Low Power Processor Design: Part I

1
Low Power Processor Design Part I

• M. Balakrishnan

2
Contents

• Introduction
• Processor development history
• Data storage and movement
• Control and sequencing
• Component
• Processor Power

3
Components of Computation

• Any algorithm is a sequence of steps
• Any algorithm execution has the following
  components
• Computation perform the computation
• Data bring the data to the compute units and
  take away the results
• Control schedule and activate the steps and
  generate the associated control signals to
  bring/take away the data and perform the
  computation

4
Processors What is different?

• Processors vis-à-vis ASICs are distinguished (or
  identified) by instructions being associated
  with control
• These instructions isolate the user from the
  micro-architectural details and provide an easy
  programming paradigm

Instructions
Micro-architecture
5
Processor Developments 1971-2008

• Processor architecture over the years have
  developed in all the three components with the
  primary focus on increasing performance
• Apart from performance, complexity of
  applications and portability across platforms
  have also driven the architectural developments
• More recently, we have been forced to look into
  the impact on power due to these architectural
  developments. Now the trend exemplified by
  multi-core design is to look at performance-power
  benefits

6
Computation in Processors
Single ALU for add/sub/logic ops
Increase in effective rate of computation per
unit time (integer ops or floating ops per
second)
Increase in data word-length
Dedicated hardware op. units
Pipelined ALUs
Vector ops
Multiple ALUs (superscalar/VLIW)
7
Data Movement in Processors
Memory Single Accumulator
Increase in effective rate of memory access per
unit time
Secondary storage/ Virtual memory
Register file
Cache
Bypass paths
Write/read buffers
8
Instruction Flow
Instruction register decoder
Increase in effective rate of instructions
executed per unit time (mips)
Microprogramming
Instruction prefetch
Instruction pipelining
Speculative execution
Issue units
9
Register File Power Reduction2

• Large size register file with multiple ports is
  a key to processor performance measured in term
  of IPC (instructions per cycle).
• Such large register files consume considerable
  energy as well as delay.
• Many techniques have been used to reduce RF
  access requirements and many of them revolve
  around de-allocating the existing registers as
  soon as it is possible, which reduces the
  register pressure and thus improves performance
  for a given RF.
• Here we discuss a technique to reduce writes to
  the RF instead use the bypass network for feeding
  the operand.

10
Multi-port Register File
Multi-ported RF
ALU
ALU
11
Multi-port RF Access Energy
ReadPort 1
WriteAdr 1
ReadAdr 1
ReadPort 2
ReadAdr 2
12
Writeback Avoidance Condition

• A result value is a transient if
• The value must be short-lived. A value generated
  by instruction x is short-lived, if the target
  register of x is redefined by another instruction
  before x is written back
• There is only one consumer for this value.
• The consuming instruction is issued before the
  value is produced
• There must be no branch instruction between the
  value producer and re-definer.
• The sole consumer of the value should not be
  subject to replay caused by load latency
  mis-prediction or memory dependence
  mis-prediction.

13
Selective Writeback

• Transient values need not be written back into
  the register file but can be sent directly to the
  ALU executing units through Bypass.
• This requires three bits per register file for
  making sure the required conditions for transient
  value is met. Further check-pointing is used for
  rolling back in case of interrupts etc.

14
Register File Bypass Path
Multi-ported RF
Bypass buffer
ALU
ALU
15
Results of Selective Write-back

• Write energy is 1.8 times read energy
• 45 of the produced results are transients and
  need not be written back
• This results in 36 reduction in energy
  consumption in the RF. Assuming RF itself takes
  10 to 25 of the overall energy, this results in
  3 to 7 overall reduction.
• It also improves10.9 performance of the base
  processor. Over related techniques it improves
  performance by 5 to 10.
• The technique can be used to reduce the number of
  registers and/or ports and thus save energy.

16
Associative Memory

• A number of associative memories are getting
  used in a modern processor design. These include
  DTLB, ITLB, (Data and Instruction TLB), STQ and
  LDQ (Store and load queue).
• These are energy intensive components as both
  broadcast as well as concurrent comparison across
  all the key elements are involved at each step.
• As the key data repeats frequently, the same can
  be exploited for energy reduction.3

17
Associative Memory Structure
comparator
multiplexer
Broadcast key
key 0
data 0
key 1
data 1
match
key (n-1)
data (n-1)
encoder
18
Search Key Memoization3

• Typically high order bits repeat frequently
• The optimal dividing line between H and L bits
  vary from application to application. It is also
  a function of address allocation strategy of OS
• If the H part of the key repeats, it is neither
  broadcast nor compared again. The result of the
  previous match for H bits is stored in a
  flip-flop in each entry and that is reused

19
Key Memoization Structure
comparator
KeyL
KeyH
comparator
key 0H
key 0L
match
clock
drive-upper
20
Results

• For a 40-bit virtual address, size of L varied
  from 10 to 20 bits
• DTLB power consumption was reduced by 70 and
  ITLB by 93. For ITLB the L was only 3-bits
• More than 2-way split could reduce power further.
  With 3 components, DTLB power reduction went up
  to 81

21
Off-Chip Bus Energy Reduction

• Off-chip busses typically connect cache to the
  main memory (and possibly other peripherals).
• Studies show they also consume 10 to 23 of
  system power.
• Techniques for data encoding have been proposed
  to reduce the activity on these busses.
• More recently value caches on both sides with
  associated encoding have been used for power
  reduction.

22
Value Cache Approach

• Yang4 first proposed a cache based system for
  transmitting frequently occurring values. With a
  cache size restricted to word length (32), all
  hits can be transmitted by just toggling one bit
  with control indicating hit/miss. In miss the
  original data values are sent.

On-chip Data Cache
Off-chip Memory
Control
Value cache
Value cache
Data Bus
23
References

• V. Venkatachalam and M. Franz, Power Reduction
  Techniques for Microprocessor systems, ACM
  Computing Surveys, Vol. 37, No. 3, sep. 2005, pp.
  195-237
• D. Balkan et.al., Selective writeback exploiting
  transient values for energy-efficiency and
  performance, ISLPED 2006, Oct. 2006, pp. 37-42
• J. Sharkey et.al.,Power efficient wakeup tag
  broadcast, ICCD 2005, Oct 2005, pp. 654-661
• J.Yang et. al,FV encoding for low power data
  I/O, ISLPED 2001, Aug. 2001, pp. 84-87
