Summer Internship at the Keck Observatory

1
Summer Internship at the Keck Observatory

• Department Software

Mentors Erik Johansson Al Honey
Cameron Lewis
2
Overview of Projects

• STRAP control system
• JStamp (real-time Java chip)
• EDAS (Ethernet Data Acquisition System)
• NIRC2 log processing

3
S.T.R.A.P.

• What is it?
• System for Tip/Tilt Removal with Avalanche
  Photo-diodes
• Commercially built sensor and control unit for
  the adaptive optics system.
• Designed for ESO but currently being adapted for
  Keck AO system
• Made in Italy

4
The STRAP Control System

• Currently Obsolete console interface on a
  windows laptop.
• Soon Integrated EPICS-based control system to
  allow high speed, efficient access to the STRAP
  unit.

5
STRAP Control System - Layers
6
Strap Control System - Construction
GNU C Compiling in XEmacs
7
Strap Control System Construction
Capfast Ultra-advanced design? Or in need of
screen refresh?
8
Strap Control System Construction
Capfast After I found the magic Screen Redraw
command
9
Strap Control System Construction
DM Screen Editor
10
Summary of STRAP Project

• STRAP is nearly ready for mainstream science use.
• Control system is almost complete it will be
  tested with the STRAP unit on the summit
  tomorrow.
• The new system will soon be providing efficient
  control capabilities for STRAP devices wherever
  EPICS is used!

11
JStamp Microcontroller
12
JStamp Microcontroller

• Got JStamp up and running successfully
• Tested Jtag I/O, serial I/O
• Wrote a JStamp setup tutorial to supplement aJile
  Systems online examples.

13
EDAS
14
EDAS

• Ethernet Data Acquisition System
• Allows for remote sensing/output of data via a
  standard ethernet interface
• Tested
• All Digital Inputs/Outputs work
• All Analog Inputs/Outputs work
• System accessible over the ethernet

15
NIRC2 Log Processing
16
NIRC2 Log Processing

• Need a means of determining the causes/times in
  which NIRC2 stall faults occur
• Must determine whether or not the failures are
  getting worse or are remaining constant
• Results will be used to determine if NIRC2 needs
  to be repaired

17
Log Processing Procedure

• Start with 1-3 million line log files
• Build flexible, command-line C program to extract
  relevant log entries to a new file
• Incorporate a smart entry repetition removal
  routine and generate stall-fault statistics
• Create appropriate data analysis tables and
  supporting graphs to demonstrate the stall trends

18
NIRC2 Log Processing Results
19
NIRC2 Log Processing Results
20
NIRC2 Log Processing Results
