COMP 5138 Relational Database Management Systems

1
COMP 5138Relational Database Management Systems
Semester 2, 2007 Lecture 8 Database System
Architectures
2
Todays Agenda

• Database System Architectures
• Centralized systems
• Client-Server systems
• Three-tier systems
• Presentation layer technologies
• Application layer technologies

3
Data-intensive Systems

• Three types of functionality
• The system architecture determines whether these
  three components reside on a single system
  (1-tier) or whether they are distributed across
  several tiers

• Presentation Services
• Input keyboard/mouse
• Output monitor/printer

GUI Interface
Application Services- Business rules - I/O
processing
Procedures, functions, programs
Data Management(Storage Logic) - data storage
and retrieval
DBMS activities
4
Single-User System
centralized system
DBMS
presentation application services
services
user module

• Presentation Services - displays forms, handles
  flow of information to/from screen
• Application Services - implements user request,
  interacts with DBMS
• Transactional properties automatic (isolation is
  trivial) or not required (this is not really an
  enterprise)
• DBMS runs within the user process
• Examples Access or Berkeley DB

5
Centralized Multi-User System

• Dumb terminals connected to mainframe
• Application and presentation services on
  mainframe
• ACID properties required
• Atomicity - Consistency - Isolation - Durability
• Isolation DBMS sees an interleaved schedule
• Atomicity and durability system supports a major
  enterprise
• Transaction abstraction, implemented by DBMS,
  provides ACID properties
• More details on implementing transactions in week
  11

6
Centralized Multi-User System
communication
central machine
presentation application services
services

DBMS
presentation application services
services
user module
dumb terminal
7
Evaluation

• All functionality combined into a single tier
• Centralised system runs on a single computer
  system and does not interact with other computer
  systems
• System resources must be used for both DBMS and
  application logic
• Usually mainframe, but also PC
• Benefit
• Easy maintenance and central administration
• Drawback
• Bad scalability for larger number of users
• Typically only dumb terminals as a user interface

8
Two-Tier Architectures Client-Server

• Functionality divided between client and server
• typically separated by a network
• Server systems satisfy requests of m client
  systems

9
Front-End versus Back-End

• Database functionality can be divided into
• Back-end manages access structures, query
  evaluation and optimization, concurrency control
  and recovery.
• Front-end consists of tools such as forms,
  report-writers, and graphical user interface
  facilities.
• The interface between the front-end and the
  back-end is through SQL or through an application
  program interface.

SQL user-interface
formsinterface
report writer
graphical interface
front-end
interface(SQL API)
SQLengine
back-end
10
Thin versus Thick Client

• Database applications data management
  application logic presentation
• Work division Thin client
• Client responsible for presentation (typically
  GUI)
• Server business logic and data management
• Work division Thick client
• Client implements both user interface and
  business logic
• Server data management only

Server
Data Management
ApplicationLogic
?
?
11
C/S Architecture Zoom-In

• Client and server are completely separated
• 2 separated processes / systems
• Communication between client server via network
• Usage of a special protocol, e.g. JDBC, Net8
  (Oracle)

Server
Client
DB Server
Client
Process
Process
DB ServerLibrary
DB ClientLibrary / Driver
Network
OperatingSystem
OperatingSystem
12
DB Server Internals
DB Server
Monolithic Server single DB process
Multiple Server multiple DB processes
Symmetric per AP one DB process
Asymmetric dynamic assignment of APs to DB
processes
13
Monolithic Server

• Exactly one server process for all clients
  (One-to-many)
• DBMS server process typically prioritised by
  operating system
• Server uses multi-threading
• Server does own resource management
• Examples Sybase, MS SQL Server

AP Client i
DBMS Server
AP Client 1
AP Client k

CL
CL
CL
operating system 1
operating system n
network
14
Multiple Server

• DBMS consists of several processes
• Scheduling done by the operating system
• Communication between
• server processes via shared memory
• clients and servers via operating system or
  network
• Two variants
• Symmetric - each client is mapped to exactly one
  server process static mapping with a certain
  number of n servers pre-generated ? maximal
  degree of parallelism is n
• Asymmetric - a dispatcher connects a client to a
  server process. Again, a certain number of
  servers are instantiated beforehand, but degree
  of parallelism can be higher
• Examples Oracle, Informix, DB2

