B. Hagmar

1
Salivary gland tumorsCytology - Histopathology

• B. Hagmar

2
SALIVARY GLAND FNAB

• High sensitivity - 80
• High specificity - 98
• But - correct typing is difficult and requires
  extensive experience (WHO)
• Giemsa for background
• Pap for nuclei

3
Normal Salivary gland

• Strong cellular cohesion
• Acinar structures,
• Ducts
• Few myoepithelial cells (cf pleomorphic adenoma,
  where these cells are abundant)

4
GIEMSA
Duct
Acini
5
PAPANICOLAOU
6
SIALOADENITIS

• Acini and inflammatory cells

7
(No Transcript)
8
DNR17132-93
Cave Differenial diagnosis
9
DNR17132-93
Cave Differenial diagnosis
10
DNR17132-93
Obvious atypia
11
DNR 1068-93
12
DNR1068-93
Nasopharyngeal carcinoma, undifferentiated
(lympho- epithelial carcinoma)
13
ADENOMAS

• Pleomorphic adenoma
• Myoepithelioma
• Basal cell adenoma
• Warthin tumor (adenolymphoma)
• Oncocytoma
• Canalicular adenoma
• Ductal papilloma
• Cystadenoma

14
PLEOMORPHIC ADENOMA

• Three components
• Epithelial cells - ducts, sheets or nests
• Myoepithelial cells - spindle shaped or
  plasmacytoid
• Chondromyxoid stroma

15
Myoepithelial cells
16
Myoepithelial cells
Papanicolaou
17
C496-02
Myoepithelial cells and chondromyxoid background
18
Epithelial cells
19
(No Transcript)
20
PLEOMORPHIC ADENOMA

• Diagnostic elements
• Plasmacytoid cells and chondro-myxoid stroma

21
PLEOMORPHIC ADENOMA

• 82 year old man with tumor in his left parotid
  gland
• FNAB - myxoma
• Parotidectomy

21
22
(No Transcript)
23
(No Transcript)
24
PLEOMORPHIC ADENOMACHONDROMYXOID TYPE
25
B9382/02
26
B9382/02
Bone and bone marrow in pleomorphic adenoma
27
B9277/02
CELLULAR PLEOMORPHIC ADENOMA
Atypical? Malignant?
28
B9277/02
Mitoses
Atypia?
29
B9277/02
Ki 67 labelling for mitotic activity
30
Case 3

• 27 year old woman with slowly growing tumor in
  her left parotid glandATYPIA

31
Case 3

• 27 year old woman with slowly growing tumor in
  the left parotid gland
• FNAC pleomorphic adenoma
• Parotidectomy pleomorphic adenoma with carcinoma
  in situ
• Recurrence after 1 year
• Multiple recurrencies for 4 years

32
CA EX PLEOMORPHIC ADENOMA

• Multiple recurrencies for 4 years

33
CA EX PLEOMORPHIC ADENOMA
34
CA EX PLEOMORPHIC ADENOMA

• 4,5 of all mixed tumors
• Rapid growth, facial palsy
• Benign and malignant components vary greatly
• Epithelial atypia
• Practically all types of carcinoma represented
• Atypical mixed tumor/ carcinoma in situ, if
  malignancy criteria are not met

35
PLEOMORPHIC ADENOMA

• Atypia must be evaluated in any p.a.
• Any type of carcinoma may arise in p.a.
• The stroma remains typically myxoid, the
  epithelial component is malignant
• Clinically, progression is heralded by rapid
  growth of the lesion

36
DD Pleomorphic adenoma

• Adenoma - epithelium sharply delineated from
  stroma
• LGPCa - epithelium more variable and occurs in
  tubular/papillary structures

37
DD Pleomorphic adenoma

• Carcinoma ex. Pleomorphic adenoma
• Adenoid cystic carcinoma - Alcian blue
• Basal cell adenoma, canalicular adenoma -
  epithelium sharply delineated from stroma
• Myoepithelioma epithelial-myoepithelial
  carcinoma - no ducts

38
Pleomorphic adenoma

• 93.5 in parotis
• 6.3 in submand. Gland
• 0.2 in sublingual gland
• 60 of all salivary gland tumors

