Support for Distributed Pair Programming in the Transparent Video Facetop

1
Support for Distributed Pair Programming in
the Transparent Video Facetop

• David Stotts
• Jason Smith, Karl Gyllstrom, Dorian Miller
• Dept. of Computer Science
• Univ. of North Carolina at Chapel Hill
• October 2004

2
Interesting Collaborative Systems

• Bush Memex (45)
• Great grandfater of the Web
• Video Window (BellCore, 90)
• Collaborative coffee lounge
• Clearboard (Ishi, 94)
• Expensive custom hardware
• HyperMirror

3
Extreme Programming (XP)

• Kent Beck, late 90s
• One Agile software development processes
• change happens deal with it
• Small teams (2 to 10 people)
• Modest sized projects

If we know something is a good idea, lets take
it to the extreme
4
XP Practices

• Test-first development
• Simple design (add no function before its time)
• Re-factoring
• User/client on-site
• Planning game
• 100 regression tests
• run end of each day
• No overtime

best known for Pair programming
5
Pair Programing has known benefits
6
Pair Programming Benefits

• Increased productivity
• 15 increase in person-hours
• 45 reduction in clock hours
• Fewer errors
• Better program structure
• Increased engineer satisfaction
• Increased client satisfaction (for full XP)

7
Teleworking Boom

• Half of American information workers work
  offsite at least part of the time

Companies are looking at hot bunking as a way
of controlling real estate costs and increasing
productivity of the plant they are paying
for National area of technical emphasis
8
Current Studies

• COTS software how far can we get?
• Screen sharing ( pcAnywhere, VNC )
• Audio/text exchange ( Yahoo messenger )
• No video ( bandwidth concerns )
• Broadband speed or better
• Joint work with Laurie Williams, Ed Geringer at
  NCSU

9
Distributed Pair Programming

• Assume you must develop across the wire
• If we use synchronous collaboration
• If we organize as pairs
• Can we effectively develop good software?
• Will collocated PP benefits still hold?
• Can we apply all XP practices ?
• Should we?

10
Anecdotal Observation

• A student told me he had participated in 2 PP
  experiments one co-located, one distributed
• He said he was more efficient in dPP that he and
  his partner did more chit-chatting in
  co-located
• Not sure if this is social, or technical
• Or not real
• An industry engineer confirmed a similar
  phenomenon

11
Video-Enhanced Environment

• In all studies, dPP programmers say
• we need a whiteboard
• we miss facial expressions
• we cant point at what we are sharing
• We wanted to construct a video-enhanced dPP
  environment to address these issues

12
2002 Chicago Workshop

• We ran dPP/dXP workshop in Chicago
• 40 attended many had tried some form of dPP
• Video was
• Not used
• but not disproved
• Video was perceived to have benefits
• When made LARGE
• Like Bellcore VideoWindow

13
(No Transcript)
14
The Basic Facetop

• Transparency combined with user self-view
• Uniquely integrates video conferencing with
  desktop information and applications
• Works as a single-use PC interface
• Works as dual-user collaboration support
• Most effective in projected context

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Some Good Press

• Technology Research News
• ACM tech Notes
• Gizmodo
• Gadgetopia
• Slash Dot
• Wired

Blogs UNC Endeavors UR Alumni Review
20
Geek Magazine!!

• Look for it in early September

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Related work

• Englebart 60s collaboration on text
• Clearboard 90s expensive custom hardware
• Video Mirrors combined video spaces
• Hand Tracking, gestures lots
• Augmented reality lots
• Columbia Feiner blueprints
• Office of the Future Fuchs

27
Dual-head Collaborative FaceTop
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
No Registration Issues

• No registration worries
• Object tracking (fingertip) allows camera motion
• User self-registers 30 fps
• For natural pointing camera must be generally in
  front of user and oriented face-on

34
Directions

• User studies
• Controlled dPP studies in fall
• Medical imaging group
• Architects, blueprints
• Emergency room use
• Enabling technology
• Hearing-impaired can participate in dPP, other
  sync. remote collaborations