15
Asymmetric Multiple Server
DBMS Server k
AP Client i
DBMS Server 1
AP Client 1
AP Client m
Dispatcher


CL
CL
CL
sharedmem
Operating system 1
Operating system n
network
16
Oracle Server Architecture
17
Oracle Server Configurations
18
Oracle Client-Server Connections
19
Comparison

• Thick Clients
• Makes good use of resources on desktop machines
  which are often lightly loaded
• Allows server machine to concentrate on disk
  transfers etc
• More responsive
• Some responses dont need to cross the network
• Eg data validation done in client
• May scale better
• Perhaps smaller and fewer data transfers between
  client and server (if many different
  presentations are needed of the same data)

• Thin clients
• Server doesnt need to trust clients
• No threat to data integrity from malicious client
• Less complex administration and maintenance
• Eg no need to deploy upgrades or patches to
  application logic?
• May scale better
• Perhaps smaller and fewer data transfers between
  client and server (if results of database queries
  are further reduced and filtered in application
  layer, to just what user needs)

The best design varies according to technology
changes
20
Three-Tier Architectures
Client Program
Presentation Tier

• primary interface to the user (e.g. web
  browser)
• needs to adapt to different display devices
  (PC, PDA, ...)

Web / Application Server
Middle Tier

• implements business logic and workflow
• may access several different DBMSs

Database System
Data ManagementTier

• one or more standard database management systems

21
Three-Tiered Model of TPS
database server machine
applic. server machines
trans. server machines
client machines
present. server
DBMS

trans. server
applic. server
present. server
communication
22
Interconnection/Clustering of Servers in
Three-Tiered Model
presentation server
presentation server
presentation server
presentation server


application server
application server


transaction server
transaction server
database server
database server
23
E-Commerce as Example
Web Browser
http
Web Server (dynamic web pages such as CGI or JSP)
JDBC or ODBC

• Web browser is client
• Application logic in dynamic web pages
• Servlets or Java Server Pages (JSP) Java code
  that runs in web server
• Non-Java world ASP, PHP, CGI,
• Database access from servlets / JSPs via JDBC

Database System
24
More complicated example
Web Browser
Web Server (servlets JSP)
http
RMI
Application Server

• Dynamic web pages mostly presentation
• Again servlets or JSPs
• Application Server
• Container for application logice.g. Enterprise
  Java Beans (EJB)
• Resource mgmt. (e.g. db connections)
• Database system
• is accessed from application serverusing JDBC or
  ODBC

EJB
EJB
EJB
EJB
JDBC ODBC
Database System
25
Example 1 Course Enrolment System

• Build a system in which students can enroll in
  courses
• Client Program
• Log in different users (students, staff,
  faculty), display forms and human-readable output
• Web Server
• Logic to add a course, drop a course, create a
  new course, etc.
• Database System
• Student info, course info, instructor info,
  course availability, pre-requisites, etc.

Browser
Client
Web Server
Server
Client
Server
Database(s)
26
Example 2 Internet Shop
Browser

• Web Browser GUI, navigation, presentation,
  simple input checks
• WWW ServerLog in different users, session
  management, display forms etc.
• Application ServerLogic for placing orders,
  purchasing, order status checks, etc.
• Databaseitem infos, customer data, orders,

Client
Server
Web Server
Client
Application Server
Server
Client
Server
Database(s)
27
Technologies for the Three Tiers
Client Program (Web Browser)
HTML JavaScript
HTTP
Application Logic(Web Server Application
Server)
Servlets JSP ASP J2EE EJB .NET
JDBC SQLJ OLEDB
Data Management(Database System)
SQL, XML Stored Procedures
28
Advantages of Three-Tier Architectures

• Heterogeneous Systems
• Tiers can be independently maintained, modified,
  and replaced
• Thin Clients
• Only presentation layer at clients (web browser)
• Integrated data access
• Several database systems can be handled
  transparently at the middle tier
• Central management of connections
• Scalability
• Replication at middle tier allows scalability of
  business logic
• Software development
• Code for business logic is centralised
• Interaction between tiers through well-defined
  APIsOne can reuse standard components at each
  tier

