Applied Signal Processing Emphasizing Nonlinear Dynamics

1
Applied Signal ProcessingEmphasizing Nonlinear
Dynamics

• Presentation slides available at
• http//www.viskom.oeaw.ac.at/joydeep/course.html


2
Course Contents

• Prologue
• Modeling Basics
• Nonlinear Dynamical System Theory
• State Space Reconstruction
• Quantification of Dynamics
• Nonlinearity
• Fractal Scaling Analysis
• Modeling of Oscillatory Process Periodic
  Decomposition
• Singular Spectrum Analysis
• Time Frequency Analysis
• Hierarchical Model Based Analysis
• Neural Networks
• Polynomial based Modeling
• Multivariate Signal Processing
• Epilogue

3
Application of Applied Signal Processing One
example Human Brain
4
Nonlinearity Surrogates
Histogram
S 0.01
Original
Angle variation
Power spectrum
Histogram
Angle variation
S 0.39
Surrogate
Power spectrum
5
Nonlinearity Surrogates
Histogram
S 0.01
Original
Angle variation
Power spectrum
Histogram
Angle variation
S 0.39
Surrogate
Power spectrum
6
Scaling Analysis
ablue1.02
ared0.53
log F(n)
agreen1.46
log n
7
Scaling Analysis
ablue1.02
ared0.53
log F(n)
agreen1.46
log n
8
Synchronization
9
Henon-X x(k1) 1.4 - x2(k) -
0.3x(k-1) Henon-Y y(k1) 1.4 (Cx(k) (1
C)y(k))y(k) 0.3y(k-1) C coupling
coefficient Cxy
No coupling
Henon-Y
Coupled
Henon-X
10
Henon-X
Henon-Y
No coupling
SI(12)0.001 SI(21)0.001
11
Henon-X
Henon-Y
Very Weakly Coupled
SI(12)0.044 SI(21)0.023
12
Temporal Synchrony?
Importance of Time-Frequency Analysis
13
What is a Signal?

• Any system or a variable when measured over time
  produces a signal
• Signal ? Time Series ? Data
• Only output is available, dynamics and inputs are
  unknown
• Assumption There exists strong internal coupling
  between the variables so the scalar valued signal
  contains enough information about the underlying
  dynamics

14
Signal Processing

• Manipulation of a signal with the following
  purposes
• To remove unwanted signal components or noise
• To extract information by rendering it in a
  obvious and useful form
• To predict future values
• To detect abnormalities
• To control the dynamics of the source

15
Deterministic vs. Random

• Deterministic explicit mathematical description
  is availablee.g., height of a ball throwing
  vertically, motion of a satellite in orbit,
  temperature of fluid under external heat etc
• Random only probabilistic description, no
  explicit descriptione.g., turbulent flow,
  electrical output of a noise generator, brain
  signals (EEG) etc.

16
(No Transcript)
17
Sinusoidal Periodic Signal

• Instantaneous value at time t
• x(t) A sin(2pfotq) A amplitude fo
  frequency q initial phase angle wrt
  time origin
• Tp Period

x(t)
t
Tp
Amplitude
Ex Voltage output of an electrical
alternator,vibratory motion of an unbalanced
weight,
Frequency
fo
18
Complex Periodic Signal

• x(t) x(t nTp), n 1, 2, 3,
• It can be Fourier expanded

19
Complex Periodic Signal

• Alternatively,
• Complex periodic signal ? DC component (X0) an
  infinite number of sinusoidal components, called
  harmonics, with amplitudes Xn and phases qn.

20
Almost Periodic Signal

• Sum of two or more periodic signals with
  incommensurate period, i.e. ratio of two periods
  is not a rational number

The time profile looks close to periodic but
there is no Tp for which x(t) x(tnTp) In
general where fn/fm is not a rational number
?m,n
21
Transient Aperiodic Signal

• Transient in nature, and not periodic

A
A
A
w
x(t) A, w t 0 0, w lt t lt 0
x(t) Ae-at cos bt, t0 0, tlt0
x(t) Ae-at, t0 0, tlt0
Ex heat dissipation, damped vibration, stress in
a cable which breaks at time w
Discrete spectral representations are not
possible but continuous spectral is possible
22
(No Transcript)
23
Random Signals

• No explicit mathematical relationship
• Each observation is unique
• Also any given observation represents only one of
  many possible outputs
• Sample Function (or Sample Record) A single
  time history representing a random phenomenon
• Random (or Stochastic) Process Collection of
  all possible sample functions that the random
  phenomenon might produce
• Thus, sample record is one physical realization
  of a random process

24
x1(t)
Different Sample Records
x2(t)
xN(t)
Time, t
t1t
t1
25
Stationary Random Signal

