Composing

1
Composing PerformingInteractive Music

• October 18-23, 2004
• Faculty of Music
• McGill University

Bruce Pennycook, DMA Dept. of Composition, School
of Music Dept. of Radio Television Film, College
of Communication University of Texas at Austin
2
Introduction
3
Schedule Topics

• Monday 3-6 Principals and Aesthetics of
  Interactive Music
• Tuesday 9-12 Impact of interactive music on
  performance practice and
• on compositional methods
• Wed 9-12 Systems Design (composer/performer
  perspective)
• Thur 9-12 New directions and possibilities
• Friday 9-12 Music and Audio Visualization -
  interactive, real-time video-music

4
Objectives of the Seminars

• Present an overview of the history of interactive
  composition and performance
• Provide in depth resources and materials for
  graduate level study and research
• Propose new areas of creativity and research from
  emerging aesthetics, styles and technologies
  including visualization systems

5
Seminar Format

• Presentations by B. Pennycook
• Examples and demonstrations
• Daily contributions by students
• Short paper (due October 31, 2004)

6
Resources

• Read - Rowe, Winkler
• CMJ articles
• Recordings
• Max, Max/MSP SuperCollider 2, 3

7
Seminar 1Principals and Aesthetics of
Interactive Music
(who will turn the knobs when I die)
Monday, October 18, 2004 300 pm - 600 pm Room
LSR3
8
Principals and Aesthetics of Interactive Music

• What is interactivity ? (he says/she says)
• Are there pre-computer examples ?
• What about live electronic music ?
• Why are these early pieces different from our
  current thinking on this topic? That is, what
  role does the computer play in this?
• What separates computational control from machine
  control?

9
Principals and Aesthetics of Interactive Music

• What is the essential attraction of interactive
  music? Why do composers (and for that matter,
  performers) want to create/play it?
• How has the software community influenced music
  making and vice-versa?
• What connection exists (or should exist) with
  other forms of interactive art?

10
Principals and Aesthetics of Interactive Music

• Tape instruments/voices
• Instrumental karaoke (music minus n)
• Free the player from the tyranny of the clock
  (tape, cd)
• Like asking an actor to perform to video or film
• Eliminates the normal elasticity of gestures
  especially on the large scale (local elasticity
  is possible - like Chopin LH/RH) rubato has to
  be built in to the score
• No error tolerance - clock keeps ticking no
  matter what

11
Principals and Aesthetics of Interactive Music

• BUT - (Music - n) works!
• Many very important pieces (Berio, Davidovsky,
  Risset, Lanza, Morrill, Parmagiani, ) that remain
  performed
• Low-stress rehearsal environment
• Easily replicated performance after performance
• Players can memorize aural events very precisely
• Players can emulate interaction convincingly
• Sonic domain can be managed easily
• Low gear, setup, help environment

12
Principals and Aesthetics of Interactive Music

• Principals of interactive music
• Establish a dialogue between man and machine
• Permit modes and levels of adaptation
• Seek new performance results - from slightly
  interpretive to full improvisation
• Seek new or at least dynamic compositional
  results
• Explore relationship between man and machine to
  some degree
• Explore machine autonomy to some extent

13
Principals and Aesthetics of Interactive Music

• Temporal Control
• What are the key interpretive issues?
• What degree of flexibility is required?
• What are the macro/micro level of temporal
  controls that would have direct and audible
  impact on the listener?
• Why not just fake it?
• How can this be managed with minimal impact on
  the player or ensemble?

14
Principals and Aesthetics of Interactive Music

• Computer assisted composition.
• Grab/alter/play metaphor is very seductive given
  the inherent compositional cohesion that ensues.
  But despite some clever efforts (Risset,Rowe,
  Pennycook, Pinkston, Hamel, Chafe, others) -
  these have not been embraced into the
  repertoire)
• Is this a MIDI thing? Is MIDI dead?
• If yes, why? What problems exist with this method
  of work that prohibits it from finding a solid
  niche in the overall ea or chamber music genre?

