ICC - Irrigation Control Center

1

2
MOTOROLA in the Water Irrigation Control
Market for over than 25 Years

• MIR1080 - 1974
• MIR2000 - 1979
• MIR3000 - 1986
• MIR5000 - 1991
• IRRInet - 1996
• ICC SW - 2000
• IRRInet XL - 2002

3
IRRInet XL - System Concept
4
IRRInet XL Field Unit
Basic unit
5
IRRInet XL Field Unit
6
IRRInet XL Field Unit

• Consists of
• CPU
• Up to 3 I/O modules AC I/O, DC
  I/O, Single Cable, Analog I/O
• Power supply module
• Radio and/or line modem
• Operates also as Field Interface Unit (FIU)
• Operates with
• conventional UHF/VHF
• TETRA
• Spread Spectrum
• RS232
• RS485
• TCP/IP (LAN)

• Leased line
• Dial-up
• Wi-Fi (WLAN)
• Fiber Optic interface
• GSM\GPRS interface

7
IRRInet XL Field Unit

• IRRinet XL controls
• 500 Outputs (valves, pumps, relays etc.)
• 500 inputs (including 250 water meters)
• 500 irrigation programs
• 100 fertilizing pumps
• 100 filter batteries
• IRRInet XL may control and monitor reservoirs,
  pumps, valves, water meters, water pressure,
  water level, flow sensors, temperature, humidity
• IRRInet XL has unique condition programs for
  local process
• The IRRInet XL communicates with the central unit
  and field units (IRRIcom, IRRInet XL,Piccolo XR )
  with one or two radios
• IRRInet XL has a unique Single Cable (S.C.)
  module which controls Piccolo RTUs
• The IRRInet XL is designed to operate in rough
  environment conditions (-30 to
  60C)

8
Store Forward Application
Node
IRRInet XL allows radio Communication between
IRRInet-to-Central and IRRInet-to-IRRInet,
using existing units as nodes in the network
Store Forward feature may be utilized to pass
information from IRRInet to IRRInet throughout
the system
Area 2
9
IRRInet XL - Single Cable Concept
10
Piccolo RTU and Single Cable Advantages

• Operates via 2 X 1.5mm cable from IRRInet single
  cable module
• Controls one solenoid and receives two digital
  inputs
• Up to 63 piccolo units on one cable
• Up to 10km cable length
• IP65 plastic box housing
• No energy is required in the field. The single
  cable module provides the energy to operate
  solenoids and to receive back information data
• Optional Lightning Protection Unit (LPU) is
  available for the Single Cable module
  (better and advantageous protection )

11
Radio Piccolo-XR
12

• The Piccolo-XR RTU is a small sized unit consists
  of electronic board packed in an IP68 sealed
  waterproof plastic housing
• The unit operates up to 4 solenoids and receives
  up to 8 inputs (depends on the model). The
  Piccolo-XR has also the options of analog I/O
• The Piccolo-XR communicates via low-power radio
  to IRRInet-XL and other Piccolo-XR units for a
  distance of approximately 3 km
• Up to 256 digital inputs, 256 digital outputs, 32
  analog inputs and 32 analog outputs of
  Piccolo-XR are supported per IRRInet-XL unit
• Power external 6VDC battery
• Ambient Temperature -30 ºC to 60 ºC (-22 ºF to
  140 ºF)
• I/o options 1
  solenoid output 1 digital input
• 2 solenoid outputs 2 digital inputs
• 4 solenoid outputs 4 digital inputs

• 8 solenoid inputs
• 1 analog input
• 1 analog output

13
Piccolo-XR Communication Network
14
Piccolo-XR I/O Capabilities
15
IRRIcom AC DC

• Remotely controlled RTU from IRRInet/IRRInet XL
  FIU
• External 1-4W standard UHF/VHF radio
• Power Save Mode.
• Power is provided only to the circuits and
  elements activated by the application program.
• This unique capability is reducing battery/solar
  pannel sizes

16
IRRIcom

• Basic Hardware Capacity
• DC model 12 DC latched outputs
• AC model 12 AC outputs
• 4 dry contacts (digital) inputs
• Expansions
• 12 outputs4 digital inputs
• 18 digital inputs

Future I/O expansion 4 analog inputs1 analog
output3 digital inputs
17
IRRIcom

• Software Capacity
• 50 outputs
• 50 inputs
• 20 main lines
• 100 programs
• 50 groups
• 10 virtual meters
• 20 fertilizing pumps
• 20 fertilizing farms
• 300 conditions
• (by three condition types)

• Communication Capabilities
• RS232
• RS485
• Line
• Radio

Connecting up to 16 IRRIcoms via line, for up to
10km cable length
18
IRRIcom

• Power Source
• External 12VDC (DC model) or 24VAC (AC model)
• Internal 4.5V DC (3 standard C-Type 1.5V
  batteries)
• Internal power source for external radio
• Extra Features
• Selecting solenoids operating voltage
• (6-20V in DC model)
• Selecting input pulse width (50-1000 mSec)

19
IRRIcom

• Future Operation Modes
• Remote Mode - slave of IRRInet XL or another
  IRRIcom
• Stand-alone Mode - the IRRIcom operates a preset
  program no radio is required
• Auto Mode - switching from remote to stand-alone
  mode
• Stand-alone Remote Mode - the IRRIcom runs its
  own
• programs and may receive commands from
• an IRRInet XL or another IRRIcom

20
ICC XL- IRRInet Control Center

• SCADA software package
• Fully graphical software
• 5 password levels
• New interrogation concept
• Graphics screens for field
• elements status
• (on-off elements, levels, pressures, flows,
  quantities, temperatures etc.)
• Multi-lingual software (English, Spanish,
  Portuguese, Italian, French and more)

21
ICC XL an Open System

• Windows 2000/XP Professional compatible
• Compatibility with IRRInet/IRRInet XL/XM units
• Controls up to 999 IRRInet field units
• Open architecture system - provides easy files
  and
• database transfer (ODBC interface)

Client/Server
System many users may operate the system
concurrently, using several computers connected
through modem and/or TCP/IP.
ODBC - Open Database Connectivity Microsoft
database programming interface that provides a
common language for Windows applications to use
in accessing databases across a computer network.
22
ICC Networking Method
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Local Area Network (LAN) System Concept
27
Mixed System Concept
28
Upgrading Existing IRRInet System to IRRInet XL
? IRRInet XM
29
Scorpio - Radio Controlled Unit

• 8/16 outputs, 2/4 inputs
• Operates 24V AC and 24V DC latched solenoids
• Local programming (by keyboard)
• Communication to IRRInet/IRRInet XL
• via external radio

30
Scorpio With External Radio

• External 1-4 Watt conventional UHF / VHF radio
• Two Scorpios can be connected with RS232

• sharing one radio

• Wall mount installation
• Standard BNC connection
• for external antenna
• Power source
• 230V AC
• 115V AC
• 12V DC
• Low power consumption

31
Impact - Radio Valve

• Operates one solenoid
• Powered by 3 standard
• AA 1.5V batteries
• Includes a built-in
• UHF/VHF radio receiver
• Internal antenna
• Avoids trenching and cables installation
• Minimizes lightning damage risk