• Mean
• Correlation
• If mx(t1) and Rxx(t1,t1t) vary as time t1
  varies, the random process x(t) is
  non-stationary
• For weakly stationary process, mx(t1) is
  constant, and Rxx(t1,t1t) depends only on time
  displacement. Thus, mx(t1) mx Rxx(t1,t1t)
  Rxx(t)
• When all possible moments and joint moments are
  time invariant, the random process x(t) is
  strictly stationary

26
Ergodic Random Signal

• Sample mean,
• Sample correlation
• If a random process x(t) is stationary, and
  mx(k) and Rxx(t,k) do not differ when computed
  over different sample records, it is called
  ergodic, i.e. mx(k) mx Rxx(t,k) Rxx(t)
• In short, for ergodic process, time average
  space average
• Ergodicity is practically important because all
  properties of ergodic random processes can be
  obtained from a single sample record
• Not all stationary processes are ergodic

27
Wold Decomposition

• A stationary process x(t) can be decomposed as
• x(t) xd(t) xr(t)
• where xd(t) ? purely deterministic part
• xr(t) ? purely random part

28
Markov Process

• Future depends on the knowledge of the present
  but not on the knowledge of the past
• A random process x(t) is a Markov process if
  Px(tdt)x(t),x(t-dt),, x(t0)
  Px(tdt)x(t)
• Order or Markov process is determined by the
  duration of past to describe the future
• Some properties
• A subset of a Markov sequence is also a Markov
  sequence
• If a Markov sequence is time reversed, it will
  still be Markov
• Px(tdt)x(t2dt),x(t3dt),, x(T)
  Px(tdt)x(t2dt)

29
Gaussian Distribution

• A random variable x(k) is called Gaussian or
  normally distributed if its probability density
  function is given bywhere

30
N-dimensional Gaussian

• Consider N random variables x1(k), x2(k), ,
  xN(k).
• Their joint distribution will be N-dimensional
  Gaussian if the associated N-fold probability
  density function is
• C is the covariance matrix of Cij, C is the
  determinant and Cij is the cofactor of Cij in
  determinant C

31
Cofactor Cij of any element Cij is defined to
be the determined of order N-1 formed by
omitting the i-th row and j-th column of C
and multiplied by (-1)ij Outstanding feature of
N-dimensional Gaussian All of its properties
are determined solely by means and covariances.
32
Random Gaussian Process (RGP)

• A random process xk(t) is said to be RGP if for
  every set of fixed times tn, the random
  variables xk(tn) follow a multidimensional
  Gaussian normal distributions.
• A linearly transformed Gaussian process is also a
  Gaussian process

33
White Noise Process

• A random sequence x(kn), x(kn-1), x(k1) is
  said to be purely white noise sequence if x(ki)
  and x(kj) are completely independent for i ? j.
• Then, conditional density is same as marginal
  density
• Px(kn) x(kn-1) Px(kn)
• Properties (i) white noise is memory less
• (ii) the present is independent of the
  past, whereas future is independent of
  present
• (iii) Ex(ki) x(kj) R dij, d is the
  Kronecker delta function.
• (iv) Usually, white noise process has
  zero mean and its power spectrum will be
  constant

34
Wiener process

• It is a stochastic process with stationary
  increments, x(s)-x(r), which are normally
  distributed with zero mean and variance
  proportional to the time difference (s-r)
• Ex(s)-x(r) 0
• Ex(s)-x(r))2 s2 s - r, s2 is a positive
  constant.
• Thus the probability density of displacement from
  time r to time s is the same as from time (rt)
  to (st) because the density depends on the
  length of time interval and not on the specific
  time reference.
• Ex Integrated white Gaussian noise

35
Poisson Process

• An integer valued stochastic process constituting
  of discrete events occurring at random time
  intervals.
• Thus x(t1)-x(t2) represents the number of events
  that occurred in the time interval (t2,t1).
• The probability of m events in the time interval
  of length t is given by
• where lt is the mean.
• The probability that no event (m0) happened in
  the interval (0,1) e-l
• The probability that at least one event happened
  in the interval (0,1) 1 - e-l

36
Process Models

• Primary requirements of a model
• Representativeness
• Parsimony
• Long-term validity


37
Some choices of Models

• Transfer-function models
• Models based on Trigonomeric fn
• State-Space models
• Models based on Orthogonal Transform
• Hierarchical models

38
Factors influencing choices

• Linearity
• No process is strictly linear but linear modeling
  is highly favored due to
• (i) simplicity
• (ii) robustness
• (iii) ease of implementation
• (iv) analytically tractable
• (v) nonlinearity can be broken into piecewise
  linearity
• Periodicity/ Regularity
• (i) strictly periodic
• (ii) almost periodic
• (iii) quasi periodic
• Stationarity
• Most models assume stationarity. Suitable
  transformations of the data are needed to achieve
  stationarity
