Renal Pathology

1
Review Course

• Renal Pathology
• Stephen M. Bonsib, MD
• Professor and Chairman of Pathology, Director of
  Renal Pathology Consultative Services, Albert G.
  and Harriet G. Smith Professor of Pathology
• Louisiana State University Health Sciences Center
  in Shreveport, Louisiana

2
Challenges of Renal Pathology

• The diagnosis requires correlation of multiple
  studies LM special stains, IF and EM
• You may see the LM, but often the IF is not seen
  and the EM may not be timely
• Most gns are primary, but they may be secondary
  clinical information is crucial and influences
  the terms used in the final diagnosis.

3
Challenges of Renal PathologyExample 1

• Diseases that may be histologically identical
• Membranoproliferative gn, type 1
• Dense deposits disease/MPGN, type 2
• Hepatitis C-associated gn
• Cryoglobulinemic gn
• Diffuse proliferative lupus nephritis
• Other infectious disease-associated gns

4
Challenges of Renal PathologyExample 2

• Focal segmental glomerular scars
• Focal segmental glomerulosclerosis
• Collapsing gn
• HIV nephropathy
• IgA nephropathy
• Alports syndrome
• Other hereditary nephritis
• Inactive crescentic gn

5
Pathogenic Mechanisms in Glomerulonephritis

• 1. Immune complex/antibody negative (cytokines
  or other circulating factors)
• Minimal change disease
• Focal segmental glomerulosclerosis
• 2. Immune complex formation/deposition
• Numerous forms of glomerulonephritis
• 3. Nephrotoxic autoantibodies
• AGBM and ANCA

6
Major Types of Glomerulonephritis (patterns of
glomerular injury and secondary causes)

• LPD, NSIAD
• HIV, iv drugs, obesity, parvovirus B-19, Alports
• Infection, SLE
• SLE, Cryogl., Hep. B/C
• SLE, Hep B, neoplasms, drugs
• AGBM, ANCA, I.C.
• Henoch-Schonlein purpura
• Diabetes, paraprotein/amyloid

• Minimal change disease
• Focal segmental glomerulosclerosis
• Proliferative gns
• Membranoproliferative gn
• Membranous gn
• Crescentic gns
• IgA nephropathy
• Mesangial sclerosis

7
Terminology

• Nephrotic syndrome 3.5 g proteinuria, edema,
  hypercholesterolemia
• Nephritic syndrome acute renal failure,
  hypertension, hematuria
• Focal some glomeruli (lt 80) involved
• Diffuse most glomeruli (gt80) involved
• Segmental portion of a glomerulus involved
• Global entire glomerulus involved

8
Glomerulonephritidies to be Discussed and Major
Presentation

• Minimal change disease
• Focal-segmental GS
• Membranous gn
• Diabetic nephropathy
• Acute Post. Strept. gn
• Crescentic gns
• Membranoproliferative gns
• SLE
• IgA nephropathy
• Alports syndrome/thin BMS

• Nephrotic
• Nephrotic
• Nephrotic
• Nephrotic
• Nephritic
• Nephritic
• Nephrotic/Nephritic
• Nephrotic/Nephritic
• Nephrotic/Nephritic
• Nephrotic/nephritic

9
Glomerulonephritidies not discussed

• Fibrillary gn
• Immunotactoid gn
• Collgenous/collagenofibrotic gn
• Fibronectin gn
• C1q nephropathy
• Idiopathic nodular glomerulosclerosis
• Congenital/hereditary gns - Finnish type CNS,
  diffuse mesangial sclerosis, nail-patella
  syndrome, oligomeganephronia

10
Proteinuria / Nephrotic Syndrome

• Immune complex negative Children Adults
• Minimal change disease 95 20
• Focal segmental 5 20
• Immune complex positive
• Membranous gn. uncommon 20
• IgA nephropathy uncommon 20

11
Minimal Change Disease

• 95 pediatric and 20 adult nephrotic syndrome,
  usually normal renal function
• Biopsy
• LM - normal
• IF - negative
• EM - loss of podocyte foot processes
• Steroid responsive with an excellent prognosis
• Most important secondary causes
• Non steroidal anti-inflammatory drugs
• Lymphoproliferative disorders

12
Normal light microscopy HE stain
13
Normal glomerulus
14
Normal glomerulus
15
EM-podocyte foot process effacement
16
EM-normal capillary loop
17
Focal Segmental Glomerulosclerosis

