P573 Scientific Computing Lecture 4: Vector Operations

1
P573Scientific ComputingLecture 4 Vector
Operations

• Peter Gottschling
• pgottsch_at_cs.indiana.edu
• www.osl.iu.edu/pgottsch/courses/p573-06

2
Outline

• Vector space
• Defining your own vector type
• Programming operators
• Norms
• Inner product

3
Vector Space

• V is a vector space over the field F if
• V is an Abelian group
• Vector addition is associative ? u, v, w ? V
  (u v) w u (v w)
• Vector addition is commutative? u, v ? V u v
  v u
• Vector addition has an identity element 0? v ?
  V v 0 v
• Vector addition is invertible? v ? V ? w ? V v
  w 0w is called additive inverse
• Scalar multiplication is associative? v ? V, ?
  a, b in F a (b u) (a b) u
• Scalar multiplication as an identity element 1?
  v ? V 1 v v
• Distributivity holds for scalar multiplication
  over vector addition? u, v ? V , ? a ? F a (u
  v) a u a v
• Distributivity holds for scalar multiplication
  over scalar addition? v ? V , ? a, b ? F (a
  b) v a v b v

4
Implementing our own Vector Type

• For simplicity we use STL vector
• See http//www.sgi.com/tech/stl/Vector.html
• Does not provide arithmetic operations
• Before we add operations, we define a new type
• In its own namespace

5
Defining new Vector Type

• namespace algebra
• template lttypename Fgt
• class vector
• typedef F value_type
• typedef F pointer
• typedef F reference
• typedef const F const_reference
• //
• reference operator(size_type n)
• return my_vectorn
• stdvectorltFgt my_vector
• We have to define everything again!

6
Defining new Vector Type with Inheritance

• namespace algebra
• template lttypename Fgt
• class vector public stdvectorltFgt
• // typedef F value_type already
  exist
• typedef stdvectorltFgt base
• vector(typename basesize_type n) base(n)

• We only need to re-implement constructors.
• We can overwrite and add members if we want.

7
New operators

• template lttypename Fgt
• algebravectorltFgt operator(const
  algebravectorltFgt x,
• const
  algebravectorltFgt y)
• assert(x.size() y.size())
• algebravectorltFgt result(x.size())
• for (int i 0 i lt x.size() I)
• resulti xi yi
• return result
• What is wrong with this?

8
What is the problem with operators in C?

• Imagine you want to compute with vectorsz x
  y
• What happens?
• Adding the vectors and storing it in the
  temporary vector
• Copy this vector into the stack
• Deleting the temporary
• Then assigning the vector on the stack to z
• What it takes?
• One loop for the addition
• One memcopy to the stack
• Another loop in the assignment (or a faster copy)
• Optimization
• Might remove the memcopy
• We still have two loops
• Anyway we go twice over the vectors

9
How Can This be Computed Faster?

• Write an inline function for this, like add(x, y,
  z)
• The easiest way
• Will be as fast as any code you write inplace
• Need to be implemented for any combination of
  operations and operands
• Shallow copy
• Values are actually not copied but only the
  pointer pointing to the data
• Actually data are only aliased not really copied,
  e.g.,x y y3 7also changes x3
• Becomes very error prone

10
How Can This be Computed Faster?

• Move semantics
• Shallow copies are not critical if only 1 copy
  exist
• Results of expressions only exist once
• After assigning the temporary variable or using
  in another expression it will be destroyed
• Perfect for z x y
• Does not avoid multiple loops in z x y w (in
  2 additions)
• Expression templates
• Operator only returns object of some type that
  contains information about operands and operator
• In assignment computation will be finally
  executed
• In one loop only no matter how many operands
• Needs a lot of compile time when excessively used
• Invented by Todd Veldhuizen from IU
• See Blitz http//www.oonumerics.org/blitz/

11
How Can This be Computed Faster?

• Source-to-source code transformation
• Source program is parsed and represented as
  abstract syntax tree
• Tree can be searched for certain patterns and
  modified
• Tree retransformed into source code
• For instance Rose
• Special treatments for loops predefined
• http//www.llnl.gov/CASC/rose/
• Drawback dependence on rose (or other tool)

12
Vector Norms

• Mapping from V to R
• Always non-negative
• Only 0 for additive neutral element
• Must fulfill triangle inequality
• Mostly used Lp-Norm and their discrete
  equivalents