29
Review Question

• What kind of system architecture has Oracles
  iSQLPlus, which we are using in the labs?
• 1-Tier (centralized)
• 2-Tier (Client/Server)
• 3-Tier

30
Todays Agenda

• Database System Architectures
• Presentation layer technologies
• HTML, Javascript
• Application layer technologies

31
Overview of the Presentation Tier

• Recall Functionality of the presentation tier
• Primary interface to the user
• Needs to adapt to different display devices (PC,
  PDA, cell phone, voice access?)
• Simple functionality, such as field validity
  checking
• We will cover
• HTML Forms How to pass data to the middle tier
• JavaScript Simple functionality at the
  presentation tier

32
HTML Forms

• Common way to communicate data from client to
  middle tier
• General format of a form
• ltFORM ACTIONpage.jsp METHODGET NAMELogin
  Formgtlt/FORMgt
• Components of an HTML FORM tag
• ACTION Specifies URI that handles the content
• METHOD Specifies HTTP GET or POST method
• NAME Name of the form can be used in
  client-side scripts to refer to the form

33
Inside HTML Forms

• INPUT tag
• Attributes
• TYPE text (text input field), password (text
  input field where input is, reset (resets all
  input fields)
• NAME symbolic name, used to identify field value
  at the middle tier
• VALUE default value
• Example ltINPUT TYPEtext Nametitlegt
• Example form
• ltform method"POST" action"TableOfContents.jsp"gt
• ltinput type"text" name"userid"gt
• ltinput type"password" name"password"gt
• ltinput type"submit" value"Login
  name"submit"gt
• ltinput typereset valueCleargt
• lt/formgt

34
Passing Arguments

• Two methods GET and POST
• GET
• Form contents go into the submitted URI
• Structureaction?name1value1name2value2name3
  value3
• Action name of the URI specified in the form
• (name,value)-pairs come from INPUT fields in the
  form empty fields have empty values (name)
• Example from previous password formTableOfConten
  ts.jsp?useridjohnpasswordjohnpw
• Note that the page named action needs to be a
  program, script, or page that will process the
  user input

35
HTTP GET Encoding Form Fields

• Form fields can contain general ASCII characters
  that cannot appear in an URI
• A special encoding convention converts such field
  values into URI-compatible characters
• Convert all special characters to xyz, were
  xyz is the ASCII code of the character. Special
  characters include , , , , etc.
• Convert all spaces to the character
• Glue (name,value)-pairs from the form INPUT tags
  together with to form the URI

36
HTML Forms A Complete Example

• ltform method"POST" action"TableOfContents.jsp"gt
• lttable align "center" border"0" width"300"gt
• lttrgt
• lttdgtUseridlt/tdgt
• lttdgtltinput type"text" name"userid"
  size"20"gtlt/tdgt
• lt/trgt
• lttrgt
• lttdgtPasswordlt/tdgt
• lttdgtltinput type"password" name"password"
  size"20"gtlt/tdgt
• lt/trgt
• lttrgt
• lttd align "center"gtltinput type"submit"
  value"Login
• name"submit"gtlt/tdgt
• lt/trgt
• lt/tablegt
• lt/formgt

37
JavaScript

• Goal Add functionality to the presentation tier.
• Sample applications
• Detect browser type and load browser-specific
  page
• Form validation Validate form input fields
• Browser control Open new windows, close existing
  windows (example pop-up ads)
• Usually embedded directly inside the HTML with
  the ltSCRIPTgt lt/SCRIPTgt tag.
• ltSCRIPTgt tag has several attributes
• LANGUAGE specifies language of the script (such
  as javascript)
• SRC external file with script code
• ExampleltSCRIPT LANGUAGEJavaScript
  SRCvalidate.jsgtlt/SCRIPTgt

