Underbalance Drilling

1
Underbalance Drilling

• Rotating Heads
• Rotating BOPs

2
(No Transcript)
3
(No Transcript)
4
Rotating HeadsRotating BOPs

• Used to divert the return flow stream down the
  blooey line, flow line or to the choke manifold.

5
Rotating Drilling Heads

• Two types of systems hydraulic active (RBOP) and
  mechanical sealing (RH)
• Both are used successfully in air and
  underbalanced wells

6
Rotating HeadMechanical Sealing Type
7
Rotating Head Mechanical Sealing Mechanism
8
Rotating BOPHydraulic ActiveRBOPTM Kelly Packer
9
Closing Unit
10
Manufacturers

• Williams
• Smith Grant
• Shaffer RSBOP (Varco)
• Northland Inter-Tech
• RBOP
• TESCO1
• Alpine - Technicorp
• Lynn International
• Others

11
Mechanical Seal Rotating Heads

• Pressure Ranges
• Low 300psi
• Medium 700psi
• High 1500psi
• Very High 3000psi
• Static pressure ranges are twice as high

12
Mechanical Sealing Rotating Heads

• Kelly Bushing
• Drive Bushing
• Swing Bolt Clamp
• Stripper Rubber

Grant - Smith
13
Conventional Rotating HeadWilliams Model 9000
Kelly Driver
500 psi rotating
Bearing Assembly
1000 psi static
Up to 200 rpm
Stripper Rubber
Geothermal model - two stripper rubbers
Bowl
14
Negative Impact to Stripper Rubber Elements

• The purpose of the stripper rubber is to provide
  a seal around the kelly as it rotates and to seal
  around the drill pipe while tripping in or out of
  the hole.

15
Stripper Rubber Composition

• Natural- Air, Mist, Foam, Gas
• Polyurethane- Oil Based below 140 F
• Nitrile - Oil Based above 140 F
• Butyl - Geothermal and H2S

16
Negative Impact to Stripper Rubber Elements

• Kelly condition is critical.
• Surface condition- check wear pattern on corners
• Bent Kellys

17
Alignment

• Rig to Stack Alignment is critical
• Check Daily
• Suspect to excessive element usage

18
Other Negative Impacts

• Drill pipe identification grooves
• Pitting and abrasion on drill pipe
• Tong and slip die damage
• Some hardbanding
• Mills and bits

19
Other Negative Impacts

• Extreme cold
• Extreme heat
• Age
• Sun light

20
Low Pressure Rotating Head
21
Medium Pressure RDH

• Pressure to 700 psi
• Single or Dual Element
• Lower Mounting Spools from 7 1/16 2000 psi to 13
  5/8- 5000 psi.
• Outlet Flanges are 7 1/16-2000/3000 psi

Grant - Smith
22
High Pressure MODEL 7000
For use on rigs with top drives or Kellys
CALL FOR SIZES AVAILABLE
23
MODEL 7000 COMPONENTS
U.S. Patent No.5,662,181 Rotating Blowout
Preventer
REMOTE MODULAR POWER UNIT
REMOTE MONITORING CONTROL CONSOLE
MODEL 7000 ROTATING CONTROL HEAD
MODEL 7000 EXPLODED CUT-AWAY VIEW
24
Rotating Head Schematics
Single Element
Dual Element
25
Main Components

• Hydraulic Oiler Lubricator/ And cooling System
• Heavy Duty Rotating Drilling Head

26
Bearing Assembly

• Contains large heavy duty tapered roller bearings
• Bearing Chamber sealed with low pressure seals
  against atmospheric pressure
• Separate high pressure seal assembly to contain
  wellbore pressure

27
Drive Assembly andStripper Rubber

• Elastomers available for oil, gas or geothermal
  drilling
• Available in single or dual element systems
• Combination one piece drive assembly and stripper
  rubber

28
KELLY DRIVERS
29
MODEL 8000/9000 STRIPPER RUBBERS

• Standard
• Heavy duty
• Oil resistant

Stripper rubber usage is determined by the
operating pressures, Kelly and drill pipe
conditions and stack alignment.
30
MODEL 9200 GEOTHERMAL STRIPPER RUBBERS

• Drill collar (1)
• Drill pipe (2)

Stripper rubber usage is determined by the
operating pressures, Kelly and drill pipe
conditions and stack alignment.
31
7000 SERIES STRIPPER RUBBERS
Stripper rubber usage is determined by the
operating pressures, Kelly and drill pipe
conditions and stack alignment.
32
CASING STRIPPER RUBBERS
Available for all models
33
LOGGING ADAPTER
Available for all models
34
SPACER SPOOLS
Available in all sizes Specify flange series and
height when ordering
TO ONLY BE USED ABOVE ANNULAR BOP
35
FLOWLINE FLANGES
Used to connect flowline to Rotating Head 7
1/16" - 3000 - w / swages from 6" - 12" 11" -
3000 - w / swages from 6" - 12"
Available for all models
36
PIPE WIPER HOLDER
Available for all models
37
OILER - LUBRICATOR
38
DRILLING NIPPLE
Available for all models
39
SNUBBING ADAPTER
40
BLANKED FLANGES
41
TEST PLUG
Available for all models
42
RBOP - Oil Tools International

• Developed by SealTech, Oryx Energy, Clayton
  Williams and Exxon
• Designed for use in High GOR wells, Wells With
  H2S and High Pressure Wells.

43
Wellhead Pressure Control

• Active pressure unit
• Multiple pressure settings
• Simple quick packer change
• 2000 psi static pressure
• 11 ID capabilities

44
(No Transcript)
45
RBOP Schematic
46
Wellhead Pressure Control
Quick-Change Packer Assembly
Kelly Drive Assembly
Inner Packer
Outer Packer
Bearing
Hydraulic Fluid Inlet
Surge Bottle
Seal
Outlet Flange
Bottom Flange
47

48
Wellhead Pressure Control

• Simple quick packer change
• Redundant element sealing
• 11 ID capabilities

49

• Multiple pressure
• settings
• Rig floor operation

50
RBOP Closing Unit
51
Shaffer Rotating Blow-Out Preventer

• 2,500 psi rotating - 5,000 psi static

52
Shaffer PCWD
53
Passing a Tool Joint
54
Techcorp 3000
55
Inner Replaceable Element
56
TESCO DOUBLE ANNULAR

• Not a rotating preventer
• Uses two small modified Shafer packers
• Used like a rotating preventor

57
(No Transcript)
58
Rotating Heads and Rotating Blow Our
PreventersSUMMARY
59
Rotating Drilling HeadsLow - High Pressure
Systems

• Mechanical Interface
• Systems
• Not API certified as a blowout preventer
• Stretch-interface seal maintained, assisted with
  wellbore pressure
• Wellsite replaceable bearing assembly

• Hydraulic Activated Systems
• Not API certified as a blowout preventer
• Sealability is electronically hydraulically
  actuated as a function of wellbore pressure
• Shop serviced bearing assembly

60
Hydraulic Lubricator Systems

• Hydraulic Active
• System
• Seal is hydraulically actuated as a function of
  wellbore pressure and lubricates the bearing
• Usually a common oil reservoir cools bearing

• Mechanical Interface System
• Seal is activated by well pressure
• Circulating system for high pressure used to
  lubricate and cool bearing -does not activate
  elements

61
Rotating Drilling HeadsHigh Pressure Systems

• Hydraulic Activated Systems
• Pressure to activate is controlled by sensor or
  manually.
• Seal is totally controllable.

• Mechanical Interface
• Systems
• Seal is always active and increases with
  increasing well pressure.
• No pressure seal is function of stretch fit.

62
END
