The ORASS Approach for Designing

1
The ORA-SS Approach for Designing Semistructured
Databases

• Xiaoying Wu, Tok Wang Ling, Mong Li Lee
• National University of Singapore
• Gillian Dobbie
• University of Auckland, New Zealand

2
Outline

• Motivation
• Introduction to ORA-SS (Object-Relationship-
• Attribute ) Model
• From ORA-SS to XML DTD
• Normal form for ORA-SS schema diagram
• Designing ORA-SS schema diagram into normal
  form
• Comparison with related proposals
• Summary

3
1. Motivation

• Example 1.1 Redundancy in XML document

ltdepartmentgt ltnamegtcslt/namegt
ltprofessorgt ltstaffnumbergt12lt/staffnumber
gt ltnamegtSmithlt/namegt
ltcoursegt ltcoursecodegt230lt/coursecod
egt lttitlegtDatabaselt/titlegt
lt/coursegt lt/professorgt ltprofessorgt
ltstaffnumbergt22lt/staffnumbergt
ltnamegtJoneslt/namegt ltcoursegt
ltcoursecodegt230lt/coursecodegt
lttitlegtDatabaselt/titlegt lt/coursegt
lt/professorgt lt/departmentgt
4
1. Motivation (Cont.)

• Example 1.1 (Cont.)

5
1. Motivation (Cont.)

• Example 1.1 (Cont.)
• Corresponding ORA-SS instance diagram and schema
  diagram

6
1. Motivation (Cont.)

• Example 1.1 (Cont.)

A better Designed ORA-SS schema diagram
7
1. Motivation (Cont.)

• Example 1.1 (Cont.)

A better Designed ORA-SS instance schema diagram
8
1. Motivation (Cont.)

• Example 1.2Ambiguity in OEM database and its
  DataGgide

9
1. Motivation (Cont.)

• Example 1.2(Cont.) Ternary Relationship Type
  Representation

10
1. Motivation (Cont.)

• Example 1.2 (Cont.)Binary Relationship Type
  Representation

Note the DataGuide for the schema diagram is the
same as for the previous schema!
11
2. Introduction to ORA-SS Model

• Four concepts
• object classes
• relationship types
• attributes
• references
• Four Diagrams
• schema diagram
• instance diagram
• functional dependency diagram
• inheritance diagram

12
2. Introduction to ORA-SS Model(Cont.)

• Object Class
• attributes of object class
• Single valued
• Multi-valued
• ordering on object class

Object class employee with attributes in an
ORA-SS schema diagram
13
2. Introduction to ORA-SS Model(Cont.)

• Relationship Type
• attributes of relationship type
• Single valued
• Multi-valued
• degree of n-ary relationship type
• participation constraints of objects in
  relationship type
• disjunctive relationship type
• recursive relationship type

14
2. Introduction to ORA-SS Model(Cont.)

• Relationship type(Cont.)

Representing binary relationship type
15
2. Introduction to ORA-SS Model(Cont.)

• Relationship type(Cont.)

Representing ternary relationship type
16
2. Introduction to ORA-SS Model(Cont.)

• Attributes
• key attribute and identifier
• composite attribute
• disjunctive attribute
• attribute with unknown structure (ANY)
• ordering on attribute
• Attributes of object class/relationship type
• Single-valued / multi-valued attribute
• fixed and default values of attribute
• derived attribute

17
2. Introduction to ORA-SS Model(Cont.)

• Attributes(Cont.)

Object classes with relationship type and
attributes in an ORA-SS schema diagram
18
2. Introduction to ORA-SS Model(Cont.)

• Attributes(Cont.)

Disjunctive attribute and relationship in
an ORA-SS schema diagram
19
2. Introduction to ORA-SS Model(Cont.)

• References

Referencing an object class in an ORA-SS schema
diagram
20
2. Introduction to ORA-SS Model(Cont.)

• References (Cont.)