38
JavaScript (Contd.)

• If ltSCRIPTgt tag does not have a SRC attribute,
  then the JavaScript is directly in the HTML file.
• ExampleltSCRIPT LANGUAGEJavaScriptgtlt!--
  alert(Welcome to our bookstore)//--gtlt/SCRIPTgt
• Two different commenting styles
• lt!-- comment for HTML, since the following
  JavaScript code should be ignored by the HTML
  processor
• // comment for JavaScript in order to end the
  HTML comment

39
JavaScript (Contd.)

• JavaScript is a complete scripting language
• Variables
• Assignments (, , )
• Comparison operators (lt,gt,), boolean operators
  (, , !)
• Statements
• if (condition) statements else statements
• for loops, do-while loops, and while-loops
• Functions with return values
• Create functions using the function keyword
• f(arg1, , argk) statements

40
JavaScript A Complete Example

• HTML Form
• ltform method"POST
• action"TableOfContents.jsp"gt
• ltinput type"text" name"userid"gt
• ltinput type"password" name"password"gt
• ltinput type"submit" value"Login
  name"submit"gt
• ltinput typereset valueCleargt
• lt/formgt

• Associated JavaScript
• ltscript language"javascript"gt
• function testLoginEmpty()
• loginForm document.LoginForm
• if ((loginForm.userid.value "")
• (loginForm.password.value ""))
• alert('Please enter values for userid and
  password.')
• return false
• else return true
• lt/scriptgt

41
Stylesheets

• Idea Separate display from contents, and adapt
  display to different presentation formats
• Two aspects
• Document transformations to decide what parts of
  the document to display in what order
• Document rending to decide how each part of the
  document is displayed
• Why use stylesheets?
• Reuse of the same document for different displays
• Tailor display to users preferences
• Reuse of the same document in different contexts
• Two stylesheet languages
• Cascading style sheets (CSS) For HTML documents
• Extensible stylesheet language (XSL) For XML
  documents

42
CSS Cascading Style Sheets

• Defines how to display HTML documents
• Many HTML documents can refer to the same CSS
• Can change format of a website by changing a
  single style sheet
• ExampleltLINK RELstyle sheet TYPEtext/css
  HREFbooks.css/gt
• Each line consists of three parts
• selector property value
• Selector Tag whose format is defined
• Property Tags attribute whose value is set
• Value value of the attribute

43
CSS Cascading Style Sheets

• Example style sheet
• body background-color yellow
• h1 font-size 36pt
• h3 color blue
• p margin-left 50px color red
• The first line has the same effect as
• ltbody background-coloryellowgt

44
XSL

• Language for expressing style sheets
• More at http//www.w3.org/Style/XSL/
• Three components
• XSLT XSL Transformation language
• Can transform one document to another
• More at http//www.w3.org/TR/xslt
• XPath XML Path Language
• Selects parts of an XML document
• More at http//www.w3.org/TR/xpath
• XSL Formatting Objects
• Formats the output of an XSL transformation
• More at http//www.w3.org/TR/xsl/

45
Todays Agenda

• Database System Architectures
• Presentation layer technologies
• Application layer technologies
• CGI, application servers, Servlets,
  JavaServerPages, maintaining state

46
Overview of the Middle Tier

• Recall Functionality of the middle tier
• Encodes business logic
• Connects to database system(s)
• Accepts form input from the presentation tier
• Generates output for the presentation tier
• We will cover
• CGI Protocol for passing arguments to programs
  running at the middle tier
• Application servers Runtime environment at the
  middle tier
• Servlets Java programs at the middle tier
• JavaServerPages Java scripts at the middle tier
• Maintaining state How to maintain state at the
  middle tier. Main focus Cookies.

