Title: SCR 101: Getting Ready for EPA 2010


1
SCR 101 Getting Ready for EPA 2010
Moderated by Guest Host Steve Sturgess,
Executive Editor, Heavy Duty Trucking Presented
by
2
Educating the Trucking Industry on 2010 SCR
Technology
  • How we got here
  • Technology Overview
  • SCRs impact
  • Fuel Economy
  • Driver Interface
  • Engine Changes
  • Aftertreatment Changes
  • Maintenance Intervals
  • SCR in use today
  • Diesel Exhaust Fluid
  • Where to get DEF
  • How often you will refill DEF
  • FAQs

3
22 Years of Truck Emission Changes
Weve Come a Long Way
1988
Particulate Matter - PM (g/bhp-hr)
By 2010, 65 trucks will emit the same amount of
Pollutants as 1 truck did in 1988
Nitrogen Oxides - NOx (g/bhp-hr)
4
What Does That Mean?
Common Terms
  • SCR Selective Catalytic Reduction
  • A vehicle emissions control technology to reduce
    diesel engine emissions for passenger cars, light
    heavy duty trucks. Reduces NOx using a reducing
    agent by converting NOx into nitrogen, water and
    tiny amounts of carbon dioxide.
  • BlueTec
  • Daimlers branded SCR emissions technology

32.5 Urea
100 DEF Diesel Exhaust Fluid
  • DEF Diesel Exhaust Fluid
  • A solution of 32.5 automotive-grade urea and
    67.5 purified water used in the SCR process
    also referred to as AUS32

67.5 Water
  • DPF Diesel Particulate Filter
  • Additional Aftertreatment hardware added to truck
    in 2007 to reduce the amount of Particulate
    Matter in the vehicles exhaust

5
Two Technologies to Meet 2010 Emissions
Selective Catalytic Reduction (SCR)
In-Cylinder EGR
SCR Catalyst
6
How EGR Works Basic Laws of Combustion
Efficiency
2002-2007 EGR
2010 EGR Only
Pre 2002 No EGR
Cool Air
EGR
Cool Air
Cool Air
EGR
  • Highest Firing Temperatures
  • Highest NOx
  • Highest Efficiency
  • Lower Firing Temperatures
  • Lower NOx
  • Lower Efficiency

EGR
Cool Air
7
How SCR Works Cleaning the Air After the Engine
Exhaust leaves the engine with the pollutants
NOx and PM
  • Exhaust

Diesel Exhaust Fluid (DEF)
Particulate Matter (PM) is trapped in the Diesel
Particulate Filter (DPF)
DEF injected into the exhaust stream
NOx PM
DEF
NOx
PM
Ammonia (NH3) and Nitrogen Oxides (NOx) react in
the catalyst to form Nitrogen and Water
NH3
DEF solution hydrolyzes into ammonia gas (NH3)
which mixes with the exhaust
SCR Catalyst
N2
H2O
8
2010 Technology Comparison
9
ECONOMY
SIMPLICITY
EXPERIENCE
DEMAND IT ALL
10
Economy For Your Business
6
Up to 5
5.8
5.6
Up to 5
Fuel Economy, MPG
5.4
5.2
5
4.8
1998
2002
2004
2007
2010
11
Simplicity For Drivers
PRE - EPA 2007
EPA 2007
EPA 2010
STOP ENGINE
CHECK ENGINE
STOP ENGINE
CHECK ENGINE
STOP ENGINE
CHECK ENGINE
DPF Regeneration Lamp
DPF Regeneration Lamp
High Exhaust Temperature Lam
High Exhaust Temperature Lam
Fuel Gauge
Malfunction Indicator Lamp (MIL)
Malfunction Indicator Lamp (MIL)
Fuel and DEF Gauge
Fuel Gauge
12
Simplicity for Drivers
FULL
EMPTY
Malfunction Indicator Lamp (MIL)
13
Simplicity Under the Hood
EPA 2007 DD15
EPA 2010 DD15
14
Simplicity Under the Hood
15
1-Box Configuration
Simplicity For Packaging
16
Simplicity For Maintenance
17
Experience for SCR
  • SCR has Experience all over the World…Over
    600,000 Trucks in operation
  • SCR 2010 Test Fleet Have Performed Extremely Well
  • Detroit Diesel Launched Our 2010 Engine in
    2007…Tried and True With Nearly 2 Billion
    Customer Miles Already

18
Where to Get Diesel Exhaust Fluid (DEF)
19
How Far Can You Go?
3 Gallons 900 Miles
6 Gallons 1800 Miles
9 Gallons 2700 Miles
12 Gallons 3600 Miles
3
6
9
12
DEF RANGE IN GALLONS
20
SCR101 Summary
  • Selective Catalytic Reduction (SCR) Is…
  • The most efficient way to meet 2010 emissions
  • Simple for truckers to operate and maintain
  • Already in use today and heavily tested in the
    United States
  • Diesel Exhaust Fluid (DEF) Is…
  • Easy and economical to purchase and simple to use

21
Question
  • Is DEF unsafe to handle? Is it flammable or
    hazardous?

Answer NO
  • Material Safety Data Sheet (MSDS)
  • Hazards Identification Urea Solution is not
    Flammable
  • First Aid Measures Wash area thoroughly with
    soap and water
  • Fire Fighting Measures Urea solution is not
    flammable
  • Transportation Information Urea solution is not
    listed by any US or Canadian transportation
    authority as a hazardous material…

22
Question
  • Does DEF become toxic at extremely high
    temperatures?

Answer NO
Urea does not become toxic at any
temperature …at 122F, DEF will still meet ISO
specifications of less than 0.2 ammonia for at
least 35 days. At that rate it would take more
than 2 years to reach the ammonia level of
household ammonia which is still not classified
as toxic James Spooner VP GM Colonial
Chemical Company
23
Question
  • Will DEF freeze at 12F?

Answer YES
Engine coolant is used to thaw DEF in tank.
System will function until DEF begins to flow.
DEF will start to freeze at 12F
EPA Requires DEF flow within 70 minutes
24
Question
  • Will DEF go bad in my truck if I operate in a hot
    climate?

Answer NO
At 86F DEF has a shelf life of 1 YEAR!
95F avg. July temp
Source Terra Industries
25
Question
Will I be able to get DEF at a reasonable price?
TA Saginaw, MI June 26, 2009 2.5 Gallons _at_
3.99/gal
Answer YES
Detroit Diesel Test Fleet June 23, 2009 275
Gallons _at_ 2.42/gal
Pilot Travel Center Brooks, OR Sept 14, 2009
Fuel Island Bulk Fill _at_ 2.79/gal
DEF is available through a variety of
distribution networks today, at affordable
prices.
26
Question
If I run out of DEF will my truck still start?
Answer YES
The DEF gauge indicates the level of DEF in the
tank and has a series of alerts when the tank is
running low
UNITED STATES ENVIRONMENTAL PROTECTION
AGENCY NATIONAL VEHICLE AND FUEL EMISSIONS
LABORATORY SUBJECT Certification Requirements
for Heavy-Duty Diesel Engines Using Selective
Catalyst Reduction (SCR) Technologies
When the DEF tank is empty …the vehicle will be
limited to 5 mph with inducement notification
27
Question
Is the packaging of SCR system complicated?
Answer NO
  • BlueTec Installation

28
SCR 101 Getting Ready for EPA 2010
Presented By Detroit Diesel Moderated by Guest
Host Steve Sturgess, Executive Editor, Heavy Duty
Trucking