• Recursive relationship type in an ORA-SS schema
  diagram

Symmetric relationship sets in an ORA-SS schema
diagram
21
3. Mapping ORA-SS schema diagram to XML DTD

• Algorithm 1 Mapping ORA-SS Schema Diagram to XML
  DTD
• input an ORA-SS schema diagram SD
• output an XML DTD
• Begin
• For each object class O in SD do
• Step 1. sub-object classes of O
  lt!ELEMENT O (subelementsList)gt.
• Step 2. For each attribute A of O
• Case (1)A is a single valued simple attribute
  lt!ATTLIST O A typegt
• Case (2)A is a single valued composite
  attribute, replace A with its
• components and add them to
  lt!ATTLIST O attributeName typegt
• Case (3)A is a multivalued simple attribute
  lt!ELEMENTA (PCDATA)gt.
• Case (4)A is a multivalued composite attribute
  lt!ELEMENTA (EMPTY)gt,
• As components lt!ATTLIST
  A componentName type gt

22
3. Mapping ORA-SS schema diagram to XML DTD
(Cont.)

• Algorithm 1 mapping ORA-SS schema diagram to XML
  DTD (cont.)

Step 3. For each relationship attribute A under O
Case (1)A is a simple attribute
lt!ELEMENTA (PCDATA)gt add A to O s
subelementsList. Case (2)A is a multi-valued
simple attribute lt!ELEMENTA (PCDATA)gt
and add A to O s
subelementsList . Case (3)A is a single-valued
composite attribute lt!ELEMENTA
(PCDATA)gt. As components
lt!ATTLISTA componentName type gt. Case (4) A is
a multi-valued composite attribute
lt!ELEMENTA (PCDATA)gt. As
components lt!ATTLISTA componentName type
gt. add A to O s subelementsList. Step 4. For
each reference O-Ref Case (1) O is a child
object class of O1, and has no extra attributes
and child object classes
lt!ATTLIST O1 O-Ref IDREF(S)gt Case (2) O
is a root object class or it has nested
attributes or child object classes
lt!ATTLIST O O-Ref IDREF(S)gt
23
3. Mapping ORA-SS schema diagram to XML DTD
(Cont.)

• Example 3.1

Referencing an object class in an ORA-SS schema
diagram
24
3. Mapping ORA-SS schema diagram to XML DTD
(Cont.)

• Example 3.1 (Cont.)

An XML DTD for the ORA-SS schema diagram
25
4. Normal form for ORA-SS schema diagram

• Observation ORA-SS is similar to nested
  relations
• tree-like structure
• repeating groups or multiple occurrences of
  objects.
• e.g. the corresponding nested relation for the
  following ORA-SS schema diagram is
• Dept (dept-name, course (code, title, student
  (number, s-name, grade)))

26
4. Normal form for ORA-SS schema diagram(Cont.)

• Objectives To ensure the corresponding set of
  nested relations of the ORA-SS schema diagram is
  in normal form for set of nested relations
  (NF-NR) 5,6
• We will define
• Object class normal form (O-NF)
• Relationship type normal form (R-NF)
• ORA-SS normal form schema (ORA-SS NF)

27
4. Normal form for ORA-SS schema diagram(Cont.)

• Defn object class normal form (O-NF)
• An object class O of an ORA-SS schema diagram
  is said to be in object class normal form (O-NF),
  if the nested relation constructed by Os single
  valued attributes as its atomic attributes, Os
  multivalued attributes as its repeating groups,
  is in normal form NF-NR.

28
4. Normal form for ORA-SS schema diagram(Cont.)

• Example 4.1Assume we have following functional
  dependencies S ?dept, dept?faculty for the
  ORA-SS schema diagram

The corresponding nested relation for the schema
diagram is Staff(s,dept,faculty), it is not
in 3NF, since faculty is transitive dependent on
S , hence the relation is not in NF-NR.
A better Designed ORA-SS schema diagram
Transitive functional dependency is removed.
29
4. Normal form for ORA-SS schema diagram(Cont.)