13
Scalar Product

• For vectors over real vectors defined as
• algebravector x, y
• s 0
• for (int c 0 c lt x.size() c)
• s xc yc
• For vectors over complex number we would need the
  conjugates of xs elements

14
Optimization for Superscalar Processors

• Some processors can compute multiple operations
  in parallel
• All operations depend on s
• Solution using partial sums
• for (int c 0 c lt NP c 4)
• sp0 xc yc
• sp1 xc1 yc1
• sp2 xc2 yc2
• sp3 xc3 yc3
• for (int c 4(NP/4) c lt NP c)
• sp0 xc yc
• Sp0 sp1 sp2 sp3

15
Optimizing Blocking Factor

• Running tests and see which unrolling factor is
  optimal
• Have to program this for each factor
• Wouldnt it be nice to let the factor be a
  parameter
• For instance a template parameter

16
Warm up

• How we can compute at compile time?
• Parameter must be known at compile time
• Iterations must be transformed into recursions
• Recursions are more expressive anyway
• Class members which are static const are forced
  to be computed at compile time
• Otherwise it yields a compilation error (or
  linkage error)
• Example factorial

17
Computing Factorial at Compile Time

• include ltiostreamgt
• template ltunsigned Xgt
• struct factorial
• static const unsigned value X
  factorialltX-1gtvalue
• template ltgt
• struct factoriallt0gt
• static const unsigned value 1
• int main(int argc, char argv)
• stdcout ltlt factoriallt7gtvalue ltlt '\n'
• return 0

18
What We Need to Unroll the Dot Product?

• Computable at run time
• Stop criterion
• How many iterations with blocks
• Cleanup
• How many iterations without blocks
• To define at compile time
• U independent operations in each block
• U partial sums
• How to compute the sum of the U partial sums
• Again using recursion
• Starting with data structure containing U
  variables
• Next defining loop calling block in separate
  function
• Recursive definition of computation in each block

19
Recursive Data

• template ltunsigned Depthgt
• struct recursive_data
• double sum
• recursive_dataltDepth-1gt remainder
• recursive_data(double s) sum(s),
  remainder(s)
• double sum_up()
• return sum remainder.sum_up()
• template ltgt
• struct recursive_datalt1gt
• double sum
• recursive_data(double s) sum(s)
• double sum_up()
• return sum

20
Main function of Unrolled Dot product

• template ltunsigned Depthgt
• double unrolled_dot(vectorltdoublegt const v1,
• vectorltdoublegt
  const v2)
• // check v1.size() v2.size()
• unsigned size v1.size(), blocks size /
  Depth,
• blocked_size blocks Depth
• recursive_dataltDepthgt sum_block(0.0)
• for (unsigned i 0 i lt blocked_size i
  Depth)
• dot_blockltDepth, Depthgt()(v1, v2,
  sum_block, i)
• double sum sum_block.sum_up()
• for (unsigned i blocked_size i lt size i)
• sum v1i v2i
• return sum

21
Definition of Blocks

• template ltunsigned Depth, unsigned MaxDepthgt
• struct dot_block
• static unsigned const offset MaxDepth -
  Depth
• void operator() (vectorltdoublegt const v1,
  vectorltdoublegt const v2,
• recursive_dataltDepthgt sum_block, unsigned
  i)
• sum_block.sum v1 i offset v2 i
  offset
• dot_blockltDepth-1, MaxDepthgt() (v1, v2,
  sum_block.remainder, i)

22
Closing Definition of Block

• template ltunsigned MaxDepthgt
• struct dot_blocklt1, MaxDepthgt
• static unsigned const offset MaxDepth - 1
• void operator() (vectorltdoublegt const v1,
• vectorltdoublegt
  const v2,
• recursive_datalt1gt sum_block,
  unsigned i)
• sum_block.sum v1 i offset v2 i
  offset

23
How Much Faster We are?

• regular 4.09s, result 6000
• unrolled 2 2.89s, result 6000
• unrolled 4 2.52s, result 6000
• --------------------
• template 1 3.82s, result 6000
• template 2 4.03s, result 6000
• template 3 4.4s, result 6000
• template 4 3.74s, result 6000
• template 5 3.83s, result 6000
• template 6 3.62s, result 6000
• template 7 3.53s, result 6000
• template 8 3.55s, result 6000
• template 9 3.46s, result 6000
• template10 3.54s, result 6000
• template12 3.6s, result 6000
• template14 4.15s, result 6000
• template16 4.53s, result 6000
• On Mac PowerBook with 1.33 GHz PowerPc

