An Overview of: Partially Observable Markov Decision Process

1
An Overview of Partially Observable Markov
Decision Process

• Dr Karl Altenburg
• 18 OCT 02

2
Introduction

• The operation of a UAV (or any automated device)
  is dependent of decisions and actions
• The decision of which action to take is typically
  based on the state of the environment
• if sense_a_target then strike
• if sense_a_threat then avoid
• Understandably, given limited sensors, a UAVs
  view of the state of the environment is only
  partially complete
• It cant see through mountains, for example

3
Introduction

• A challenge in the design of intelligent agents,
  such as a UAV, is to find a very effective
  mapping of actions for various environmental
  states, even if the agent isnt completely sure
  what environmental its in

4
Markov Chains

• Developed by A.A. Markov in 1906
• Markov chains applied to chains of events
• Repeated trials
• Outcomes depend only on the outcome of the
  previous trial
• Each experiment has a finite fixed number of
  outcome called states
• The outcomes may be stochastic, that is, entry
  into the next state is based on a probability

5
Markov Chains

• A Markov process may be depicted as a state
  transition diagram where the nodes are states and
  the transitions are probabilities leading to the
  succeeding state

0.5
heads
tails
0.5
0.5
0.5
6
STDs and Agent Specification

• State Transitions Diagrams are also used to
  depict finite state automata, which are often
  used to describe, and even specify, autonomous
  agent behavior

7
FSM and Agents
8
Partially Observable Markov Decision Process

• For a good introduction see
• Atrash A, Koenig S. 2001. Probabilistic Planning
  for Behavior-Based Robotics. GA Tech/AAAI.
• Describes a police robot that has a noisy sensor
  and the task of
• searching rooms for victims
• avoiding rooms with terrorists
• Avoiding rooms with victims is bad
• Searching rooms with terrorists is worse

9
POMDP

• A POMDP may be described as follows
• S finite set of states
• O finite set of observations
• ? initial state distribution
• s current state
• A(s) set of actions for that state
• a an action
• p(s s, a) transition function
• q(o s, a) observation function
• r(s, a) reward function

10
(No Transcript)
11
POMDP and Policy Graphs

• Given some observed state of the world, a
  decision maker must take some action, which
  results in a new observation and a reward
• The mapping of actions and observations may be
  done with a policy graph
• Nodes are actions
• Arcs are observations

12
(No Transcript)
13
Policy Graph

• The objective of the planner is to derive a
  policy (graph) that maximizes the average total
  reward over an infinite planning horizon (not
  sure when things will end)
• ? a discount factor
• Typically set to slightly less than 1.0 (i.e.,
  0.9) to assure that total reward is always finite

14
Policy Graph

• Mapping policy graphs to finite state automata is
  strait forward
• Note
• Optimal policy graphs can potentially be large
  but often are not
• Finding optimal policy graph is PSPACE-complete
  (see, Papadimitriou Tsitsiklis), and only
  feasible for small planning tasks
• There may be unreachable nodes, which can be
  removed

15
(No Transcript)
16
POMDP vs. FSM

• POMDP assume discrete actions and observations
  made after each action
• FSM assume continuous behavior and triggers could
  be observed at any time
• POMDP planners assume every observation can be
  made in every state
• Leads to a combinatorial explosion
• FSM ignore non-trigger observations
• Atomic packaging and abstracting of actions are
  solutions to these differences

17
Ideas

• Enter or continue is very much like our UAV
  search or strike question
• POMDP appear to be a good fit of a formal model
  for planning to emergent swarm intelligence
• Work needs to be done to clearly define the set
  of states, actions, observation, and rewards