15
Principals and Aesthetics of Interactive Music

• Guided Improvisation
• http//smc04.ircam.fr/ProgWorkshop.html
• Workshop on computer improvisation, Oct 20 IRCAM
• What is guided improvisation
• In what sense does a player actually improvise
• In what sense can a computer improvise
• One-way, two-way, n-way improvisation
• Stylistic norms and boundaries help manage
  conditional environment

16
Principals and Aesthetics of Interactive Music

• Guided Improvisation
• Essential criterion for improvisation is the
  ability to listen
• Application of analytic/generative processes to
  the incoming musical information
• Segmentation, feature extraction and pattern
  matching
• Modular compositional automaton
• Other factors such as parallel process
  management, multi-computer audio, midi and data
  interfaces

17
Principals and Aesthetics of Interactive Music

• Audio Processing Compositions
• Modes of operation
• outboard rack approach
• New audio from previous audio (lag issues)
• Stored files
• Stored audio altered on the fly as per incoming
  data
• Real-time pitch tracking, segmenting, pattern
  matching (huge topic to be returned to later in
  the week)
• Computational demands much higher than MIDI hence
  must be worth it

18
Principals and Aesthetics of Interactive Music

• General Properties - Summary
• Modes of performance
• Active - triggers, footswitch, etc. initiated
  by operator and/or performer(s)
• Passive - system detects appropriate flags from
  processes such as beat detection, pitch
  detection, silence/pause detection, motion
  capture, time-code (clock) etc.
• Granularity
• Section, event, note, clock time,
• Governed by compositional style and process
  compexity

19
Principals and Aesthetics of Interactive Music

• General Properties - Summary
• Input and Sources
• MIDI - seems passé now but why?
• Audio - transducer properties, analytical,
  processing and generative algorithms
• Motion/Image - use of gesture may be critical to
  effective interaction secondary channel?
• Output
• MIDI? - this is really dead
• Audio - channels, mixing, loudspeaker management
• Video/Image - supporting

20
Principals and Aesthetics of Interactive Music

• General Properties - Summary
• Longevity (who will turn the knobs)
• Very few pieces are playable without the composer
  or trained operator present
• Players largely disenfranchised due to tech-gap
• No obvious solution to hardware/software
  obsolescence
• Many components defy notation or even adequate
  description
• Teachers will never (?) undertake this repertoire
  thus the cycle of master-apprentice is
  essentially broken beyond repair
• Many acoustic composers consider this little more
  than gear-tinkering
• No systematic reviewing process
• Vast arena of techno-pop has totally overshadowed
  the genre

21
Seminar 1Principals and Aesthetics of
Interactive Music
END
Monday, October 18, 2004 300 pm - 600 pm
22
Seminar 2Composition and Performance of
Interactive Music
(the chamber music tradition)
Tuesday, October 19, 2004 900 am - 1200 pm Room
LSR 1
23
Interactive Compositions

• Early adoptors (MIDI)
• Roger Dannenburg, Chris Chafe, Joel Chadabe,
  Dexter Morrill, Keith Hamel, Russell Pinkston,
  Jean-Claude Risset, Morton Subotnick.
• Early adopters (Audio/DSP)
• Cort Lippe, Zack Settel, Tod Machover, Russell
  Pinkston, .
• Reference - Joel Chadabe .

24
Interactive Compositions

• Pennycook PRAESCIO series
• First public performance - Buffalo, April 1987 -
  Praescio I

25
Praescio - I

• Soprano saxophone
• Original version constructed with Dannenburg
  software cmidi (?) on PC-AT/286.
• Setup included
• PC/at with MIDI IN, IVL Pitchrider
• Sax data processed with delays, harmonizations,
  etc.
• PC/at with midi version of score-11 developed by
  BP and CS grads at Queens University, called
  M-SCORE
• Files were hand triggered on a
  section-by-section basis
• Extreme underflow occurred during performance
  causing bursts and cascades

26
Selected Compositions Praescio-I Rec. 1991, McGill
27
Praescio - I

• Versions II, III
• Reconstructed using MIDI-LIVE software developed
  at McGill (Pennycook, Fujinaga, Hillborn,
  Quesnel)
• Current version - Max
• (more on this tomorrow)

