TINA Concepts that are Actually Turning into
Reality With IP and NGN

• Jean Craveur, Fabrice Dupuy, Jean-Marc Pageot,
  Stéphane Pensivy

2
Outline

• Seven years that have being turned into one, by
  Internet
• Concepts that are turning into reality
• The Business Model
• The Retailer
• The Service Architecture
• The need of API
• Some Technical issues that are still to be looked
  at
• Conclusion

3
Seven years that have being turned into one, by
InternetSince 1993...

• TINA consortium birth!
• The 1993 main focus IN / PSTN, ATM, QoS,
  VoD/Videoconferencing
• Telecommunication experts forecast the value
  will be more and more on the (value added)
  services and content provisioning (compared to
  pipe provisioning, or dumb network)
• TINA, a group of technical experts defining the
  basis of
• an architecture that clearly splits the service
  layer and the transport layer with a high focus
  on the above mentioned acronyms and services
• the first business model based on the cooperation
  of different service providers
• the convergence between (up-to-date)
  Telecommunication Technologies and (up-to-date)
  Information Technologies (IT), particularly
  through the use of DPEs (Distributed Processing
  Environment)
• ... for a business case, not totally identified

4
Seven years that have being turned into one, by
Internet ... to 2000

• The technical evolution...
• The Internet phenomena !!!
• The mobile market boom !!!!
• 330 millions subscribers in Europe, in June 2000
• The NGN wave, ridden also by new entrant
  manufacturers
• ... associated with the regulatory and market
  evolution and pressure...
• copper local loop unbundling
• radio local loop unbundling
• UMTS standard favouring the third party service
  providers
• ... bring the missing business cases and make
  some TINA principles more up-to-date than ever
• the business model,
• the need of a Service Architecture
• the use of the latest IT technologies and
  off-the-shelves environments

5
Concepts That are Turning into RealityThe
Business Model

• Deregulation, market demands make necessary to
  define the business responsibilities - An overall
  architecture is needed
• various on-going activities (ITU-T, ETSI, IETF,
  MSF, ISC, OMG..)
• The TINA work gets acceptance in various bodies
• adoption of TINA business model by ITU-T SG11
• adoption of (Ret) reference point by OMG TSAS
• The separation between Service Provider and
  Network Resource Provider
• Hot topic and spread concern (NGN, 3G mobile)!!!!
• Various on-going activities such as Jain or
  Parlay (with TINA Access Session semantic for the
  Parlay framework)
• The result of this work has to be endorsed by
  bodies driven by specific business cases
• Parlay phase 2 adopted in UMTS for VHE

6
Concepts That are Turning into RealityThe
Retailer

• TINA SA 5.0 definition ...providing Customers
  access to services
• The concept was appealing but without clear
  business cases few years ago...
• The telecommunication landscape evolution makes
  the separation between access and services a
  cornerstone
• local loop unbundling
• NGN advent with access and residential gateways
• customers portal accessible from different
  devices (WAP phone, PC,...) and access networks
  (ADSL, GSM, GPRS)
• A good ground is naturally the Retailer Platform
  specifications, and the notion of TINA Access
  Session

7
Concepts That are Turning into RealityThe
Service Architecture

• TINA SA 5.0 objectives
• Objective 8 Definition of partition and
  layering principles leading to the separation of
  services from the network and computing
  infrastructure and related resources
• Objective 9 Definition of interfaces providing
  an abstract view of the network and computing
  infrastructure that enables service applications
  to make use of network and computing resources
  transparently
• Objective 10 Definition of principles and
  mechanisms that allow third-party development of
  services and applications

8
Concepts That are Turning into RealityThe Need
of API

• Shortening time-to-market is also facilitated by
  the shortening the service development process
• The service development process must be open
• in term of tools and environment - towards
  off-the-shelves tools environment
• in term of actors - towards open and published
  interface
• The notion of API is a enabling factor to ease
  and speed this step
• numerous tolls and environment (C libraries or
  Java packages) available
• These tools and environment are already mastered
  by a large community of developers - The Internet
  community
• API vs Protocol they are complementary
• use of protocols for specifying interaction
  between remote systems
• use of APIs to ease the service development
  process
• The success of APIs in telecommunication business
  and market relies highly on their ability to be
  consistent with legacy telecommunication protocols

9
Study caseWhich Service Platform for NGN

• Risk of loosing the separation brought by IN
  between the service logic and call control!!!

10
Some technical issues that are still to be looked
at

• Multi-party Call Control
• A real requirement from service provider, that
  implies a sophisticated flexible accounting
  system, not fully implemented yet
• Hopefully, in the new NGN products, less
  constrained (SIP, H.323)
• Intelligent Peripheral Integration in a NGN
  network
• The Intelligent Peripheral will evolve toward an
  Internet Integration (IP-IP)
• These will create IP subnetworks with specific
  QoS requirements to manage by the service
  providers
• Services Interaction
• The profile notion and its externalisation that
  will be more and more crucial do not solve the
  problem of consistency execution of various
  services.
• First step For a service provider, to list the
  information manipulated by its services to be
  able to detect the potential concurrency access
  of various services on the same information.
• Second step Build a consistent execution of the
  various services. Yet an open issue with some
  solutions to investigate.

11
Conclusion

• Not all specifications bodies manage to turn
  their results into standard de facto, widely
  accepted by the market. Let us remind that TINA-C
  primary aim was RD cooperation, i.e.
  collaborative assessment of technology innovation
• Even if TINA is not a standard de facto, the
  Consortium has been particularly successful in
  anticipating, vulgarising, influencing, promoting
  concepts/ideas.
• Since 1993, the telecommunications context has
  changed dramatically IP, mobile, NGN.
• The best TINA concepts are naturally turning into
  specifications and products in the bodies
  addressing specific market needs (3GPP, OMG,
  IETF, SoftSwitch, etc)
