Ultrasound

1
Ultrasound

• presented
• by BAM

2
Equipment BAM

• Power supply
• Waveform generator (any arbitrary of pulse forms)
• Power Amplifier
• Oscilloscope
• Computer

3
Measurements Overview
4
Measurement - Historic Masonry

• Kirche am Anger
• Potsdam-Babelsberg
• Brandenburg / Germany

Year of construction 1850-52 By Ch. H. Ziller
5
Transducers
A1220 array with transversal transducers (no
coupling agent required)
12 Transmitters

Polarisation of waves
12 Receivers
6
Result measurement Historic Masonry
Position cm
4 8 12 16 20 40
60 80
100
0
Represents the depth of 118 mm
100
200
Depth mm
300
400
500
600
700
7
Measurements Overview
8
Specimen Brickwork 25 cm
Specimen Homogeneous brickwork Used for
Selection of optimal transducers
9
Transducers A1220
A1220 array with transversal transducers (no
coupling agent required)
12 Transmitter

Polarisation of waves
12 Receiver
10
Results
Only the first row of bricks was detectable with
the A1220 The system seems not to be suitable
for masonry investigation
11
Measurements Overview
12
Specimen Brickwork 25 cm
Specimen Homogeneous brickwork Used for
Selection of optimal transducers
13
Transducers planar and exponential
Broad band (planar) transducer (coupling agent
glycerine) G 0,1 R and G 0,2 R nominal
Frequency 80 to 250 kHz
Narrow band transducer (point contact,
exponential horn) nominal Frequency 50 and 100
kHz
14
Results specimen 25cm (G 0,2 GC)
Intensity a.u.
t
Time µs
Intensity a.u.
t
Time µs
15
Measurements Overview
16
Specimen Brickwork 49 cm
Measuring line 0-70cm
Specimen Brickwork with voids used for tomography
Location of voids
17
Transducers planar and exponential
Broad band (planar) transducer (coupling agent
glycerine) G 0,1 R and G 0,2 R nominal
Frequency 80 to 250 kHz
Narrow band transducer (point contact,
exponential horn) nominal Frequency 50 and 100
kHz
18
Aperture Angle

• Intensity of transmitted signal related to the
  aperture angle
• (Broad band transducer)

19
Measurements Overview
20
Measurements tomography 1
Intensity a.u.
t
Time µs

• DATA FOR TOMOGRAPHY
• Measurement time of flight
• (Broad band transducer G0,2R)
• Signal No 3 and 32

Intensity a.u.
t
Time µs
21
Measurements tomography 2
Intensity a.u.
t
Time µs

• DATA FOR TOMOGRAPHY
• Measurement time of flight
• (Narrow band transducer
• exponential horn)
• Signal No 1 and 21

Intensity a.u.
t(?)
Time µs
22