• 5 pediatric and 20 adult nephrotic syndrome,
  normal renal function or renal insufficiency
• Biopsy
• LM - segmental sclerosis is diagnostic lesion
• IF - no immune deposits are present
• EM - foot process loss /- segmental sclerosis
• Steroid resistant and progressive in 30-50
• Secondary causes, numerous, but remember HIV
  nephropathy

18
Focal segmental glomerulosclerosis- PAS stain
19
Segmental scar - HE stain
20
Segmental scar-JMS stain
21
IF- nonspecific IgM deposits in areas of sclerosis
22
EM-hyaline, foam cell and effacement of podocyte
foot processes
23
Focal Segmental Glomerulosclerosis

• Primary/idiopathic FSGS
• Secondary/variants FSGS
• I.V. drugs
• Collapsing gn HIV, parvovirus B-19,
  pamidronate, CS2, Loa Loa
• Obesity-associated - reversible with weight
  reduction
• Familial FSGS - podocin, alpha-actinin-4
  mutations
• Congenital - Finnish type (nephrin mutation),
  DMS
• Cholesterol emboli
• Lithium
• Mitochondrial myopathies/cytopathies

24
HIV Nephropathy

• A combination of glomerular, tubular, and
  interstitial abnormalities, often with an
  ultrastructural finding that predicts HIV
  seropositivity
• Collapsing focal segmental glomerulosclerosis
• Dilated tubular casts
• Prominent interstitial inflammation and
  fibrosis
• Endothelial reticulotubular inclusions on EM
• Clinical course - rapid progression to renal
  failure over several months

25
HIV nephropathy with collapsing form of FSGS
26
HIV nephropathy-capillary loop collapse and
epithelial proliferation
27
HIV nephropathy endothelial cell
tubuloreticular inclusion
28
Membranous Glomerulonephritis

• 20 adult nephrotic syndrome, rare in children,
  normal renal function or renal insufficiency
• Biopsy
• LM - normal to thick capillary loops,
• /- spikes or pinholes on silver stain
• IF - diffuse granular capillary loop IgG/C3
• EM - diffuse subepithelial deposits
• Variable course remission, progression, or
  prolonged proteinuria
• Secondary forms Hepatitis B, SLE, drugs

29
Membranous gn
30
Membranous gn thickened capillary loops
31
Membranous gn spikes
32
IF membranous gn - IgG
33
IF membranous gn - IgG diffuse granular deposits
34
Membranous gn diffuse subepithelial deposits
with spikes
35
IgA Nephropathy

• The most common gn in the world
• 20 adult nephrotic syndrome, uncommon in
  children, usually with hematuria /- RI
• Biopsy
• LM - variable with proliferation /- sclerosis
• IF - IgA immune deposits, primarily mesangial
• EM - mesangial deposits
• Variable course
• Secondary form Henoch-Schonlein purpura

36
IF IgA nephropathy diffuse mesangial deposits
of IgA
37
IgA nephopathy mesangial proliferative pattern
38
IgA nephropathy segmented proliferative pattern
39
IgA Nephropathy crescentic pattern
40
EM- mesangial deposits of IgA
41
Diffuse ProliferativeGlomerulonephritis
Multiple Forms

• Acute post streptococcal (post infectious) gn
• Membranoproliferative gn, types 1 and 2
• Cryoglobulinemic glomerulonephritis
• Diffuse proliferative lupus nephritis (WHO class
  IV)
• Diffuse proliferative IgA nephropathy

42
HypocomplementemicGlomerulonephritis

• Acute post infectious glomerulonephritis
• Membranoproliferative glomerulonephritis
• Proliferative lupus nephritis
• Cryoglobulinemic glomerulonephritis
• Complement deficiency syndromes

43
Acute Poststreptococcal (Postinfectious)
Glomerulonephritis

• Primarily in children, uncommon in adults
• Hypocomplementemic acute nephritic syndrome
  10d-2wks following an URI (or skin, other
  infection)
• Biopsy
• LM - diffuse glomerular hypercellularity
• IF - large capillary loop /- mesangial
  deposits IgG/C3
• EM - large, infrequent hump-like
  subepithelial deposits
• Children Favorable, self-limited
• Adults progressive with a poor prognosis