39
ADENOMASwith basaloid cells

• Canalicular and basal cell adenomas
• Monomorphous small ovoid basal cells
• Small hyaline globules no chondromyxoid

40
(No Transcript)
41
(No Transcript)
42
B9147/02
43
B9147/02
S 100
Smooth Muscle Actin
44
ADENOMAS WITH BASALOID CELLS

• Monotonous cohesive or dissociated small ovoid
  basal cells
• Bland nuclei no nucleolus
• Pseudopapillæ
• No chondromyxoid stroma

45
DD ADENOMAS WITH BASALOID CELLS

• Basal cell adenocarcinoma
• Adenoid cystic carcinoma
• Epithelial-myoepithelial carcinoma
• PLGA
• Cellular pleomorphic adenoma

46
BASAL CELL ADENOCARCINOMA
47
(No Transcript)
48
(No Transcript)
49
B6953/02
BASAL CELL ADENOCARCINOMA
Solid type
50
BASAL CELL ADENOCARCINOMATubular type
B7413/02
51
BASAL CELL ADENOCARCINOMA

• 4 subtypes solid, trabecular, tubular and
  membraneous
• Three-dimensional clusters of basaloid cells with
  small hyaline globules
• Mild cellular pleomorphism

52
WARTHINS TUMOR,adenolymphoma

• Fluid, oncocytes and lymphocytes

53
WARTHINS TUMOR,adenolymphoma
54
(No Transcript)
55
(No Transcript)
56
Squamous Metaplasia
57
Cave DD Plateepitelcarcinom
58
CAVE
59
WARTHINS TUMOR,adenolymphoma
60
WARTHINS TUMOR,adenolymphoma

• Murky, mucoid, cystic aspirate.
• Background amorphous with granular débris.
• Monolayered oncocytic cells and lymphoid cells.

61
DD Warthin (cystadenolymphoma)

• Ductal carcinoma
• Sialoadenitis, lymphadenitis
• Acinic cell carcinoma
• Muco-epidermoid carcinoma (low-grade)
• Oncocytoma
• Acinic cell carcinoma
• Metastasis

62
SALIVARY GLANDCARCINOMAS

• Basal cell adenocarcinoma
• Polymorphous low grade carcinoma
• Epithelial-myoepithelial carcinoma
• Salivary duct carcinoma
• Acinic carcinoma
• Mucoepidermoid carcinoma
• Adenoidcystic carcinoma

63
PLGA (PLGA Polymorphous Low-Grade Carcinoma)

• Is an uncommon low-grade (terminal duct)
  adenocarcinoma occuring in minor salivary glands,
  preferably on the palate. The cells are
  clustering , small with scanty cytoplasm and may
  resemble adenoid cystic carcinoma especially
  since small hyaline globules may occur, but
  nuclear chromatin is bland.

64
B 7149/02
65
B 7149/02
66
B 7149/02
67
B7835/02
PLGA or Adenoidcystic ca?
72 year old woman
Tumores som vanskelig lar seg skille
68
EPITHELIAL-MYOEPITHELIAL CARCINOMA

• Pseudopapillae with eosinophilic stroma cores
• Spindle-shaped cells with hyperchromatic nuclei

69
EPITHELIAL-MYOEPITHELIAL CARCINOMA

• Small, ball-like or trabecular clusters. The
  cells are both basaloid with scanty cytoplasm and
  myoepithelial with abundant pale vacuolated
  cytoplasm. Nuclei are mildly atypical and show
  discrete central nucleoli. Hyaline stromal
  material is present occasionally with small
  hyaline stromal globules.