• Defn relationship type normal form (R-NF)
• A relationship type R of an ORA-SS schema
  diagram D is said to be in relationship type
  normal form (R-NF), if the nested relation
  constructed by the identifiers of the
  participating object classes, and Rs atomic
  attributes as its atomic attributes, Rs
  multivalued attributes and composite attributes
  as its repeating groups, is in normal form NF-NR.

30
4. Normal form for ORA-SS schema diagram(Cont.)

• Example 4.2The ORA-SS schema attempts to show
  that the lecturer can teach all the courses using
  all the textbooks as described on the curriculum,
  i.e. it should satisfy a MVD constraints
  course-code??isbn staff..

The nested relation for the relationship type ctl
is ctl(course-code,isbn,staff) It is not in
4NF, so is not in NF-NR, hence the relationship
type ctl is not in R-NF.
A better design MVD is removed
31
4. Normal form for ORA-SS schema diagram(Cont.)

• Defn ORA-SS normal form schema
• An ORA-SS schema diagram D is in normal form (NF)
  iff it satisfies the
• following conditions
• 1.Every object class in D is in O-NF.
• 2.For every relationship type R in D
• (a) R is in R-NF.
• (b) Case(1) R is a binary relationship type
  from object class A to object class
• B, then all the Bs attributes can stay
  with B only if R is a one-to-many or
• one-to-one binary relationship type from
  A to B. All the attributes of R
• (if any) should be attached to B.
• Case (2) R is a n-ary relationship type with n
  (ngt2) participating object
• classes O1,O2,,On, and the path going downward
  from the top of D
• linking those object classes is /O1/O2//On, then
  for each object class
• Oi (2?i?n),
• (i) Oi should have an i-ary relationship
  Ri with its ancestors O1,O2,,Oi-1.
• (ii) The attributes of Oi can stay with
  Oi only if functional dependency
• Oi ? O1,O2,,Oi-1 can be derived
  from the functional dependency
• diagram for D. The attributes of Ri
  (if any) should be attached to Oi.
• 3.There is no relationship type nested under
  another many-to-many or many-to

32
4. Normal form for ORA-SS schema diagram(Cont.)

• Example 4.4 The ORA-SS schema diagram is not in
  NF, if professor is also an employee in the
  department the qualification of a professor can
  be derived from that of employee, such
  information will be repeated in the underlying
  databases.

A ORA-SS schema diagram that not in NF
A ORA-SS schema diagram that in NF
33
5. Converting ORA-SS Schema Diagrams into Normal
Form

• Two Approaches for Designing Semistructured
  Databases
• Approach 1.
• based on the users requirements, come out an
  initial ORA-SS schema diagram
• normalize the ORA-SS schema diagram to its normal
  form
• map it to an XML DTD or XML Schema
• Approach 2.
• Extract schema from the instances using the
  schema extracting techniques.
• Translate the schema into ORA-SS schema diagram.
  Here we need semantic enrichment, since not all
  semantics needed are available from the extracted
  schema.
• Convert the ORA-SS schema diagram into its normal
  form.
• translate the NF ORA-SS schema diagram back to
  XML DTD or XML Schema.
• Restructuring the initial data instance to
  conform to the generated XML DTD or XML Schema.

34
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Algorithm 2 Converting an ORA-SS schema diagram
  into NF ORA-SS
• schema diagram.
• Input an ORA-SS schema diagram SD, and its
  functional dependency diagram.
• Output a NF ORA-SS schema diagram.
• step 1. Convert any non O-NF object class to
  O-NF.
• step 2. Make each relationship type R in R-NF.
• step 3. This step involves two sub-steps.
• (1) Construct diagrams for each
  object class with their attributes.
• (2) Represent each relationship
  type R. We make R satisfy the item (b)
• of condition 2 as well as
  condition 3 of the NF definition by introducing
• referencing object classes,
  and requiring each relationship type start
• with an object class with
  attributes (i.e., non-reference object class).
• step 4. Remove those relationship types along
  with their associated attributes
• that can be derived from other
  relationship types in the schema diagram
• to satisfy condition 4 of NF
  definition.

