Title: LKCD Linux Kernel Crash Dumps


1
LKCDLinux Kernel Crash Dumps
  • Matt D. Robinson
  • matt_at_aparity.com

2
LKCD Overview
  • Description
  • Kernel Implementation
  • Configuration
  • Invocation/Kernel State
  • User-Level Analysis (lcrash)
  • lcrash Example Output
  • Future Development/Evolution

3
Description
  • LKCD is a set of kernel and application code to
    configure, implement, and analyze system crash
    dumps.
  • These slides will cover a high-level view of the
    kernel side of LKCD, with a brief introduction to
    the user-level analysis tools.

4
Kernel Implementation
  • dump.o is the primary kernel driver, and can be
    either a module or built by default into the
    kernel
  • Dump driver is dormant until either invoked for
    configuration or for dumping
  • Configuration of dump device determines what
    occurs on invocation
  • Disruptive and non-disruptive dumping available

5
Kernel Implementation
  • Dump compression available through modules (or
    standalone) GZIP or RLE
  • Access to dump driver through /dev/dump (device
    pair 227,0)
  • panic() or die_if_kernel() will invoke the
    dumping process dumping only occurs if dumps
    are configured

6
Kernel Implementation
panic()
die_if_kernel()
  • Current dump path uses existing I/O subsystem for
    dumping
  • Disks (primarily swap) are used for now future
    direction will be MUCH different

dump() dump_execute() dump_add_page() dump_wri
te_pages()
dump_compress_page()
I/O Subsystem (Disk, Network, Etc.)
7
Configuration
  • Dump configuration takes place via ioctl() to the
    kernel driver
  • DIOSDUMPLEVEL
  • DUMP_LEVEL_NONE Dont dump any pages
  • DUMP_LEVEL_ALL Dump all memory pages
  • DUMP_LEVEL_KERN Dump just kernel level pages
  • DIOSDUMPFLAGS
  • DUMP_FLAGS_NONE No flags set
  • DUMP_FLAGS_NONDISRUPT Try and continue standard
    system operation after a dump takes place

8
Configuration
  • DIOSDUMPCOMPRESS
  • DUMP_COMPRESS_NONE Raw dump format
  • DUMP_COMPRESS_RLE Use RLE compression
  • DUMP_COMPRESS_GZIP Use GZIP compression
  • DIOSDUMPDEV
  • This is the device to dump to (for example,
    /dev/sda4)
  • Each configuration parameter is dependent on the
    system state, whether dump compression is loaded
    into the kernel, etc.

9
User-Level Analysis (lcrash)
  • Linux Crash (lcrash) is used for analyzing system
    crash dumps. It is extremely powerful for
    support and engineering personnel for finding
    solutions to kernel crashes
  • Evaluates CPU state
  • Mode, register settings, etc.
  • Displays all tasks
  • Includes which task is running on a given CPU
  • Stack trace for each running task
  • This is accomplished WITHOUT frame pointers built
    into the kernel (-fomit-frame-pointer)
  • Allows for memory dumping, struct analysis,
    finding symbols, etc.
  • lcrash is amazingly versatile for problem
    analysis
  • Crash dump reports can be created automatically
    on boot-up after a system crash

10
lcrash Example Output
  • stat head
  • sysname Linux
  • nodename crashme.atmyhouse.com
  • release 2.4.8
  • version 9 SMP Mon Dec 10 000519 PST 2001
  • machine i686
  • domainname (none)
  • LOG_BUF
  • dump log_buf 10
  • 0xc0332c60 4c3e343c 78756e69 72657620 6e6f6973
    Linux version
  • 0xc0332c70 342e3220 2820382e 746f6f72 74617740
    2.4.8 (root_at_cra
  • 0xc0332c80 79657265 70612e65
    shme.atm

11
lcrash Example Output
  • task
  • ADDR UID PID PPID STATE FLAGS
    CPU NAME

  • 0xc02e4000 0 0 0 0 0
    - swapper
  • 0xdfffc000 0 1 0 0 0x100
    - init
  • 0xdfff2000 0 2 1 1 0x40
    - keventd
  • 0xdffee000 0 3 0 0 0x40
    - ksoftirqd_CPU0
  • . . .
  • 0xde47a000 0 867 1 1 0x100
    - mingetty
  • 0xda0fe000 0 1017 660 0 0x140
    - sshd
  • 0xd9c06000 0 1018 1017 1 0x100
    - bash
  • 0xde4b4000 0 1101 1018 0 0x100
    0 insmod

  • 31 active task structs found

12
lcrash Example Output
  • t 0xda0fe000

  • STACK TRACE FOR TASK 0xda0fe000(sshd)
  • 0 schedule1040 0xc0111250
  • 1 schedule_timeout121 0xc0110d89
  • 2 do_select506 0xc014251a
  • 3 sys_select820 0xc01428c4
  • 4 system_call44 0xc0106ed4

  • fsym panic_timeout
  • ADDR OFFSET TYPE NAME

  • 0xc0332804 0 GLOBAL_DATA panic_timeout

  • 1 symbol found
  • od panic_timeout
  • 0xc0332804 00000005
    ....

13
lcrash Example Output
  • px ((struct task_struct )0xd8abf000).thread.es
    p0
  • 0x15a159
  • px ((struct task_struct )0xd8abf000).thread.de
    bugreg0
  • 0x0
  • whatis user_struct
  • struct user_struct
  • atomic_t __count
  • atomic_t processes
  • atomic_t files
  • struct user_struct next
  • struct user_struct pprev
  • uid_t uid
  • px (struct user_struct )(((struct task_struct
    )0xd8abf000).user).uid
  • 0xfffff000

14
Future Development/Evolution
  • The 2.5 implementation of LKCD will use dump
    methods to allow multiple dumping paths through
    the kernel (multiple devices!)
  • Low-level device drivers will register their own
    set of dump functions so that each driver does
    what it thinks is correct
  • Additions to lcrash and other LKCD utilities will
    be extended to allow for this functionality
  • LKCD will be extended to work on multiple OS
    architectures (such as FreeBSD)

15
Questions/Comments?