70
EPITHELIAL-MYOEPITHELIAL CARCINOMA
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
EPITHELIAL-MYOEPITHELIAL CARCINOMA

• DD
• Adenoidcystic carcinoma
• PLGA
• Pleomorphic adenoma
• Acinic cell cancer
• Metastatic cancer

76
ACINIC CELL CARCINOMA

• Large acinar cells (oncocytelike), in clusters or
  dissociated
• Azurophilic cytoplasmic granulation
• Naked nuclei
• Monotonous smear
• Lymphoid back-ground

77
ACINIC CELL CARCINOMA

• Ca 17 of all malignbant salivary gl. tumors
• Low grade malignancy
• Solid, microcystic, papillary-cystic and
  follicular
• Acinar, intercalated ductal, vacuolated and NOS
  glandular cells
• PAS positive cells and gland content

78
ACINIC CELL CARCINOMA
79
ACINIC CELL CARCINOMA
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
ACINIC CELL CARCINOMA

• Woman born in 1928
• 3 year history of slowly growing in the parotid
  gland
• Primary diagnosis PLGA

87
B6486/02
88
B6486/02
89
B6486/02
90
ACC, Papillary, cystic variant

• Juan Rosai is a very nice example of.
• Abrahams et al. Cancer 181145, 1965
• It is largely, if not entirely composed of
  intercalated cells.but the intercalated portion
  of the ducts and the acinar cells is an
  anatomico-functional unit

91
DD Acinic Cell Carcinoma

• Sialoadenitis normal gland
• Warthin tumor
• Epithelial-myoepithelial carcinoma
• Metastasis, e.g. Renal cell carcinoma
• Cave This tumor is easily overlooked because of
  the monomophic cellular picture!

92
MUCOEPIDERMOIDCARCINOMA

• Dirty background
• 3 celltypes mucoid, sqamous and intermediate

93
MUCOEPIDERMOIDCARCINOMA
94
(No Transcript)
95
Mucoep. ca
vacuole
96
Squamous differentiation
97
MALIGNANCY GRADINGMucoepidermoid ca

• Intracystic component lt 20 2
• Neural invasion 2
• Necrosis 3
• 4 or more mitoses/10 HPF 3
• Anaplasia 4
• Low grade 0 - 4
• Intermediate 5 - 6
• High grade 7 or more

98
DD MUCOEPIDERMOID CARCINOMA

• Squamous cell carcinoma
• Salivary duct carcinoma
• Warthins tumor
• Carcinoma ex pleomorphic adenoma

99
SALIVARY DUCT CARCINOMA

• Cytology as in comedocarcinoma of the
  breastwith large cells,pleomorphism and
  oftennecrosis
• High grade carcinoma

100
SALIVARY DUCT CARCINOMA
101
SALIVARY DUCT CARCINOMA

• 70 year old man with longstanding infection in
  his right parotid gland
• FNAB by oncologist - oncocytoma
• FNAB by cytologist - oncocytic carcinoma
• Parotidectomy

102
(No Transcript)
103
(No Transcript)
104
SALIVARY DUCT CARCINOMA
105
SALIVARY DUCT CARCINOMA

• 62 year old woman
• Tumor in the right parotid gland
• Sialoadenitis?

106
C87-02
107
C87-02
108
B1120-02
109
B1120-02
110
B6821/02
111
(No Transcript)
112
B6966/02
Ductal carcinoma ex pleomorphic adenoma
113
ADENOIDCYSTIC CARCINOMA

• Ovoid or round hyaline globules
• Tubular and cylindrical or fingerlike structures
• Basaloid cells

114
ADENOIDCYSTIC CARCINOMA

• 4th most common (after mucoepidermoid, acinic
  cell and adenocarcinoma NOS)
• Pimarily in major salivary glands, but also in
  oral and tracheal glands breast
• Cribriform, tubular and solid subtypes

115
ADENOIDCYSTIC CARCINOMA
116
(No Transcript)
117
(No Transcript)
118
ADENOIDCYSTIC CARCINOMA
119
ADENOIDCYSTIC CARCINOMA

• Ovoid or round hyaline globules surrounded by
  tumour cells (arrow). Tubular and cylindrical or
  fingerlike structures. Compact aggregates of
  basaloid cells with hyperchromatic nuclei with
  coarse chromatin and nucleoli.

120
ADENOIDCYSTIC CARCINOMASolid type
121
(No Transcript)
122
C2474-01
123
C2474-01
124
B11794-01
125
B11794-01
126
B11794-01
127
AdenocarcinomaUndifferentiated carcinoma
128
(No Transcript)
129
(No Transcript)
130
Immunocytochemistry, CK
131
HistologyPoorly differentiated adenocarcinoma
132
(No Transcript)
133
(No Transcript)
