems
  • You can only buy capacity in chunks it is
    lumpy
  • Attempt to smooth out capacity requirements
  • pricing promotions to change demand from period
    to period
  • Demand Side Management
  • countercyclical demands Lawn mowers and Snow
    blowers Water skis and Snow skis
  • Try to identify the optimal operating level

33
Can be much more challenging when planning
service capacity
  • May need to be near customers
  • Capacity and location are closely tied
  • Inability to store services
  • Capacity must be matched with timing of demand
  • Degree of volatility of demand
  • Peak demand periods

34
Evaluating Alternative Capacity Scenarios
35
Economies of Scale
  • Economies of scale
  • If the output rate is less than the optimal
    level, increasing output rate results in
    decreasing average unit costs
  • Diseconomies of scale
  • If the output rate is more than the optimal
    level, increasing the output rate results in
    increasing average unit costs

36
Comparing minimum average costs from several
sizes of plants

Minimum cost optimal operating rate are
functions of size of production unit.
Small plant
Average cost per unit
Medium plant
Large plant
0
Output rate
37
Cost-Volume AnalysisAssumptions
  • One product is involved
  • Everything produced can be sold
  • Variable cost per unit is the same regardless of
    volume
  • Fixed costs do not change with volume or they
    are stepwise changes
  • Revenue per unit constant with volume
  • Revenue per unit exceeds variable cost per unit

38
Cost-Volume Relationships
39
Cost-Volume Relationships
40
Breakeven Point
P TR TC R Q (FC v Q)
P Q(R v) - FC
Q (P FC) / (R v)
If TR TC, P 0
Breakeven Q (0 FC) / (R v)
41
Standard financial (cost-benefit) analysis
techniques also can be used
  • Cash Flow - the difference between cash received
    from sales and other sources, and cash outflow
    for labor, material, overhead, and taxes.
  • Present Value - the sum, in current value, of all
    future cash flows of an investment proposal.
