INFO624 Week 9 Effective Information Retrieval

1
INFO624 -- Week 9Effective Information Retrieval

• Dr. Xia Lin
• Assistant Professor
• College of Information Science and Technology
• Drexel University

2
Effective Information Retrieval

• Systems perspectives
• Fast indexing and retrieval algorithms
• Inverted indexing. Tree structures, Hash tables
• Semantic indexing and mapping
• Subject indexing
• Latent semantic indexing
• Intelligent information retrieval
• Knowledge representation
• Logical inferences

3
Effective Information Retrieval

• Users perspectives
• Iteration
• Relevance Feedback
• Use User's Profiles
• Graphical Display of Search Results
• Browsing/Interactive Searching
• We cant change the user. We should make the
  system to adapt to the users needs

4
Iteration

• Most search needs to be done iteratively
• From the users point of view
• The first query often does not retrieve what the
  user wants
• The user needs to see the output of previous
  queries to construct the next query
• The user often needs to reconstruct his/her
  information needs after they read/browse search
  results.

5
Iteration Users strategies

• Modify queries repeatedly based on some goals
• Starting with high precision
• Use a specific query first
• Broaden queries to include more relevant
  documents
• "pearl growing"
• Starting with high recall
• Use a very broad query
• Improve precision gradually
• "onion peeling"
• Starting with known items
• Find documents similar to the known items
• Browsing/interactive searching

6
Iteration Systems strategies

• If the system can learn from the users
  activities, the system likely can retrieve better
  results to meet users needs.
• Relevance feedback
• Users profiles
• The system should provide better output
  representations to help the user
• Browse
• Conduct interactive searches.

7
Relevance Feedback

• Feedback The user provides information that the
  system can use to modify its next search or next
  display
• Relevant Feedback
• Users let the system know
• what documents are relevant to their information
  needs
• What concepts or terms are related to their
  information needs
• What weights they would like the system to put on
  each relevant documents/terms

8
Relevant Feedback Systems Strategy

• The system should invite the user to select
  relevant documents/terms from the retrieved
  results before the second retrieval is conducted
• The system should use information from user's
  feedback to conduct next search.

9
Design IR Systems with relevance feedback

• Collect relevance feedback through
• Binary vs. scales
• Positive and negative feedback
• Apply relevance feedback to
• Query
• Profile
• Document
• Retrieval algorithm

10
User Profiles

• User profiles
• information about the users information needs
  that IR system can use to modify its search
  process.
• Simple user profiles
• A list of terms that the user selects to
  represent his/her information needs
• A list of terms with weights

11

• Extended user profiles
• More complex term structures
• Information use patterns
• levels of interests
• Users background information
• Users browsing behaviors
• What pages the user has visited last week, last
  month,
• From which page to which page

12
Use of user Profiles

• Selective Dissemination of Information (SDI)
• The system regularly runs the search to get any
  new information that matches users profiles.
• The user can set up several profiles
• Once they are set up, the queries are always the
  same.
• The user can set the frequency of the update
  searches.

13
SDI

• Advantages of SDI
• Automatic retrieval of new information for the
  user
• Set up a profile once, use the profile for
  retrieval many times.
• The user can change the profiles or the search
  frequency as needed.
• Disadvantages of SDI
• The query based on the profile is static
• Timing problems
• Information in need is information indeed.
• Something I am very interest, but it did not come
  at the time I want to read it.

14
Use profiles during the search

• Modify the query
• When the user sends a query, the system
  automatically adds some terms to the query from
  the users profiles.
• When the user sends a query, the system checks if
  the query terms is in users profile. If it is,
  increase the weight for the terms.
• Organize the search results
• When the user sends a query, the system uses the
  profiles information to organize the search
  results (such as clustering, ranking, )

15
Browsing

• Browsing is an act of human information seeking
• a mental process of identifying and choosing
  information
• a dynamic process that varies in time and depends
  on intermediate results.
• a part of process of decision making, problem
  solving, etc.

16
Browsing for Information Retrieval

• A kind of searching process in which the initial
  search criteria or goals are only partly defined
• general-purpose web browsing
• An art of not knowing what one wants until one
  finds it
• visual recognition
• content recognition

17
Browsing for Information Retrieval

• A learning activity that emphasizes structures
  and interactive process
• exploratory
• movements based on feedback
• A process of finding and navigating in a unknown
  or unfamiliar information space
• becoming aware of new contents
• finding unexpected results

18
Search or Browse?

• Would you like to search using a search engine or
  would you like to browse from pages to pages (or
  through a hierarchy)?
• Depend on what?

