XC 2: Flying Further and Faster

1
XC 2 Flying Further and Faster
2
The Plan

• The polar curve and performance
• Flying Further maximising the glide
• Flying faster in theory
• In practice rules of thumb
• Final glides
• Technology

3
Performance
4
Polar Curve
5
Different Gliders
6
Flying Further
7
Glide Ratio at max LD
49/1.62 30.3
8
20 kt Headwind
34/1.85 18.4
9
15 kt Tailwind
62/1.55 40.0
10
2 kts Sink
60/4.2 14.3
11
6 kts Sink 30 kt Headwind
57/11.2 5.1
12
Flying Faster
13
Assumptions Climb by circling i.e. cover no
distance while climbing. Thermal strength is
constant with altitude. Thermal strength is
known in advance (!)
14
x
Caution Algebra Ahead
15
V Airspeed S Rate of Sink (negative) C Rate
of Climb (positive) During the glide we fly
distance e with loss of height h in time t1 We
then climb h in time t2 (1) Total time, t t1
t2 (2) Average speed, Vav e/t (3) Altitude loss
in glide, -h S t1 (4) Altitude gained while
climbing, h Ct2 (5) Gliding time, t1 e/V (6)
Combining 3 and 4 t2 t1(-S/C) (7) Substitute
for t2 from (1) t - t1 t1(-S/C) (8) Substitute
for t1 from (5) t (e/V)(1- S/C) (9) Substitute
for t from (2) e/Vav (e/V)(1- S/C) gt
Vav/V C/(C - S)
h
e
16
Climb of 2kts
Vav/V C/(C - S)
17
As our expected rate of climb increases we fly
faster.
But how much faster?
18
(No Transcript)
19
(No Transcript)
20
Climb or Glide?
21
Climb of 2kts
22
(No Transcript)
23
2 Kt
2 Kt
2 Kt
6 Kt
1819
730
1520
1321
14.49
24
So much for Theory...
25
Rules of Thumb

• Final Climb Speed Ring Initial Climb
  (Reichmann/Comté)
• Do I have enough height to get to a (probably)
  better climb yet? (Chris Rollings)
• MIAROC Minimum Instantaneous Acceptable Rate of
  Climb (Platypus)

26
A Typical Flight
4 Kt
5 Kt
4 Kt
3 Kt
6 Kt
5 Kt
4 Kt
5 Kt
3 Kt
4 Kt
5 Kt
5 Kt
4 Kt
4 Kt
5 Kt
4 Kt
3 Kt
4 Kt
4 Kt
4 Kt
27
A Typical BRITISH Flight
5 Kt
0.1 Kt
-2 Kt
8 Kt
0 Kt
?
!
!
28
Final Glides
29
The Final Climb
4 Kt
?
30
When to Begin?

• Set McCready to 4 Kts
• How much more height do I need to arrive home at
  my chosen safety margin?
• Remember the wind
• Keep updating as the climb rate changes
• When no more height is needed then go!

31
On Glide (or not)

• If you're getting above glide then increase the
  McCready setting
• If you're getting below glide then reduce it
  and/or take another climb

32
That Safety Margin

• How far is it?
• What are conditions like on track?
• What is the performance of the glider?
• What is the McCready setting?

33
Having Finished

• Do remember to...
• Put the wheel down
• Dump any ballast
• Attempt some sort of reasonable landing
• Not crash

34