28
Tornado (McGill EMS) Praescio-II amnesia
29
Praescio - II amnesia

• Commissioned by Geoffrey Wright for 25th
  anniversary of Peabody Conservatory EMS
• With Morton Subotnick Jacobs Room
• Instrumentation, System
• Soprano, flute, vln, vcello, dx7, system
• First version of MIDI-LIVE software (Low-latency
  MIDI composition system for real-time
  performance)
• Soprano and flute were close micd and provided
  pitch data to software via 2 IVL Pitchriders
• Stored sequences were triggered (by operator)
• MIDI Channel management was the crucial component

30
MIDI-LIVE 0.8

• Designed to permit fluent interchange of live
  data with stored data
• Premise was that MIDI files could be played like
  pieces of tape
• Transformations included
• Assign out channel(s)
• Assign tempo, velocity (volume) on a per-track
  basis
• Specifiy harmonization, transposition
• Gather inmcoming note-ons, strip temporal info,
  resend in various ways
• Any number of tracks could be active at a time
  all under their own local metronome
• Scripting language playback interface for live
  performance that showed channel activity
• Read/process standard midi files produced from
  sequencer, M-SCORE (score11/midi) OR recorded and
  stored internally

31
PRAESCIO-III The desert speaks Vivien Spiteri,
Harpsichord 1989
32
Praescio-III the desert speaks

• MIDI-LIVE 1.0 - program, much more stable, more
  processing capabilities, better user interface
  for scripting
• Praescio-III harpsichord and midilive
• Challenge as the harpsichord - first interface
  was developed with Eric Johnstone at McGill using
  organ retrofit midi package with a complete set
  of switches for upper manual
• Small control unit attached to harpsichord to
  permit the player to reset, advance, etc. and
  manage fswitch and vol pedal (critical for the
  performance)

33
Praescio-III the desert speaks

• Version 2 of the interface was built for concert
  in Europe - original interface stolen out of a
  van (very high return for sure!)
• New version entirely optical - individual
  LED/Receptor pairs per note on upper manual
• Worked OK but susceptible to sudden lighting
  changes!
• Never truly debugged, hard to regulate (but
  better than the mechanical one)

34
Praescio-III the desert speaks

• 3 movement format
• I - colorize
• II - record/strip/process/play
• III - triggered sequences, colorize

35
PRAESCIO-IV Jean-Guy Boisvert, Clarinet 1991
36
Praescio-IV

• Commission for the 1991 International Clarinet
  Conference by Jean-Guy Boisvert
• Challenge was to provide clarinetist with maximum
  freedom of control over temporal components
• Non-improvisatory
• Cheap MIDI tone generators to facilitate travel
  (but that may have been a bad idea)

37
Praescio-IV

• Unique harness for the clarinet designed and
  built by BP and Eric Johnstone
• Provided attachment (DIN) for
• Contact mic on reed to improve IVL tracking
• 3 ultra-light keys placed by LH thumb and RH
  little-finger to permit cross-fingered sustain
  and trigger
• Volume pedal on floor was unavoidable then,
  perhaps with gesture tracking this too could be
  eliminated
• Images in CMJ
• Performed successfully by many different players
  - learning curve very short using the device and
  score cues

38
Praescio-V

• Praescio-V - a kind of joint performance piece
  for Dexter Morrill and myself
• 1990 MIDI-LIVE road tour in Europe/Eastern
  Europe
• Trumpet, sax and small rack of midi tone
  generators Yamaha DMP-11 midi controlled mixer
  for processing audio (software controlled)
• No longer extant but lots of fun to play.
• Note that Dexter Morrill made numerous
  compositions using MIDI-LIVE and even shipped a
  system around to performers. A version was made
  for the Yamaha laptop that supported MIDI (not
  the CX5).

