A Golden Catalyst For Organic Reactions

1

• A Golden Catalyst For Organic Reactions

Jiaojie Li Department of Chemistry Brandeis
University
2
Outline
Introduction
Gold catalyzed C-C bond formation

• Synthesis and Functionalization of arene systems
• Rearrangement and Cycloisomerization
• Carbocyclization
• Coupling Reaction

Summary
3
Introduction

• Gold is an environmentally friendly catalyst, and
  it is able to catalyze reactions under mild
  conditions.
• Gold(I) and Gold(III) exhibit a soft Lewis acid
  character and a high affinity for p-bond
• Common Gold catalysts
• Gold(I) AuCl(PPh3),Au(Me)(PPh3)
• Gold(III) AuCl3, HAuCl4, NaAuCl4

4
Introduction Gold catalyzed C-C bond Formation

• Synthesis and Functionalization of arene systems
• Rearrangement and Cycloisomerization
• Carbocyclization
• Coupling Reaction

Summary
5
AuCl3 Catalyzed Phenol Synthesis
Hashmi, A. S. et al. J. Am. Chem. Soc. 2000, 122,
11553
6
Table 1. Gold(III) Catalyzed Phenol synthesisa
a Reactions were conducted with 2-5 mol AuCl3 in
MeCN at 20?
7
Proposed Mechanism
8
Supporting Experiment
Hashmi A. S. et. al. Org. Lett., 2001, 3, 3769
9
Advantages of Au-catalyzed Phenol Synthesis

• 1) It offers a new possibility for the
  application of Gold-catalysis in organic
  synthesis.
• 2) The old problem of a regioselective
  introduction of substituents at a benzoid arene
  now shift to furan, where such control of
  selectivity is much easier for both electrophilic
  attack and metalation.

10
Application in the Synthesis of Jungianol and
epi-Jungianol
?
?
?
Hashmi A. S. et. al. Chem. Eur. J. 2003, 9, 4339
11
AuCl3-Catalyzed Benzannulation

80?
Yamamoto Y. et. al. J. Am. Chem. Soc. 2002, 124,
12650
12
Table2. The AuCl3-Catalyzed Benzannulationa
a Reactions were conducted with 1 equiv
o-alkynylbenzaldehydes , 3 equiv alkynes and 3
mol AuCl3 in dichloroethane at 80 ? for 2-24h.
13

1a) R Me 40
1b)
R Ph 60
14
Proposed Mechanism
2
15
Regioselective Discussion
16
Au-Catalyzed Cyclialkylation of Electron-Rich
Arenes
,?
He C. et. al. J. Am. Chem. Soc. 2004, 126, 5964
17
Table 3. Gold(III)-Catalyzed Intramolecular
Cyclialkylationa
a Reactions were conducted with 0.5mmol of
oxiranes and 2.5 mol of AuCl3/ 3AgOTf in 3ml of
dichloroethane for 4h, the temperature is from
50? to 80? .
18
Direct Functionalization of Arenes
ClCH2CH2Cl, 120?
He C. et. al. J. Am. Chem. Soc. 2004, 126, 13596
19
Table 4. Gold-Catalyzed Functionalization of
Arenesa
a Reactions were conducted at 120? in DCE with
0.5mmol of arenes, 1mmol of sulfonate ester, and
5 mol AuCl3/3AgOTf for 48h.
20
Two Competing Mechanisms
21
Control Experiment
22
Gold-Catalyzed Addition of Arenes to Imines
Li C. J. et. al. Chem. Commun., 2004, 1930
23
Table 5. Gold-catalyzed Addition of
Arenes to Iminesa
a Reactions were conducted with 3mol
AuBr3/3AgOTf at 50? to 80? .
24
Introduction Gold catalyzed C-C bond Formation

• Synthesis and Functionalization of arene systems
• Rearrangement and Cycloisomerization
• Carbocyclization
• Coupling Reaction

Summary
25
Background of Claisen Rearrangement

• Lewis acid catalyzed Claisen rearrangement
• Hard Lewis acids, which catalyze the reaction by
  coordination to Oxygen atom.
• Soft Lewis acids, such as Pd(II) and Hg(II),
  which catalyze the reaction by coordination to
  ?-bond.

