EXCEL-Project, Applications of Calculus (part
A)Entropy Function and Decision Tree Classifiers

• Faculty Mollaghasemi, Georgiopoulos
• Graduate Students Sentelle and Kaylani
• Dates August 29 and September 5, 2006

2
Presentation Outline

• Introduction and Motivation
• Calculus Problems from your Textbook
• Problem 29, page 47
• Problem 31, page 47
• Problem 37, page 47
• Machine Learning and Applications
• Decision Tree Classifier
• An Example
• Designing a Decision Tree Classifier
• Learning Objective 1 Constructing the Entropy
  Function
• Learning Objective 2 Design a Decision Tree
  Classifier for an Example
• Learning Objective 3 Using a Decision Tree Tool

3
Introduction and Motivation The Entropy Function

• This module will introduce to you the idea of the
  entropy function and its usefulness in the design
  of decision tree classifiers
• In Mathematics a classifier is a function from a
  discrete (or continuous) feature space X (domain)
  to a discrete set of labels
• Y (range of the function)
• An example of a classifier is one which accepts
  as inputs a persons salary details, age, marital
  status, home address and previous credit card
  history and classifies the person as acceptable
  or unacceptable to receive a credit card, or a
  loan

4
Introduction and Motivation The Entropy Function

• A decision tree classifier is being built by
  splitting the space of the input features (domain
  of the function) into smaller sub-spaces, in a
  way that all the points in these smaller
  sub-spaces are mapped to the same label (value
  from the range of the function)
• The splitting of the input space into smaller
  sub-spaces is accomplished by using a
  mathematical function, called entropy
  (uncertainty, disorder) function, introduced by
  Claude Shannon
• Observe, in the following figures, a
  classification problem (IRIS Flower
  Classification Problem), and possible splits of
  the input space into sub-spaces and why these
  splits are important in the design of the
  classifier

5
Introduction and Motivation Iris Flower
Classification Problem

• Iris data consists of 150 data-points of three
  different types (labels) of flowers
• Iris Setosa
• Iris Versicolor
• Iris Virginica
• Each datum has four features
• Sepal Length (cm) (Feature 1)
• Sepal Width (cm) (Feature 2)
• Petal Length (cm) (Feature 3)
• Petal Width (cm) (Feature 4)
• 120 of the 150 points are used for the design of
  the classifier
• 30 of the 150 points are used for the testing of
  the classifier

6
Introduction and Motivation Iris Flower
Classification Problem
7
Introduction and Motivation Iris Flower
Classification Problem
8
Introduction and Motivation Iris Flower
Classification Problem
9
Introduction and Motivation Iris Flower
Classification Problem
10
Introduction and Motivation The Entropy Function

• The entropy (uncertainty, disorder) function of a
  two-label (label A and B) dataset, where p is the
  probability that the datum in the dataset is of
  label A is defined as follows

11
Introduction and Motivation The Entropy Function

• The entropy (uncertainty, disorder) function of
  a dataset is used in a decision tree classifier
  to split the space of the input features into
  smaller sub-spaces that contain data (objects) of
  a single label, or expressed differently, data of
  0 uncertainty (disorder)
• Remember the Iris Flower Dataset

12
Introduction and Motivation The Entropy Function

• The entropy function is related to your Calculus
  topic, entitled, Combinations of Functions (page
  42 of your Calculus textbook) and Composition of
  Functions (page 43 of your Calculus textbook)
  because in order to construct the entropy
  function you need
• Multiplication of functions, such as in
• Composition of functions, such as in
• Addition of functions, such as in

13
Problems from your Calculus Book Problem 29,
Page 47
14
Problems from your Calculus Book Problem 31,
Page 47
15
Problems from your Calculus Book Problem 31,
Page 47
16
Problems from your Calculus Book Problem 31,
Page 47
17
Problems from your Calculus Book Problem 31,
Page 47
18
Problems from your Calculus Book Problem 31,
Page 47
19
Problems from your Calculus Book Problem 31,
Page 47
20
Problems from your Calculus Book Problem 37,
Page 47

• The following functions are given to you
• The composite function is defined as
• The domain of the composite function is defined
  to be the interval

21
Decision Tree Classifier Applications

• Medical Applications
• Wisconsin Breast Cancer (predict whether a tissue
  sample taken from a patient is malignant or
  benign two classes, nine numerical attributes)
• Bupa Livers Disorder (predict whether or not a
  male patient has a liver disorder based on blood
  tests and alcohol consumption two classes, six
  numerical attributes)

