Title: Value Proposition and Challenges of Cloud Computing

Value Proposition and Challenges of Cloud
Steven A. Warner, Ph.D NGIS/ATG/Technology August
What is Cloud Computing?
  • Hype, smoke mirrors, snake oil
  • A new way of looking at buying and managing IT
    infrastructure and applications
  • Something weve been doing for a long time but
    with a different name
  • A great way to make my budget go farther
  • A great way to burn up my budget faster
  • Not sure, I hear different definitions

Cloud Computing Defined
  • NIST.GOV definition Cloud computing is a model
    for enabling available, convenient, on-demand
    network access to a shared pool of configurable
    computing resources (e.g., networks, servers,
    storage, applications, services) that can be
    rapidly provisioned and released with minimal
    management effort or service provider
  • This is a user-centric view and highlights
  • Access method availability, convenience,
    on-demand, via network,
  • Computing method shared pools, configurable
    virtualized resources, including application,
    storage, and print
  • Setup rapid provisioning/release, dynamic
    scalability, minimal management and
    service-provider interaction
  • Pay-per-use where relevant (differs from
    hosted environments, where model is pay for
    maximum capacity)
  • Not a technology but a means for using technology
    (or façade for the user)
  • Treats IT more as a utility than as a capital
    expense (etc.) that must be managed and upgraded

Business Drivers
  • A recent working group identified potential
    government savings of 6.6 B over the next three
    years through cloud/SaaS (IDC Total Cloud
    Market 42B by 2012)
  • Economics
  • Cost avoidance
  • Capital purchase
  • Power!
  • Maintenance
  • Staff
  • Pay for only what you use do not need to size
    systems to maximum capacity required (also
    simplifies planning)
  • Enables some reallocation of budgets, assets, and
    people into primary business/mission areas or
    other IT tasks
  • Agility
  • Avoids capital procurement timing
  • Very rapid access to new capabilities/capacity
    provides a way to add/increase services
    just-in-time without investing in new
    infrastructure, training new personnel, or
    licensing new software

Delivery Models
  • Good industry agreement on three major layered
  • Software-as-a-Service (SaaS) Clouds, where an
    application environment is provided
  • Platform-as-a-Service (PaaS) Clouds, where an
    application development platform is provided
  • Infrastructure-as-a-Service (IaaS), where
    infrastructure capabilities such as storage or a
    bare operating system are provided
  • Within each model there is the dimension of
  • Public (someone else owns it outside of the
    enterprise either hosted or open)
  • Can be either a consumer or enterprise market
  • Private (the enterprise has sole ownership)
  • Focus is enterprise, not consumer market
  • Many dimensions to private, the enterprise can
    potentially include groups of enterprises,
    special interest groups, etc.

Diagram courtesy of Cloud Security Alliance
Implementation Patterns
  • Transference -- Take an existing on-premises
    application and move it to the cloud.
  • Drivers include economics, consolidation, and
  • Often includes out-sourcing
  • Development and Multi-Tenancy Develop, assess,
    and operate new applications with unknown
    loadings without requiring a full initial capital
  • Drivers are rapid and inexpensive prototyping,
    verification/validation, and risk reduction.
  • Surge (aka Burst) -- Ability to handle additional
    requirements on an as-needed basis.
  • Drivers are economic avoiding paying for
  • Elastic Storage -- Application can grow
    exponentially from a value-added storage
  • Drivers are economic avoiding paying for
    over-capacity and also risk reduction. For
    example, data replication for disaster recovery,
    near-line storage for less frequently accessed
    data, archiving, backup
  • Collaboration Moving shared inter-organizational
    resources into a common area.
  • Driver is ease of management, also keeps traffic
    out of the enterprises internal network.

Implementation Patterns (continued)
  • These patterns drive various deployment models
  • Pure Cloud everything is in the cloud (whether
    internal, external private, or external hosted
    or SaaS, PaaS, or IaaS)
  • Cloud lt-gt Cloud -- two to many, could federate
  • Enterprise lt-gt Cloud hybrid of on-premises and
    one or more clouds (this will become a common
  • New design possibilities arise
  • If we assume host virtualization is a core
    component of any PaaS or SaaS solution…
  • Virtual machines then become a fundamental level
    of application component (eliminates need for a
    common run-time across complex multi-component
  • This will change how we design multi-tier
    applications, especially with state-less,
    clustered components (e.g. application servers)
  • However the added complexity emphasizes the need
    for good architecture, security, data
    classification, and systems engineering practices
    that takes into account the unique aspects of the
    cloud paradigm

How to Build a Cloud (High-Level)
  • First and foremost (!), execute using good
    systems engineering practices!
  • Begin with governance
  • Understand goals, objectives, and requirements
  • Define an architecture, then design services,
    infrastructure, etc. to it
  • Obtain a suitable infrastructure of arbitrarily
    adequate capacity with network access
  • Virtualize the infrastructure and secure it
  • Add requisite components if goal is SaaS
  • Provide a means for end-users to obtain and
    release resources upon request in a dynamic
    manner (where relevant, to be charged for use

The Virtual Private Cloud
Communications Circuit (dedicated, Internet, etc.)
Inter-Cloud Access
Non-Cloud Local Applications
Inter-Cloud Access
The Virtual Private Cloud is the aggregate of all
the above environments.
Challenges to Adoption
Challenges to Adoption (continued)
Challenges to Adoption (continued)
  • Understanding of the Paradigm
  • Definition Lack of agreement over what exactly
    constitutes cloud computing
  • Confusion Over what benefits cloud computing
    will provide, and the trade-offs
  • Multi-Tenancy
  • How comfortable is an enterprise in storing its
    data in an environment shared with other
  • What is the risk and the mitigation for data
  • How does this differ from what we did in the
    mainframe era?
  • Outrageous Vendor Claims and Obfuscation of
  • Hinder understanding of cloud computing
  • What exactly are we buying?
  • To what is the vendor committing (especially true
    for a hosting vendor)?