35
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.1
• There is a many-to-many binary relationship pc
  between professor and course, and a many-to-many
  binary relationship ct between course and
  textbook.
• It is not in NF ORA-SS since it violates the
  condition 3 of the NF definition.

.
(a) Initial ORA-SS schema diagram
36
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.1 (Cont.)
• Step 1. The three given object classes are
  already in O-NF.
• Step 2. The two relationship type pc and ct are
  already in R-NF.
• Step 3.
• (1) generate three diagrams for the object
  classes with attributes.

(b) Fragment diagrams for object classes
37
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.1 (Cont.)
• Step 3.(Cont.)
• (2) represent the binary relationship
  pc, by creating a reference
• object class course1 referencing
  course and nest course1
• under professor

(c) Diagrams after representing relationship pc
38
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.1 (Cont.)
• Step 3.(Cont.)
• (2) represent the binary
  relationship ct, by creating a
• reference object class
  textbook1 referencing textbook
• and nest textbook1 under
  course.

(d) Final ORA-SS schema diagram that in NF
Step 4.(passed). The schema generated is in NF.
39
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.2.
• There is a binary relationship cs between
  course and student and a ternary relationship cst
  between course, student and tutor. The grade is
  an attribute of the binary relationship cs, and
  feedback is an attribute of the ternary
  relationship cst.
• It is not in NF ORA-SS since it violates the item
  (ii) of case 2 in condition 2-(b) of NF
  definition.

(a) Initial ORA-SS schema diagram
40
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.2(Cont.)
• Step 1. The three given object classes are
  already in O-NF.
• Step 2.The two relationship type cs and cst are
  already in R-NF.
• Step 3.
• (1) generate three diagrams for the object
  classes with attributes.

(b) Fragment diagrams for object classes
41
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.2 (Cont.)
• Step 3.(Cont.)
• (2) represent the binary relationship cs.
  we create a reference
• object class student1 referencing
  student and nest student1
• under course. Relationship
  attribute grade is attached to
• student1.

(c) Diagram representing binary relationship cs
42
5. Converting ORA-SS Schema Diagrams into Normal
Form(Cont.)

• Example 5.2 (Cont.)
• Step 3.(Cont.)
• (2) represent the relationship cst. we
  create a reference object class
• tutor1 referencing tutor, and nest
  tutor1 under student1. Relationship
• attribute feedback is attached to
  tutor1.

(d) Final ORA-SS schema diagram that in NF
Step 4.(passed). The schema generated is in NF.
43
6. Comparison with Related Proposal

• The first attempt to define normal form for
  semistructured data4
• Defines a schema called S3-Graph, a labeled graph
  in which vertices correspond to objects and edges
  represent the object-subobject relationship. Its
  data instance is called semistructured data
  graph.
• S3-Graph cannot show the degree of a n-ary
  relationship type, neither can it distinguish
  between attributes of object classes and
  attributes of relationships types.

44
6. Comparison with Related Proposal(Cont.)

• The first attempt to define normal form for
  semistructured data4 (Cont.)
• Defined a dependency constraint SS-dependency.
• Proposes S3-NF. An S3-Graph is in S3-NF if there
  is no transitive SS-dependency. Hence, only this
  kind of redundancy can be recognized by S3-NF

45
6. Comparison with Related Proposal(Cont.)

• The first attempt to define normal form for
  semistructured data4 (Cont.)
• Presents two approaches to design S3-NF databases

• The decomposition method can remove identified
  transitive SS-dependency and achieve S3-NF, while
  may not able to remove the partial functional
  dependency inside an entity type or object
  classes, as well as the redundancy result from
  over-nesting.
• The transformation of a normal form ER diagram
  into an S3-Graph. The result may not be unique
  but is dependent on the path constructed. Hence
  some results may not satisfy the application
  requirements and comply with the users
  viewpoints.