47
CGI Common Gateway Interface

• Goal Transmit arguments from HTML forms to
  application programs running at the middle tier
• Details of the actual CGI protocol unimportant à
  libraries implement high-level interfaces
• Disadvantages
• The application program is invoked in a new
  process at every invocation (remedy FastCGI)
• No resource sharing between application programs
  (e.g., database connections)
• Remedy Application servers

48
CGI Example

• HTML form
• ltform actionfindbooks.cgi methodPOSTgt
• Type an author name
• ltinput typetext nameauthorNamegt
• ltinput typesubmit valueSend itgt
• ltinput typereset valueClear formgt
• lt/formgt
• Perl code
• use CGI
• dataInnew CGI
• dataIn-gtheader()
• authorNamedataIn-gtparam(authorName)
• print(ltHTMLgtltTITLEgtArgument passing
  testlt/TITLEgt)
• print(The author name is authorName)
• print(lt/HTMLgt)
• exit

49
Application Servers

• Idea Avoid the overhead of CGI
• Main pool of threads of processes
• Manage connections
• Enable access to heterogeneous data sources
• Other functionality such as APIs for session
  management

50
Application Server Process Structure

• Process Structure

HTTP
Web Browser
Web Server
C Application
JavaBeans
JDBC
Application Server
DBMS 1
ODBC
DBMS 2
Pool of Servlets
51
Servlets

• Java Servlets Java code that runs on the middle
  tier
• Platform independent
• Complete Java API available, including JDBC
• Example
• import java.io.
• import java.servlet.
• import java.servlet.http.
• public class ServetTemplate extends HttpServlet
• public void doGet(HTTPServletRequest
  request, HTTPServletResponse response)throws
  SerletExpection, IOException PrintWriter
  outresponse.getWriter()
• out.println(Hello World)

52
Servlets (Contd.)

• Life of a servlet?
• Webserver forwards request to servlet container
• Container creates servlet instance (calls init()
  method deallocation time calls destroy()
  method)
• Container calls service() method
• service() calls doGet() for HTTP GET or doPost()
  for HTTP POST
• Usually, dont override service(), but override
  doGet() and doPost()

53
Servlets A Complete Example

• public class ReadUserName extends HttpServlet
• public void doGet( HttpServletRequest request,
• HttpSevletResponse response)
• throws ServletException, IOException
• reponse.setContentType(text/html)
• PrintWriter outresponse.getWriter()
• out.println(ltHTMLgtltBODYgt\n ltULgt \n
• ltLIgt request.getParameter(userid) \n

• ltLIgt request.getParameter(password)
  \n
• ltULgt\nltBODYgtlt/HTMLgt)
• public void doPost( HttpServletRequest request,
• HttpSevletResponse response)
• throws ServletException, IOException
• doGet(request,response)

54
Java Server Pages

• Servlets
• Generate HTML by writing it to the PrintWriter
  object
• Code first, webpage second
• JavaServerPages
• Written in HTML, Servlet-like code embedded in
  the HTML
• Webpage first, code second
• They are usually compiled into a Servlet

55
JavaServerPages Example

• lthtmlgt
• ltheadgtlttitlegtWelcome to BNlt/titlegtlt/headgt
• ltbodygt
• lth1gtWelcome back!lt/h1gtlt String nameNewUser
• if (request.getParameter(username) ! null)
  namerequest.getParameter(username)
• gt
• You are logged on as user ltnamegt
• ltpgt
• lt/bodygt
• lt/htmlgt

56
Maintaining State

• HTTP is stateless.
• Advantages
• Easy to use dont need anything
• Great for static-information applications
• Requires no extra memory space
• Disadvantages
• No record of previous requests means
• No shopping baskets
• No user logins
• No custom or dynamic content
• Security is more difficult to implement

57
Application State

• Server-side state
• Information is stored in a database, or in the
  application layers local memory
• Client-side state
• Information is stored on the clients computer in
  the form of a cookie
• Hidden state
• Information is hidden within dynamically created
  web pages

58
Application State
59
Server-Side State

• Many types of Server side state
• 1. Store information in a database
• Data will be safe in the database
• BUT requires a database access to query or
  update the information
• 2. Use application layers local memory
• Can map the users IP address to some state
• BUT this information is volatile and takes up
  lots of server main memory

5 million IPs 20 MB
60
Server-Side State

• Should use Server-side state maintenance for
  information that needs to persist
• Old customer orders
• Click trails of a users movement through a
  site
• Permanent choices a user makes

61
Client-side State Cookies

• Storing text on the client which will be passed
  to the application with every HTTP request.
• Can be disabled by the client.
• Are wrongfully perceived as "dangerous", and
  therefore will scare away potential site visitors
  if asked to enable cookies1
• Are a collection of (Name, Value) pairs