24
How Much Faster We are?

• Overall performance is slower then C program
• Unrolling has still some impact
• Why the unrolled version is slower
• Recursive class definition apparently avoid
  register use
• Partial sums are kept in memory, well in cache
• Proof template-less computation with recursive
  data structure has same timing
• This are results with gcc
• Other compilers, icc and kcc, can allocate it in
  registers
• How can we get gcc to use registers?
• Can we recursively define variables that are
  stored in registers?

25
How to Use Registers for Summation?

• Define single variables in outer function
• Call recursively function for block using
• Functions must be inlined
• Pass all variables to block function
• As reference to modify the partial sums
• Different statements in block must use different
  variable
• Single computation adds to first variable
• Call next statement in block without first
  variable
• Every call would have different number of
  parameters
• Unrolling will be limited to the number of
  variables

26
How to Use Registers for Summation?

• Define single variables in outer function
• Call recursively function for block using
• Different statements in block must use different
  variable
• Instead of dropping the first variable rotate it
• All call have the same number of parameters
• If unrolling factor is larger than of variables

• Then variables are reused
• Does not falsify the result
• Parallelism is limited to the number of variables
• But not the unrolling factor
• If unrolling factor is smaller than of
  variables
• Some variables stay 0
• Does not falsify either

27
Unrolled Dot Product Revised

• template ltunsigned Depthgt
• double unrolled_dot(vectorltdoublegt const v1,
• vectorltdoublegt
  const v2)
• // check v1.size() v2.size()
• unsigned size v1.size(), blocks size /
  Depth,
• blocked_size blocks Depth
• double s0 0.0, s1 0.0, s2 0.0, s3 0.0,
  s4 0.0, s5 0.0,
• s6 0.0, s7 0.0
• for (unsigned i 0 i lt blocked_size i
  Depth)
• dot_blockltDepth, Depthgt()(v1, v2, i, s0, s1,
  s2, s3, s4, s5, s6, s7)
• s0 s1 s2 s3 s4 s5 s6 s7
• for (unsigned i blocked_size i lt size i)
• s0 v1i v2i
• return s0

28
Single Statement in Block

• template ltunsigned Depth, unsigned MaxDepthgt
• struct dot_block
• static unsigned const offset MaxDepth -
  Depth
• void operator() (vectorltdoublegt const v1,
  vectorltdoublegt const v2, unsigned i,
• double s0, double s1, double s2,
  double s3,
• double s4, double s5, double s6,
  double s7)
• s0 v1 i offset v2 i offset
• dot_blockltDepth-1, MaxDepthgt() (v1, v2, i, s1,
  s2, s3, s4, s5, s6, s7, s0)

29
Last Statement in Block

• template ltunsigned MaxDepthgt
• struct dot_blocklt1, MaxDepthgt
• static unsigned const offset MaxDepth - 1
• void operator() (vectorltdoublegt const v1,
  vectorltdoublegt const v2, unsigned i,
• double s0, double, double, double,
• double, double, double, double)
• s0 v1 i offset v2 i offset

30
How Much Faster We are?

• regular 3.98s, result 6000
• unrolled 2 2.78s, result 6000
• unrolled 4 2.39s, result 6000
• --------------------
• template 1 3.74s, result 6000
• template 2 2.65s, result 6000
• template 3 2.34s, result 6000
• template 4 2.42s, result 6000
• template 5 2.24s, result 6000
• template 6 2.11s, result 6000
• template 7 2.12s, result 6000
• template 8 2.1s, result 6000
• template 9 2.08s, result 6000
• template10 2.01s, result 6000
• template11 2.11s, result 6000
• template12 1.97s, result 6000
• template13 2.47s, result 6000
• template14 2.76s, result 6000
• template15 2.97s, result 6000

31
Analysis

• Templated version is as fast as pure C code
• For 2 and 4 unrolling factor
• Unrolling beyond number of partial sum can speed
  up
• Program is even simpler than the original
• The simplest solutions are often the best.