However, it is often limited by binding of
electronphilic metal center to strong
nucleophilic vinyl ethers, thus prevents the
activation of ?-bond.
26
Gold(I)-Catalyzed Propargyl Claisen Rearrangement
Toste F. D. et. al. J. Am. Chem. Soc. 2004, 126,
15978
27
Table 6 Au(I)-Catalyzed Propargyl Claisen
Rearrangementa
1)
2)
a Reactions were conducted with 0.1
mol(Ph3PAu)3OBF4 at 75? in dichloroethane for
1-25h.
28
Control Reactions
?
(Ph3PAu)3OBF4(1mol),CH2Cl2, 4h, 40? 81
gt 201dr NaBH4, MeOH, R.T. PhCH3, 3h, 170 ?
NaBH4, MeOH, R.T. 90 11.5dr
29
Proposed Mechanism for the Au(I)-Catalyzed
Rearrangement
30
Gold(I)-Catalyzed Isomerization of 1,5-Enynes
Toste F. D. et. al. J. Am. Chem. Soc. 2004, 126,
10858
31
Table 7. Au(I)-Catalyzed Synthesis of
Bicyclo3.1.0hexenesa
a Reactions were conducted with 0.5M 1,5-enyen
and 1-3mol (PPh3)Au(I) in dichloroethane for
2-24h, rt.
To be continued
32
continue
a Reactions were conducted with 0.5M 1,5-enyen
and 1-3mol (PPh3)Au(I) in dichloroethane for
2-24h, rt
33
Proposed Mechanism for Au(I)-Catalyzed
Cycloisomerization
34
Introduction Gold catalyzed C-C bond Formation

• Synthesis and Functionalization of arene systems
• Rearrangement and Cycloisomerization
• Carbocyclization
• Coupling Reaction

Summary
35
Gold(I)-Catalyzed Carbocyclization
36
Gold(I)-Catalyzed 5-exo-dig Cyclization
Toste F. D. et. al. J. Am. Chem. Soc. 2004, 126,
4526
37
Table 8. Gold(I)-Catalyzed 5-exo-dig cyclizationa
a Reactions were conducted with 1 mol(PPh3)AuCl,
1 molAgOTf, 0.4M ketoester in dichloromethane,
rt.
38
Mechanistic Hypotheses
39
Gold(I)-Catalyzed 5-endo-dig Carbocyclization

No reaction lt 5 conversion 93 yield
Toste, F. D. et. al. Angew. Chem. Int. Ed. 2004,
43, 5350.
40
Table 9. Au(I)-Catalyzed 5-endo-dig
carbocyclizationa
aReactions were conducted with 1 mol(PPh3)AuCl,
1 molAgOTf, 1.0M ketoester in dichloromethane,
rt.
41
Mechanistic Comparison for the Gold(I)-Catalyzed
Carbocyclization
42
Introduction Gold catalyzed C-C bond Formation

• Synthesis and Functionalization of arene systems
• Rearrangement and Cycloisomerization
• Carbocyclization
• Coupling Reaction

Summary
43
Au(I)-Catalyzed three-Component Coupling of
Aldehydes, Alkynes and Amines
Li, C.J. et. al. J. Am. Chem. Soc. 2003, 125,
9584
44
Table10. Gold-Catalyzed Coupling of Aldehydes,
Alkynes and Amines in watera
a Reactions were conducted with 1 mol AuCl at
75? in water for 12h.
45
Proposed Mechanism
46
Summary

• Both Gold(I) and Gold(III) complexes exhibit a
  high ability for alkyne activation.
• Gold salts can also activate the C-H bond of
  electron-rich arenes.
• Most of Gold-catalyzed reactions can proceed in
  mild conditions.

47
Thank You!
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
Hashmi A. S. et. al. Org. Lett., 2001, 3, 3769
52
Table 5. Gold-Catalyzed intramolecular
Cyclialkylation