1http//www.webdevelopersjournal.com/columns/state
ful.html
62
Client State Cookies

• Advantages
• Easy to use in Java Servlets / JSP
• Provide a simple way to persist non-essential
  data on the client even when the browser has
  closed
• Disadvantages
• Limit of 4 kilobytes of information
• Users can (and often will) disable them
• Should use cookies to store interactive state
• The current users login information
• The current shopping basket
• Any non-permanent choices the user has made

63
Creating A Cookie

• Cookie myCookie
• new Cookie(username", jeffd")
• response.addCookie(userCookie)
• You can create a cookie at any time

64
Accessing A Cookie

• Cookie cookies request.getCookies()
• String theUser
• for(int i0 iltcookies.length i)
• Cookie cookie cookiesi
• if(cookie.getName().equals(username))
• theUser cookie.getValue()
• // at this point theUser username
• Cookies need to be accessed BEFORE you set your
  response header
• response.setContentType("text/html")
• PrintWriter out response.getWriter()

65
Cookie Features

• Cookies can have
• A duration (expire right away or persist even
  after the browser has closed)
• Filters for which domains/directory paths the
  cookie is sent to
• See the Java Servlet API and Servlet Tutorials
  for more information

66
Hidden State

• Often users will disable cookies
• You can hide data in two places
• Hidden fields within a form
• Using the path information
• Requires no storage of information because the
  state information is passed inside of each web
  page

67
Hidden State Hidden Fields

• Declare hidden fields within a form
• ltinput typehidden nameuser
  valueusername/gt
• Users will not see this information (unless they
  view the HTML source)
• If used prolifically, its a killer for
  performance since EVERY page must be contained
  within a form.

68
Hidden State Path Information

• Path information is stored in the URL request
• http//server.com/index.htm?userjeffd
• Can separate fields with an character
• index.htm?userjeffdpreferencepepsi
• There are mechanisms to parse this field in Java.
  Check out the javax.servlet.http.HttpUtils
  parserQueryString() method.

69
Multiple state methods

• Typically all methods of state maintenance are
  used
• User logs in and this information is stored in a
  cookie
• User issues a query which is stored in the path
  information
• User places an item in a shopping basket cookie
• User purchases items and credit-card information
  is stored/retrieved from a database
• User leaves a click-stream which is kept in a log
  on the web server (which can later be analyzed)

70
Todays Agenda

• Extra non-examined material
• Parallel System
• Distributed System
• See RG ch 22 for more information

71
Parallel Systems

• Parallel database systems consist of multiple
  processors and multiple disks connected by a fast
  interconnection network.
• A coarse-grain parallel machine consists of a
  small number of powerful processors
• A massively parallel or fine grain parallel
  machine utilizes thousands of smaller processors.
• Two main performance measures
• throughput --- the number of tasks that can be
  completed in a given time interval
• response time --- the amount of time it takes to
  complete a single task from the time it is
  submitted

72
Terminology
Ideal

• Speed-Up
• More resources means proportionally less time for
  given amount of data.
• Scale-Up
• If resources increased in proportion to increase
  in data size, time is constant.

Xact/sec. (throughput)
degree of parallel
Ideal
sec./Xact (response time)
degree of parallel
73
Factors Limiting Speedup and Scaleup

• Speedup and scale-up are often sub-linear due to
• Startup costs Cost of starting up multiple
  processes may dominate computation time, if the
  degree of parallelism is high.
• Interference Processes accessing shared
  resources (e.g.,system bus, disks, or locks)
  compete with each other, thus spending time
  waiting on other processes, rather than
  performing useful work.
• Skew Increasing the degree of parallelism
  increases the variance in service times of
  parallel executing tasks. Overall execution time
  determined by slowest of parallel executing tasks.