35
Directions

• Windows version (Mac only for now)
• Faster tracking
• 3person versions
• Better video compositing foggy
• Voice activations
• 3D version for dome display

36
All windows can be resized / re-opaqued /
overlayed
37
Development

• Funding for 1 student so we did not do pair
  programming for most of the development
• Did pair for first 3 sessions for overall system
  design and for initial exploration of some
  candidate legacy codes and an initial system.
• Mac OS X is the platform ( openGL )
• Longhorn will enable Windows version, if not
  earlier

38
System Architecture
39
Early evaluations

• Had pairs that had done non-video dPP try Facetop
  for dPP
• Results very encouraging no team found the
  system objectionable
• All found it preferable to non-video
• All found the pointing to be natural and effective

40
Other evaluations

• Had two people with hearing-impairments try it
• Asked them to attempt signing and lip reading via
  Facetop to discuss document on the screen
• No problems signing (18 fps on 100mb switched
  dept ethernet)
• Lip reading not possible yet (more fps)
• Tic-Tac-Toe collaborative chess coming

41
(No Transcript)
42
(No Transcript)
43
But serendipity

• Discussing PhD work with Jason
• Projected on the board in my office
• Happened to have just installed a Firewire cam
• Happened to have reversed the image horizontally

44
Environment Schematic

Right-hand user, can reach from seat, write on
projected digital whiteboard
Shared PC projection
projector
keyboard, etc.
Partner / whiteboard
projection
programmer
camera
projector
45
Alternatives

Partner projection
Shared PC projection
Less useful for whiteboard , Perhaps more
effective with multi-screen unified wide display
keyboard, etc.
camera
programmer
projector
projector
46
90º Projector Setup
Daily use 2 PCs switched between 2 projectors and
a monitor
dPP use Both projectors at once, one for
communication, one for shared PC desktop
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
Starts as normal app window
52
Resized by control-dragging up and down over the
window
53
Move window with the mouse
54
Opaqueness adjusted by alt-dragging up and down
55
(No Transcript)
56
Network settings pane used to start 2-head
57
Second window opens after connection
Remote local
58
Command-drag window rotates
59
Double clicking a window makes it full screen
This is both full screen
60
Resolution and frames per second can be adjusted
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
dPP teams do as well as collocated
68
dPP teams do as well as collocated
69
dPP teams do as well as collocated
70
dPP teams do as well as collocated
71
PP teams better communication
How was the communication with your team?
72
PP teams better cooperation
How was the cooperation among team members
73
End of Presentation
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
Findings

• dPP software development over the wire is
• feasible,
• effective,
• affordable (COTS),
• pleasant for the participants
• Small-scale distributed development is better
  done as pairs (synchronous) than as individuals
  who integrate
• Synchronous pairing engenders better teamwork and
  communications for remote work

79
Distance Matters

• Distance matters is a truism among
  collaborative systems researchers ( Olson
  Olson )
• Studies of graduate programmers (136, 16, 12, 2)
• Paired, non-paired, co-located, distributed

We are finding that distance doesnt always
matter doesnt matter as much as thought
80
Findings

• Joint studies with Laurie Williams, Ed Gehringer
  at NC State
• dPP programs were equal in quality to those of
  co-located pairs ( also distributed non-paired
  teams )
• Distributed pairs maintain many of the advantages
  of collocated pairs ( fewer errors, etc. )
• Distributed pairs maintain many of the pair
  effects ( pair pressure, pair learning, two
  brains ) oserved in co-located PP

81
Environment Schematic

Right-hand user, can reach from seat, write on
projected digital whiteboard
Shared PC projection
projector
keyboard, etc.
Partner / whiteboard
projection
programmer
camera
projector
82
Alternatives

Partner projection
Shared PC projection
Less useful for whiteboard , Perhaps more
effective with multi-screen unified wide display
keyboard, etc.
camera
programmer
projector
projector
83
Solving the Pointing Problem

The Transparent Video FaceTop
Single-user track finger, drive mouse, self-image
provides cues not found in other UIs
Collaborative put two people on one shared
screen, Each sees the other pointing
