Amino Acids, Peptides, and Proteins.

1
Amino Acids, Peptides, and Proteins.
2
Classification of Amino Acids
3
Fundamentals

• While their name implies that amino acids are
  compounds that contain an NH2 group and a CO2H
  group, these groups are actually present as NH3
  and CO2 respectively.
• They are classified as a, b, g, etc. amino acids
  according the carbon that bears the nitrogen.

4
Amino Acids
an a-amino acid that is anintermediate in the
biosynthesisof ethylene
a
a b-amino acid that is one ofthe structural
units present incoenzyme A
b
a g-amino acid involved inthe transmission of
nerveimpulses
g
5
The 20 Key Amino Acids

• More than 700 amino acids occur naturally, but 20
  of them are especially important.
• These 20 amino acids are the building blocks of
  proteins. All are a-amino acids.
• They differ in respect to the group attached to
  the a carbon.
• These 20 are listed in Table 27.1 (p 1054-1055).

6
(No Transcript)
7
(No Transcript)
8
Table 27.1

• The amino acids obtained by hydrolysis of
  proteins differ in respect to R (the side chain).
• The properties of the amino acid vary as the
  structure of R varies.

9
Table 27.1
Glycine
(Gly or G)

• Glycine is the simplest amino acid. It is the
  only one in the table that is achiral.
• In all of the other amino acids in the table the
  a carbon is a stereogenic center.

10
Table 27.1
O
H


O
H3N
C
C
CH3
Alanine
(Ala or A)
11
Table 27.1
O
H


O
H3N
C
C
CH(CH3)2
Valine
(Val or V)
12
Table 27.1
O
H


O
H3N
C
C
CH2CH(CH3)2
Leucine
(Leu or L)
13
Table 27.1
O
H


O
H3N
C
C
CH3CHCH2CH3
Isoleucine
(Ile or I)
14
Table 27.1
O
H


O
H3N
C
C
CH3SCH2CH2
Methionine
(Met or M)
15
Table 27.1
Proline
(Pro or P)
16
Table 27.1
Phenylalanine
(Phe or F)
17
Table 27.1
Tryptophan
(Trp or W)
18
Table 27.1
Asparagine
(Asn or N)
19
Table 27.1
Glutamine
(Gln or Q)
20
Table 27.1
O
H


O
H3N
C
C
CH2OH
Serine
(Ser or S)
21
Table 27.1
O
H


O
H3N
C
C
CH3CHOH
Threonine
(Thr or T)
22
Table 27.1
Aspartic Acid
(Asp or D)
23
Table 27.1
Glutamic Acid
(Glu or E)
24
Table 27.1
Tyrosine
(Tyr or Y)
25
Table 27.1
O
H


O
H3N
C
C
CH2SH
Cysteine
(Cys or C)
26
Table 27.1
O
H


O
H3N
C
C

CH2CH2CH2CH2NH3
Lysine
(Lys or K)
27
Table 27.1
O
H


O
H3N
C
C
CH2CH2CH2NHCNH2

NH2
Arginine
(Arg or R)
28
Table 27.1
O
H


O
H3N
C
C
Histidine
(His or H)
29
27.2Stereochemistry of Amino Acids
30
Configuration of a-Amino Acids

• Glycine is achiral. All of the other amino acids
  in proteins have the L-configuration at their a
  carbon.

31
27.7Peptides
32
Peptides

• Peptides are compounds in which an amide bond
  links the amino group of one a-amino acid and the
  carboxyl group of another.
• An amide bond of this type is often referred to
  as a peptide bond.

33
Alanine and Glycine
34
Alanylglycine

• Two a-amino acids are joined by a peptide bond in
  alanylglycine. It is a dipeptide.

35
Alanylglycine
N-terminus
C-terminus
AlaGly
AG
36
Alanylglycine and glycylalanine are
constitutional isomers
Alanylglycine AlaGly AG
Glycylalanine GlyAla GA
37
Alanylglycine

• The peptide bond is characterized by a planar
  geometry.

38
Higher Peptides

• Peptides are classified according to the number
  of amino acids linked together.
• dipeptides, tripeptides, tetrapeptides, etc.
• Leucine enkephalin is an example of a
  pentapeptide.

39
Leucine Enkephalin
TyrGlyGlyPheLeuYGGFL
40
Oxytocin
C-terminus
N-terminus

• Oxytocin is a cyclic nonapeptide.
• Instead of having its amino acids linked in an
  extended chain, two cysteine residues are joined
  by an SS bond.

41
Oxytocin
SS bond
An SS bond between two cysteines isoften
referred to as a disulfide bridge.
