Color Perception

1
Color Perception
2
And now, a word from our sponsor

• Light is characterized by brighness and spectrum
• What really matters is how humans perceive this
  spectrum

3
Overview

• Anatomy of the eye
• Talking about Color

4
The Human Eye
5
(No Transcript)
6
Anatomy of the eye
7
Photo of Human Retina
8
Rods and Cones

• Retina is lined with lots of photoreceptors
• Rods (grey)
• Cones (color)
• red
• green
• blue

9
Rods

• perceive overall brightness but not color.
• lots of them (about 120 million)
• much more sensitive in low light levels
• evenly spaced around the retina
• not very directional
• much faster response
• light flickering
• out of the corner of your eye

10
Cones

• 3 flavors red, green, blue
• concentrated in fovea
• very few (7M)
• very directional
• not good in dark
• slower response

11
Anatomy of the Eye
12
The Fovea

• tiny pit in retina at center of vision field
• only a couple of degrees of view
• huge number of photoreceptors
• almost all detail is perceived there
• almost all cones are there

13
2d Cone Density
14
1d Cone Density
15
Filtering down the connections

• there are too many rods/cones to fit through
  optic nerve
• need to reduce the amount of information

16
Paired responses

• Each of 6 kinds has a positive color and a
  negative color

17
Green

• Green should excite the g/r neurons, suppress the
  r/g neurons and leave the rest alone

18
Red

• Red should excite the r/g neurons, suppress the
  g/r neurons and leave the rest alone

19
Light Orange

• Light orange should excite white, red and yellow.

20
Describing color

• Even though cones are R/G/B, humans do not
  usually describe colors in terms of R, G and B
• What color are these?

21
Describing color

• Even though cones are R/G/B, humans do not
  usually describe colors in terms of R, G and B
• What color are these?

Red0, Green50, Blue50
22
Describing color

• Even though cones are R/G/B, humans do not
  usually describe colors in terms of R, G and B
• What color are these?

Red0, Green50, Blue50
Red50, Green25, Blue0
23
Hue Saturation and Lightness

• a much more natural way to talk about color is
  hue, saturation and lightness.
• Hue
• what color of the rainbow is it closest to?
• Saturation
• how pure is that color?
• Lightness/Brightness
• how bright is that color?

24
Hue

• What color of the rainbow is it closest to?

25
Saturation

• How pure is that color?

26
Lightness/Brightness

• How light/bright is that color?

brightness
lightness
27
Naming colors

• of course the most natural way to describe colors
  is to use their name
• basic names
• red, orange, yellow, green, blue, violet/purple
• combinations
• red-orange, orangish yellow
• not reddish green or yellowish blue
• descriptions of objects
• teal, mocha, rust, burgundy

28
Naming colors

• not all cultures have the same number of basic
  colors

white
white
white
white
light-warm
warm
warm
red
red
yellow
yellow
black
black
black
dark-cool
dark-cool
green
cool
cool
blue
29
Naming colors

• most typical colors are the same across
  cultures
• most typically warm
• most typically red 564nm
• peak response of red cone
• most typically cool
• most typically blue or green 420nm or 534nm

• peak response of blue or green cone
• boundaries between color classes vary widely

30
Colors are relative
31
stare at me
32
stare at me
33
Retinal fatigue

• eye adjusts to staring in one place
• image burns in
• when you look away, the inverse is shown.

34
stare at me
35
stare at me

• eye starts averaging areas together so blue dot
  disappears.

36
The end
37
Visual Pathways
38
Spectral Response of Eye
39
Spectral Response of Eye (w/ colors)
40
another eye diagram
41
Phototopic efficiency
42
Sensitivity in dark
43
Relative brightness
44
Color blindness tests
45
Hidden Digit Colorblindness test