19
Factors of browsing

• Purposes
• Fact retrieval
• Concept formation or interpretation
• Current awareness
• Tasks
• Well-defined tasks
• Ill-defined tasks
• number of items to browse

20
Factors of browsing

• Individual characteristics
• Motivation
• Experience and knowledge
• Cognitive styles
• Context
• Subject disciplines
• Organizational schemes
• Nature of text/information
• Medium
• Does the system support browsing?

21
IR Systems that support browsing

• Good navigation tools
• Easy to move from one item to another
• Links
• good structures
• fast access
• Easy to back track
• Correct any errors
• make new selections

22
IR Systems that support browsing

• Good displays
• easy to read
• meaningful orders of retrieval results
• graphical presentation
• Meaningful content organization
• contextual hierarchical structures
• Grouping of related items
• Contextual landmarks

23
why just browse when you can fly?

• HotSauce is an innovative 3D fly-through
  interface for navigating information spaces. It
  was developed, largely as a one-man effort, by
  Ramanathan V. Guha while at Apple Research in the
  mid-1990s. HotSauce was a specific 3D
  spatialization of the Meta Content Framework
  (MCF) also developed by Guha.

24
HotSauce
25
Why Surf alone?

• What if you had an assistant always looking ahead
  for you when browsing the web.
• The assistant could warn you if the page was
  irrelevant, could alert you if that link or some
  other link merited your attention.
• The assistant could save you time and
  frustration.

CACM,44(8), p.71, 2001
26
Information Agents

• a software that applies user profiles,
  dynamically and intelligently, to search tasks
• Search distributed, possibly heterogeneous
  information resources on the users behalf.
• Gather and integrate search results by some
  Artificial Intelligence techniques
• Accept users feedback and use the feedback to
  modify the user profiles and search strategies

27
Architecting Browsable Websites

• Design site structures
• Metaphor Exploration
• Organizational metaphors
• Functional metaphors
• Visual metaphors
• Define Navigation
• Global navigation
• Local navigation
• Design Document

28
Interactive Systems

• When an interactive system is well-designed, the
  interface almost disappears, enabling users to
  concentrate on their work, exploration, or
  pleasure.
• Ben Shneiderman

29
Design Principles

• Offer informative feedbacks
• Relationships between query and documents
  retrieved
• Relationships among retrieved documents
• Relationships between metadata and documents
• Reducing working memory load
• Keep tracks of choices made during the search
  process
• Allow user to return temporarily abandoned
  strategies or jump from one strategy to another
• Retain information and context across search
  session.

30

• Provide alternative interfaces for novice and
  expert users.
• Simplicity vs. power

31
Output Presentation for Search engines

• Two major issues
• What information to present?
• How to organize the output items?
• Information in the output display
• Traditional databases
• Document reference numbers (unique number)
• Citations (author, title, source)
• Document surrogate (citation plus abstract and/or
  indexing terms)
• fulltext

32

• On the web
• title, url
• First few sentences/related sentences/summaries
• Dates / page sizes
• Degree of relevance
• special links
• find similar one
• Types of links
• Related categories

33

• What other information you may wish to have in
  the retrieval output?
• Citations (or links from this document)?
• Critique or evaluation?
• Access information (how many times it was
  accessed in last 6 months)?
• Links to this document
• Author contact information ?
• Why documents were retrieved?

34
Output organization

• Linear
• a list of documents
• listed by
• best match
• alphabetical orders
• dates
• order of selected fields (authors, titles, web
  sites)

35

• Linear display
• Practical and most popular
• easy to generate
• users know how to use it
• Did not shown relationships among documents!
• Document relationships are more complex than a
  linear one

36

• Hierarchical display
• Separate data into different levels or branches
• Branches can be expanded/collapsed.
• Show more data in less space
• Show the organization of the data

37

• Graphical displays
• Show more complex relationships
• Use location, colors, dimensions, etc to
  represent documents, terms or concepts.
• Provide more interactive functions

38
What is IV?
System-centered View

• The use of computer-supported, interactive,
  visual representations of abstract data
• to assist navigation in large information spaces
• to reveal complex information structures
• to amplify cognition

User-centered
39
IV and IR

• Both need to process a large amount of
  information
• Both are tools to assist the cognitive process of
  finding, learning, and understanding information.
• Both face the challenge of uncertainty
• Not an Exact science
• Both subject to humans interpretation.