22
Decision Tree Classifier Applications

• Medical Applications
• PIMA Indian Diabetes (the patients are females at
  least 21 years old of Pima Indian heritage living
  near Phoenix, Arizona the problem is to predict
  whether a patient would test positive for
  diabetes there are two classes, seven numerical
  attributes)
• Heart Disease (the problem here is to predict the
  presence or absence of heart disease based on
  various medical tests there are two classes,
  seven numerical attributes and six categorical
  attributes)

23
Decision Tree Classifier Applications

• Image Recognition Applications
• Satellite Image (this dataset gives the
  multi-spectral values of pixels within 3x3
  neighborhoods in a satellite image, and the
  classification associated with the central pixel
  the aim is to predict the classification given
  the multi-spectral values. There are six classes
  and thirty six numerical attributes)
• Image Segmentation (this is a database of seven
  outdoor images every pixel should be classified
  as brickface, sky, foliage, cement, window, path,
  or grass there are seven classes and nineteen
  numerical attributes)

24
Decision Tree Classifier Applications

• Other Applications
• Boston Housing (this dataset gives housing values
  in Boston suburbs there are three classes,
  twelve numerical attributes, one binary
  attribute)
• Congressional Voting Records (this database gives
  the votes of each member of the U.S. House of
  Representatives of the 98th Congress on sixteen
  key issues the problem is to classify a
  congressman as a Democrat, or a Republican based
  on the sixteen votes there are two classes,
  sixteen categorical attributes (yea, nay,
  neither)

25
A Case Study Iris Flower Data Hand-Crafting a
Classifier

• Iris data consists of 150 data-points of three
  different types of flowers
• Iris Setosa
• Iris Versicolor
• Iris Virginica
• Each datum has four features
• Sepal Length (cm) (Feature 1)
• Sepal Width (cm) (Feature 2)
• Petal Length (cm) (Feature 3)
• Petal Width (cm) (Feature 4)
• 120 of the 150 points are used for the design of
  the classifier
• 30 of the 150 points are used for the testing of
  the classifier

26
A Case Study Iris Flower Data Visualization
of the Iris Features
27
A Case Study Iris Flower Data A Hand-Crafted
Classifier
28
A Case Study Iris Flower Data Testing the
Hand-Crafted Classifier
29
Design of a Decision Tree Classifier An
Example
30
Design of a Decision Tree Classifier An
Example
31
Design of a Decision Tree Classifier An
Example

• We have data 1, 2, 3, 4, 5 of Class A and data
  (6, 7, 8, 9, 10 of class B, with attributes
  (features) x and y.
• Our objective is to use values for the attributes
  x and y that would separate the data into smaller
  datasets of purer classification labels
• Remember the Iris Flower data-set where we were
  trying to separate the colors (labels) by drawing
  lines perpendicular to specific attribute values

32
Design of a Decision Tree Classifier Split
Choices

• Here the choices for splitting the data are
  limited
• The possible x-splits that we need to consider
  are
• The possible y-splits that we need to consider
  are

33
DTC First Split equals x0.15
34
DTC First Split equals x0.25
35
DTC First Split equals x0.35
36
DTC First Split equals 0.4
37
DTC First Split equals x0.5
38
DTC First Split equals x0.55
39
DTC First Split equals x0.6
40
DTC First Split equals y0.5
41
DTC First Split equals y0.6
42
DTC First Split equals y0.7
43
Decision Tree Classifier How do we find the
Optimal Split?

• The optimal split corresponds to an x or y
  attribute value that minimizes the average
  entropy (uncertainty, disorder) of the resulting
  smaller datasets, or equivalently maximizes the
  difference in entropy (uncertainty) between the
  original dataset (data-points 1, 2, 3, 4, 5, 6,
  7, 8, 9, and 10) and the resulting smaller
  datasets
• This leads us into a natural way into the
  following two learning objectives
• Learning Objective 1 Calculating the entropy of
  a dataset
• Learning Objective 2 Using the entropy values to
  determine the optimal split

44
Learning Objective 1 Calculating the Entropy
Function

• The entropy function of a dataset consisting of
  points belonging to two distinct labels (A or B),
  where the probability that the points are of
  label A is equal to p, was defined by the
  following equation
• We will calculate the entropy function of a
  dataset in a sequence of steps

45
Learning Objective 1 Calculating the Entropy
Function

• Step 1 (In-Class Student Assignment 1.1)
  Calculate the function
• at points p 0, 0.2, 0.4, 0.5, 0.6, 0.8, and 1
  and then plot this function