39
Praescio-VI

• Praescio-VI commissioned by Christine Little,
  Toronto flautist
• Several performances by different players -
  Montreal, Toronto, Ottawa, ICMC-San Jose, Mexico
  City
• Fairly stable short learning curve
• 4 innovations for this piece
• Max version of MIDI LIVE under development
• MIDI Time Clip (remote signaling device to be
  described tomorrow)
• Use of audio-on-CD as part of the controlled
  environment, more than MIDI output
• Digidesign Sample-Cell hence entirely internal to
  the Mac
• But, some serious level issues, hard to control
  in real-time

40
Praescio-VII (piano and them some..) alcides
lanza, piano
41
Praescio-VII

• Praescio-VII (piano and then some) commissioned
  by ACREQ for alcides lanza to perform
• many performances by different players plus tours
  in Europe, South America by lanza
• MIDI Time Clip crucial for both the conception
  of the piece and the performance - very difficult
  to perform without feedback from computer-player

42
Praescio-VII

• Most complex of the Praescio series
• Midi data generated from Common Music/LISP
  programs written by BP -- SMFs
• Full max implementation of MIDI-LIVE 2.x
  (Stammen)
• Several specialized Max objects written by Dale
  Stammen
• MIDI in from triggers (no piano data)
• Feedback to player with MIDI Time Clip, complete
  Time Clip software package (Pennycook/Stammen)

43
Praescio-VII

• Large array of piano tone modules for midi out
• Dual CD under complex Max control to permit
  overlap
• 8 audio outs and 8 loudspeakers with real-time
  placement using MIDI-controlled MIXER (simple
  unity gain device - no EQ)
• Full integration of prerecorded audio tracks and
  prepared MIDI sequences
• Temporal management of triggers only - no
  improvisation
• More than 60 events

44
Other mixed pieces

• The Black Page Tropes (1995)
• Drums, percussion, midi out audio
• One section of triggered improvisation using
  loops derived from Pyhrite external in Max
• Long complex work primarily for the players -
  audio/MIDI more supportive and commentary
• The Yonge Street Variations (1998)
• Cello, MIDI (drum head), audio, DSP
• Less notes, more processing and sound
• Much greater reliance on stored audio files
  triggered by player
• Based on very early work for viola and percussion
  (recorded)

45
Summary

• Much was learned from the development of all
  these works
• End of the MIDI era (almost)
• 8 audio outs and 8 loudspeakers with real-time
  placement using MIDI-controlled MIXER (simple
  unity gain device - no EQ)
• Full integration of prerecorded audio tracks and
  prepared MIDI sequences
• Temporal management of triggers only - no
  improvisation
• More than 60 events

46
Seminar 3Interactive System Design
Wednesday, October 20, 2004 900 am - 1200
pm Room 806
47
Design issues

• What is the definition of Tod Machovers
  interactive solo cello piece for Yo-Yo Ma, Begin
  again and again

48
Design issues

• 1 cellist, 6 technicians 2 18-wheelers
• (1991 view)

49
Brief History

• Risset - Duet for one piano
• Jaffe/Schloss - Wildlife
• Wessel - phrase recorder
• Lippe - Music for Clarinet and ISPW

• Dannenberg - CMU Midi Toolkit
• Rowe - Cypher
• Pennycook - MidiLive/Max, T-MAX, Listener Project
  (with Hillborn, Stammen, Quesnel)

50
Looking backwards

• Development of interactive, live-perf systems
• Max Software (version 2) 1990/91
• This program was written for 68k Mac.
• PlaySMF (Dale Stammen - superb Midilive
  implementation for MAX)
• Led to more ambitious implementations especially
  T-MAX, a version of Rowes Cypher running across
  a Mac IIfx and 4 Inmos T805 Transputers
• Listener project - Stammen/Pennycook (see Rowe)

51
MIDI-LIVE -Max

• Max Software (version 2) 1990/91
• This program was written for 68k Mac.
• PlaySMF (Dale Stammen - superb Midilive
  implementation for MAX)
• allnotesoff (Dale Stammen), case (Dale Stammen)
• (more on this tomorrow)

52
Looking back

• Demo of playSMF
• Pre audio example
• Black Page Tropes
• Max - MIDI (playSMF) audio cds
• Event list driven, operator required (me).
• Drums, perc, system
• Interactive drum solo (Pyhrite code in Max)

53
Design Criteria Today

• Compositional Strategy
• Improvisatory?
• Accompanying?(as in my stuff for the most part)
• Sound Art?
• Solo? Multiplayer?
• Multiple media types (visuals, video, dance,
  lighting)

54
Design Criteria Today

• Technical Strategy
• Small, portable? (G5 makes this almost a
  non-issue)
• Audio Only? Controller functions?