40
VIRI -- Visual Information Retrieval Interfaces

• 2-dimensional graphical display
• use graphical objects (icons, dots etc.) to
  represent documents
• Use geographical relationships to indicate
  document relationships
• use colors to group/differentiate documents
• use animation to assist interaction

41
Concept Visualization

• AltaVista LiveTopic
• HiBrowse Interface
• SemioMap
• Hyperbolic Trees
• Visual Thesaurus
• Visual Concept Explorer

42
Alta Vistas LiveTopic
43
ConceptSpace
44
HiBrowse Interface
45
SemioMap
46
Inxight.com
47
Topic Maps

• Highwire http//www.highwire.org

48
Visual Thesaurus
49
Visual Concept Explorer
50
Concept Mapping
51
(No Transcript)
52
MedLine Search
53
IBM Visualization Space

• This information system understands the user.
• It "hears" users' voice commands and "sees"their
  gestures and body positions. Interactions are
  natural, more like human-to-human interactions.

54
Visual Search Engines

• TheBrain
• Mooter
• Kartoo
• MapStan
• Grokker
• ToughGraph
• StarNight
• NewsLink

55
WebBrainhttp//www.webbrain.com/
56
Mooter http//www.mooter.com/
57
Kartoo http//www.kartoo.com/
58
MapStan http//search.mapstan.com/
59
Grokker

• http//www.groxis.com/service/grok/g_products.html


60
Touchgraph

• http//www.touchgraph.com/

61
(No Transcript)
62
Starrynight from RHIZOME
63
Galaxy of News Rennison 95
64
Galaxy of News Rennison 95
65
Map of Information Scientists
66
Author Mapping
67
AuthorLink
68
NewsLink

• Integrate
• And cross mapping
• Mapping on topics displaying by people
• Mapping on people display by organization
• Etc.
• NewsLink http//project.cis.drexel.edu/lexislink/


69
Discussion

• Information Visualization
• What works and what does not?

70
VIRI

• Advantages
• More representational power
• show more information in a limited screen space
• many different ways to group documents
• can put both keywords and documents in the same
  2-dimensional space
• Provide good overview
• Provide more interaction

71
VIRI

• Disadvantages
• Difficult to generate
• Not always easy to understand
• Many not be specific enough
• Hard to use

72
Evaluation of IR Systems

• Using Recall Precision
• Conduct query searches
• Try many different queries
• Results may depend on sampling queries.
• Compare results of Precision Recall
• Recall Precision need to be considered together.

73
How to calculate Recall

• Determine recall for the whole collection
• Take a random sample to estimate
• Use a broad query to select a sample collection
  for the estimation
• Use seed documents
• Use relative recall
• Use two more expert searches as the base.
• Use one system as the base to estimate recall on
  other systems
• Use a small test collection
• Use experts to judge relevance of every document.

• Prepare special collections.

74
Functionalities

• Precision and Recall are particularly useful for
  evaluating searching/indexing algorithms, and
  system features.
• Compare P R with and without fuzzy search.
• Compare P R with different type of indexing
  options
• Compare P R across systems with the sample
  features
• Precision and Recall are query-oriented, not
  system-oriented.

75
Evaluation without P R

• The emphasis should be on the user and the
  interaction.
• Be specific on data collection
• How data are collected and indexed?
• Is there a quality control for the data
  collection?
• Be creative on the test questions and methods
• Not just questionnaires
• Be selective on subject groups

76
Quality Evaluation

• Data quality
• Coverage of database
• It will not be found if it is not in the
  database.
• Completeness and accuracy of data
• Indexing methods and indexing quality
• It will not be found if it is not indexed.
• indexing types
• currency of indexing ( Is it updated often?)
• indexing sizes

77
Interface Consideration

• User friendly interface
• How long does it take for a user to learn
  advanced features?
• How well can the user explore or interact with
  the query output?
• How easy is it to customize output displays?

78
User Satisfaction

• User satisfaction
• The final test is the user!
• User satisfaction is more important then
  precision and recall
• Measuring user satisfaction
• Survey
• Use statistics
• User experiments

79
User Experiments

• Observe and collect data on
• System behaviors
• User search behaviors
• User-system interaction
• Interpret experiment results
• for system comparisons
• for understanding users information seeking
  behaviors
• for developing new retrieval systems/interfaces
