Articular Cartilage Injury

1
Articular Cartilage Injury

• The Knee Blowout

Jon D. Koman, MD
2
Tire Analogy

• Tread of a tire articular cartilage

3
Degenerative
4
Traumatic
5
Focal Cartilage Defects

• Traumatic
• Concomitant ligament injury -- ex ACL
• Osteochondritis Dissecans lesion
• Localized cartilage lesion due to unexplainable
  localized poor blood supply.
• Most commonly seen on lateral part of medial
  femoral condyle.

6
Cartilage Lesion Classification
7
Bad to the Bone
8
Diagnosis

• History/Physical
• X-rays
• MRI
• Diagnostic arthroscopy

9
History/Physical

• Intermittent, vague, poorly localized pain.
• Locking or catching if loose body present.
• May have associated secondary degenerative
  changes if bony incongruity present.

10
X-rays
11
MRI
12
Treatment Options

• Bone marrow stimulation (lt5 mm).-- scar
  cartilage, not real weight bearing type of
  articular cartilage.
• Autologous Chondrocyte Implantation (gt 2x2 cm
  lesions)--requires open arthrotomy and at least
  two surgeries but theoretically same type of
  weight bearing articular cartilage.
• Osteochondral Autograft Transplant Surgery
  (O.A.T.S.)( lt2 x2 cm lesions ?) -- limited number
  of donor plugs but covers lesion with same type
  of weight bearing articular coverage.

13
Bone Marrow Stimulation
14
Autologous Chondrocyte Implantation
15
O.A.T.S.
16
O.A.T.S.
17
O.A.T.S.
18
Rehabilitation Phases

• Protective (4 wks) NWB x 2 wks then 20-30lbs
  weight bearing. PROM exercises.
• Transition (5th and 6th wks) 25 weight
  bearing, mini squats and aqua jogging.
• Maturation (7-12 wks) Full WB, full squats,
  walking swimming and stairmaster.
• Functional (gt12 wks) Full activity.

19
Back to Work Issues

• No sooner than 3 mos.
• ? Permanent work restrictions depending on size
  of lesion and concomitant injuries.
• Will more than likely have lifting restrictions
  depending on size of lesion and concomitant
  injuries.

20
Case Study

• 25 year old male sustained a fall/twist on right
  knee.
• PE 2 effusion, ROM 0-130 deg, 2 Lachman,
  pivot shift and anterior drawer .
• Xrays wnl
• MRI ACL tear, medial/lateral meniscus tears,
  full thickness cartilage defect of medial femoral
  condyle.

21
MRI
22
Arthroscopic Findings

• ACL tear
• MFC defect measuring 8mm x 16 mm.
• Med/lat meniscus tears

23
Arthroscopic Treatment

• Partial Med/lat menisectomies
• O.A.T.S. of MFC
• ACL reconstruction

24
Conclusions

• O.A.T.S. procedure provides quick and near
  complete coverage of most focal full thickness
  cartilage lesions.
• Covers cartilage lesion with same type of weight
  bearing articular cartilage
• Can be done at same surgery as other planned
  procedures.
• Can be done arthroscopically providing faster
  rehabilitation and sooner return to work.