Challenges to Adoption (continued)
  • Understanding of the Paradigm (continued)
  • Role changes The CIO (or equivalent) may need to
    evolve to a general contractor in many areas.
  • Lock-In
  • How difficult would it be to move large volumes
    of data to a different cloud (cloud provider)?
  • This is both a procedural and a technical issue
    (format, bandwidth)

Challenges to Adoption (continued)
  • Implementation and Operations
  • Architecture
  • There is much disagreement over the necessary
    elements for a cloud technical architecture, and
    the elements are not mature.
  • In addition, SOA is the best approach for
    interface to clouds, yet culture for SOA success
    is immature and poorly understood.
  • There is much discussion over common cloud APIs,
    but none exist
  • Manageability from the user perspective
  • Existing management tools do not seem to be able
    to track metrics for applications that may reside
    on a varying number of different systems (not a
    problem where solution is a single VM)
  • How does asset management change in the cloud?
  • Distributed Management Task Force (DMTF) has
    initiated a working group to address
  • Memory limits within VM technology VMs, which
    are approaching being a requisite design element,
    can address less memory than the physical OS.
    The latest product releases largely obviate this
  • WAN performance Many geographies still are
    limited in their backbone capacity.

Challenges to Adoption (continued)
  • Implementation and Operations (continued)
  • Loss of control Will business elements of the
    enterprise bypass the enterprises IT
  • Governance
  • In which deployment models and use-cases does
    this play?
  • Is governance antithetical to the concept of
  • Will lack of governance aggravate problems
    already associated with lack of SOA governance?
  • Provisioning For SaaS, how will applications
    and application components be provisioned?
  • Licensing Vendors have been slow to develop
    appropriate models.
  • Confidence As to reliability, scalability, and
    security in public clouds (economics will also
    drive cloud vendors to minimize costs)

Challenges to Adoption (continued)
  • Implementation and Operations (continued)
  • Motivation for the Provider
  • Ideally, providers keep just ahead of demand
  • May provide motivation for providers to federate
    and sell capacity to each other as do utility
    companies. Are there lessons from the power
    utility companies?
  • Aggravates manageability problem
  • Is the capacity really there for surge levels?
    Will another tenants surge impede your ability
    to do the same?
  • Service-Level Agreements There have been
    effectively no substantive guarantees from public
    cloud providers.

Challenges to Adoption (continued)
  • Security and Compliance
  • Threat Models What new models arise in the
    cloud? Have we further aggravated issues already
    present within SOA and with standard computing
  • Examples
  • Dynamic virtual machines How much control to
    the user?
  • Resource isolation (appropriate isolation
    measures are needed)
  • VM-to-VM attacks
  • Data leakage
  • Weakened perimeter Firewall ports enabling user
    access are a vulnerability
  • Patch and security control management Becomes
    the users responsibility aggravated by VM
  • Hybrid usage Consistency of control ensuring
    the user understands where their data resides
  • Administrative access across networks A
    vulnerability also inconsistent with some
    security policies

Challenges to Adoption (continued)
  • Security and Compliance (continued)
  • Cross-Domain Security How does an organization
    extend or federate its authentication and
    authorization mechanisms into the cloud?
  • Data-at-Rest Security What encryption and
    segregation mechanisms are provided?
  • Auditability Can access to the data be audited?
  • Are data storage formats even amenable to
    auditing (more of an issue for chunking types of
    storage that lose the concept of a file)?
  • Forensics, as applications are not linked to
    physical infrastructure and the number of
    physical assets in play may vary
  • Accreditation in the Cloud
  • How can you tell a cloud is secure?
  • Is there governing policy and procedures to
    accredit a cloud?
  • What processes and controls must be in place?
    (Pre-accredited clouds may actually simplify this

Challenges to Adoption (continued)
  • Security and Compliance (continued)
  • Compliance May preclude cloud paradigm in some
    cases due to
  • Physical chain of custody requirements
  • Regulatory requirements
  • Physical Location
  • Do you know what country your cloud resides in?
  • Would you know if it changed?
  • What compliance requirements change?
  • Is there governing law that recognizes the
  • Conclusions
  • There are many challenges to adoption of the
    cloud paradigm
  • Public clouds and private clouds have different
    sets of challenges, with some overlap

Federal Government Environments
  • There are a few early adopters or near term
  • GovCloud
  • Significant interest by the Obama Administration
    in cloud computing, recognizing the following
    possible applications
  • End-user communications and computing
  • Secure virtualized data centers
  • Portals, collaboration and messaging
  • Content, information, and records management
  • Workflow and case management
  • Data analytics, visualization, and reporting
  • Enterprise business applications
  • DISA Rapid Access Computing Environment (RACE)
    a PaaS solution for DoD users, with option for
    hardened environment
  • Nimbus cloud computing environment at Argonne
    National Laboratories
  • NIST much thought leadership by Peter Mell and
    Tim Grance has defined the need for a Cloud
    Interoperability Profile

So What Can I Do Today?
  • Good public cloud applications today (look for
    high wow factor)
  • Backup/restore
  • Publication of shared (sanitized) data
  • Business analytics
  • Development, test, prototyping
  • Good private cloud applications today
  • Almost anything unless there is a high security
    or compliance requirement
  • Wait for public cloud
  • Mission-critical applications
  • Security- or compliance-sensitive data

(No Transcript)
