(More) Biologically Plausible Learning

1
(More) Biologically PlausibleLearning

• Psych 419/719
• March 13, 2001

2
A Bit About Neurons
3
There are a lot of them...

• It has been estimated that the brain has about
  1011 or so neurons
• Each neuron on average connects to about 1,000
  synapses
• So thats about 1014 connections

4
Action Potentials

• At rest, the charge across a neurons membrane is
  slightly negative
• When a neuron is stimulated strongly enough, an
  action potential results.
• A wave of positive charge that propagates along
  the axon or dendrite
• Kind of like a cable
• Tend to be all-or-nothing. If stimulation is
  enough, you get a spike. Otherwise, nothing.

5
Motion of Electrical Charge
6
In Models Weve Considered..

• Some output a floating point value, say 0 to 1
• Can be thought of as the firing rate. Neurons
  fire at around 2-400 hz (give or take)
• Some stochastic networks weve considered either
  are on or off, probabilistically
• But are typically time-locked

7
The Problem with Backprop

• In backprop, activity proceeds from one unit to
  another along weighted connections. Fine.
• But error proceeds backwards along those same
  connections.
• That doesnt seem to happen with real neurons...

8
(Broadly) How the BrainIs Connected
9
Different Layers Often WorkAt Different Levels
of Abstraction

• Area V1 codes things like line segments, local
  colors and such
• Have a small receptive field
• Higher areas (like IT) code for objects
• Much larger receptive field

10
This Isnt How We (Typically) Do Things

• We allow excitatory and inhibitory connections to
  be intermixed
• Dont tend to constrain connectivity in this way
• We (generally) dont force our units to have
  restricted receptive fields. Hidden units tend to
  see the whole input

11
Competitive Learning

• Here, we can force pools of units to compete with
  each other in a winner-take-all fashion
• Competition can be done explicitly, or through
  lateral inhibition

12
The Idea...

• Each unit in a cluster gets input from same units
• A unit learns if and only if it wins the
  competition within its cluster
• Each units total input weight is the same

13
Mathematically..

• c determines if unit i is on for pattern k
• n is the number of active units in pattern k

14
What it Means

• Each winning units weight decays in proportion
  to g
• But gains some weight in proportion to g, and how
  many input are on.
• Shifts weight from inactive to active unit lines.
  Makes it more sensitive to what was going on in
  the input

15
An Alternate Formulation

• If a unit always loses, something still happens
  to it.
• Strength of what happens for winner is higher
  than for loser

16
What Happens

• Based on the statistics of the input, the network
  shifts its weights to respond selectively to
  common patterns
• Level of activity across units comes to reflect
  the structure of the input
• Has an inductive bias

17
Inductive Biases

• Form a reduced representation - preform
  dimensionality reduction
• Identify abstract or relational features which
  predict other inputs (e.g., QU)
• A coarse code
• A sparse code - independent components
• Topological features in the structure of inputs

18
Finding k Means
19
Restricting Input
Instead of each unit receiving input from each
input unit, only from a set of organized input
units
The receptive field of each unit can overlap
with other ones, but not totally
20
Local Excitation, Distal Inhibition

• We can arrange our lateral connections in space
  so that units near us are excited by us, and
  those further away are inhibited
• Can help preserve topology of inputs

-
Space
21
Ex Retinotopic Mapping

• The connections from the retina to visual area V1
  preserve the approximate topology of the retina
• How? Takes a lot of DNA to prescribe that
• Von Der Malsburgs solution combine inhibition
  and excitation in right spatial configuration

22
The 1D Case
Either line preserves topology
Output Units
Inhibition and excitation depending on location
Input Units
23
Phoneme Discrimination

• The phenomena Young Japanese infants (less than
  8 months) can distinguish the /r/ and /l/ phoneme
• They lose this ability as they get older
  phonemes are not contrastive in their language
• Lost discrimination seems resilient to experience

24
A Theory...

• In a backprop net, exposures to training generate
  error if you make the wrong output. Thus, errors
  should get fixed over time.
• Doesnt seem to happen with such critical
  period effects like the /r/ - /l/ distinction
• With hebb learning, your output gets reinforced,
  even if its wrong.

25
A Solution

• Generate stimuli that is so far outside of the
  normal range, that conditioned response cant
  happen
• Thus, conditioned response isnt reinforced
• And unlearning can occur.

26
The /r/ - /l/ Intervention

• Based on a competitive map of phoneme space
  system learns to map similar sounds to the same
  representation.
• If you bombard the system with stimuli that are
  similar to what its seen, but different enough to
  force a new representation, these items can be
  discriminated
• As can the more similar ones

27
The Experiment

• Expose subjects to exaggerated tokens of
  language. No feedback
• Adaptive case push the contrast so that they
  dont reinforce wrong results
• Non-Adaptive case used fixed contrasts
• Result Both improved perception
• Adaptive case more so than non-adaptive

28
Upcoming...

• Next class
• Reinforcement learning. No required reading
• Hand in project proposals
• Homework 4 handed out
• Next Tuesday Steve Gotts guest lecture
• Next Thursday Anthony Cate guest lecture