46
6. Comparison with Related Proposal(Cont.)

• The most recent proposal XNF (XML Normal
  Form)2
• It mainly provides algorithms to translate a
  schema, represented in a conceptual model called
  CM hypergraph to a scheme-tree forest in XNF.
• CM hypergraph has no concept of attribute (so too
  many objects) and no hierarchical structure.
• The given algorithms are non-deterministic, and
  suffers from efficiency.
• Adding new required information requires redesign
  schema.
• The algorithms generate a large no of solutions
  rather than verifying whether a SS schema is in
  normal form or not.
• ISA hierarchies are removed from CM hypergraph
  before input to the algorithms.

47
6. Comparison with Related Proposal(Cont.)

• The advantages of our proposal
• 2-level design incremental and iterative
• First, identify or figure out object classes,and
  relationship types from user requirements.
• Then add attributes for object classes and
  relationship types.
• In contrast, XNF requires all the
  needed
• information to be presented at once.
  Even a
• small change in information
  requirements
• requires redesign the whole schema.

48
6. Comparison with Related Proposal(Cont.)

• The advantages of our proposal (Cont.)
• Preserve the hierarchical structure satisfying
  users requirements.
• In contrast, since CM graph has no
  hierarchy,
• XNF needs to generate many solutions.
  The
• approach fails when user already has a
• hierarchical structure, and wants to
  preserve
• it and verifies the design is good or
  not.

49
7. Summary

• ORA-SS model helps to detect redundancy in
  semistructured data.
• We need a normal form for ORA-SS, since ORA-SS
  schema diagrams may contain redundancies and
  suffers from considerable updating anomalies.
• We define a normal form ORA-SS schema diagram. It
  ensures
• no unnecessary redundancy and
• no updating anomalies for semistructured
  databases generated from the schema .
• We present an algorithm for mapping ORA-SS schema
  diagram into XML DTD/Schema

50
7. Summary (Cont.)

• We give a design methodology and present a
  comprehensive algorithm for normalizing an ORA-SS
  schema diagram into its normal form. The steps
  presented can also be used as guidelines for
  designing semistructured databases using the
  ORA-SS model
• As ORA-SS distinguished objects Vs. attributes,
  the design complexity is reduced.
• ORA-SS allows 2 levels of design first object
  classes and relationship type then add in
  attributes.
• We show that ORA-SS design approach outperform
  other related proposals.

51
References

• G.Dobbie, X.Y.Wu, T.W.Ling and M.L.Lee. ORA-SS
  An Object-Relationship-Attribute Model for
  Semistructured Data. Technical Report TR21/00,
  School of Computing, National University of
  Singapore, 2000.
• D.W.Embley and W.Y.Mok. Developing XML Documents
  with Guaranteed Good Properties. ER 2001.
• R. Goldman and J. Widom. DataGuides Enabling
  Query Formulation and Optimization in
  Semistructured Databases. Proceedings of the
  Twenty-Third International Conference on Very
  Large Data Bases, pages 436-445, Athens, Greece,
  August 1997.
• S. Y. Lee, M. L. Lee, T. W. Ling and L. A..
  Kalinichenko. Designing Good Semi-structured
  Databases. ER 1999 131-145
• T.W. Ling. A Normal Form for Entity-Relationship
  Diagrams. Proc. 4th International Conference on
  Entity-Relationship Approach (1985)
• T. W. Ling. A normal form for sets of
  not-necessarily normalized relations. In
  Proceedings of the 22nd Hawaii International
  Conference on System Sciences, pp. 578-586.
  United States IEEE Computer Society Press, 1989.
• X.Y.Wu, T.W. Ling, M.L.Lee, G.Dobbie. Designing
  Semistructured Databases Using ORA-SS Model, in
  Proceedings of the 2nd International Conference
  on Web Information Systems Engineering (WISE),
  IEEE Computer Society Kyoto, Japan, December 2001.
