Petri Nets: PROPERTIES , ANALYSIS AND APPLICATIONS

1
Petri Nets PROPERTIES , ANALYSIS AND
APPLICATIONS
Submitted for HLDM term paper by -
Rajneesh Gupta M.Tech. (CS)
2
Petri Nets Definition

• Petri Nets are graphical and mathematical
  modeling tool applicable to many systems.
• Promising tool for describing and studying
  information processing systems.
• As a graphical tool it can be used as
  visual-communication aid similar to flow charts,
  block diagrams and networks.

3
Components of Petri Nets

• It is a particular kind of directed, weighted,
  bipartite graph, consisting of two type of nodes.
• Places
• Transitions
• And arcs from place to transition or from
  transition to place. And places marked with
  tokens (non-negative integer).

4
Petri Nets Formal Definition
A 5-Tuple , PN (P, T , F , W , M0)
where Pp1,p2,.pm is a finite set of
places, Tt1,t2,..tn is a finite set of
transitions, F is a set of arcs (P X T) U (T X
P), W F -gt 1,2,3,. is a weight function, M0
P -gt0,1,2,3, is the initial marking
5
An illustration of firing (transition) rule
t
H2
2
H2O
2
O2
2H2O
a)
Before firing
2H2 O2
t
2
H2
2
H2O
O2
b)
After firing
6
Petri Nets Structure
tl
t1
tp
. . . . . .
. . . . . . .
. . .
. . .
tk
td
7
Transition (Firing) rules

• Each input place p of transition t should have at
  least w(p,t) tokens where w(p,t) is the weight of
  the arc from p to t.
• A firing of an enabled transition t removes
  w(p,t) tokens from each input place p of t and
  adds w(t,p) tokens to each output place p of t ,
  Where w(t,p) is the weight of arc from t to p.
• An enabled transition may or may not fire.

8
The Power of Petri Nets

• Finite State machine
• Parallel Activities or Concurrency
• Dataflow computation
• As powerful as CDFG
• Communication Protocols
• Synchronization Protocols e.g.
• Producers-Consumers Problem
• Readers-Writers Problem
• Formal Languages
• As powerful as Lower Bound Automata (LBA)

9
Concurrency
p3
p1
t2
Par Begin
Par End
t1
p2
p4
t4
t3
p5
10
Dataflow Computation
a
X(ab)/(a-b)
Add
Copy
Divide
a
x
(a
b)
/(a-b)
If a-b ltgt 0
b
Subtract
Copy
b
If a-b0
11
Communication Protocol
Ready to send
Ready to receive
Buffer full
Send message
Receive message
Process2
Process1
Message Received
Wait for ack
Buffer full
Receive ack
Send ack
Ack. sent
Ack Received
12
Context Sensitive Language
Final
Start
a
c
b
Language generated L an bn cn ngt0
13
Non determinism
t1
p
t2
Conflict
14
Situation Called Confusion

• Conflict and Concurrency

p2
p1
t1
t3
t2
a) Symmetric Confusion
t1 and t2 are concurrent as well as in conflict
with t3
15
Confusion (Contd..)
b) Asymmetric Confusion
p2
t2
p1
p3
p4
t3
t1
t1 is concurrent with t2 but will be in conflict
with t3 if t2 fires before t1
16
Behavioral Properties of Petri Nets

• Reachability
• Boundedness
• Liveness
• Reversibility
• Coverability
• Persistence

17

• Reduction Rules
• Fusion of series places (FSP)
• Fusion of series transitions (FST)

1) Fusion of Series Places(FSP)
18
Reduction Rulesc) Fusion of parallel placesd)
Fusion of parallel transitions
19
Reduction Rulese) Elimination of self-loop
placesf) elimination of self loop transition
20
High level Nets and Logic Programs
p1
p3
a,a d,d
ltx,zgt
2x
t
e
lta,bgt ltb,cgt ltd,agt
p4
ltx,ygt lty,zgt
p2
Before firing
21
High level Nets and Logic Programs
p1
p3
lta,cgt
d,d
ltx,zgt
2x
t
e
ltd,agt
e
p4
ltx,ygt lty,zgt
p2
After Firing with substitution a/x, b/y, c/z
22
High level Nets and Logic Programs
p1
p3
ltd,bgt
a,a
ltx,zgt
2x
t
e
ltb,cgt
e
p4
ltx,ygt lty,zgt
p2
After Firing with substitution d/x, a/y, b/z
23
An example Logic Program

• Parent(David,Mary) lt-
• Parent(Mary,Tom) lt -
• Ancestor(x,y) lt- Parent(x,y)
• Ancestor(x,z) lt- Parent(x,y) , Ancestor(y,z)
• lt- Ancestor(x,Tom)


24
Logic Program Petri Net
25

• THANK YOU