44
Acute poststreptococcal glomerulonephritis
showing diffuse proliferation
45
Acute poststreptococcal glomerulonephritis-diffuse
proliferation
46
APSGN endocapillary proliferation
47
IF - APSGN large subepithelial IgG deposits
48
EMAPSGN large subepithelial deposits capillary
loop hypercellularity
49
Membranoproliferative Glomerulonephritis, type 1

• Most pediatric cases primary, most adult cases
  secondary
• Hypocomplementemic acute nephritic syndrome
• Biopsy
• LM - diffuse glomerular hypercellularity with
  GBM duplication
• IF - numerous subendothelial and mesangial
  deposits
• EM - subendothelial and mesangial deposits with
  GBM duplication
• Chronic slowly progressive course
• Secondary forms hepatitis C /- type 2
  cryoglobulinemia

50
Membranoproliferative glomerulonephritis (MPGA)
51
MPGN notice capillary loop basement membrane
duplication
52
IF - MPGN - heavy IgG deposits in capillary loop
and mesangium
53
EM MPGM subendothelial deposits
54
HEPATITIS C-ASSOCIATED MPGN (Johnson, et al.,
Kidney Int 461700, 1994)

• 75 nephrotic syndrome
• 66 elevated liver function test
• 59 cryoglobulins
• 44 extrahepatic manifestations of cryoglobulins
• Interferon therapy (3K units, 3x/wk)
• 100 decrease in proteinuria
• HCV RNA disappears from serum

55
MPGN secondary to essential mixed cryoglobulins
notice capillary loop
thrombi-like deposits
56
MPGN cryoglobulin - notice microtubular
structure
57
Prevalence of HCV Infection inVarious Types of
Glomerulonephritis(Yamabe, et al., JASN 1995)

• MPGN, Type I
• Membranous
• IgA nephropathy
• Lupus nephritis
• Minimal change disease
• Others

• 6/10 60
• 2/24 8.3
• 1/58 1.7
• 0/14 0
• 0/12 0
• 0/24 0

58
(No Transcript)
59
Dense Deposit Disease (Membranoproliferative
Glomerulonephritis, type 2)

• Clinical presentation identical to MPGN, type 1
• Biopsy
• LM - usually indistinguishable from type 1
• IF - linear C3 with mesangial rings, IgG is
  negative
• EM - electron dense transformation of the GBM
  lamina densa
• Course identical to MPGN, type 1
• Secondary forms none

60
Dense deposit disease (DDD)
61
IF - Dense deposit disease C3
62
IF DDD C3
63
EM-DDD- dense transformation of capillary loop
basement membrane
64
EM DDD
65
Crescentic Glomerulonephritis(Rapidly
Progressive Gn)

• Rapidly progressive (renal failure developing
  over 2 weeks to 2 months)
• There are a variety of causes which are most
  easily resolved by IF and serologic data
• Three categories are defined by their IF features

66
A cellular crescent
67
Tubules containing red blood cell casts
68
Capillary loop necrosis with fibrin
69
Capillary basement membrane disruption with fibrin
70
Circumferential crescent
71
Crescentic Glomerulonephritis

• Type 1 - Linear immunoflourescence
• Goodpasture syndrome
• Anti-glomerular basement membrane disease
• Type 2 - Granular immunoflourescence
• Many primary and secondary immune complex
  diseases
• Type 3 - Negative (pauci immune)
  immunoflourescence
• Predominately anti-neutrophil cytoplasmic
  antibody associated systemic vasculitis and renal
  limited crescentic gn

72
IF fibrin in a large crescent
73
Anti-glomerular Basement Membrane Diseases

• Diseases mediated by circulating anti-glomerular
  basement antibody
• Goodpasture syndrome
• Pulmonary hemorrhage and rapidly progressive
  glomerulonephritis
• Anti-glomerular basement membrane disease
• Rapidly progressive glomerulonephritis

74
IF linear reactions for IgG in Goodpastures
syndrome
75
IF linear reaction for IgG in Goodpastures
syndrome
76
Anti-neutrophil Cytoplasmic Antibodies

• A family of autoantibodies that have specificity
  for proteases located in primary granules of
  neutrophils and monocytes
• Useful in the diagnosis and monitoring of
  patients with several forms of systemic
  vasculitis and renal-limited (pauci-immune)
  crescentic glomerulonephritis