55
Audio Pieces

• Panmure Vistas
• SC2, state driven knobs
• Requires operator for truly fluent presentation
• Solo violin sc2

opening
midpoint
ending
56
(No Transcript)
57
Audio Pieces

• Club Life (2003)
• SC2, state driven knobs, much more complex
  software
• Requires operator for truly fluent presentation
• 2 saxes, piano, system
• Not really interactive, just live

58
(No Transcript)
59
Audio Pieces

• Fast Dance (2004/05)
• Clarinet and Max/MSP (in progress)
• Commission from Jean-Guy Boisvert
• Interactive audio only, no MIDI
• Surround audio, 2-5 mics on stage (clarinetist
  moves around somehow)
• Want to avoid the grab and hack metaphor and
  rack-in-a-box
• Several highly intensity/rhythmic audio processes
  initiated by player position on stage, pitch
  (maybe), input volume (for sure)
• Stored audio clips processed under algorithmic
  control

60
Summary

• Audio is different but not necessarily better
  than MIDI as a compositional tool many clichés
  to avoid
• Multichannel audio leads to positional
  information as data channel
• If G5 dependent, I will still need someone to
  turn the knobs when I die!

61
Guest Performers

• alcides lanza (Praescio VII - piano and then
  some)
• Director of the McGill EMS
• Composer and performer of electroacoustic works
• Jean-Guy Boisvert (Praescio IV)
• Specialist in new music for clarinet
• Extensive touring experience with midi and audio
  systems

62
Guest Performers

• 30 minute round table on performance issues

63
Seminar 4New Directions, Emerging Technologies
Thursday, October 21, 2004 900 am - 1200 pm LSR
2
64
Seminar 4

• 0900-1045 Emerging Technologies
• 1100-1200 Performer Interview

65
Seminar 4

• 0900-1045
• Emerging Technologies

• 1100-1200
• Performer Interviews
• alcides lanza, piano
• Jean-Guy Boisvert, clarinet
• Discussion of perforrmance practice of
  interactive music (Praescio IV, VII)

66
Emerging Technologies

• What would a unified interactive
  performance/composition system look like?
• What do we (creators) want to do?
• What are the aesthetic objectives?

67
Emerging Technologies

• Single voice pitch tracking combined with
  beat/rhythm tracking can produce stable and
  reliable real-time data input.

68
Emerging Technologies

• Real-time feature detection can segment and
  identify macro-structures can be implemented

69
Emerging Technologies

• Motion capture systems permit reasonable and
  stable gesture capture such that movements can be
  integrated into the overall data input

70
Emerging Technologies

• Tracking of multiple audio sources can be
  enhanced with various types of source separation
  then subjected to other processes

71
Emerging Technologies

• Technologies to control in real-time a wide
  variety of devices - lighting, stage mechanicals,
  video, audio diffusion - can be driven from a
  variety of computer-mediated inputs (audio,
  motion capture, other data sources)

72
Emerging Technologies

• Through more elaborate, dynamic data-mapping
  processes, musical input (audio, MIDI, motion)
  can be translated into complex visualizations.
• Note that visualizations and show-control
  systems are merging under a few clean standards.
  Large scale display systems called digital light
  projection (DLP) that are bright enough for 500
  seat theaters open up huge possibilities for
  visualization. (more on this tomorrow).

73
Emerging Technologies

• Gaming and audience participation technologies
  begin to impact presentation spaces.
• Perhaps not relevant in the aesthetics of the
  academy or Fine Arts schools, audience
  expectations are shifting.

74
Emerging Technologies

• Theatrical spectacle now the norm for major shows
• Seen DVD - Nine Inch Nails (2003)

75
Emerging Technologies

• WHO IS THE AUDIENCE???
• (break for 15)

76
Seminar 4

• 1100-1200
• Performer Interviews
• alcides lanza, piano
• Jean-Guy Boisvert, clarinet
• Discussion of performance practice of interactive
  music (Praescio IV, VII)

77
Seminar 5Music Audio Visualization Systems
Public Presentation (90 minutes)
Friday, October 22, 2004 900 am - 1200 pm Room
LSR 3
