Cabling Infrastructure For Commercial
Residential Applications
2
Agenda

• Distribution of Data, Voice, Broadband (CATV),
  Misc. (CCTV, Paging Systems etc.)
• Commercial / Business Applications
• Residential Applications

3
Distribution in Commercial Areas

• Examples of such areas
• Airports
• Clubs
• Hotels
• Educational Mfg. Campuses
• Benefits of having a single agency address media
  needs
• Efficient design
• Savings in pathway costs
• Smoother faster implementation.

4
Case Study Educational Campus
MAIN BLDG. (CORE SWITCH)
HOSTEL
6 CORE FIBER
AUDI / LIB
SECURITY
12 CORE FIBER
HOUSING COLONY
LABORATORY
WORKSHOP
FIBER OPTIC BACKBONE FOR DATA, X CAMPUS
5
TIA/EIA 568B Generic Cabling Length
Extract from TIA/EIA 568B.2
6
Fiber Applications
7
TIA/EIA 568B Generic Cabling Length
MAIN BLDG.
GUEST HS.
STAFF HSG AREA
HOSTEL
AUDI/LIB.
SECURITY
CLUB HS.
ARMOURED JELLY FILLED TEL. CABLES
WORKSHOP
LABORATORY.
VOICE / EPABX CABLING FOR X CAMPUS
8
Key points for the voice backbone

• Determine no. of channels in a link I.e. users
  to be serviced between two wiring closets
• Leave min. 30 buffer in pair count and
  termination hardware.
• Follow appropriate termination and handling
  practices for outdoor cables.

9
6 CORE INDOOR FIBER CABLE
RACK TYPE A
RACK TYPE A
EPABX MDF
TOP VIEW OF HOSTEL BLDG. (75 mtrs. x 75 mtrs.)
RACK TYPE B
COPPER / FIBER BACKBONE
SIDE VIEW OF HOSTEL BLDG.
LAYOUT CABLING OF HOSTEL BLDG. FOR DATA
10
ANSI/EIA/TIA 568-B Hierarchical Star
Extract from ANSI/EIA/TIA 568-B.1
11
CATV Backbone
RG 11 MAIN CABLE (OR FIBER)
GUEST HOUSE
RG 6 cable for residential wiring
Broadband Amplifier
HOSTEL
STAFF HOUSING AREA
CATV SYSTEM CABLING DISTRIBUTION
12
Key points for the CATV Network

• The CATV System works on the concept of Frequency
  Multiplexing over Broadband carrier (as against
  Baseband in Data).
• It is Analog Broadband.
• The frequency spectrum used by CATV system is
  from 33 MHz to 750 MHz, with a 7 MHz gap between
  channels, called Guard Band.
• As CATV signals are much less sensitive to noise,
  copper is an effective medium for distribution in
  small networks (upto 5 km radial distribution).
• The Backbone run can be extended by adding
  Amplifiers in series, upto 7-8 quality broadband
  amplifiers can be cascaded in a single run.

13
Key points for the CATV Network

• USE OF FIBER IN CATV NETWORK Fiber cable is
  typically used in large, commercial MAN
  (Metropolitan Area Networks) CATV systems.
• Hybrid Amplifiers used.
• Can be used in Campus network to share media and
  optimise costs.
• NOTE The CATV access is mostly in the
  residential Staff Colony area and with a few
  points to Guest House, Club House and Hostel.

14
Distribution in the CATV Network

• Bus wiring
• Important to maintain signal integrity uptil the
  end point
• Variable losses High Frequencies have higher
  losses
• Use of Slope Amplifiers to provide variable
  gain to bandwidth.
• Use of Tap Offs and Splitters to branch Trunk
  routes and service end points.

15
CATV Components

• HEAD END / CONTROL ROOM (OR FEED)
• Dish Antennae with LNB
• Power Dividers
• Satellite Receivers as per no. of simultaneous
  channels required
• A/V Frequency Modulators as per total no. of
  simultaneous channel broadcast on the network
• Channel Mixer / Combiner
• Head End Broadband Amplifier
• DISTRIBUTION NETWORK
• Distribution broadband amplifiers
• RG-11 coaxial cable for main distribution
• RG-6 coaxial cable for residential cabling
• Tap offs / splitters as required.

