Applied Mathematics for Database Professionals

1
Applied MathematicsforDatabase Professionals

• Part two The Application

Lex de Haan and Toon Koppelaars
2
Recap Logic

• Predicate, proposition
• Logical connectives
• Rewrite rules
• Quantifiers
• Nesting of quantifiers
• More rewrite rules

3
Recap Set Theory

• Set specification
• Union, intersection, difference
• Cardinality, empty set
• Subset, powerset
• Ordered pair
• Functions, set functions
• Generalized product

4
Goal

• Logic and set theory provide discourse to

Specify database models including all involved
data integrity constraints in a formal way
Database modeling Integrity constraint modeling
5
Repeat notice

• Take a few seconds to
• Clear your mind
• Forget everything you know about data modeling,
  ER-model, UML,
• Be spongy there is a lot to tell

6
Database Model

• Model of real world we want to capture
• Every state of real world maps to state of
  model
• A database state
• We do not want model to be able to take on states
  that cannot (or should not) happen in real world
• Integrity constraints

7
Database Model
lt - - - - - - - - - - application - - - - - - - -
- - - - - gt
The Real World
A model of TRW
Queries Transactions
Map
Robust database
Business Logic
Data Integrity Constraints
Business Rules
8
Database Model

• What is a database state?
• Database state is a set of tables
• Table is a set of tuples
• Tuple is a set of attribute-value pairs
• The set of allowed database states is called
  database universe
• Database fairly complex variable
• Database universe its data type

9
Defining this Data Type
Object characterizations
10
Example Database Model
HIST
TERM
SREP
EMP
DEPT
CRS
OFFR
REG
GRD
11
Phase 1 Database Skeleton

• Bottom-up construction of a DB-Universe
• Database SkeletonPer table, what are the
  attributes
• Defines our vocabulary

12
Phase 1 Database Skeleton
DB-S (EMP -- Employees EMPNO
/ Employee number / , ENAME
/ Employee name / , JOB
/ Employee job / , BORN
/ Date of birth / , HIRED
/ Date hired / , MSAL
/ Monthly salary / , DEPTNO )
/ Department number / , (DEPT --
Departments DEPTNO / Department
number / , DNAME / Department
name / , LOC / Location
/ , MGR ) / Manager
emp-number /
13
Phase 1 External Predicates
Bridge to the real world

• Employee ENAME has unique employee number EMPNO,
  job JOB, was born at BORN, is hired at HIRED, has
  a monthly salary of MSAL dollars and works for
  the department with department number DEPTNO.
• Department DNAME has the unique department number
  DEPTNO, is located at LOC, and is managed by the
  employee with employee number MGR.

14
Phase 2 Object Characterizations

• Per attribute of tables introduced in
  skeletonWhat is its value set?
• The flesh on the skeleton

15
Phase 2 Object Characterizations
ochEMP ( EMPNO n n?num(4,0) ? n gt 999
) , ( ENAME vch(9)
) , ( JOB s s?vch(9) ?
s?'PRESIDENT','MANAGER'
,'SALESREP','TRAINER','ADMIN') , ( BORN
date ) , ( HIRED
date ) , ( MSAL
n n?num(7,2) ? n gt 0 ) , (
DEPTNO n n?num(2,0) ? n gt 0 )
Use available data types as driving sets
16
Phase 2 Object Characterizations
ochDEPT ( DEPTNO n n?num(2,0) ? n gt 0
) , ( DNAME vch(10) ) ,
( LOC vch(8) ) , ( MGR
n n?num(4,0) ? n gt 999 )
17
Phase 3 Tuple Universes

• Possible tuples
• Generalized product of object characterization
• Add to that tuple constraints ? Tuple Universes
• Predicates over different attributes in same
  tuple
• Scope of constraint the tuple

18
Phase 3 Tuple Universes
tup-EMP e e??(ochEMP) ? / We hire
adult employees only / e(BORN)
18 ? e(HIRED) ? / The president earns more
than 10K monthly / e(JOB) ? 'PRESIDENT' ?
e(MSAL) ? 10000 ? / Administrators earn
less than 5K monthly / e(JOB) ? 'ADMIN' ?
e(MSAL) ? 5000
tupDEPT d d??(ochDEPT)
19
Phase 4 Table Universes

• Possible tables
• Powerset of tuple universe
• Set of all subsets
• Add to that table constraints ? Table Universes
• Predicates over different tuples in same table
• Scope of constraint the table