46
Learning Objective 1 Calculating the Entropy
Function
47
Learning Objective 1 Calculating the Entropy
Function

• Step 1 (In-Class Student Assignment 1.2)
  Calculate the function
• at points p 0, 0.2, 0.4, 0.5, 0.6, 0.8, and 1
  and then plot this function

48
Learning Objective 1 Calculating the Entropy
Function
49
Learning Objective 1 Calculating the Entropy
Function

• Step 1 (In-Class Student Assignment 1.3)
  Calculate the function
• at points p 0, 0.2, 0.4, 0.5, 0.6, 0.8, and 1
  and then plot this function

50
Learning Objective 1 Calculating the Entropy
Function
51
Learning Objective 1 Calculating the Entropy
Function

• Step 4 (In-Class Student Assignment 1.4) Draw
  some useful observations about the entropy
  function
• Observation 1
• Observation 2
• Observation 3
• Observation 4

52
Learning Objective 2 Finding the Optimal
Split

• We return back to our problem of finding the
  optimal split of the data (1, 2, 3, 4, 5 points
  of class A, and 6, 7, 8, 9, 10 points of class B)
• The optimal split of the data is the one that
  maximizes the difference in entropy between the
  original dataset (1, 2, 3, 4, 5 points of class
  A, and 6, 7, 8, 9, 10 points of class B) and the
  datasets that result if we split the data into
  two groups of data using all possible x and y
  splits
• This objective is achieved by focusing on four
  distinct but inter-related steps

53
Learning Objective 2 Finding the Optimal
Split

• Step 1 Decide which are the possible x and y
  values to use, in order to split the data into
  two groups
• Possible x-split values
• Possibly y-split values

54
Learning Objective 2 Finding the Optimal
Split

• Step 2 For the split values that you have chosen
  to split the data with (in Step 1), determine the
  two groups of data.
• If we think that all the data (1, 2, 3, 4, 5, 6,
  7, 8., 9, 10) lie at a node of the tree (called
  root node) and data that have attribute values
  smaller than a split value go to a left node,
  branched off from this root node, while data that
  have attribute values larger than or equal to the
  split value go to a right node, branched off from
  this root node, we are interested in determining
  which data points go to the left node and the
  right node of the tree

55
Learning Objective 2 Example of a
Data-Split, x0.35

• Example of a data-split (data going to the left
  and right node of the tree) for a split value
  x0.35

56
Learning Objective 2 Finding the Optimal
Split

• Step 2 (Student Assignment 2.1) For the split
  values that you have chosen to split the data
  with (in Step 1), determine the two groups of
  data that go to the left and to the right node of
  the tree, as was illustrated in the previous
  slide for the example split value of x0.35

This is an in-class Assignment Student Assignment
2.1
57
Learning Objective 2 Finding the Optimal
Split

• Step 3 (Student Assignment 2.2) For the split
  values that you have chosen to split the data
  with (in Step 1), calculate the impurity of the
  data that go to the left and to the right node of
  the tree. You have already identified the data
  that go to the left and the right node of the
  tree (in Step 2) for the split values chosen in
  Step 1.

This is an in-class Assignment Student Assignment
2.2
58
Learning Objective 2 Finding the Optimal
Split

• Step 4 (Student Assignment 2.3) For the split
  values that you have chosen to split the data
  with (in Step 1), calculate the average impurity
  of the data that go to the left and to the right
  node of the tree. Then, calculate the difference
  between the impurity of the original dataset and
  this average impurity.

This is an in-class Assignment Student Assignment
2.3
59
Learning Objective 2 Finding the Optimal
Split

• Step 5 Choose as the optimal split value the x
  or y split value for which the difference in
  impurity, calculated in Step 4, was maximum.

60
Learning Objective 2 Finding the Optimal
Split

• Step 6 By looking at the figures of how the
  optimal split separated the data and how the
  other splits separated the data, comment on the
  validity of the statement
• the optimal split has reduced the impurity of
  the original data the most

61
Learning Objective 2 Student Assignment

• Student Assignment 2.4 (to do at home)
• You are requested to repeat steps 1-6, described
  in class, to determine what is the optimal split
  value for the dataset consisting of data with
  indices 3, 5, 6, 7, 8, 9 and 10 and residing at
  the right child of the node of the tree shown in
  the following figure
• Data-points 3 and 5 are of class label A, while
  data-points 6, 7, 8, 9 and 10 are of class label
  B

62
Learning Objective 2 Student Assignment

• Student Assignment 2.4 Repeat steps 1-6 for the
  data residing in node 3 of the tree, in order to
  find the optimal split for this dataset (3, 5, 6,
  7, 8, 9, 10)