74
Parallel System Architectures

• Shared memory -- processors share a common memory
• Shared disk -- processors share a common disk
• Shared nothing -- processors share neither a
  common memory nor common disk
• Hierarchical -- hybrid of the above architectures

75
Parallel System Architectures
76
Shared Memory

• Processors and disks have access to a common
  memory, typically via a bus or through an
  interconnection network.
• Extremely efficient communication between
  processors
• Data in shared memory can be accessed by any
  processor without having to move it using
  software.
• Downside architecture is not scalable beyond 32
  or 64 processors since the bus or the
  interconnection network becomes a bottleneck
• Widely used for lower degrees of parallelism (4
  to 8).

77
Shared Disk

• All processors can directly access all disks via
  an interconnection network, but the processors
  have private memories.
• The memory bus is not a bottleneck
• Architecture provides a degree of fault-tolerance
  if a processor fails, the other processors can
  take over its tasks since the database is
  resident on disks that are accessible from all
  processors.
• Examples IBM Sysplex and DEC clusters (now part
  of Compaq) running Rdb (now Oracle Rdb) were
  early commercial users
• Downside bottleneck now occurs at
  interconnection to the disk subsystem.
• Shared-disk systems can scale to a somewhat
  larger number of processors, but communication
  between processors is slower.

78
Shared Nothing

• Node consists of a processor, memory, and one or
  more disks. Processors at one node communicate
  with another processor at another node using an
  interconnection network. A node functions as the
  server for the data on the disk or disks the node
  owns.
• Examples Teradata, Tandem, Oracle-n CUBE
• Data accessed from local disks (and local memory
  accesses) do not pass through interconnection
  network, thereby minimizing the interference of
  resource sharing.
• Shared-nothing multiprocessors can be scaled up
  to thousands of processors without interference.
• Main drawback cost of communication and
  non-local disk access sending data involves
  software interaction at both ends.

79
Hierarchical

• Combines characteristics of shared-memory,
  shared-disk, and shared-nothing architectures.
• Top level is a shared-nothing architecture
  nodes connected by an interconnection network,
  and do not share disks or memory with each other.
• Each node of the system could be a shared-memory
  system with a few processors.
• Alternatively, each node could be a shared-disk
  system, and each of the systems sharing a set of
  disks could be a shared-memory system.

80
Distributed DBMS

• Data is stored at several sites, each managed by
  a DBMS that can run independently.
• Distributed Data Independence Users should not
  have to know where data is located (extends
  Physical and Logical Data Independence
  principles).
• Distributed Transaction Atomicity Users should
  be able to write transactions accessing multiple
  sites just like local transactions.

81
Recent Trends

• Users have to be aware of where data is located,
  i.e., Distributed Data Independence and
  Distributed Transaction Atomicity are not
  supported.
• These properties are hard to support efficiently.
• For globally distributed sites, these properties
  may not even be desirable due to administrative
  overheads of making the location of the data
  transparent.

82
Types of Distributed Databases

• Homogeneous Every site runs the same type of
  DBMS.
• Heterogeneous Different sites run different
  DBMSs (different RDBMSs or even non-relational
  DBMSs).

Gateway
DBMS1
DBMS2
DBMS3
83
Storing Data
TID

• Fragmentation
• Horizontal
• Vertical
• Replication
• Gives increased availability
• Faster query evaluation

t1
t2
t3
t4
84
Distributed Catalog Management

• Must keep track of how data is distributed across
  sites.
• Must be able to name each replica of each
  fragment.
• To preserve local autonomy
• ltlocal-name, birth-sitegt
• Site Catalog Describes all objects (fragments,
  replicas) at a site Keeps track of replicas of
  relations created at this site.
• To find a relation, look up its birth-site
  catalog.
• Birth-site never changes, even if relation is
  moved.

85
Distributed Queries
SELECT AVG(S.age) FROM Sailors S WHERE S.rating gt
3 AND S.rating lt 7

• Horizontally Fragmented Tuples with rating lt 5
  at Sydney, gt 5 at Melbourne.
• Must compute SUM(age), COUNT(age) at both sites.
• If WHERE contained just S.ratinggt6, just one
  site.
• Vertically Fragmented sid and rating at Sydney,
  sname and age at Melbourne, tid at both.
• Must reconstruct relation by join on tid, then
  evaluate the query.
• Replicated Sailors copies at both sites.
• Choice of site based on local costs, shipping
  costs.
