Man is what he thinks he is

1
Man is what he thinks he is
2
Pathology of Tuberculosis

• Dr. Venkatesh M. Shashidhar
• Associate Professor of Pathology
• Fiji School of Medicine

3
Introduction

• Infects one third of world population..!
• 3 million deaths due to TB every year
• Under privileged population -
• over crowding, malnutrition
• Since 1985 incidence is increasing in west
• AIDS, Diabetes, Immunosuppressed patients.
• Drug resistance

4
Microbiology of TB

• M. tuberculosis (air) M. bovis (milk)
• Aerobic, no toxins, no spore, non motile
• Mycolic acid in bacterial wall - Acid Alcohol
  fast (AFB)
• M. avium, M.intracellulare in AIDS - Atypical
  tuberculosis.

5
AFB - Ziehl-Nielson stain
6
(No Transcript)
7
(No Transcript)
8
Pathogenesis of TB

• Type IV hypersensitivity - Granuloma
• Escape killing by macrophages
• Mycolic acid wax coat
• Cord Factor - surface glycolipid

9
Tuberculous Granuloma

• Rounded outlines.
• Central Caseous necrosis.
• Transformed macrophages called epithelioid cells.
• Lymphocytes, plasma cells, and fibroblasts.
• Langhans giant cells.

10
Tuberculous Granuloma
11
Primary Tuberculosis

• In Non Immunized individuals (Children)
• Primary Tuberculosis
• Self Limited disease
• Ghons complex or Primary complex.
• Primary Progressive TB
• 10 of adults, Immunosuppressed individuals
• Common in malnourished children
• Miliary TB and Meningitis.

12
Secondary Tuberculosis

• Post Primary in immunized individuals.
• Reactivation or Reinfection
• Apical lobes or upper part of lower lobes
• Caseation, cavity - soft granuloma
• Pulmonary or extra-pulmonary
• Local or systemic/Miliary

13
Primary or Ghons Complex

• Primary tuberculosis is the pattern seen with
  initial infection with tuberculosis in children.
• Reactivation, or secondary tuberculosis, is more
  typically seen in adults.

14
Ghon Complex
15
Cavitary Tuberculosis

• When soft, necrotic center drain out leave behind
  a cavity.
• Cavitation is typical for large granulomas.
• Cavitation is more common in the reactivation
  tuberculosis seen in upper lobes.

16
(No Transcript)
17
(No Transcript)
18
Tuberculous Granulomas
19
Caseation Necrosis
20
Epitheloid cells in Granuloma
21
(No Transcript)
22
(No Transcript)
23
Systemic Miliary TB
24
Adrenal TB - Addison Disease
25
Spinal TB - Potts Disease
26
(No Transcript)
27
(No Transcript)
28
Miliary Tuberculosis

• Extensive infection
• Hematogenous spread
• Low immunity
• Pulmonary or Systemic types.

29
PPD Testing
30
PPD Testing
31
Lifes battles dont go always to the stronger
or faster man, But sooner or later,The
man who wins is the man who thinks he can.
32
Lung Tumours

• Dr. Venkatesh M. Shashidhar
• Senior Lecturer in Pathology
• Fiji School of Medicine

33
Lung Cancer

• Most common visceral malignancy.
• Top public enemy in western world.
• 3rd of all cancer deaths due to lung cancer.
• Significant increase in incidence.
• Dramatic increase among females
• 90 of lung cancers are related to smoking..!
  (passive smoking in 5)

34
Lung Cancer Smoking

• Depends on duration, amount of daily smoking
  deep inhaling.
• 10 fold greater risk than non smokers. 20 fold
  risk if gt40cigarettes per day
• Atypical cells in 96.7 of smokers compared to
  0.9 in non smokers.
• Significant proportion of over 1200 substances in
  smoke are carcinogenic. (not nicotine)
• Initiaters Benzoopyrenes
• Promoters Phenol derivatives
• Radioactive substances Polonium, C14, K40

35
Classification (Bronchogenic Carcinoma)

• Squamous cell carcinoma 35
• Adenocarcinoma 30
• Brochial (acinar/papillary)
• Bronchioalveolar (1-9)
• Small cell carcinoma 22
• Oat cell carcinoma

36
Bronchogenic Carcinoma
37
Bronchogenic Carcinoma
38
Bronchogenic Carcinoma
39
Adeno- Carcinoma
40
Direct Spread of carcinoma
41
Oat cell Carcinoma
42
LungMetastasis(Gross)
43
Squamous Cell Carcinoma(CT)
44
Normal Chest Radiograph
45
LungMetastasis(Multiple coin shadows)
46
Squamous Cell Carcinoma
47
Adenocarcinoma
48
Oat Cell Carcinoma (High power)
49
Pleural effusion (Gross)
50
Paraneoplastic Syndromes

• Hormone producing neoplasms.
• ADH - Hyponatremia
• ACTH Cushings syndrome
• Parathyroid hormone Hypercalcemia
• Gonadotrophins Gynecomastia

51
Find the key to yourself.. and every door in
the world is open to you
52
Thank You...

• Dr. Venkatesh M. Shashidhar
• Senior Lecturer in Pathology
• Fiji School of Medicine