20
Phase 4 Table Universes
tabEMP E E??(tupEMP) ? / EMPNO uniquely
identifies an employee / ( ?e1,e2?E
e1(EMPNO)?e2(EMPNO) ? e1?e2 ) ? / At most one
president allowed / e e?E ?
e(JOB)?'PRESIDENT' ? 1 ? / A department that
employs the president or / / a manager should
also employ at least one / / administrator
/ ( ?d? e1(DEPTNO)
e1?E ( ?e2?E e2(DEPTNO)?d ?
e2(JOB)?'PRES','MGR' ) ? ( ?e3?E
e3(DEPTNO)?d ? e3(JOB)?'ADMIN' ) )
21
Phase 4 Table Universes
tabDEPT D D??(tupDEPT) ? / Department
number uniquely identifies tuple / ( ?d1,d2?D
d1(DEPTNO)?d2(DEPTNO) ? d1?d2 ) ? /
Department name and location uniquely /
/ identify a tuple
/ ( ?d1,d2?D d1?DNAME,LOC?d2?DNAME,LOC
? d1?d2 ) ? / You cannot manage more than
two departments / ( ?m? d(MGR) d?D
d d?D ? d(MGR)?m ? 2 )
22
Phase 5 Database Universe

• Possible DB-states
• Generalized product of set of (Table-nametable-un
  iverse) pairs
• Add to that database constraints ? Database
  Universe
• Predicates over different tables in same database
  state
• Scope of constraint more than 1 table

23
Phase 5 Database Universe
DB-U s s??((EMPtab-EMP),(DEPTtab-DEPT))
? / Employee works for a known department
/ e(DEPTNO) e?s(EMP) ? d(DEPTNO)
d?s(DEPT) ? / Dept manager is a known
employee, / excluding admins and president
/ d(MGR) d?s(DEPT) ?
e(EMPNO) e?s(EMP) ? e(JOB)?'ADMIN','PRES'
? / Department manager must work for
/ / a department he/she manages
/ ( ?d1?s(DEPT) e(DEPTNO) e?s(EMP) ?
e(EMPNO)?d1(MGR) ? d2(DEPTNO) d2?s(DEPT)
? d2(mgr)d1(mgr) )
24
Phase 6 Transaction Universe

• Possible DB-state changes
• Directed graph on top of DB states
• Add to that transition-constraints ? Transaction
  Universe
• See the book

25
Goal

• Logic and set theory provide discourse to

Specify database models including all involved
data integrity constraints in a formal way
FORMAL Clear and precise
26
Benefits of This Approach

• Formal specification ? no ambiguity
• No meaning added by programmer
• Managers always manage themselves
• What are managers? What does manage
  themselves mean?
• Two salesman on duty during vacation of manager
• The same two the whole vacation?

27
Benefits of This Approach

• 2. Warning (!) and benefit
• Do NOT confront users with this formalism
• DB-professional deals with users in informal way
• Continually tries to map rules to model
• By doing so the right counter-questions will
  arise and trust will grow

The Real World
Map
Counter
Informal
The Formal Model
28
Benefits of This Approach

• Documentation dense
• Instead of 100 pages printout from repository
• 20 page document
• Risk average programmer unable to comprehend
  formal specification
• No knowledge of logic or set theory
• Create separate team of data model specialists
• Always embed informal description too

29
Benefits of This Approach

• Forces you to think clearly
• Set-oriented
• But also speak clearly
• Has spin-off to (complex) query design
• Do the formal spec first
• Play around with rewrite rules
• Then do the SQL

30
Benefits of This Approach

• Can be used to specify business logic too
• I.e. queries and transactions
• With same benefits
• Separate chapters in book

lt - - - - - - - - - - - - - application - - - - -
- - - - - gt
The Real World
A model of TRW
Queries Transactions
Map
Robust database
Business Logic
31
Benefits of This Approach

• Scope-of-data-constrained drives classification
• Closely related to implementation issues
• More issues with more scope
• Similar issues within same scope!
• Separate chapter in book on implementation
  strategies

32
Implementation Issues

• Why do we create?
• Primary keys
• Unique keys
• Foreign keys
• Check constraints
• Not because we have to

33
Implementation Issues

• DBMS vendors have barely begun to offer support
  (table database constraints)
• Tricks using MVs, complex triggers
  (serializability!)
• Huge opportunity for DBMS vendors!
• CDMRuleFrame (consulting NL)
• Based on 1994 paper (EOUG Maastricht)
• Based on Oracle7 technology
• RuleGen (personal research project)
• Based on many further insights
• Based on 10G technology

34
Summary

• Database modeling integrity constraint modeling
• Its all applied logic and set theory
• If you choose to document them
• Do it non-ambiguously
• If you choose to implement them
• Push for support in future DBMS versions
• More explanation in the book
• More examples in the book

35
End Of Part Two
Applied MathematicsforDatabase Professionals
Part two The Application
Lex de Haan and Toon Koppelaars t.koppelaars_at_centr
aal.boekhuis.nl http//web.inter.nl.net/users/T.Ko
ppelaars
Thank you for your attention I appreciate your
evaluation
36
(No Transcript)
37
RuleGen

• Takes care of
• Mutating table issue
• Locking
• Deferring
• You supply
• the when of the rule
• the how of the rule
• Including serialization logic
• All code 100 generated