77
Anti-neutrophil CytoplasmicAntibodies

• C-ANCA - cytoplasmic pattern
• Major specificity - proteinase 3
• Major clinical association - Wegeners
  granulomatosis
• P-ANCA - perinuclear pattern
• Major specificity - myeloperoxidase
• Major clinical associations - microscopic
  polyangiitis and renal-limited crescentic gn

78
C-ANCA
P-ANCA
79
Systemic Lupus Nephritis(classification now
under revision)

• Pattern of injury
• Normal
• Mesangial proliferative
• Segmental proliferative
• Diffuse proliferative gn
• Membranous gn
• Chronic sclerosing
• Interstitial nephritis
• Vascular lesions

• WHO class
• I
• II
• III
• IV
• V
• VI
• No class designation
• No class designation

80
WHO Class II lupu nephritis
81
WHO Class II Mesangial IgG
82
WHO Class III lupus nephritis
83
WHO Class IV lupus nephritis
84
WHO Class IV wire loops
85
WHO Class IV - IgG
86
WHO Class IV IgG glomerular and
tubulointerstitial deposits
87
EM WHO Class IV wire loop subendothelial and
mesangial deposits
88
EM SLE endothelial tubuloreticular inclusion
89
WHO Class V membranous lupus nephritis
90
WHO Class V membranous SLE
91
Diabetic Nephropathy

• Gradually worsening proteinuria and renal
  insufficiency
• Leading cause of end stage renal disease
• Usually requires 8-10 years of diabetes
• Microalbuminuria indicates onset of nephropathy
• Biopsy
• LM - diffuse /- nodular mesangial sclerosis,
  arteriolar insudative lesions
• IF - negative (nonspecific linear IgG)
• EM - severe thickening of GBM, mesangial
  sclerosis

92
Diabetes Kimmelstiel-Wilson nodule
93
Diabetes afferent and efferent arteriolar
hyalinosis
94
Diabetes mesangial sclerosis and capillary loop
basement membrane thickening
95
Glomerular Type IV Collagen Diseases

• Alports hereditary nephritis mutations in the
  alpha-3, -4, or -5 chain of type IV collagen
• X-linked - most common, alpha-5 mutations
  (gt300)
• Autosomal recessive - alpha-3, or -4 mutations
• Autosomal dominant - rarest, alpha-3, or -4
  mutations
• Thin glomerular basement membrane disease
• Non progressive - alpha-3, or -4 mutations
• Progressive - alpha-5 mutations

96
Alport syndrome

• Hematuria with progressive development of
  proteinuria and renal failure
• Complex genetics
• /- hearing loss, ocular changes
• Renal biopsy
• LM - normal or segmental/global sclerosis
• IF - negative
• EM - GBM thinning /- lamellation (splitting)

97
Alport syndrome GBM lamellation
98
Thin Glomerular Basement Membrane Disease

• Hematuria with normal renal function clinically
  referred to as benign familial hematuria
• Often a positive family history of hematuria
• Non progressive (with a rare exception)
• Renal biopsy
• LM - normal
• IF - negative
• EM - GBM thickness lt200-250 nm (nl 300-350 nm)

99
Thin basement membrane disease
100
Chronic Glomerulonephritis

• Not an entity, but a final outcome, of any form
  of glomerulonephritis that progresses to renal
  failure
• Defined by the presence of gt 2/3 sclerotic
  glomeruli

101
Chronic gn diffuse glomerulosclerosis
102
Amyloidosis and Immunoglobulin (Light Chain)
Associated Diseases

• Amyloidosis
• AL-associated - primary and LPD
• Diverse secondary, familial, organ-isolated,
  and neoplasm-associated forms
• Immunoglobulin (light chain) deposition disease
• Light chain cast nephropathy

103
Amyloid and Immunoglobulin (Light
Chain)-Associated Diseases

• Amyloidosis
• Immunoglobulin (light chain) deposition disease
• Light chain cast nephropathy

• Nephrotic syndrome
• Nephrotic syndrome
• Renal failure without proteinuria

104
Amyloid
105
Amyloid silver negative deposits
106
Interstitial amyloid disposition
107
Congo Red (polarized)
Congo Red (not polarized)
108
IF - amyloid lambda reaction
109
EM amyloid fibrils
110
Light chain deposition disease
111
IF - Kappa
112
EM Subendothelial kappa light chain deposits
113
Light chain cast nephropathy
114
IF Lambda light chain casts
115
The End . . . .