16
CO-AXIAL OR HYBRID AMPLIFIER
LAYOUT CABLING OF HOSTEL BLDG. FOR CATV
17
TYPICAL FLOOR WIRING, DATA VOICE
PC
VOICE RACK
DATA RACK
Phone
Shuttered I/O
UTP cable
7 patch cord, I/O to node
18
Residential Cabling

• Standards
• Applications

19
Residential Cabling Standards

• EIA/TIA-570-B
• Two Grades of cabling, Grade 1 Grade 2, based
  on services required
• Grade 1
• Supported Services Telephone, fax, modem
  Satellite TV Cable and Antenna Television Data
  (up to 1000 Mbit/s with Category 5E cabling, up
  to 10Gbit/s with Category 6 cabling).
• Recognized Cable Types Category 5E 4-pair UTP
  cable and components Category 6 4-pair UTP cable
  and components 75-Ohm RG-6 coaxial cable and
  components. 75-Ohm RG59 coaxial cable for CCTV
  only
• Topology Star
• Minimum requirements per outlet location
• 1 x 4-pair Category 5E UTP cable (Category 6
  recommended) 1 x 75-Ohm RG-6 coaxial cable.

20
Residential Cabling Standards

• Grade 2
• Supported Services Telephone, fax, modem
  Satellite TV Cable and Antenna Television Data
  (up to 1000 Mbit/s with Category 5E cabling, up
  to 10Gbit/s with Category 6 cabling). Video
  monitoring Video intercom and teleconferencing
  Other multimedia applications. VCR , DVD and
  laser disc output distribution
• Recognized Cable Types Category 5E (CAT5E)
  4-pair UTP cable and components Category 6
  (CAT6) 4-pair UTP cable and components 75-Ohm
  RG-6 coaxial cable and components. 75-Ohm RG59
  coaxial cable for CCTV only Fiber optic cables
  and components (50/125µm 62.5/125µm multimode as
  well as singlemode)
• Topology Star.
• Minimum requirements per outlet location 2 x
  4-pair Category 5E UTP cable (Category 6
  recommended) 2 x 75-Ohm RG-6 coaxial cable 1 x
  2-fiber optical fiber cable (optional)

21
Traditional Home Cabling

• Parallel or Daisy Chain Voice Cabling
• Passive Splitters for Video
• Video Accessories dedicated to individual
  Televisions

22
Standard Telephone
23
Standard Television
24
Pay TV Free to Air
25
RCS Components

• Centralised Enclosure
• Star Cable UTP for Voice and Data
• Star Cable RG6 for Broadband Video

26
Components
..with Broadband Distribution
Voice / Data Unit
Infra Red Target
Video / RF Amp.
Modulator
27
Star Cabled Voice and Data
28
(No Transcript)
29
Broadband Distribution

• Free to Air Channels are taken to CATV/Antenna IN
  port of VDU
• Decoded Modulated Pay TV Channel is taken to
  Modulator input on VDU
• This is distributed to all 8 output ports on VDU
• Pay TV and Free to Air can be watched at all
  Televisions
• Remote Control for Pay TV is at Set Top Box only,
  in this configuration

30
Example Video Distribution
31
Remote Infrared Network

• Enable Remote Control of Pay TV Set Top Box from
  any Television on the RG6 Network
• Control VCR/DVD or Laser Disk operation from any
  Television on the RG6 Network

TV with IR Target
32
Infra-Red Modulated RF Network
33
Modulators

• Modulate A/V outputs from VCR, Laser Disk,
  VCD/DVD Player to free UHF
• Channels
• Modulate Security Camera to free UHF Channel

34
Modulator Infra-Red Network
35
Central Entertainment

• Pay TV Set Top Box
• VCR
• VCD/DVD
• Laser Disk
• Networked Infrared
• Every TV has Infra-Red Target

36
Centralize Common Equipment
37
